SKU-G6F76AC000Wireless Phone Charger

• Only products that have obtained standard certification by WPC( ) are permitted use. Using the Wireless Phone Charger 1. This product operates when you press the『ACC』 start button, that is, when the product is activated. 2. The user must check on whether the product’s LED (BLUE) has flickered two times, and then has turned off. 3. Place the cell-phone at the center of the charger. The farther the phone gets from the center, the lower the efficiency of the charging. 4. When charging starts, you will be able to see the LED (BLUE) light turning on. 5. When the charging is done, you will be able to see the LED light change from blue to green. ● If the charging does not seem to go well, or if the LED (BLUE) light keeps on flickering, refer to the Problem Solving/Help section. Also, lift your cell-phone up and then shift its place again to the center of the charger. Check again whether the charger is working. This device should be installed and operated with minumium 20Cm between the radiator and your body. Problem Solving /Help When the product is not charging - Please check whether your device meets the qi standards. (This product only works for products that have been approved by the WPC standards.) - Adjust the device so it can be placed at the center of the charger. - Please check whether there are other substances (such as coins, keys, magnetic cards, tops of cans, etc.) on the wireless charger. If there are other objects on it, please remove them and then try using the charger again. When the charging LED is flickering - Please check whether your device is placed properly When the charging LED does not turn on - Please check whether the ignition key of the car, 『ACC』 is on. - Please check whether there are other substances on the charger. When the message “No smart key inside," appears, - Please remove the smart keys to another place, places outside the boundaries of wireless charging. User Manual Wireless Phone Charger Caution, Services InformationFCC Statements • • • • • • • • • • • • • • Do not put smart keys, coins, or magnetic cards on the wireless charger. Do not put wet tissues, water, or other liquids on the wireless charger. Do not dismantle or remodel the charger. When the cellphone moves and detaches while driving, stop the car and then put the cellphone back in its place. Do not put heavy or unfixed objects on the charger. Put any machinery or device that can be affected by magnetic fields far from the wireless chargers. Cell phones larger than the battery charging areas may not be charged. If problems or malfunctions occur while using, please contact the Direct Management Center of Hyundai Motors, or Hyundai Mobis Customer Service Center. Refer to pictures(9parts) before using the product. If your charge your cellphone with a cellphone case attached to it, it might not