SJ8VS2070MNetwork Video Recorder

1 CasaCam VS2072 4‐Channel Wireless NVR with 7” Touch‐screen Monitor & 2 1296P Cameras User Manual www.casacamusa.com For tech support, contact us at [email protected] 2 Table of Contents 1. SAFETY INSTRUCTIONS ............................................................................................ 4 2. WHAT’S IN THE BOX? .............................................................................................. 4 3. BASIC OPERATION ................................................................................................... 5 3.1 NVR (7” MONITOR) ................................................................................................................... 5 3.2 CAMERA .................................................................................................................................... 6 3.3 LCD Displays .............................................................................................................................. 8 4. INSTALLATION ......................................................................................................... 9 4.1 Monitor Installation .................................................................................................................. 9 4.2 Camera Installation ................................................................................................................. 10 4.3 Using the Antenna Extension .................................................................................................. 11 5. USING THE VS2072 ................................................................................................ 11 6. SYSTEM MENUS..................................................................................................... 12 6.1 Video Playback ........................................................................................................................ 13 6.2 System Setup ........................................................................................................................... 13 6.2.1 Language ....................................................................................................................... 14 6.2.2 Time Setup .................................................................................................................... 14 6.2.3 Wireless Internet .......................................................................................................... 14 6.2.4 Wireless Channel .......................................................................................................... 15 6.2.5 Camera Audio Enable .................................................................................................... 15 6.2.6 Volume setup ................................................................................................................ 15 6.2.7 Auto Close ..................................................................................................................... 16 6.3 Record Setup ........................................................................................................................... 16 6.3.1 Record Schedule ........................................................................................................... 17 6.3.2 Storage Device .............................................................................................................. 18 6.3.3 Storage Management ................................................................................................... 18 6.3.4 Overwrite ...................................................................................................................... 18 6.4 Match Code (Pairing) .............................................................................................................. 18 6.4.1 Pair additional cameras to the NVR .............................................................................. 18 6.4.2 Re‐Pair existing camera. ............................................................................................... 19 6.5 Alarm Setup ............................................................................................................................. 20 6.5.1 Alarm Volume Setup ..................................................................................................... 20 6.5.2 Mobile Split Screen ....................................................................................................... 20 6.5.3 Alarm Setting for Individual Camera ............................................................................. 21 6.6 System Manage ....................................................................................................................... 22 6.6.1 System Info .................................................................................................................... 22 6.6.2 Factory Setting .............................................................................................................. 22 3 6.6.3 Change Password .......................................................................................................... 23 6.6.4 Upgrade ......................................................................................................................... 23 6.6.5 IPC Upgrade ................................................................................................................... 23 7. REMOTE FROM APP .............................................................................................. 24 7.1 Get the App ........................................................................................................................... 24 7.2 Operating the App ................................................................................................................ 24 7.2.1 Add device ................................................................................................................... 24 7.2.2 Features on the App ...................…

Text truncated - open the document above for the full version.

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date:<2021/1/13> Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name SJ8VS2070M VS2070M For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title： Terry zhang/EngineeringManager Company: RDI Technology (Shenzhen) Co., Ltd. Address: 101 to 401, Building 1, and Building 2, No. 7 Yongyue Road,East Baishixia, Fuyong, Baoan, Shenzhen. PRC Phone: 8675527308306 Fax: 8675527308306 E-Mail: [email protected]

RDI Technology (Shenzhen) Co., Ltd. 101 to 401, Building 1, and Building 2, No. 7 Yongyue Road,East Baishixia, Fuyong, Baoan, Shenzhen. PRC Date: 2021/1/13 FCC ID: SJ8VS2070M Model Number: VS2070M To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD To Whom It May Concern, We, RDI Technology (Shenzhen) Co., Ltd., declare that this EUT (FCC ID: SJ8VS2070M) doesn’t have Ad Hoc mode function on “non-US/Canada frequencies”. In addition. The frequency selection feature is disabled by firmware for devices marked to the US/Canada. For DTS part of this device, only channels 1-11 will be used in North America, Country code selection is disabled. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, Name/Title： Terry zhang/EngineeringManager Company: RDI Technology (Shenzhen) Co., Ltd. Address: 101 to 401, Building 1, and Building 2, No. 7 Yongyue Road,East Baishixia, Fuyong, Baoan, Shenzhen. PRC Phone: 8675527308306 Fax: 8675527308306 E-Mail: [email protected]

