Prox Smart Card Reader Technology CardMan ® 5125 User's Manual Copyright © OMNIKEY 2005 (May 2005) Reproduction, adaptation or translation without prior written permission is prohibited, except as allowed under the copyright laws. The information contained in this document is subject to change without notice CardMan 5125 User's Manual English If you have any technical problems or other questions please contact our help desk: [email protected] For latest drivers, visit our homepage: http://www.omnikey.com User's Manual - English 2Prox Smart Card Reader CardMan 5125 Introduction This manual describes the physical behaviour, short data sheet and conformities of OMNIKEY's CardMan 5125, a combined contact and contactless smart card reader. To install your CardMan 5125 please follow the steps as described in the “CardMan 5125 Installation Guide”. If you are developing applications using CardMan 5125, please refer to the “CardMan 5125 Developer’s Guide”. For other detailed informations please contact the OMNIKEY support: [email protected] Box content •Smart Card Reader with fixed USB cable. •This manual The required drivers for operating your reader can be found in the internet at http://www.omnikey.com Overview The CardMan 5125 is a dual interface PC-linked reader that reads 125Khz Prox (RFID) contactless smart cards and virtually any contact smart card. The dual interface feature economically supports end-user environments where both contactless and contact smart card technology may be in use. The CardMan 5125 is a USB plug and play device. The USB cable is fixed to the reader. To connect the reader with your PC, plug the USB connector to an unused USB port of your computer. When the reader is working the LED on the right is lighting up green. If the reader is not working consult the “CardMan 5125 Installation Manual” for driver setup. For using a contact card, put the card with the contacts facing up, in the reader. For contactless operation, hold the card next to the logo on top of the reader. When the reader is exchanging data with the card (reading or writing) the LED on the right is blinking red. User's Manual - English RFID Smart Card Reader CardMan 5125 3 Short Data Sheet Dimensions 80 mm x 67 mm x 28 mm (3.15" x 2,64" x 1,1") Weight (including standard base and adapter) 190 gr (6.7 oz.) Operating temperature 10-55°C (50-131°F) Operating humidity 10-90% rH Composition ABS PC Connector cable 180 cm (6ft) Contact Interface Durability 100,000 Insertions Meantime between failure (MTBF) 500,000 Hours Host Interface USB 2.0 CCID (also supports 1.1) Host Data Transmission speed 12 Mbps (USB 2.0 Full Speed) Power supply Bus powered Conformance Information CE Marking The shipped version of this device complies with the requirements of the directives 89/336/EWG, 73/23/EWG and 1999/5/EG.

Request for Confidentiality in accordance with 47 CFR 0.459 Date: 09 June 2005 PHOENIX TEST-LAB GmbH Kˆnigswinkel 10 D32825 Blomberg Germany RE: Certification Application FCC ID: SIYCM5125 Please be advised that the following information is to be held confidential on behalf of OMNIKEY AG: • Schematics • Parts Lists • Block Diagram • Technical Description The application contains technical information which OMNIKEY AG deems to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. Thank you for your attention to this matter.

