DESI-BOK100_9103-en-C.doc 1 This equipment conforms to the Radio Equipment Directive (RED) 2014/53/EU, covering requirements included in EMC directive 2014/30/UE, and Low Voltage Directive 2014/35/UE as well as other requirements as those from ROHS Directive 2011/65/UE. Complete Declaration of Conformity at Owasys web site: http://owasys.com/bundles/owasysweb/docs/products/owa450/owa450.DoC.en.pdf This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. DISPOSAL OF OLD ELECTRICAL & ELECTRONIC EQUIPMENT (APPLICABLE IN THE EUROPEAN UNION AND OTHER EUROPEAN COUNTRIES WITH SEPARATE COLLECTION SYSTEMS). This product shall not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help preventing potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. The recycling of materials will help to conserve natural resources. For more detailed information about recycling of this product, please contact your local council, your waste disposal service or the distributor where you purchased the product. Dispose of used batteries according to the instructions in section 3.10 1. owa450 kit content ▪ owa450 unit 2. Technical specifications summary Item Specification Power Supply 9 to 48 Vdc (minimum 1.5A) Operating Temperature range -40 ºC to +85 ºC Safety Purposes Temperature range without Li-ion battery -40 ºC to +70ºC Safety Purposes Temperature range with Li-ion battery -40 ºC to +60 ºC Discharge internally limited from -20 ºC to +60ºC Charge internally limited from 0ºC to 45ºC Storage Temperature -40ºC to +85 ºC 3. Safety and other precautions 3.1. General IMPORTANT: FOR THE EFFICIENCY AND SAFE OPERATION OF YOUR owa450 MODULE READ THIS INFORMATION BEFORE USE! Care must be taken when handling the unit. Only staff authorized by Owasys can dismantle the product. If the product is dismantled by non-authorized people and/or ESD precautions are not taken the warranty is not valid. Do not push objects into connectors of your device. Doing so can cause fire or electric shock by short-circuiting. If the product is subject to severe conditions beyond the limits specified in the Technical Specifications, the product could be damaged. Keep the device away from radiators and heat sources. The device may become hot during normal operation, so switch it off and wait for a while before handling it. Do not clean the device when powered up. Clean it with a soft cloth. Do not use liquid or aerosol cleaners, which may contain flammable substances. Use only approved batteries to avoid the risk of explosion. The use of an incorrect type of battery may cause an explosion. 3.2. owa450 connections An external fuse should be included in the positive Vin supply with a rating of 2A (to protect the cables and input circuitry in case of a faulty condition if the external power supply has not short circuit protection below 3A). DESI-BOK100_9103-en-C.doc 2 The highest internal voltage applied to the owa450 unit can be 48Vdc and complies with Low Voltage European Directive. The power supply can be made with a battery or continuous voltage supply with reinforced isolation. Before you connect the device to an electrical outlet, check the voltage and current rating to ensure that the required ones match the available power source. Exceeding the specified input range may cause unexpected operation and/or irreversible damage to owa450. To remove the device from all power sources turn the device off and disconnect it from the electrical outlet. Be sure that nothing rests on the connected cables and that the cables are not located where they can be tripped over or stepped on. Applying loads outside of the specified output range may result in unintended operation and/or possible permanent damage to owa450. Read owa450 Family Integrators Manual carefully before connecting any load to the outputs. If there is any uncertainty, please contact Owasys Customer Support. Use shielded signal cables to ensure that you maintain the appropriate EMC classification for the intended environment. Keeping cables as short as possible is recommended. 3.3. Exposure to RF Energy The antenna(s) and device must be installed in such a position that a minimum separation of 33cm is maintained between the radiator (antenna(s)) and the human body. Those installations not complying with this statement are responsible for providing SAR measurement reports and corresponding declaration Do not hold the antenna during a call since it affects call quality and can cause the module to operate at a higher power level than needed. If you are concerned about RF energy exposure try to minimize exposure by limiting the duration of GSM calls and operating the unit efficiently. 3.4. Antennas care and replacement. Do not use the product with a damaged antenna because when the antenna comes into contact with the skin, a minor burn may result. Replace the antenna immediately. Only use antennas according to the technical specifications. Antennas that do not fulfill the specifications, could damage the product and may contravene local RF emissions regulations or invalidate its fulfillment. Compliance tests for certifications have been performed with ANT100_9100 and ANT100_9101 official accessories. 3.5. Electronic devices Most electronic devices are shielded from RF energy. However RF energy may cause some malfunctioning of improperly shielded electronic devices. In case that the product is mounted in a vehicle, check your vehicle to determine that all on board electronic equipment is adequately shielded from RF energy. In the sa…

Text truncated - open the document above for the full version.

