SJ8-CA520MDIGITAL WIRELESS PAN/TILT CAMERA

PORTABLE DIGITAL WIRELESS PAN/TILT CAMERA AND LCD MONITOR SYSTEM INSTRUCTION MANUAL MODEL: CMD5237M CAMERA MODEL: CA520M MONITOR MODEL：M370M 1 Welcome! Thank you for purchasing the wireless video monitor. Before you start, make sure you have the contents listed below. Contents The system comes with the following components: • Camera X1 • Video Monitor X1 • Charging cradle for video monitor X1 • Driver CD X1 • Power adapter for camera X1 • Power adapter for video monitor X1 • Mini USB cable X1 • User’s manual X1 • Hardware kit X1 Camera Video Monitor with Charging Cradle Driver CD Power Adaptor for Camera* Power Adaptor for Video Monitor* Mini USB Cable * The shape of power adaptor may not be exactly as shown Check your package to confirm that you have received the complete system, including all components shown above. 2 Features • Digital wireless technology provides excellent image quality and clarity • Interference free, secure and private signal • Up to 450ft wireless transmission range ① • Listen in with exceptional sound clarity • Two-way audio communication • Safety warning feature notifies you when out of range • System expandable up to 4 cameras ② • Micro SD card recording • Timer Function • USB output for monitoring on PC ① Maximum open space transmission range. The actual range is dependent upon building materials and other obstructions in path of wireless signal. ② Additional cameras sold separately. Camera Features • Pan & tilt camera for wider viewing angle. • Night vision allows for low light viewing up to 15 feet / 4.5 meters ③ • Built-in microphone and speaker • Two-way controlled lullabies • Adjustable audio alarm volume for sound trigger. • Adjustable sensitivity for audio alarm ③ IR illumination range of 15ft./4.5m under ideal conditions. Objects at or beyond this range may be partially or completely obscured, depending on the camera application. Receiver Features • 3.5” color LCD monitor/receiver with superior image quality • Rechargeable lithium polymer battery for true portability • Convenient receiver cradle included • Audio level indicator and alarm • Temperature display on LCD screen 3 Overview Video Monitor Overview 4 Using the joystick to navigate menus The joystick allows you to navigate through the video monitor menus. 5 Camera Overview Side controls Front / Back Controls 6 OSD Overview The video monitor displays the following icons during normal use. The table below summarizes the video monitor icons, and what they mean. 7 Basic Setup Step 1 of 2: Powering on the camera 1. Connect the power adapter to a power outlet and to the camera. 2. Slide the power switch to the ON position. Step 2 of 2: Powering on the Video Monitor 1. Connect the power adapter to a power outlet, and to the video monitor directly or charging cradle (ensure the video monitor firmly rests on the cradle). The video monitor’s charging LED indicator glows red to indicate charging is in progress. NOTE: It requires 6 hours to fully charge the rechargeable batteries. 2. Slide the power switch to ON position. The video monitor will automatically scan for cameras in range. 8 Testing your setup It is recommended that you test your camera setup before permanent installation so that you get the best picture and sound quality from your video monitor. Test the camera and video monitor reception: 1. Place the camera and video monitor in two different rooms. 2. Have one person monitor the signal strength on the video monitor. 3. If the signal strength is low, have a second person move the camera to different locations of the room to find the optimal placement location. Test the camera volume level: 1. Have a person with the video monitor press and hold the TALK button to confirm the volume level from the camera. Have the other person adjust the volume dial on the camera as required. 2. The person holding the video monitor can determine if the camera needs to move to a different location of the room for better sound clarity. Positioning your camera 1. Determine the camera position that will give you the best view. Ensure the power cable is long enough to power the camera. NOTE: Keep cables and wires at least 3 feet (1 meter) away from infants or young children. 2. Connect the power adapter to the camera. 3. Connect the power adaptor to the power outlet. 4. Adjust the camera head with the monitor as shown on Adjusting camera view (page 8). Adjusting camera view When the monitor is in LIVE VIEW mode, adjust the camera head with the monitor to achieve the optimal viewing position. The maximum vertical rotating angle is 150º, and the maximum horizontal rotating angle is 270º. 9 Camera Setup Adjusting the camera sensitivity The camera’s sensitivity dial allows you to adjust the sensitivity level for triggering an alert on the video monitor. To adjust the camera’s sensitivity level: • Scroll the sensitivity dial on the side of the camera towards the maximum position for increased sensitivity (i.e. softer noises trigger the camera). • Scroll the sensitivity dial on the side of the camera towards the minimum position for reduced sensitivity (i.e. louder noises trigger the camera). Adjusting the camera volume The camera’s speaker volume can be adjusted to the desired level. • Scroll the volume dial on the side of camera towards the maximum position to increase the volume. • Scroll the volume dial towards the minimum position to reduce the volume. Adjusting the camera view The camera’s viewing angle can be adjusted on the monitor side. To adjust the camera view, refer to the part Adjusting camera view (page 8). 10 Video Monitor Setup Unlocking the video monitor antenna The video monitor has a built-in antenna that improves signal range. It is recommended that you extend antenna for optimal performance. To unlock the monitor antenna: • Slide the lock button to the right. Reading the power indicator LED The power indicator LED glows green when the monitor is powered on. When the battery is low, the power LED blinks…

