SM3RC09037BRemote Control Toy Transmitter

21st Century Toys, Inc.

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Nov 10, 2004
Application Purpose: Original Equipment
Date of Application: Nov 10, 2004
Equipment Note: Remote Control Toy Transmitter
Frequency Range: 49.86000000 - 49.86000000
Company: 21st Century Toys, Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Owner’s Manual with Assembly Instructions Please read this manual and save it. For Model RC09037 Use only with a 12 Volt (7.0 Amp/Hr.) Battery, 12 Volt (2.0 Amp/Hr.) Charger (all included). 2 Table of Contents Product features may vary from the pictures above © 2003 21 st Century Toys, Inc. San Leandro, CA. 94577 USA All Right Reserved. Printed in China 2 Table of Contents A Important Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 B Warnings and Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 C Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 D Battery Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 E Battery Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ...10 F Battery Care and Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 G Caring For Your M5 Stuart Tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18 H How to Operate Your M5 Stuart Tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 I Problems and Solutions Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 A Important Information • You must charge your battery for 18 - 30 hours before you use your M5 Stuart Tank for the first time. We recommend that you start charging your battery before beginning assembly. Please see Battery Charging section beginning on page 5 for detailed instructions. • Read this manual carefully for important safety information and operating instructions before using your M5 Stuart Tank. Please keep this manual for future reference as it contains important information. • This M5 Stuart Tank is designed for use: on hard surfaces; on generally level terrain; and by children 8 years of age and up. • To prevent damaging the motors and gears, do not tow anything behind the M5 Stuart Tank or overload it. • If you have any questions about your M5 Stuart Tank, please call our service lines at 1-510-481-6010 from 9 AM to 5 PM (EST) Monday through Friday. Trained customer service representatives are available to take your call in English. 3 B Warnings and Cautions ELECTRICAL HAZARD WARNING ! • PREVENT FIRE - Never modify the electrical system. Alterations could cause a fire resulting in serious injury and could also ruin the electrical system. - Use of the wrong type battery or charger could cause a fire or explosion resulting in serious injury. -Use of Ultimate Solider® components in products other than Ultimate Solider® M5 Stuart Tank could cause overheating, fire or explosion. • The battery must be handled by adults only. The battery is heavy and contains sulfuric acid (electrolyte). Dropping the battery could result in serious injury. • Never allow children to charge the battery. Battery charging must be done by adults only. A child could be injured by the electricity involved in charging the battery. • Never lift or carry the battery by the wires or connector. This can damage the battery and possibly cause a fire resulting in serious injury. Lift and carry the battery by the case only. • Read the safety instructions on the battery. • Examine the battery, charger and their connectors for excessive wear or damage each time you charge the battery. If damage or excessive wear is detected, do not use the charger or the battery until you have replaced the worn or damaged part. CAUTIONS ! • Use the charger in dry locations only. 4 C Parts • If you experience a problem with this product, or are missing a part, please call us at 1-510-481-6010, rather than return this product to the store. • Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded. M5 Stuart Tank Radio Controller 12 Volt Battery Charger 12 Volt Battery 12 Volt Battery Connector 5 D Battery Charging ELECTRICAL HAZARD WARNING ! • PREVENT FIRE - Never modify the electrical system. Alterations could cause a fire resulting in serious injury and could also ruin the electrical system. - Use of the wrong type battery or charger could cause a fire or explosion resulting in serious injury. - Use of Ultimate Solider® components in products other than Ultimate Solider® M5 Stuart Tank could cause overheating, fire or explosion. • The battery must be handled by adults only. The battery is heavy and contains sulfuric acid (electrolyte). Dropping the battery could result in serious injury. • Never allow children to charge the battery. Battery charging must be done by adults only. A child could be injured by the electricity involved in charging the battery. • Never lift or carry the battery by the wires or connector. This can damage the battery and possibly cause a fire resulting in serious injury. Lift and carry the battery by the case only. • Read the safety instructions on the battery. • Examine the battery, charger and their connectors for excessive wear or damage each time you charge the battery. If damage or excessive wear is detected, do not use the charger or the battery until you have replaced the worn or damaged part. CAUTION ! • Use the charger in dry locations only. Important Notes • Your new battery must be charged for at least 18 hours before you use it in your M5 Stuart Tank for the first time. • We recommend that you start charging your battery before beginning assembly of your new M5 Stuart Tank. • The battery must be upright while charging. • The charger is not a toy. • Do not short circuit the battery. • The battery MUST be removed from your M5 Stuart Tank e…

