SHXA753-46Telemetry transceiver

A75x addWAVE Series 4 A753/A755/A757 User Guide SMART WIRELESS SOLUTIONS Proprietary Notice The Adcon logo, Adcon Telemetry, Smart Wireless Solutions, the A7xx series, addIT, addWAVE, the A840 and A850 series and Telemetry Gateway, AgroExpert, addVANTAGE®, addVANTAGE Lite and addVANTAGE Pro are trademarks or registered trademarks of Adcon Telemetry GmbH. Neither the whole nor any part of the information contained in this publication may be reproduced in any material form except with the prior written permission of Adcon Te l e me t r y G m b H . This publication is intended only to assist the reader in the use of the product. Adcon Telemetry GmbH shall not be liable for any loss or damage arising from the use of any information in this publication, or any error or omission in such information, or any incorrect use of the product. Document Release 1.0, 27 June 2011 Copyright ©2001-2011 by Adcon Telemetry GmbH. All rights reserved. CHAPTER 3 Contents Chapter 1. Introduction____________________________________ 5 About the A753 addWAVE Series 4 ___________________________ 5 Compliance Statement and Warnings _________________________ 5 Conventions _____________________________________________ 6 Chapter 2. Using the addWAVE______________________________ 7 Opening the packages _____________________________________ 7 Installing the RTU_________________________________________ 8 Field Installation_______________________________________ 8 More about the LED Tool ________________________________ 9 Configuring an A753 in the Telemetry Gateway ________________ 10 Maintaining and servicing the RTU __________________________ 11 The RTU battery ______________________________________ 11 Replacing the battery__________________________________ 12 Chapter 3. Performing Advanced Functions __________________ 14 Understanding Connectors ________________________________ 14 The POWER Connector_________________________________ 14 Communicating with the RTU ______________________________ 15 Booting the A753 ________________________________________ 16 Bootloader Mode_____________________________________ 16 Commands available in Bootloader Mode_______________ 17 Firmware Mode ______________________________________ 17 Upgrading the Firmware __________________________________ 18 CHAPTER 4 Serial Communication Protocol _____________________________ 20 General Format of a Command __________________________ 20 General Format of an Answer ___________________________ 21 Using Terminal Commands ________________________________ 21 Returned Errors List ______________________________________ 32 Command Line Interpreter______________________________ 32 Device Descriptor and Storage Handler____________________ 32 Real‐time Clock_______________________________________ 33 Notifications _________________________________________ 33 Specifications __________________________________________34 CHAPTER 1 About the A753 addWAVE Series 4 5 Chapter 1. Introduction This manual explains the hardware aspects of Adcon’s A753 addWAVE Series 4 remote telemetry units, including installation issues and certain parameter configurations. The manual is divided as follows: •Introduction, which gives some general information and document conventions. •Using the addWAVE, which details the installation and use of the remote telemetry unit. •Performing Advanced Functions, which discusses connectors and controllers and provides other information for advanced users. •Specifications, which describes operating parameters for the devices. About the A753 addWAVE Series 4 The A753 addWAVE Series 4 remote telemetry unit (RTU) is a low- power telemetry device with four digital  I/O ports, twelve analog inputs, and four counter inputs. The A753 is a ruggedized RTU, complying with the IP65 ingress protection class (NEMA 4). Depending on topography, it ensures a reliable wireless connection to other A73x RTUs or an A840/A850 Telemetry Gateway over a distance of up to 20km (12 miles). Due to its construction as well as to the software controlling it, the power consumption is extremely low. The unit operates off an internal 6.2 Volt rechargeable battery, which is charged either by a solar panel or an external power adapter. Compliance Statement and Warnings The A73x must not be used with an antenna other than the one supplied by Adcon (or an antenna with identical technical specifications). CHAPTER 1 Conventions 6 Conventions Certain conventions apply in this document. ItalicsIndicate that the text is variable and must be substituted for something specific, as indicated in the explanation. Italics can also be used to emphasize words as words or letters as letters. BoldIndicates special emphasis of the text. Also indi cates menu names and items in a window. fixed fontIndicates characters you must type or system me ssages. File Save Indicates menu selection. For example, select the File menu, then the Save option. NoteIndicates information of interest. Notes appear after the information they apply to. CAUTION Indicates that you may get unexpected results if y ou don’t follow the instructions. Cautions appear before the information they apply to. WARNING Indicates danger to yourself or damage to the de vice if you don’t follow the instructions. Warnings appear before the information they apply to. CHAPTER 2 Opening the packages 7 Chapter 2. Using the addWAVE The A753 addWAVE remote telemetry unit (RTU) is part of the A7xx series. For testing purposes, you should have an A840 or A850 Telemetry Gateway with access to the internet installed before you install the A753 RTU. For information about installing the A840 or A850, refer to device’s user’s guide. Opening the packages The addWAVE RTU package contains the following items: •A753UHF Series 4 RTU (or A752 or A751) •an antenna including a mounting bracket and a 3 m (9 ft.) cable •three ring clamps (one for tightening the mounting bracket of the antenna) If ordered, the following items come in separate packaging: •s…