Text truncated - open the document above for the full version.

RDI Technology (Shenzhen) Co., Ltd. Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: SJ8-CA520M. Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Schematics Block Diagram Operational Description SJ8-CA520M_SCH.pdf SJ8-CA520M_BlockDiagram.pdf SJ8-CA520M_CircuitDescription.pdf The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, ---------------------------- Tony Zhou / Engineering Manager

RDI Technology (Shenzhen) Co., Ltd. FCC ID: SJ8-CA520M POWER OF ATTORNEY February 7, 2012 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: We, the undersigned, hereby authorize Waltek Services (ShenZhen) Co., Ltd. (Philo Zhong) on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Waltek Services (ShenZhen) Co., Ltd. (Philo Zhong) on our behalf shall have the same effect as acts of our own. This authorization expires on February 6, 2013. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. We, RDI Technology (Shenzhen) Co., Ltd., are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Sincerely, RDI Technology (Shenzhen) Co., Ltd. ------------------------------- Tony Zhou / Engineering Manager

2.1 Product View 2.2 EUT – Appearance View

Page: 53 of 53 RDI Technology (Shenzhen) Co., Ltd. FCC ID: SJ8-CA520M The results shown in this test report refer only to the sample(s) tested , This Test report cannot be reproduced, except in full, without prior written permission of the Company. WALTEK SERVICES Reference No.: WT11127315-S-E-F 17 FCC Label This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. The Label must not be a stick-on paper. The Label on these products must be permanently affixed to the product and readily visible at the time of purchase and must last the expected lifetime of the equipment not be readily detachable. Proposed Label Location on EUT EUT Bottom View/ proposed FCC Label Location FCC ID: SJ8-CA520M This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC ID Label Sample for Model: CA520M FCC ID: SJ8-CA520M This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