RDI Technology (Shenzhen) Co., Ltd. 101 to 401, Building 1, and Building 2, No. 7 Yongyue Road,East Baishixia, Fuyong, Baoan, Shenzhen. PRC Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2021/1/13 To whom it may concern: We, RDI Technology (Shenzhen) Co., Ltd. the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: SJ8VS2070M including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： Terry zhang/EngineeringManager Company: RDI Technology (Shenzhen) Co., Ltd. Address: 101 to 401, Building 1, and Building 2, No. 7 Yongyue Road,East Baishixia, Fuyong, Baoan, Shenzhen. PRC Phone: 8675527308306 Fax: 8675527308306 E-Mail: [email protected]

Page: 3 of 11 FCC ID: SJ8VS2070M TB-RF-074-1.0 Appendix III EUT External Photographs Photo 1 Appearance of EUT Photo 2 Appearance of Adapter Page: 4 of 11 FCC ID: SJ8VS2070M TB-RF-074-1.0 Photo 3 Appearance of EUT Photo 4 Appearance of EUT Antenna for Module 6032 Antenna for Module EUS v143 Page: 5 of 11 FCC ID: SJ8VS2070M TB-RF-074-1.0 Photo 5 Appearance of EUT Photo 6 Appearance of EUT Page: 6 of 11 FCC ID: SJ8VS2070M TB-RF-074-1.0 Photo 7 Appearance of EUT Photo 8 Appearance of EUT

Page: 1 of 11 FCC ID: SJ8VS2070M TB-RF-074-1.0 Appendix IFCC ID Label Unit: mm Page: 2 of 11 FCC ID: SJ8VS2070M TB-RF-074-1.0 Appendix II ID Label Location ID LOCATION

Page: 7 of 11 FCC ID: SJ8VS2070M TB-RF-074-1.0 Appendix IV EUT Internal Photographs Photo 9 Internal of EUT Photo 10 Internal of EUT Page: 8 of 11 FCC ID: SJ8VS2070M TB-RF-074-1.0 Photo 11 Appearance of PCB Photo 12 Appearance of PCB Page: 9 of 11 FCC ID: SJ8VS2070M TB-RF-074-1.0 Photo 13 Appearance of PCB Photo 14 Appearance of PCB Module: 6032 Module: EUS_v143 RX Ant. Connector

