SHXA757GSM-GPRSTelemetry GSM/GPRS Transceiver

A753 addWAVE GSM/GPRS Series 4 User Guide SMART WIRELESS SOLUTIONS Proprietary Notice The Adcon logo, Adcon Telemetry, Smart Wireless Solutions, the A7xx series, addIT, addWAVE, the A840 and A850 series and Telemetry Gateway, AgroExpert, addVANTAGE®, addVANTAGE Lite and addVANTAGE Pro are trademarks or registered trademarks of Adcon Telemetry GmbH. Neither the whole nor any part of the information contained in this publication may be reproduced in any material form except with the prior written permission of Adcon Te l e me t r y G m b H . This publication is intended only to assist the reader in the use of the product. Adcon Telemetry GmbH shall not be liable for any loss or damage arising from the use of any information in this publication, or any error or omission in such information, or any incorrect use of the product. Document Release 2.0, November 2009 Copyright ©2001-2009 by Adcon Telemetry GmbH. All rights reserved. 3 Contents Chapter 1. Introduction____________________________________ 5 About the A753 addWAVE GSM/GPRS Series 4__________________ 5 Conventions _____________________________________________ 6 Chapter 2. Using the addWAVE______________________________ 7 Opening the packages _____________________________________ 7 Installing the RTU_________________________________________ 8 Special Notes on GSM/GPRS Functionality __________________ 8 Operating the A753 _________________________________ 9 Inserting the SIM Card _______________________________ 9 Activating the SIM Card _____________________________ 11 Configuring the GPRS Parameters _____________________ 13 Configuring the TCP Parameters_______________________ 13 Configuring the A753 Connection Settings ______________ 14 Field Installation______________________________________ 15 More about the LED Tool _______________________________ 16 Configuring an A753 in the Telemetry Gateway ________________ 16 Contents 4 Maintaining and servicing the RTU __________________________ 16 The RTU battery ______________________________________ 17 Replacing the battery__________________________________ 17 Chapter 3. Performing Advanced Functions __________________ 20 Understanding Connectors ________________________________ 20 The SOLAR CELL Connector _____________________________ 21 Communicating with the RTU ______________________________ 22 Booting the A753 ________________________________________ 22 Bootloader Mode_____________________________________ 22 Firmware Mode ______________________________________ 23 Upgrading the Firmware __________________________________ 23 Serial Communication Protocol _____________________________ 26 General Format of a Command __________________________ 26 General Format of an Answer ___________________________ 27 Using Terminal Commands ________________________________ 27 Returned Errors List ______________________________________ 44 Command Line Interpreter______________________________ 44 Device Descriptor and Storage Handler____________________ 45 Real‐time Clock_______________________________________ 45 Radio Interface (including GSM/GPRS modem)______________ 45 Notifications _________________________________________ 45 Specifications __________________________________________ 46 Index _________________________________________________ 48 5 Chapter 1. Introduction This manual explains the hardware aspects of Adcon’s A753 addWAVE GSM/GPRS Series 4 remote telemetry units, including installation issues and certain parameter configurations. The manual is divided as follows: •Introduction, which gives some general information and document conventions. •Using the addWAVE, which details the installation and use of the remote telemetry unit. •Performing Advanced Functions, which discusses connectors and controllers and provides other information for advanced users. •Specifications, which describes operating parameters for the devices. About the A753 addWAVE GSM/GPRS Series 4 The A753 addWAVE GSM/GPRS Series 4 remote telemetry unit (RTU) is a low-power, GSM/GPRS-based telemetry device with four digital I/O ports, twelve analog inputs, and four counter inputs. The A753 incorporates a GSM module and uses the standard GSM network for retrieving telemetry data (900/1800 MHz in Europe, 850/ 1900 MHz in the US). The A753 is a ruggedized RTU, complying with the IP65 ingress protection class (NEMA 4). Depending on topography, it ensures a reliable wireless connection to your cellular service provider. Your provider’s cellular network must cover the site where you want to CHAPTER 1 Conventions 6 install the RTU. The maximum theoretical distance to a base station of your provider is approximately 35km, due to timing constraints of the GSM system. The A753 operates in conjunction with the A840 and A850 Telemetry Gateway only. Due to its construction as well as to the software controlling it, the power consumption is extremely low. The unit operates off an internal 6.2 Volt rechargeable battery, which is charged either by a solar panel or an external power adapter. A special configuration can be implemented where no internal battery is used, rather the power is obtained exclusively over an external connector. This device complies with part 15 of the FCC Rules. Operation is subject to the following conditions: 1. This device must not cause harmful interference. 2. This device must accept any interference received, including interference that might cause undesired operation. 3. Any changes to the device other than those mentioned in this manual void the FCC type of approval. Conventions Certain conventions apply in this document. ItalicsIndicate that the text is variable and must be substituted for something specific, as indicated in the explanation. Italics can also be used to emphasize words as words or letters as letters. BoldIndicates special emphasis of the text. Also indicates menu names and items in a window. fixed fontIndicates characters you must type or system messages. File Save Indicates menu selection. …