be charged. In cases of small cellphones placed at the end of the charger, they might not be charged. If the charging covers are not the ones produced by the official cellphone manufacturers, cellphones using the unauthorized covers may not be charged. Do not remove anything from the vehicle unless it needs to be replaced or removed for wireless charger repair. If removed, the double-sided tape may remain on the vehicle and the double-sided tape may be removed with a sticker remover. 158.3mm Área de carregamento Telefone 82.4mm Telefone Área de carregamento Área de carregamento Cartões magnéticos Carregador Telefone Carregador Telefone Carregador Telefone Telefone Carregador Carregador Telefone Carregador Telefone Device Layout Caution Certification Mark: Mark shows the product is certified by the WPC, using technology. No Smart Keys: Do not place smart keys on the charger while charging. No Coins: Do not place coins on the charger while charging. Charging Area Left Handle Drive Right Handle Drive Certification Mark No CoinsNo Smart keys LED • WPC( ) 표준 인증을 받은 제품만 사용 할 수 있음. 사용 방법 1. 본 제품은 시동버튼 『ACC』 이상의 상태에서 작동됩니다. 2. 제품의 LED (BLUE)가 두 번 깜빡이고 꺼지는지 확인합니다. 3. 휴대폰을 충전 패드 중앙에 위치 시키십시오. 중앙에서 멀어질수록 충전 효율이 떨어질 수 있습니다. 4. 충전이 시작되면, LED (BLUE)가 켜지는 것을 확인할 수 있습니다. 5. 충전이 완료되면, LED가 BLUE에서 GREEN으로 바뀌는 것을 확인할 수 있습니다. ● 충전이 잘 되지 않거나 LED (BLUE)가 계속 깜빡이는 경우, 문제 해결을 참조 하시고 휴대폰을 들어올렸다가 다시 중앙에 위치하여 충전이 되는지를 확인 합니다. 문제 해결 제품이 충전 되지 않는 경우 - 휴대폰이 qi 기준을 충족하는지 확인하시기 바랍니다. (본 제품은 WPC 표준 인증을 받은 휴대폰만을 지원합니다.) - 휴대폰을 중앙에 위치하도록 조정하시기 바랍니다. - 무선 충전기 위에 이물질(동전, 열쇠, 마그네틱 카드, 캔 뚜껑 등)이 있는지 확인 하시고 이물질 제거 후 다시 사용하시기 바랍니다. 충전 LED가 깜빡이는 경우 - 무선 충전기 충전 영역에 휴대폰이 올바르게 위치 되었는지 확인하시기 바랍니다. 충전 LED가 켜지지 않는 경우 - 차량의 시동버튼이 『ACC』 이상의 상태인지 확인하시기 바랍니다. - 이물질이 충전기와 휴대폰 사이에 있는지 확인하시기 바랍니다. - 휴대폰을 충전기에서 떼었다가 다시 놓아 주십시오. 클러스터에 “스마트키가 실내에 없습니다” 문구가 표시될 경우 - 무선충전기의 충전 영역에서 스마트키를 다른 곳으로 이동시키시기 바랍니다. 사용자 매뉴얼 무선충전기 주의, 서비스 • • • • • • • • • • • • • • • 무선 충전기 위에 스마트키, 동전, 마그네틱 카드을 올려 놓지 마시기 바랍니다. 젖은 휴지, 물 혹은 기타 액체 류를 놓지 마십시오. 분해하거나 개조하지 마십시오. 운전 중 휴대폰이 충전영역에서 이탈하는 경우 차량 정지 후 정 위치에 놓으십시오. 무선 충전기 위에 무겁거나 고정되지 않은 물체 또는 기기를 놓지 마십시오. 자기장에 의해 영향을 받을 수 있는 기계 장치는 멀리 두시기 바랍니다. 무선 충전기가 고장이 났거나, 이상 증세가 보이는 경우 사용하지 마시기 바랍니다. 충전 영역보다 큰 휴대폰은 충전이 안될 수 있습니다. 사용 중 문제나 오작동이 발생하는 경우, 현대자동차 직영센터나 현대모비스 고객 상담실로 문의바랍니다. 제품 사용전 하기 그림을 참고 바랍니다. 무선충전이 장착된 휴대폰에 휴대폰케이스를 사용 시 충전이 안될 수 있습니다. 일부 사이즈가 작은 폰의 경우 무선 충전기 끝쪽에 위치되면 충전이 안될 수 있습니다. 휴대폰 제조사에서 제공된 충전커버가 아닐 경우 충전이 안될 수 있습니다. 무선충전기 A/S를 위해 교체 또는 탈거가 필요할 경우는 제외하고 차량에서 임의 탈거하지 마십시오. 탈거를 할 경우, 차량에 양면 테이프 자국이 남아 있을 수 있으며, 양면 테이프 자국은 스티커 제거제로 제거하시면 됩니다. 158.3mm 충전영역 휴대폰 82.4mm 휴대폰 충전영역 충전영역 마그네틱 카드 충전기 휴대폰 충전기 휴대폰 충전기 휴대폰 휴대폰 충전기 충전기 휴대폰 충전기 휴대폰 부품 명칭 주의 인증 마크 : WPC협회의 인증 제품임을 표시함. 스마트키 금지 : 충전 시에는 제품 위에 스마트키를 올려 놓지 말 것. 동전 금지 : 충전 시에는 제품 위에 동전을 올려 놓지말 것. 충전 영역 Left Handle Drive Right Handle Drive 인증 마크 동전 금지스마트키 금지 LED User Manual Wireless Phone Charger