Text truncated - open the document above for the full version.

Coverletter: Adcon Telemetry GmbH wants to get FCC-Certification for the following product: Telemetry transceiver working in the 70cm band 460-470 MHz (FCC Part 90) A753-46 The unit will get the following FCC-ID: SHX753-46 List of documents: Exhibit Thema File Exhibit 01 Label and placement label_11-112.pdf Exhibit 02 Not needed -------------------- Exhibit 03 External Photos extern_11-112.pdf * Exhibit 04 Block Diagrams blockdiagram.jpg * Exhibit 05 Schematic Diagrams schematics_A75x_mainboard.pdf schematics_A75x_RF-module.pdf Exhibit 06 Testreport 11-112.pdf Exhibit 07 Test Set-up Photos setup_11-112.pdf Exhibit 08 User Manual A75xUHF_User_Manual_V100.pdf Exhibit 09 Internal Photos intern_11-112.pdf * Exhibit 10 Tune up info/Parts list parts_list_A75x_mainboard.pdf parts_list_A75x_RF-module.pdf tuning_procedure_A75x.pdf Exhibit 11 RF exposure issues RF exposure compliance issues.pdf *Exhibit 12 Operational Description hardwareA75x_mainboard.pdf hardwareA75x_RF-module.pdf software_A75x.pdf Exhibit 13 Cover letter Request for confidentiality This file FCC_Confidentiality_A753.pdf For the Exhibits marked with ‘*’ Adcon Telemetry GmbH requested Confidentiality according to 47 CFR 0.457 and 0.459 of the FCC rules because these are sensitive parts owned by this company and include much of Know-How or sensitive data, it will not be provided to the public. The labelling on some photos may not be the actual status. The correct labelling you can find in Exhibit 1.

Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 U.S.A. Klosterneuburg, June 15, 2011 Confidentiality Request Our FRN: 0011471562 Our FCC Code 1: SHX TO WHOM IT MAY CONCERN Pursuant to Paragraphs 0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, Adcon Telemetry GmbH requests confidentiality for the following product: FCC ID Number Title/Model SHXA753-46 A753 addWAVE Series 4 For the product stated above we request that the following information be held confidential: 1. Circuit diagrams, BOM, and PCBs submitted as Equipment Authorization Electronic Filing attachment “schematics”. 2. Block diagram submitted as Equipment Authorization Electronic Filing attachment: “blockdiagram”. 3. Operational description submitted as Equipment Authorization Electronic Filing attachment: “operational description”. The above exhibits contain Adcon Telemetry GmbH trade secrets and proprietary information that could be of benefit to our competitors regarding the design of our wireless data logger. This material is not customarily available to the general public and we request that it be withheld from public inspection. For any and all questions please feel free to contact me at the address shown in the letterhead or under my personal email address [email protected] Sincerely, Bernhard Pacher CEO

RF exposure compliance issues: This telemetry device is normally used only at fixed locations far away from persons. It is collecting data from various sensors and transmitting it through the 70cm transmitter. According to Supplement C of OET Bulletin 65 for mobile transmitters operating below 1,5 GHz evaluation is not required when the effective radiated power (ERP) is below or equal to 1,5 W. This device uses a maximum power output of 500 Milliwatts, and omnidirectional antennas without antenna gain over dipole, so the ERP value is also equal to 500 Milliwatts. So this device is excluded from routine evaluation. It must be operated only as fixed or mobile device not closer than 20cm to persons.