Shenzhen Toby Technology Co., Ltd. Report No.: TB-MPE177923 Page: 1 of 4 TB-RF-074-1.0 1A/F., Bldg.6, Yusheng Industrial Zone, The National Road No.107 Xixiang Section 467, Xixiang, Bao’an, Shenzhen, China Tel: +86 75526509301 Fax: +86 75526509195 RF Exposure Evaluation FCC ID: SJ8VS2070M 1. Client Information Applicant : RDI Technology (Shenzhen) Co., Ltd Address : 101 to 401, Building 1, and Building 2, No. 7 Yongyue Road,East Baishixia, Fuyong, Baoan, Shenzhen. PRC Manufacturer : RDI Technology (Shenzhen) Co., Ltd Address : 101 to 401, Building 1, and Building 2, No. 7 Yongyue Road,East Baishixia, Fuyong, Baoan, Shenzhen. PRC 2. General Description of EUT EUT Name : Network Video Recorder Model(s) No. : VS2070M Model Different : N/A Sample ID : 20201217-17_1-03& 20201217-17_1-04 Product Description : Operation Frequency: 802.11b/g/n(HT20): 2412MHz~2462MHz 802.11n(HT40): 2422MHz~2452MHz RF Output Power: Bluetooth: -1.020dBm(GFSK) Antenna Gain: 5dBi Dipole Antenna Modulation Type: 802.11b: DSSS(CCK, DQPSK, DBPSK) 802.11g/n:OFDM(BPSK,QPSK,16QAM,64QAM) Power Supply : DC 5V from Adapter(CS18J050250FUF): Input: AC 100-240V, 50/60Hz 500mA Max. Output: DC 5.0V, 2.5A DC 3.7V by 18650 Li-ion Battery. Software Version : N/A Hardware Version : N/A Remark: The antenna gain and the adapter provided by the applicant, the verified for the RF conduction test and adapter provided by TOBY test lab. Note: More test information about the EUT please refer the RF Test Report. Report No.: TB-MPE177923 Page: 2 of 4 TB-RF-074-1.0 SAR Test Exclusion Calculations 1. FCC: According to KDB 447498 D01 Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies v06. According to KDB447498 D01 General RF Exposure Guidance v06 Section 4.3.1 Standalone SAR test exclusion considerations: “Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions.22 The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander (see 5) of section 4.1). To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, typically in the SAR measurement or SAR analysis report, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting is required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for the SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions; for example, handheld PTT two-way radios, handsets, laptops & tablets etc.23 “ [(max. power of channel, including tune-up tolerance, mW)/ (min. test separation distance, mm)] · [√f (GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f (GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to f) in section 4.1 is applied to determine SAR test exclusion. When one of the following test exclusion conditions is satisfied for all combinations of simultaneous transmission configurations, further equipment approval is not required to incorporate transmitter modules in host devices that operate in the mixed mobile and portable host platform exposure conditions. The grantee is responsible for documenting this according to Class I permissive change requirements. Antennas that qualify for standalone SAR test exclusion must apply the estimated standalone SAR to determine simultaneous transmission test exclusion. a) The [∑ of (the highest measured or estimated SAR for each standalone antenna configuration, adjusted for maximum tune-up tolerance) / 1.6 W/kg] + [∑ of MPE ratios] is ≤ 1.0. b) The SAR to peak location separation ratios of all simultaneously transmitting antenna pairs operating in portable device exposure conditions are all ≤ 0.04, and the [∑ of MPE ratios] is ≤ 1.0. Report No.: TB-MPE177923 Page: 3 of 4 TB-RF-074-1.0 2. Calculation: Test separation: 5mm 2.4G WiFi Module 6032 802.11b Frequency (GHz) Conducted Power (dBm) Turn-up Power Tolerance (dB) Max power of tune up tolerance (dBm) Max power of tune up tolerance (mw) Calculation Value Threshold Value 2.412 9.24 8.5±1.0 9.5 8.913 2.768 3.0 2.437 9.18 8.5±1.0 9.5 8.913 2.783 3.0 2.462 9.16 8.5±1.0 9.5 8.913 2.797 3.0 802.11g Frequency (GHz) Conducted Power (dBm) Turn-up Power Tolerance (dB) Max power of tune up tolerance (dBm) Max power of tune up tolerance (mw) Calculation Value Threshold Value 2.412 9.09 8.5±1.0 9.5 8.913 2.768 3.0 2.437 9.13 8.5±1.0 9.5 8.913 2.783 3.0 2.462 9.09 8.5±1.0 9.5 8.913 2.797 3.0 802.11n(HT20) Frequency (GHz) Conducted Power (dBm) Turn-up Power Tolerance (dB) Max power…

Text truncated - open the document above for the full version.