Text truncated - open the document above for the full version.

Coverletter: Adcon Telemetry GmbH wants to get FCC-Certification for the following product: Telemetry transceiver using GSM technology in the Cellular Radiotelephony Service and the broadband PCS Band (FCC Part 22 and 24) A757GSM-GPRS The unit will get the following FCC-ID: SHXA757GSM-GPRS List of documents: Exhibit Thema File Exhibit 01 Label and placement Labels_09-131.pdf Exhibit 02 Not needed -------------------- Exhibit 03 External Photos extern_09-131.pdf * Exhibit 04 Block Diagrams blockdiagram_A757GSM_GPRS.jpg * Exhibit 05 Schematic Diagrams schematics_A757GSM_GPRS.pdf Exhibit 06 Testreport 09-131.pdf Exhibit 07 Test Set-up Photos setup_09-131.pdf Exhibit 08 User Manual A753GSM_UM.pdf Exhibit 09 Internal Photos intern_09-131.pdf *Exhibit 10 Tune-up Info, Parts list partslist_A757GSM_GPRS.pdf A757GSM-GPRS_Tune_Up_Procedure.pdf Exhibit 11 RF exposure issues RF exposure compliance issues.pdf *Exhibit 12 Operational Description hardware_A757GSM_GPRS.pdf software_A757GSM_GPRS.pdf Exhibit 13 Cover letter Request for confidentiality This file FCC_Confidentiality_A757GSM.pdf For the Exhibits marked with ‘*’ Adcon Telemetry GmbH requested Confidentiality according to 47 CFR 0.457 and 0.459 of the FCC rules because these are sensitive parts owned by this company and include much of Know-How or sensitive data, it will not be provided to the public. The labelling on some photos may not be the actual status. The correct labelling you can see in Exhibit 1.

Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 U.S.A. Klosterneuburg, February 24, 2010 Confidentiality Request Our FRN: 0011471562 Our FCC Code 1: SHX TO WHOM IT MAY CONCERN Pursuant to Paragraphs 0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, Adcon Telemetry GmbH requests confidentiality for the following product: FCC ID Number Title/Model SHXA757GSM­GPRS A757 GSM/GPRS Series 4 For the product stated above we request that the following information be held confidential: 1. Circuit diagrams, BOM, and PCBs submitted as Equipment Authorization Electronic Filing attachment “schematics”. 2. Block diagram submitted as Equipment Authorization Electronic Filing attachment: “blockdiagram”. 3. Operational description submitted as Equipment Authorization Electronic Filing attachment: “operational description”. The above exhibits contain Adcon Telemetry GmbH trade secrets and proprietary information that could be of benefit to our competitors regarding the design of our wireless data logger. This material is not customarily available to the general public and we request that it be withheld from public inspection. For any and all questions please feel free to contact me at the address shown in the letterhead or under my personal email address [email protected] Sincerely, Bernhard Pacher CEO

RF exposure compliance issues: This telemetry device is normally used only at fixed locations far away from persons. It is collecting data from various sensors and transmitting it through the GSM network. According to OET Bulletin 65 for fixed transmitters operating in the Cellular Radiotelephone Service band or in the broadband PCS band evaluation is not required when the total power of all channels used is below or equal to 1000 W ERP or 2000 W ERP respectively. This device only uses one channel in the Cellular Radiotelephone Service band at 850 MHz with a maximum power output of 2 Watts, and ERP not exceeding 7 Watts or one channel in the PCS 1900 MHz Band with a maximum power output of 1 Watt, and ERP not exceeding 2 Watts. So this device is excluded from routine evaluation. It must be operated only as fixed device, never should be used as mobile or portable device.