Confidentiality request Date: 11/02/2021 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Rd. Columbia MD 21046 FCC ID: SJE-OWA450 To whom it may concern: Pursuant to §0.457(d)(1)(ii) and §0.459 of the Commission’s Rules (47 C.F.R.) and §552 (b)(4) of the Freedom of Information Act, Owasys Advanced Wireless Devices, S.L. hereby request requests that a part of the subject FCC application be held confidential to avoid release of sensitive information of the product to the public. For the product stated above, we request that the following information be withheld from public disclose: Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Internal Photos Short Term Permanent Operation Description Short Term Permanent Parts List & Placement/BOM Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term User’s Manual Permanent Confidentiality: The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to us and provide unjustified benefits to our competitors. Short-Term Confidentiality: We hereby request short-term confidentiality for the product stated above to avoid premature release of sensitive information prior to marketing or release of the product to the public. Release date of short term confidentiality is: 45 days from grant date marked 90 days from grant date marked 135 days from grant date marked 180 days from grant date marked Specific date: We are also aware that we are responsible to notify DEKRA Testing and Certification S.A.U. in the event information regarding the product or the product is made available to the public. DEKRA Testing and Certification S.A.U. will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Sincerely, By: Antonio Martínez Riberas Title: RD Engineer Telephone: +34946025344 e-mail: [email protected]

OWA450

OWA450

OWA450

DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 59770RAN.001 2020-02-14 Test report No: NIE: 59770RAN.001 Assessment report RF EXPOSURE REPORT ACCORDING TO FCC 47 CFR Part 2.1091 ISED RSS-102 Issue 5:2015 (*) Identification of item under evaluation M2M/IoT Linux based open platform designed to gather, process and report data. (*) Trademark OWASYS (*) Model and /or type reference Owa450 Other identification of the product HW version: R1A SW version: 1 FCC ID: QIPPLS62-W IC: 7830A-PLS62W (*) Features LTE, WIFI, BLUETOOTH 4.2, [email protected], 802.11@5 Manufacturer OWASYS ADVANCED WIRELESS DEVICES S.L. Parque tecnológico, 207B, 48160 Derio, Vizcaya, España Test method requested, standard FCC 47 CFR Part 2.1091 Radiofrequency radiation exposure evaluation: mobile devices. ISED RSS-102 Issue 5 (2015-03) – Radio Frequency Exposure Compliance of Radiocommunication Apparatus (All Frequency Bands) IEEE Std C95.3 TM -2002 (R2008). IEEE Recommended Practice for Measurements and Computations of Radio Frequency Electromagnetic Fields With Respect to Human Exposure to Such Fields, 100 kHz–300 GHz Summary IN COMPLIANCE Approved by (name / position & signature) Miguel Lacave Antennas Lab Manager Date of issue 2020-02-14 Report template No FAN36_01 (*) “Data provided by the client” DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 59770RAN.001 Page 2 of 12 2020-02-14 Index Competences and guarantees .................................................................................................... 3 General conditions ...................................................................................................................... 3 Data provided by the client .......................................................................................................... 3 Identification of the client............................................................................................................. 3 Document history ........................................................................................................................ 3 General description of the device under evaluation ..................................................................... 4 RF Exposure Assessment result and verdict ............................................................................... 5 Appendix A: FCC RF Exposure information ................................................................................ 7 FCC RF Exposure evaluation ................................................................................................. 8 FCC MPE Evaluation ............................................................................................................. 9 Appendix B: ISED RF Exposure information ............................................................................. 10 ISED RF Exposure evaluation for mobile devices ................................................................. 11 ISED MPE Evaluation .......................................................................................................... 12 DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 59770RAN.001 Page 3 of 12 2020-02-14 Competences and guarantees In order to assure the traceability to other national and international laboratories, DEKRA Testing and Certification, S.A.U. has a calibration and maintenance program for its measurement equipment. DEKRA Testing and Certification, S.A.U. guarantees the reliability of the data presented in this report, which is the result of the measurements and the tests performed to the item under test on the date and under the conditions stated on the report and, it is based on the knowledge and technical facilities available at DEKRA Testing and Certification, S.A.U. at the time of performance of the test. DEKRA Testing and Certification, S.A.U. is liable to the client for the maintenance of the confidentiality of all information related to the item under test and the results of the test. The results presented in this Assessment Report apply only to the particular item under test established in this document. IMPORTANT: No parts of this report may be reproduced or quoted out of context, in any form or by any means, except in full, without the previous written permission of DEKRA Testing and Certification, S.A.U. General conditions 1. This report is only referred to the item that has undergone the assessment. 2. This report does not constitute or imply on its own an approval of the product by the Certification Bodies or competent Authorities. 3. This document is only valid if complete; no partial reproduction can be made without previous written permission of DEKRA Testing and Certification, S.A.U. 4. This test report cannot be used partially or in full for publicity and/or promotional purposes without previous written permission of DEKRA Testing and Certification, S.A.U. and the Accreditation Bodies Data provided by the client The following data has been provided by the client: 1. Information relating to the description of the sample ("Identification of the item tested", "Trademark", "Model and/or type reference tested"). 2. Maximum output power and maximum antenna gain information. 3. The device includes a Linux core with different communication interfaces, cellular communication with LTE capabilities, WIFI, BT, and GNSS. DEKRA Testing and Certification S.A.U. declines any responsibility with respect to the information provided by the client and that may affect the validity of results. Identification of the client OWASYS ADVANCED WIRELESS DEVICES S.L. Parque tecnológico, 207B, 48160 Derio, Vizcaya, España. Document history Report number Date…