2.1 EUT – Open View 2.2 EUT – PCB View 2.3 RF Module - View 2.4 PCB of Camera - View

Page: 1 of 53 FCC TEST REPORT The results shown in this test report refer only to the sample(s) tested , This Test report cannot be reproduced, except in full, without prior written permission of the Company. WALTEK SERVICES Reference No.: WT11127315-S-E-F FCC ID : SJ8-CA520M Applicant : RDI Technology (Shenzhen) Co., Ltd. Address : Building C1 Xingtang Industrial Park, East Baishixia, Fuyong, Baoan, Shenzhen, China Equipment Under Test (EUT) : Product Name : Digital Wireless Pan/Tilt Camera Model No. : CA520M Standards : FCC CFR47 Part 15 Section 15.247:2010 Date of Test : December 23, 2011 ~ January 13, 2012 Date of Issue : February 6, 2012 Test Engineer : Hunk yan / Engineer Reviewed By : Philo zhong / Manager Test Result : PASS Prepared By: Waltek Services (Shenzhen) Co., Ltd. 1/F, Fukangtai Building, West Baima Rd., Songgang Street, Baoan District, Shenzhen 518105, China Tel :+86-755-27553488 Fax:+86-755-27553868 Page: 2 of 53 RDI Technology (Shenzhen) Co., Ltd. FCC ID: SJ8-CA520M The results shown in this test report refer only to the sample(s) tested , This Test report cannot be reproduced, except in full, without prior written permission of the Company. WALTEK SERVICES Reference No.: WT11127315-S-E-F 2 Test Summary Test Items Test Requirement Result Radiated Spurious Emissions (9kHz to 25GHz) 15.205(a) 15.209 15.247(d) PASS Conduct Emission 15.207 PASS 20dB Bandwidth 15.247(a)(1) PASS Maximum Peak Output Power 15.247(b)(1) PASS Frequency Separation 15.247(a)(1) PASS Number of Hopping Frequency 15.247(a)(1)(iii) PASS Dwell time 15.247(a)(1)(iii) PASS Maximum Permissible Exposure (Exposure of Humans to RF Fields) 1.1307(b)(1) PASS Page: 3 of 53 RDI Technology (Shenzhen) Co., Ltd. FCC ID: SJ8-CA520M The results shown in this test report refer only to the sample(s) tested , This Test report cannot be reproduced, except in full, without prior written permission of the Company. WALTEK SERVICES Reference No.: WT11127315-S-E-F 3 Contents Page 1 COVER PAGE ........................................................................................................................................................ 1 2 TEST SUMMARY .................................................................................................................................................. 2 3 CONTENTS............................................................................................................................................................. 3 4 GENERAL INFORMATION ................................................................................................................................ 5 4.1 CLIENT INFORMATION........................................................................................................................................... 5 4.2 GENERAL DESCRIPTION OF E.U.T. ........................................................................................................................ 5 4.3 DETAILS OF E.U.T................................................................................................................................................. 5 4.4 DESCRIPTION OF SUPPORT UNITS.......................................................................................................................... 5 4.5 STANDARDS APPLICABLE FOR TESTING................................................................................................................ 5 4.6 TEST FACILITY...................................................................................................................................................... 6 4.7 TEST LOCATION.................................................................................................................................................... 6 5 EQUIPMENT USED DURING TEST .................................................................................................................. 7 6 CONDUCTED EMISSION .................................................................................................................................... 9 6.1 E.U.T. OPERATION................................................................................................................................................ 9 6.2 EUT SETUP......................................................................................................................................................... 10 6.3 CONDUCTED EMISSION TEST RESULT................................................................................................................. 10 6.4 PHOTOGRAPH – CONDUCTED EMISSION TEST SETUP.......................................................................................... 13 7 RADIATED SPURIOUS EMISSIONS ............................................................................................................... 14 7.1 EUT OPERATION :............................................................................................................................................... 14 7.2 MEASUREMENT UNCERTAINTY........................................................................................................................... 14 7.3 TEST SETUP......................................................................................................................................................... 15 7.4 SPECTRUM ANALYZER SETUP............................................................................................................................. 16 7.5 TEST PROCEDURE................................................................................................................................................ 17 7.6 CORRECTED AMPLITUDE & MARGIN CALCULATION........................................................................................... 17 7.7 SUMMARY OF TEST RESULTS.............................................................................................................................. 18 7.8 PHOTOGRAPH – RADIATION SPURIOUS EMISSION TEST…

Text truncated - open the document above for the full version.

2.1 Photograph – Radiation Spurious Emission Test Setup Below 1GHz Above 1GHz 2.2 Photograph – Conducted Emission Test Setup