Shenzhen Toby Technology Co., Ltd. Report No.: TB-FCC177922 Page: 1 of 131 TB-RF-074-1.0 1A/F., Bldg.6, Yusheng Industrial Zone, The National Road No.107 Xixiang Section 467, Xixiang, Bao’an, Shenzhen, China Tel: +86 75526509301 Fax: +86 75526509195 FCC Radio Test Report FCC ID: SJ8VS2070M Original Grant Report No. : TB-FCC177922 Applicant : RDI Technology (Shenzhen) Co., Ltd Equipment Under Test (EUT) EUT Name : Network Video Recorder Model No. : VS2070M Series Model No. : N/A Brand Name : CasaCam Sample ID : 20201217-17_1-03& 20201217-17_1-04 Receipt Date : 2020-12-28 Test Date : 2020-12-28 to 2021-01-11 Issue Date : 2021-01-12 Standards : FCC Part 15, Subpart C 15.247 Test Method : ANSI C63.10: 2013 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above, The EUT technically complies with the FCC and IC requirements Test/Witness Engineer : Rebeca Engineer Supervisor : Ivan Su Engineer Manager : Ray Lai This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TB-FCC177922 Page: 2 of 131 TB-RF-074-1.0 Contents CONTENTS ............................................................................................................................................. 2 1. GENERAL INFORMATION ABOUT EUT ............................................................................. 5 1.1 Client Information ................................................................................................................. 5 1.2 General Description of EUT (Equipment Under Test) ................................................... 5 1.3 Block Diagram Showing the Configuration of System Tested ...................................... 6 1.4 Description of Support Units .............................................................................................. 6 1.5 Description of Test Mode .................................................................................................... 7 1.6 Description of Test Software Setting ................................................................................ 8 1.7 Measurement Uncertainty .................................................................................................. 8 1.8 Test Facility ........................................................................................................................... 9 2. TEST SUMMARY ..................................................................................................................... 10 3. TEST SOFTWARE ................................................................................................................... 10 4. TEST EQUIPMENT .................................................................................................................. 11 5. CONDUCTED EMISSION TEST ........................................................................................... 12 5.1 Test Standard and Limit .................................................................................................... 12 5.2 Test Setup ........................................................................................................................... 12 5.3 Test Procedure ................................................................................................................... 13 5.4 Deviation From Test Standard ......................................................................................... 13 5.5 EUT Operating Mode ........................................................................................................ 13 5.6 Test Data ............................................................................................................................. 13 6. RADIATED EMISSION TEST ................................................................................................ 14 6.1 Test Standard and Limit .................................................................................................... 14 6.2 Test Setup ........................................................................................................................... 15 6.3 Test Procedure ................................................................................................................... 16 6.4 Deviation From Test Standard ......................................................................................... 17 6.5 EUT Operating Condition ................................................................................................. 17 6.6 Test Data ............................................................................................................................. 17 7. RESTRICTED BANDS REQUIREMENT ............................................................................. 18 7.1 Test Standard and Limit .................................................................................................... 18 7.2 Test Setup ........................................................................................................................... 18 7.3 Test Procedure ................................................................................................................... 19 7.4 Deviation From Test Standard ......................................................................................... 19 7.5 EUT Operating Condition ................................................................................................. 19 7.6 Test Data ............................................................................................................................. 19 8. BANDWIDTH TEST ................................................................................................................. 20 8.1 Test Standard and Limit ...............................…

Text truncated - open the document above for the full version.

