Coverletter: Adcon Telemetry GmbH wants to get FCC-Certification for the following product: Telemetry transceiver working in the 70cm band 450-470 MHz (FCC Part 90) A732-46 The unit will get the following FCC-ID: SHXA732-46 List of documents: Exhibit Thema File Exhibit 01 Label and placement label_05-103.pdf Exhibit 02 Not needed -------------------- Exhibit 03 External Photos extern_05-103.pdf * Exhibit 04 Block Diagrams A73x_block_diagrams.pdf * Exhibit 05 Schematic Diagrams A73x_schematics.pdf Exhibit 06 Testreport 05-103_1.pdf 05-103_2.pdf Exhibit 07 Test Set-up Photos A732_RX_spurs.jpg A732_TX_spurs.jpg Exhibit 08 User Manual A733_UserGuide_English_V21_01.pdf Exhibit 09 Internal Photos intern_05-103.pdf * Exhibit 10 Tune up info/Parts list a431_E_BillOfMaterial.pdf A733_C_BillOfMaterial.pdf Exhibit 11 RF exposure issues RF exposure compliance issues.doc *Exhibit 12 Operational Description A73x_TechnicalReference_V21.pdf Exhibit 13 Cover letter Request for confidentiality This file FCCConfidentialityA732.pdf For the Exhibits marked with ‘*’ Adcon Telemetry GmbH requested Confidentiality according to 47 CFR 0.457 and 0.459 of the FCC rules because these are sensitive parts owned by this company and include much of Know-How or sensitive data, it will not be provided to the public. The labelling on some photos may not be the actual status. The correct labelling you can in Exhibit 1.

Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 U.S.A. Klosterneuburg, March 30, 2005 Confidentiality Request Our FRN: 0011471562 Our FCC Code 1: SHX TO WHOM IT MAY CONCERN Pursuant to Paragraphs 0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, Adcon Telemetry GmbH requests confidentiality for the following product: FCC ID Number Title/Model SHX A732 A732-46 addWAVE-LE For the product stated above we request that the following information be held confidential: 1. Circuit diagrams, BOM, and PCBs submitted as Equipment Authorization Electronic Filing attachment “schematics”. 2. Block diagram submitted as Equipment Authorization Electronic Filing attachment: “blockdiagram”. 3. Operational description submitted as Equipment Authorization Electronic Filing attachment: “operational description”. The above exhibits contain Adcon Telemetry GmbH trade secrets and proprietary information that could be of benefit to our competitors regarding the design of our wireless data logger. This material is not customarily available to the general public and we request that it be withheld from public inspection. For any and all questions please feel free to contact me at the address shown in the letterhead or under my personal email address [email protected] Sincerely, Bernhard Pacher CEO

RF exposure compliance issues: This telemetry device is normally used only at fixed locations far away from persons. It is collecting data from various sensors and transmitting it through the 70cm transmitter. According to Supplement C of OET Bulletin 65 for mobile transmitters operating below 1,5 GHz evaluation is not required when the effective radiated power (ERP) is below or equal to 1,5 W. This device uses a maximum power output of 0,5 Watts, and omnidirectional antennas without antenna gain over dipole, so the ERP value is also equal to 0,5 Watts. So this device is excluded from routine evaluation. It must be operated only as fixed or mobile device not closer than 20cm to persons.