Text truncated - open the document above for the full version.

DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 59770REM.002A1 2021-02-10 Test report No: NIE: 59770REM.002A1 Test report FCC Rules and Regulations CFR 47, Part 15, Subpart B (10-1-19 Edition) & ICES-003 Issue 7 (October 2020) (*) Identification of item tested M2M/IoT Linux based open platform designed to gather, process and report data (*) Trademark OWASYS (*) Model and /or type reference tested owa450 Other identification of the product FCC ID: SJE – OWA450 IC: 7830A-PLS62W Contains FCC ID: QIPPLS62-W Contains FCC ID: X02SPB209A HW version: R1A SW version: 1 (*) Features LTE, WIFI, BLUETOOTH 4.2, [email protected], 802.11@5 Manufacturer OWASYS ADVANCED WIRELESS DEVICES S.L. Parque tecnológico, 207B 48160 Derio, Vizcaya, SPAIN Test method requested, standard FCC Rules and Regulations CFR 47, Part 15, Subpart B (10-1-19 Edition) & ICES-003 Issue 7 (October 2020) Summary IN COMPLIANCE Approved by (name / position & signature) Rafael López EMC Consumer & RF Lab. Manager Date of issue 2021-02-10 Report template No FDT08_22 (*) “Data provided by the client” DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 59770REM.002A1 Page 2 of 20 2021-02-10 Index Competences and guarantees ...................................................................................................................... 3 General conditions ......................................................................................................................................... 3 Uncertainty ..................................................................................................................................................... 3 Data provided by the client ............................................................................................................................ 3 Usage of samples .......................................................................................................................................... 4 Test sample description ................................................................................................................................. 4 Identification of the client ............................................................................................................................... 6 Testing period and place ............................................................................................................................... 6 Document history ........................................................................................................................................... 6 Environmental conditions .............................................................................................................................. 7 Remarks and comments ................................................................................................................................ 8 Testing verdicts .............................................................................................................................................. 8 List of equipment used during the test........................................................................................................... 8 Appendix A: Test results ..............................................................................................................................10 DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 59770REM.002A1 Page 3 of 20 2021-02-10 Competences and guarantees DEKRA Testing and Certification is a testing laboratory accredited by the National Accreditation Body (ENAC - Entidad Nacional de Acreditación), to perform the tests indicated in the Certificate No. 51/LE 147. In order to assure the traceability to other national and international laboratories, DEKRA Testing and Certification has a calibration and maintenance program for its measurement equipment. DEKRA Testing and Certification guarantees the reliability of the data presented in this report, which is the result of the measurements and the tests performed to the item under test on the date and under the conditions stated on the report and, it is based on the knowledge and technical facilities available at DEKRA Testing and Certification at the time of performance of the test. DEKRA Testing and Certification is liable to the client for the maintenance of the confidentiality of all information related to the item under test and the results of the test. The results presented in this Test Report apply only to the particular item under test established in this document. IMPORTANT: No parts of this report may be reproduced or quoted out of context, in any form or by any means, except in full, without the previous written permission of DEKRA Testing and Certification. General conditions 1. This report is only referred to the item that has undergone the test. 2. This report does not constitute or imply on its own an approval of the product by the Certification Bodies or competent Authorities. 3. This document is only valid if complete; no partial reproduction can be made without previous written permission of DEKRA Testing and Certification. 4. This test report cannot be used partially or in full for publicity and/or promotional purposes without previous written permission of DEKRA Testing and Certification and the Accreditation Bodies. Uncertainty Uncertainty (factor k=2) was calculated according to the DEKRA Testing and Certification internal document PODT000. The total uncertainty of the measurement system for the measured conducted disturbance characteristics of EUT from 150kHz to 30 MHz is I = ± 3,9 dB for quasi-peak measurements, I = ± 3,2 dB for aver…