Text truncated - open the document above for the full version.

External Photos

PHOTOGRAPH OF THE PRODUCT FRONT VIEW OF THE PRODUCT REAR VIEW OF THE PRODUCT

ID Label/Location Info

FCC ID: SM3RC09037B MADE IN CHINA This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 45 MM 40 MM

ID Label/Location Info

Internal Photos

PHOTOGRAPH OF THE PRODUCT INNER CIRCUIT TOP VIEW INNER CIRCUIT BOTTOM VIEW

Operational Description

FCC ID: SM3RC09037B Circuit Description The 49.86MHz crystal oscillator drives the base of Q2 the final/buffer amplifier. The modulation provided by IC. The output of Q2 has the matching network consisting of L3 and C9 that limit the harmonic content and effect the proper coupling of the antenna to the output stage. Antenna, Ground and Power Source The antenna consists of a 76.5cm long metal antenna. There is no external ground connection. The ground is only that of the printed circuit board. Electric current is supplied by a 9 Volt (“6F22” size battery x 1) primary battery

Test Report

香港標準及檢定中心 Hong Kong Standards and Testing Centre Date : 2004-11-01 TEST REPORT Page 1 of 18 No. : HM152563 This report shall not be reproduced unless with prior written approval from the Hong Kong Standards and Testing Centre. 香港新界大埔工業村大宏街10號 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] For full text of “Conditions of Issuance of Test Report”, please refer to overleaf or refer to the website of STC: www.hkstc.org (the section “Application and Quotation”). Applicant: 21 st Century Toys, Inc. 2456 Verna Court, San Leandro, CA 94577 USA Description of Samples: Model name: Radio Control M5 Stuart Tank Model no.: RC09037 Brand name: 21 st Century Toys, Inc. FCC ID: SM3RC09037B Date Samples Received: 2004-09-21 Date Tested: 2004-10-06 Investigation Requested: FCC Part 15 Subpart C Conclusions: The submitted product COMPLIED with the requirements of Federal Communications Commission [FCC] Rules and Regulations Part 15. The tests were performed in accordance with the standards described above and on Section 2.2 in this Test Report. Remarks: ---- K C Lee, EMC for Chief Executive 香港標準及檢定中心 Hong Kong Standards and Testing Centre Date : 2004-11-01 TEST REPORT Page 2 of 18 No. : HM152563 香港新界大埔工業村大宏街10號 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] For full text of “Conditions of Issuance of Test Report”, please refer to overleaf or refer to the website of STC: www.hkstc.org (the section “Application and Quotation”). CONTENT: Cover Page 1 of 18 Content Page 2-3 of 18 1.0 General Details 1.1 Test Laboratory Page 4 of 18 1.2 Applicant Details Page 4 of 18 Applicant HKSTC Code Number for Applicant Manufacturer 1.3 Equipment Under Test [EUT] Page 5 of 18 Description of EUT operation 1.4 Date of Order Page 5 of 18 1.5 Submitted Samples Page 5 of 18 1.6 Test Duration Page 5 of 18 1.7 Country of Origin Page 5 of 18 1.8 Additional Information of EUT Page 6 of 18 2.0 Technical Details 2.1 Investigations Requested Page 7 of 18 2.2 Test Standards and Results Summary Page 7 of 18 3.0 Test Results 3.1 Emission Page 8-11 of 18 3.2 Bandwidth Measurement Page 12-13 of 18 香港標準及檢定中心 Hong Kong Standards and Testing Centre Date : 2004-11-01 TEST REPORT Page 3 of 18 No. : HM152563 