FCC ID SIYCM5125 FCC ID SIYCM5125 FCC ID SIYCM5125 FCC ID SIYCM5125 FCC ID SIYCM5125 FCC ID SIYCM5125

FCC ID SIYCM5125 FCC ID SIYCM5125 FCC ID SIYCM5125 FCC ID SIYCM5125 FCC ID SIYCM5125

Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Note: The test data of this report is related only to the individual item which has been tested. This report shall not be reproduced except in full extent without the written approval of the testing laboratory. Test Report No. 55465-050219-1 (Edition 1) Page 1 of 41 Pages Straubing, Mai 9, 2005 T E S T - R E P O R T No. 55465-050219-1 (Edition 1) for Cardman 5125 Inductive TAG Reader Applicant: OMNIKEY GmbH Test Specifications: FCC Code of Federal Regulations, CFR 47, Part 15, Sections 15.205, 15.207 and 15.209 Industry Canada Radio Standards Specification RSS-210 Issue 5, Sections 6.2.1, 6.3 and 6.6 (Category I Equipment) Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55465-050219-1 (Edition 1) Page 2 of 41 Pages Table of Contents 1 Description of the Equipment Under Test (EUT) ........................................................ 3 2 Administrative Data..................................................................................................... 4 3 Identification of the Test Laboratory ........................................................................... 5 4 Summary .................................................................................................................... 6 5 Operation Mode and Configuration of EUT................................................................. 7 6 Measurement Procedures........................................................................................... 8 6.1 Bandwidth Measurements .................................................................................... 8 6.2 Pulse Train Measurement .................................................................................... 9 6.3 Conducted AC Powerline Emission .................................................................... 10 6.4 Radiated Emission Measurement 9 kHz to 30 MHz ........................................... 12 6.5 Radiated Emission in Fully or Semi Anechoic Room.......................................... 14 6.6 Radiated Emission at Open Field Test Site........................................................ 16 7 Photographs Taken During Testing .......................................................................... 17 8 Test Results .............................................................................................................. 23 8.1 Occupied Bandwidth........................................................................................... 24 8.2 Emission Bandwidth ........................................................................................... 27 8.3 Designation of Emissions ................................................................................... 28 8.4 Pulse Train Measurement .................................................................................. 29 8.5 Restricted Bands of Operation ........................................................................... 31 8.6 Conducted Powerline Emission Measurement 150 kHz to 30 MHz................... 32 8.7 Radiated Emission Measurement 9 kHz to 30 MHz .......................................... 35 8.8 Radiated Emission Measurement 30 MHz to 1 GHz ......................................... 37 8.9 Exposure of Humans to RF Fields...................................................................... 39 9 Referenced Regulations ........................................................................................... 40 10 Charts taken during testing ....................................................................................... 41 Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55465-050219-1 (Edition 1) Page 3 of 41 Pages 1 Description of the Equipment Under Test (EUT) General data of EUT Type designation 1 : Cardman 5125 Parts 2 : 1 Serial number(s): Manufacturer: OMNIKEY GmbH Type of equipment: Inductive TAG Reader Version: As delivered FCC ID: Additional parts/accessories: --- Technical data of EUT Application frequency range: 119 - 127 kHz Frequency range: 119 - 127 kHz Operating frequency: 125 kHz Type of modulation: ASK Pulse train: 420 ms Pulse width: 85 ms Number of RF-channels: 1 Channel spacing: Not Applicable Designation of emissions 3 : 10K0A1D Type of antenna: Integrated Size/length of antenna: 50 x 55 mm Connection of antenna: detachable not detachable Type of power supply: DC supply over USB-Port Specifications for power supply: nominal voltage: 5.00 V minimum voltage: 4.50 V maximum voltage: 5.50 V 1 Type designation of the system if EUT consists of more than one part. 2 Type designations of the parts of the system, if applicable. 3 Also known as "Class of Emission". Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55465-050219-1 (Edition 1) Page 4 of 41 Pages 2 Administrative Data Application details Applicant (full address): OMNIKEY GmbH Ferihumerstrafle 13 4040 Linz Austria Contact person: Mr. Stefan Kollingbaum Contract identification: --- Receipt of EUT: 4 th May 2005 Date(s) of test: 5 th May 2005 - 9 th May 2005 Note(s): --- Report details Report number: 55465-050219-1 Edition: 1 Issue date: Mai 9, 2005 Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55465-050219-1 (Edition 1) Page 5 of 41 Pages 3 Identification of the Test Laboratory Details of the Test Laboratory Company name: Senton GmbH EMI/EMC Test Center Address: Aeussere Fruehlingstrasse 45 D-94315 Straubing Germany Laboratory accreditation: DAR-Registration No. DAT-P-171/94-02 FCC test site registration number 90926 Industry Canada test site registration: IC 3050 Contact person: Mr. Johann Roidt Phone: (+49) (0)9421 5522-0 Fax: (+49) (0)9421 5522-99 Senton GmbH Aeussere Fruehlingstrasse 45 D-94315 Straubing Test Report No. 55465-050219-1 (Edition 1) Page 6 of 41 Pages 4 Summary Summary of test results The tested sample complies with the requirements set forth in the Code of Federal Regulations CFR 47, Part…