Report No.: TB-FCC177922 Page: 82 of 131 TB-RF-074-1.0 Temperature: 23.5 °C Relative Humidity: 42% Test Voltage: AC 120V/60Hz Ant. Pol. Horizontal Test Mode: TX N(HT40) Mode 2422MHz(Module: EUS_v143) Remark: N/A Remark: 1. Corr. = Antenna Factor (dB/m) + Cable Loss (dB) 2. Peak/AVG (dBμV/m)= Corr. (dB/m)+ Read Level (dBμV) 3. Margin (dB) = Peak/AVG (dBμV/m)-Limit PK/AVG(dBμV/m) Fundamental Frequency Fundamental Frequency Report No.: TB-FCC177922 Page: 83 of 131 TB-RF-074-1.0 Temperature: 23.5 °C Relative Humidity: 42% Test Voltage: AC 120V/60Hz Ant. Pol. Vertical Test Mode: TX N(HT40) Mode 2422MHz(Module: EUS_v143) Remark: N/A Remark: 1. Corr. = Antenna Factor (dB/m) + Cable Loss (dB) 2. Peak/AVG (dBμV/m)= Corr. (dB/m)+ Read Level (dBμV) 3. Margin (dB) = Peak/AVG (dBμV/m)-Limit PK/AVG(dBμV/m) Fundamental Frequency Fundamental Frequency Report No.: TB-FCC177922 Page: 84 of 131 TB-RF-074-1.0 Temperature: 23.5 °C Relative Humidity: 42% Test Voltage: AC 120V/60Hz Ant. Pol. Horizontal Test Mode: TX N(HT40) Mode 2452MHz(Module: EUS_v143) Remark: N/A Remark: 1. Corr. = Antenna Factor (dB/m) + Cable Loss (dB) 2. Peak/AVG (dBμV/m)= Corr. (dB/m)+ Read Level (dBμV) 3. Margin (dB) = Peak/AVG (dBμV/m)-Limit PK/AVG(dBμV/m) Fundamental Frequency Fundamental Frequency Report No.: TB-FCC177922 Page: 85 of 131 TB-RF-074-1.0 Temperature: 23.5 °C Relative Humidity: 42% Test Voltage: AC 120V/60Hz Ant. Pol. Vertical Test Mode: TX N(HT40) Mode 2452MHz(Module: EUS_v143) Remark: N/A Remark: 1. Corr. = Antenna Factor (dB/m) + Cable Loss (dB) 2. Peak/AVG (dBμV/m)= Corr. (dB/m)+ Read Level (dBμV) 3. Margin (dB) = Peak/AVG (dBμV/m)-Limit PK/AVG(dBμV/m) Fundamental Frequency Fundamental Frequency Report No.: TB-FCC177922 Page: 86 of 131 TB-RF-074-1.0 (2) Conducted Test Temperature: 25 °C Relative Humidity: 55% Test Voltage: AC 120V/60Hz Test Mode: TX B Mode 2412MHz / TX B Mode 2462MHz(Module: 6032) Remark: The EUT is programmed in continuously transmitting mode Report No.: TB-FCC177922 Page: 87 of 131 TB-RF-074-1.0 Temperature: 25 °C Relative Humidity: 55% Test Voltage: AC 120V/60Hz Test Mode: TX G Mode 2412MHz / TX G Mode 2462MHz(Module: 6032) Remark: The EUT is programmed in continuously transmitting mode Report No.: TB-FCC177922 Page: 88 of 131 TB-RF-074-1.0 Temperature: 25 °C Relative Humidity: 55% Test Voltage: AC 120V/60Hz Test Mode: TX N(HT20) Mode 2412MHz / TX N(HT20) Mode 2462MHz(Module: 6032) Remark: The EUT is programmed in continuously transmitting mode Report No.: TB-FCC177922 Page: 89 of 131 TB-RF-074-1.0 Temperature: 25 °C Relative Humidity: 55% Test Voltage: AC 120V/60Hz Test Mode: TX N(HT40) Mode 2422MHz / TX N(HT40) Mode 2452MHz(Module: 6032) Remark: The EUT is programmed in continuously transmitting mode Report No.: TB-FCC177922 Page: 90 of 131 TB-RF-074-1.0 Temperature: 25 °C Relative Humidity: 55% Test Voltage: AC 120V/60Hz Test Mode: TX B Mode 2412MHz / TX B Mode 2462MHz(Module: EUS_v143) Remark: The EUT is programmed in continuously transmitting mode Report No.: TB-FCC177922 Page: 91 of 131 TB-RF-074-1.0 Temperature: 25 °C Relative Humidity: 55% Test Voltage: AC 120V/60Hz Test Mode: TX G Mode 2412MHz / TX G Mode 2462MHz(Module: EUS_v143) Remark: The EUT is programmed in continuously transmitting mode Report No.: TB-FCC177922 Page: 92 of 131 TB-RF-074-1.0 Temperature: 25 °C Relative Humidity: 55% Test Voltage: AC 120V/60Hz Test Mode: TX N(HT20) Mode 2412MHz / TX N(HT20) Mode 2462MHz(Module: EUS_v143) Remark: The EUT is programmed in continuously transmitting mode Report No.: TB-FCC177922 Page: 93 of 131 TB-RF-074-1.0 Temperature: 25 °C Relative Humidity: 55% Test Voltage: AC 120V/60Hz Test Mode: TX N(HT40) Mode 2422MHz / TX N(HT40) Mode 2452MHz(Module: EUS_v143) Remark: The EUT is programmed in continuously transmitting mode Report No.: TB-FCC177922 Page: 94 of 131 TB-RF-074-1.0 Attachment D-- Bandwidth Test Data Temperature: 25 °C Relative Humidity: 55% Test Voltage: AC 120V/60Hz Test Mode: TX 802.11B Mode(Module: 6032) Channel frequency (MHz) 6dB Bandwidth (MHz) 99% Bandwidth (MHz) Limit (MHz) 2412 8.539 / >=0.5 2437 8.567 / 2462 8.093 / 802.11B Mode 2412 MHz Report No.: TB-FCC177922 Page: 95 of 131 TB-RF-074-1.0 802.11B Mode 2437 MHz 802.11B Mode 2462 MHz Report No.: TB-FCC177922 Page: 96 of 131 TB-RF-074-1.0 Temperature: 25 °C Relative Humidity: 55% Test Voltage: AC 120V/60Hz Test Mode: TX 802.11G Mode(Module: 6032) Channel frequency (MHz) 6dB Bandwidth (MHz) 99% Bandwidth (MHz) Limit (MHz) 2412 16.34 / >=0.5 2437 16.35 / 2462 16.32 / 802.11G Mode 2412 MHz Report No.: TB-FCC177922 Page: 97 of 131 TB-RF-074-1.0 802.11G Mode 2437 MHz 802.11G Mode 2462 MHz Report No.: TB-FCC177922 Page: 98 of 131 TB-RF-074-1.0 Temperature: 25 °C Relative Humidity: 55% Test Voltage: AC 120V/60Hz Test Mode: TX 802.11N(HT20) Mode(Module: 6032) Channel frequency (MHz) 6dB Bandwidth (MHz) 99% Bandwidth (MHz) Limit (MHz) 2412 16.30 / >=0.5 2437 17.20 / 2462 17.27 / 802.11N(HT20) Mode 2412 MHz Report No.: TB-FCC177922 Page: 99 of 131 TB-RF-074-1.0 802.11N(HT20) Mode 2437 MHz 802.11N(HT20) Mode 2462 MHz Report No.: TB-FCC177922 Page: 100 of 131 TB-RF-074-1.0 Temperature: 25 °C Relative Humidity: 55% Test Voltage: AC 120V/60Hz Test Mode: TX 802.11N(HT40) Mode(Module: 6032) Channel frequency (MHz) 6dB Bandwidth (MHz) 99% Bandwidth (MHz) Limit (MHz) 2422 35.66 / >=0.5 2437 34.45 / 2452 35.14 / 802.11N(HT40) Mode 2422 MHz Report No.: TB-FCC177922 Page: 101 of 131 TB-RF-074-1.0 802.11N(HT40) Mode 2437 MHz 802.11N(HT40) Mode 2452 MHz Report No.: TB-FCC177922 Page: 102 of 131 TB-RF-074-1.0 Temperature: 25 °C Relative Humidity: 55% Test Voltage: AC 120V/60Hz Test Mode: TX 802.11B Mode(Module: EUS_v143) Channel frequency (MHz) 6dB Bandwidth (MHz) 99% Bandwidth (MHz) Limit (MHz) 2412 10.03 / >=0.5 2437 9.067 / 2462 9.600 / 802.11B Mode 2412 MHz Report No.: TB-FCC177922 Page: 103 of 131 TB-RF-074-1.0 802.11B Mode 2437 MHz 802.11B Mode 2462 MHz Report No.: TB-FCC177922 Page: 104 of 131 TB-RF-074-1.0 Temperature: 25 °C Relative Hum…

Text truncated - open the document above for the full version.

Page: 10 of 11 FCC ID: SJ8VS2070M TB-RF-074-1.0 Appendix V EUT Test Photographs Photo of Setup for Radiated Emission (Above 1 GHz) Photo of Setup for Radiated Emission (Below 1 GHz) Page: 11 of 11 FCC ID: SJ8VS2070M TB-RF-074-1.0 Photo of Setup for Conducted Emission -----END OF REPORT-----