香港新界大埔工業村大宏街10號 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] For full text of “Conditions of Issuance of Test Report”, please refer to overleaf or refer to the website of STC: www.hkstc.org (the section “Application and Quotation”). Appendix A List of Measurement Equipment Page 14 of 18 Appendix B Duty Cycle Correction During 100 msec Page 15-16 of 18 Appendix C Photographs Page 17-18 of 18 香港標準及檢定中心 Hong Kong Standards and Testing Centre Date : 2004-11-01 TEST REPORT Page 4 of 18 No. : HM152563 香港新界大埔工業村大宏街10號 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] For full text of “Conditions of Issuance of Test Report”, please refer to overleaf or refer to the website of STC: www.hkstc.org (the section “Application and Quotation”). 1.0 General Details 1.1 Test Laboratory The Hong Kong Standards and Testing Centre Ltd. EMC Laboratory 10 Dai Wang Street, Taipo Industrial Estate New Territories, Hong Kong 1.2 Applicant Details Applicant 21 st Century Toys, Inc. 2456 Verna Court, San Leandro, CA 94577 USA HKSTC Code Number for Applicant CET002 Manufacturer Kin Sun Industrial Ltd. 2-12 Au Pui Wan St., Fo Tan, Shatin, N.T., Hong Kong. 香港標準及檢定中心 Hong Kong Standards and Testing Centre Date : 2004-11-01 TEST REPORT Page 5 of 18 No. : HM152563 香港新界大埔工業村大宏街10號 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] For full text of “Conditions of Issuance of Test Report”, please refer to overleaf or refer to the website of STC: www.hkstc.org (the section “Application and Quotation”). 1.3 Equipment Under Test [EUT] Description of Sample Model Name: Radio Control M5 Stuart Tank Manufacturer: Kin Sun Industrial Ltd. Brand Name: 21 st Century Toys Model Number: RC09037 Input Voltage: 9Vd.c (“6F22” size battery x 1) 1.3.1 Description of EUT Operation The Equipment Under Test (EUT) is a 21 st Century Toys Inc., Radio Control M5 Stuart Tank. The transmitter is a 2 button transmitter. The EUT continues to transmit while button is being pressed, Modulation by IC. and type is pulse modulation. 1.4 Date of Order 2004-09-21 1.5 Submitted Sample(s): 1 Sample per model 1.6 Test Duration 2004-10-06 1.7 Country of Origin China 香港標準及檢定中心 Hong Kong Standards and Testing Centre Date : 2004-11-01 TEST REPORT Page 6 of 18 No. : HM152563 香港新界大埔工業村大宏街10號 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] For full text of “Conditions of Issuance of Test Report”, please refer to overleaf or refer to the website of STC: www.hkstc.org (the section “Application and Quotation”). 1.8 Additional Information of EUT Submitted Not Available User Manual Part List Circuit Diagram Printed Circuit Board [PCB] Layout Block diagram FCC ID Label 香港標準及檢定中心 Hong Kong Standards and Testing Centre Date : 2004-11-01 TEST REPORT Page 7 of 18 No. : HM152563 香港新界大埔工業村大宏街10號 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] For full text of “Conditions of Issuance of Test Report”, please refer to overleaf or refer to the website of STC: www.hkstc.org (the section “Application and Quotation”). 2.0 Technical Details 2.1 Investigations Requested Perform E…

Text truncated - open the document above for the full version.

Test Setup Photos

TEST SET UP PHOTOGRAPH OF THE PRODUCT MEASUREMENT OF RADIATED EMISSION TEST SET UP