DONGYANG E&P Inc. 31B 3-1, Jinwi Industrial Estate, Cheongho-Ri, Jinwi- Myeon, Pyeongtaek-Si, Gyeonggi-Do, South Korea Date: 02/10/2020 Timco Engineering, Inc. 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 USA Letter of Authorization We, the undersigned, hereby authorize Geunki Son of DT&C Co., Ltd. to act on our behalf in all manners relating to application for equipment authorization for FCC ID: SKU-G6F76AC000 including signing of all documents relating to these matters. Any and all acts carried out by Geunki Son of DT&C Co., Ltd. on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from DONGYANG E&P Inc. “I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a).” Sincerely, Contact Name: Jin-bum Kim Title: Deputy department head

DONGYANG E&P Inc. 31B 3-1, Jinwi Industrial Estate, Cheongho-Ri, Jinwi- Myeon, Pyeongtaek-Si, Gyeonggi-Do, South Korea Date: 02/10/2020 Timco Engineering, Inc. 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 USA RE: Request of Confidentiality for FCC ID: SKU-G6F76AC000 To Whom It may Concern: Pursuant to Sections 0.457 and 0.459 of the Commission`s Rules(CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, DONGYANG E&P Inc. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The requested permanent and Short-Term Confidential exhibits are listed as follows: PERMANENT & SHORT-TERM CONFIDENTIAL LIST Exhibit Description PERMANENT 1 Block Diagram 2 Schematics 3 Part Lists 4 Operation Description 5 NA The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be public before the date of the Grant for this application. Sincerely, Contact Name: Jin-bum Kim Title: Deputy department head

FCC ID : SKU-G6F76AC000 Copyright Ⓒ 2020, DT&C Co., Ltd. G6F76AC000 (Left) FCC ID : SKU-G6F76AC000 Copyright Ⓒ 2020, DT&C Co., Ltd. View 1 FCC ID : SKU-G6F76AC000 Copyright Ⓒ 2020, DT&C Co., Ltd. View 2 FCC ID : SKU-G6F76AC000 Copyright Ⓒ 2020, DT&C Co., Ltd. View 3 FCC ID : SKU-G6F76AC000 Copyright Ⓒ 2020, DT&C Co., Ltd. G6F76AC300 (Right) FCC ID : SKU-G6F76AC000 Copyright Ⓒ 2020, DT&C Co., Ltd. View 1 FCC ID : SKU-G6F76AC000 Copyright Ⓒ 2020, DT&C Co., Ltd. View 2 FCC ID : SKU-G6F76AC000 Copyright Ⓒ 2020, DT&C Co., Ltd. View 3

FCC ID: SKU-G6F76AC000 Copyright Ⓒ 2020 DT&C Co., Ltd. SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. - The FCC label shown is representative of the label that will appear on the radio when in production. Other information may also be included on this label.

FCC ID : SKU-G6F76AC000 Copyright Ⓒ 2020, DT&C Co., Ltd. G6F76AC300 (Right) FCC ID : SKU-G6F76AC000 Copyright Ⓒ 2020, DT&C Co., Ltd. View 1 FCC ID : SKU-G6F76AC000 Copyright Ⓒ 2020, DT&C Co., Ltd. View 2 FCC ID : SKU-G6F76AC000 Copyright Ⓒ 2020, DT&C Co., Ltd. View 3

FCC ID : SKU-G6F76AC000 Copyright Ⓒ 2020, DT&C Co., Ltd. G6F76AC000 (Left) FCC ID : SKU-G6F76AC000 Copyright Ⓒ 2020, DT&C Co., Ltd. View 1 FCC ID : SKU-G6F76AC000 Copyright Ⓒ 2020, DT&C Co., Ltd. View 2 FCC ID : SKU-G6F76AC000 Copyright Ⓒ 2020, DT&C Co., Ltd. View 3

