med2 RF-module FCC ID: SJ3MUG1223 IC: 5496A-MUG1223 FCC/IC ID Label Sample Label Design Actual Realization The FCC/IC ID label is realized using a laser marker on an adhesive labelling is then placed on the front side of the module PCB.
med2 RF-module FCC ID: SJ3MUG1223 IC: 5496A-MUG1223 FCC/IC ID Label location The FCC/IC ID label is realized using a laser marker on an adhesive labelling is then placed on the front side of the module PCB.
Test Report No.: G0M-1205-1968-TFC249D-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 1 of 48 FCC TEST REPORT FCC 47 CFR Part 15C Industry Canada RSS-210 Intentional radiator operating within the 2400 – 2483.5 MHz band Report Reference No. .................... : G0M-1205-1968-TFC249D-V01 Testing Laboratory ........................ : Eurofins Product Service GmbH Address ............................................ : Storkower Str. 38c 15526 Reichenwalde Germany Accreditation .................................... : A2LA Accredited Testing Laboratory, Certificate No.: 1983.01 FCC Filed Test Laboratory, Reg.-No.: 96970 IC OATS Filing assigned code: 3470A Applicant’s name ........................... : Otto Bock Healthcare Products GmbH Address ............................................ : Kaiserstr. 39 1070 Vienna AUSTRIA Test specification: Standard ........................................... : 47 CFR Part 15C RSS-210, Issue 8, 2010-12 RSS-Gen, Issue 3, 2010-12 ANSI C63.4:2009 Equipment under test (EUT): Product description med2 RF- Module Model No. mug1223 Hardware version a1 Firmware / Software version V1.0 FCC-ID: SJ3MUG1223 IC: 5496A-MUG1223 Test result Passed Test Report No.: G0M-1205-1968-TFC249D-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 3 of 48 REPORT INDEX 1 EQUIPMENT (TEST ITEM) DESCRIPTION: 4 1.1 Photos – Equipment External 5 1.2 Photos – Equipment internal 7 1.3 Photos – Test setup 8 1.4 Supporting Equipment Used During Testing 9 1.5 Test Modes 10 1.6 Test Equipment Used During Testing 11 1.7 Sample emission level calculation 12 2 RESULT SUMMARY 13 3 TEST CONDITIONS AND RESULTS 14 3.1 Test Conditions and Results – Occupied Bandwidth 14 3.2 Test Conditions and Results – Fundamental field strength emissions 18 3.3 Test Conditions and Results – Emissions radiated outside the specified frequency band 26 3.4 Test Conditions and Results – Receiver radiated emissions 36 3.5 Test Conditions and Results – AC power line conducted emissions 46 Test Report No.: G0M-1205-1968-TFC249D-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 4 of 48 1 Equipment (Test item) Description: Description med2 RF- Module Model mug1223 Serial number None Hardware version a1 Software / Firmware version V1.0 FCC-ID SJ3MUG1223 IC 5496A-MUG1223 Equipment type Radio module Radio type Transceiver Radio technology custom Operating frequency range 2401 - 2482 MHz Assigned frequency band 2400 - 2483.5 MHz Frequency range F LOW 2401 MHz F MID 2442 MHz F HIGH 2482 MHz Spreading None Modulations Frequency Number of channels unspecified Channel spacing unspecified Number of antennas 1 Antenna Type integrated Model printed inverted-F antenna Manufacturer see Manufacturer Gain 2.5 dBi Manufacturer Otto Bock Healthcare Products GmbH Kaiserstr. 39 1070 Vienna AUSTRIA Power supply V NOM 3.6 VDC V MIN N/A V MIN N/A AC/DC-Adaptor Model N/A Vendor N/A Input N/A Output N/A Test Report No.: G0M-1205-1968-TFC249D-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 5 of 48 1.1 Photos – Equipment External EUT ON EVALUATION BOARD EUT ON EVALUATION BOARD Test Report No.: G0M-1205-1968-TFC249D-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 6 of 48 EUT EVALUATION BOARD BOTTOM Test Report No.: G0M-1205-1968-TFC249D-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 7 of 48 1.2 Photos – Equipment internal EUT Test Report No.: G0M-1205-1968-TFC249D-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 8 of 48 1.3 Photos – Test setup TEST SETUP : RADIATED EMISSIONS TEST SETUP : CONDUCTED EMISSIONS Test Report No.: G0M-1205-1968-TFC249D-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 9 of 48 1.4 Supporting Equipment Used During Testing Product Type* Device Manufacturer Model No. Comments AE Laptop Dell D430 *Note: Use the following abbreviations: AE : Auxiliary/Associated Equipment, or SIM : Simulator (Not Subjected to Test) CABL : Connecting cables Test Report No.: G0M-1205-1968-TFC249D-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 10 of 48 1.5 Test Modes Mode # Description Transmit General conditions: EUT powered by fully charged battery Radio conditions: Mode = standalone transmit Modulation = Frequency Power level = Maximum Receive General conditions: EUT powered by fully charged battery Radio conditions: Mode = standalone receive Modulation = Frequency Test Report No.: G0M-1205-1968-TFC249D-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 11 of 48 1.6 Test Equipment Used During Testing Occupied Bandwidth Description Manufacturer Model Identifier Cal. Date Cal. Due Spectrum Analyzer R&S FSP 30 EF00312 2011-12 2012-12 Field strength emissions Description Manufacturer Model Identifier Cal. Date Cal. Due Semi-anechoic chamber Frankonia AC 5 EF00395 - - Spectrum Analyzer R&S FSIQ26 EF00242 2012-05 2013-05 Biconical Antenna R&S HK 116 EF00012 2010-01 2013-01 LPD Antenna R&S HL 223 EF00187 2011-02 2014-02 LPD Antenna R&S HL 025 EF00327 2010-02 2013-02 Conducted emissions Description Manufacturer Model Identifier Cal. Date Cal. Due AMN R&S ESH2-Z5 EF00182 2010-09 2012-09 AMN R&S ESH3-Z5 EF00036 2010-11 2012-11 EMI Test Receiver R&S ESCS 30 EF00295 2011-06 2012-06 Test Report No.: G0M-1205-1968-TFC249D-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 12 of 48 1.7 Sample emission level calculation The following is a description of terms and a sample calculation, as appears in the radiated emissions data table. The numbers used in the calculation are for example only. There is no direct correlation to the specific data taken for the product described in this document: Reading: This is the reading obtained on the sp…
Text truncated - open the document above for the full version.
Kaiserstra�e 39 · Vienna · Austria
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | - |

Remote Control for low limp hightech prostheses
Equipment Class
DCD - Part 15 Low Power Transmitter Below 1705 kHz
Serial Cable Replacement
Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
Serial Cable Replacement
Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