Report No.: DRTFCC2002-0035 FCC ID: SKU-G6F76AC000 TRF-RF-220(04)170613 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 2 / 7 Test Report Version Test Report No. Date Description Tested by Reviewed by DRTFCC2002-0035 Feb. 12, 2020 Initial issue JaeHyeok Bang JaeJin Lee Report No.: DRTFCC2002-0035 FCC ID: SKU-G6F76AC000 TRF-RF-220(04)170613 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 3 / 7 CONTENTS 1. Equipment information ............................................................................. 4 1.1 Equipment description ............................................................................ 4 1.2 Support equipment .................................................................................. 4 2. Information about test items .................................................................... 5 2.1 Test Configuration and Mode .................................................................. 5 2.2 Tested environment ................................................................................. 5 3. E and H field strength ............................................................................... 6 Report No.: DRTFCC2002-0035 FCC ID: SKU-G6F76AC000 TRF-RF-220(04)170613 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 4 / 7 1. Equipment information 1.1 Equipment description FCC Equipment Class Part 15 Low Power Transmitter Below 1705 kHz (DCD) Equipment type Wireless Phone Charger Equipment model name G6F76-AC000 Equipment add model name G6F76-AC300 Note Equipment serial no. Identical prototype Frequency 111 kHz ~ 205 kHz Output power Max : 5 W Power Supply DC 12.5 V Antenna type Coil Antenna Note: The hardware and software are the same as the basic model G6F76-AC000, but differ in the orientation of the appearance. 1.2 Support equipment Equipment Model No. Serial No. Manufacturer Note Passive Coil NA NA DONGYANG E&P Inc. 5W Note: The above equipment was supported by manufacturer. Report No.: DRTFCC2002-0035 FCC ID: SKU-G6F76AC000 TRF-RF-220(04)170613 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 5 / 7 2. Information about test items 2.1 Test Configuration and Mode ▪Test configuration The field strength of both E-field and H-field were measured at 15 cm using RF exposure survey meter with E-field and H- field probes for determining compliance with the MPE requirements of FCC Part 1.1310 During measurements, the wireless charging pad (EUT) was loaded with the client device using the resistor as described below summary table for test modes and conditions. These testing were performed at test configuration as test setup diagram on clause 3 of this test report. EUT was placed on a non-conductive turntable, and the client device with resistive load for drawing max charging current. This device uses a wireless charging circuit for power transfer operating at the frequency of 111 kHz ~ 205 kHz. Thus, the 300 kHz RF exposure limits were used as below table. ▪Test mode This device has been tested with the below test modes and charging current conditions: Test Mode Output Power Model Name Support Equipment TM1 5 W G6F76-AC000 Client device(Passive Coil) TM2 5 W G6F76-AC300 Client device(Passive Coil) ▪ Limit Frequency E-Field limit H-Field limit FCC Part 1.1310 300 kHz ~ 3 MHz 614 V/m 1.63 A/m 2.2 Tested environment Temperature : 23 °C ~ 25 °C Relative humidity content : 43 % ~ 45 % Details of power supply : DC 12.5 V Report No.: DRTFCC2002-0035 FCC ID: SKU-G6F76AC000 TRF-RF-220(04)170613 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 6 / 7 3. E and H field strength For RF exposure purposes, the E and H field strengths are measured separately with E and H probes and meters at different locations surrounding the test setup. ▪ Test setup diagram ▪ Measurement procedure: KDB 680106 These testing were performed at test configuration as above diagram. EUT was placed on a turntable, and the measurement distance of 15 cm from the center of the probe to the edge of the device. And test was performed all sides of the EUT(except bottom side). ▪Measurement data: Test Mode E-field(V/m) Limit(V/m) Front Rear Right Left Top FCC TM 1 0.640 0.550 0.510 0.550 0.860 614 TM 2 0.570 0.570 0.540 0.540 0.720 - - - - - - Test Mode H-field(A/m) Limit(A/m) Front Rear Right Left Top FCC TM 1 0.221 0.249 0.224 0.220 0.374 1.63 TM 2 0.218 0.231 0.223 0.218 0.388 - - - - - - Measurement Distance (15cm) Rear Front Right Top Left Report No.: DRTFCC2002-0035 FCC ID: SKU-G6F76AC000 TRF-RF-220(04)170613 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 7 / 7 ▪Test equipment list Type Manufacturer Model Cal.Date (yy/mm/dd) Next. Cal.Date (yy/mm/dd) S/N EMF Meter NARDA ELT-400 19/12/10 20/12/10 N-0342 EMF probe NARDA B-Field Probe 19/12/10 20/12/10 M-0779 Broadband field meter NARDA NBM-550 19/12/16 21/12/16 E-1275 Broadband field probe NARDA EF-0391 19/12/16 21/12/16 D-0894 Thermohygrometer BODYCOM BJ5478 19/12/16 20/12/16 120612-2

Report No.: DRTFCC2002-0036 FCC ID: SKU-G6F76AC000 TRF-RF-204(06)170613 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 2 / 14 Test Report Version Test Report No. Date Description Tested by Reviewed by DRTFCC2002-0036 Feb. 12, 2020 Initial issue JaeHyeok Bang JaeJin Lee Report No.: DRTFCC2002-0036 FCC ID: SKU-G6F76AC000 TRF-RF-204(06)170613 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 3 / 14 CONTENTS 1. General Information ................................................................... 4 1.1. Testing Laboratory .................................................................. 4 1.2. Testing Environment ............................................................... 4 1.3. Measurement Uncertainty ...................................................... 4 1.4. Details of Applicant ................................................................. 5 1.5. Description of EUT ................................................................. 5 2. Information about test items ..................................................... 6 2.1 Test mode ................................................................................ 6 2.2 Support equipment .................................................................. 6 2.3 EMI Suppression Device(s)/Modifications ............................... 6 3. Antenna requirements ............................................................... 6 4. Test Report ................................................................................. 7 4.1 Summary of tests .................................................................... 7 4.2 Transmitter requirements ........................................................ 8 4.2.1 20 dB Bandwidth ................................................................. 8 4.2.2 Radiated Emissions .......................................................... 10 4.2.3 AC Line Conducted Emissions .......................................... 12 APPENDIX I................................................................................... 13 Report No.: DRTFCC2002-0036 FCC ID: SKU-G6F76AC000 TRF-RF-204(06)170613 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 4 / 14 1. General Information 1.1. Testing Laboratory DT&C Co., Ltd. The 3 m test site and conducted measurement facility used to collect the radiated data are located at the 42, Yurim-ro, 154beon-gil, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea 17042. The test site complies with the requirements of § 2.948 according to ANSI C63.4-2014. - FCC MRA Accredited Test Firm No. : KR0034 www.dtnc.net Telephone : + 82-31-321-2664 FAX : + 82-31-321-1664 1.2. Testing Environment Ambient Condition ▪ Temperature 23 °C ~ 25 °C ▪ Relative Humidity 43 % ~ 45 % 1.3. Measurement Uncertainty Test items Measurement uncertainty Radiated spurious emission (1 GHz Below) 5.1 dB (The confidence level is about 95 %, k = 2) Report No.: DRTFCC2002-0036 FCC ID: SKU-G6F76AC000 TRF-RF-204(06)170613 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 5 / 14 1.4. Details of Applicant Applicant : DONGYANG E&P Inc. Address : 31B 3-1, Jinwi Industrial Estate, Cheongho-Ri, Jinwi-Myeon, Pyeongtaek-Si, Gyeonggi-Do, South Korea 451-862 Contact person : Jin-bum Kim 1.5. Description of EUT FCC Equipment Class Part 15 Low Power Transmitter Below 1705 kHz (DCD) Equipment type Wireless Phone Charger Equipment model name G6F76-AC000 Equipment add model name G6F76-AC300 Note Equipment serial no. Identical prototype Hardware Version Rev3 Software Version Ver 1p15 Frequency 111 kHz ~ 205 kHz Output power Max : 5 W Power Supply DC 12.5 V Antenna type Coil Antenna Note: The hardware and software are the same as the basic model G6F76-AC000, but differ in the orientation of the appearance. Report No.: DRTFCC2002-0036 FCC ID: SKU-G6F76AC000 TRF-RF-204(06)170613 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 6 / 14 2. Information about test items 2.1 Test mode This device has been tested with the below test modes and charging current conditions: Test Mode Output Power Model Name Support Equipment TM1 5 W G6F76-AC000 Client device(Passive Coil) TM2 5 W G6F76-AC300 Client device(Passive Coil) 2.2 Support equipment Equipment Model No. Serial No. Manufacturer Note Passive Coil NA NA DONGYANG E&P Inc. - Note: The above equipment was supported by manufacturer. 2.3 EMI Suppression Device(s)/Modifications EMI suppression device(s) added and/or modifications made during testing → None 3. Antenna requirements “An intentional radiator antenna shall be designed to ensure that no antenna other than that furnished by the responsible party can be used with the device. The use of a permanently attached antenna or of an antenna that uses a unique coupling to the intentional radiator shall be considered sufficient to comply with the provisions of this section.” The antenna is permanently attached. Please refer to the internal photo. Therefore this E.U.T Complies with the requirement of §15.203 Report No.: DRTFCC2002-0036 FCC ID: SKU-G6F76AC000 TRF-RF-204(06)170613 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 7 / 14 4. Test Report 4.1 Summary of tests FCC Part Section(s) Parameter Limit Test Condition Status Note 1 2.1049 20 dB Bandwidth N/A Radiated C 15.209 Radiated Emission FCC 15.209 limits C 15.207 AC Conducted Emissions FCC 15.207 limits AC Line Conducted NA Note3 15.203 Antenna Requirements FCC 15.203 - C Note 1: C=Comply NC=Not Comply NT=Not Tested NA=Not Applicable Note 2: For radiated emission tests below 30 MHz were performed on semi-anechoic chamber which is correlated with OATS. Note 3 : This device is installed in a car. Therefore the power source is a battery of car. Report No.: DRTFCC2002-0036 FCC ID: SKU-G6F76AC000 TRF-RF-204(06)170613 Prohibits the copying and re-issue of this report without DT&C approval. Pages: 8 / 14 4.2 Transmitter requiremen…
