SMC-K970AOSmart Projector

Quick Start Guide Model No.J93-8K2 EN 1-1 • Read this product manual thoroughly before attempting to use this product. Store the product manual in a safe location so it may be referenced at any time. • Do not look directly into the light lens of the device as your eyes may be damaged by a strong laser. • When the projector is working, do not block the projection lens with any object. • If you encounter an issue with the product, do not attempt to disassemble it without authorization. Contact professional after-sales personnel to resolve the issue. Safety Notice Certificate of Conformity CERTIFICATE INSPECTED Dear JMGO User, Thank you for choosing JMGO projectors to enhance your life! Whether it is for an immersive home cinema experience, creating a healthier viewing environment for your children, or elevating your outdoor adventures, we are truly honored to be part of your journey. Your trust and expectations inspire us to keep innovating. With advanced pure Triple-color laser technology, a revolutionary gimbal design for versatile projection, and our proprietary operating system, we have redefined the audiovisual experience. We have also introduced eco-friendly, portable packaging to make your projector travel-friendly, ensuring you can take your cinematic experience anywhere. At JMGO, our mission goes beyond delivering outstanding visuals; we strive to inspire a more relaxed, diverse lifestyle. Whether it is bonding with family, celebrating with friends, or enjoying peaceful moments alone, we hope JMGO becomes your trusted companion. We are excited to continue surprising you with more as you explore your JMGO projector. If you have any feedback or suggestions, we would love to hear from you via email at: [email protected]. Thank you for letting us be part of your story. Warm regards, Chief Executive Officer & Chief Experience Officer JMGO Appreciation Letter Scope of Delivery Projector Body Remote Control Power CablePower Adapter Quick Start Guide Allen Wrench AAA Battery x 2 1-2 Quick Start Guide �. Slide down to open the back cover, and then install 2 AAA batteries. �. Insert new batteries matching the polarity (+/-) and close the battery compartment. 1-3 Remote Control Power On/Off Direction Keys Return Menu Settings YouTube Netflix Google Assistant Confirm Home Volume Input Source Prime Video 1 2 3 4 5 6 7 8 9 10 11 12 13 10 11 12 13 *After the projector is turned on, press and hold and on the remote control for 3 seconds at the same time to enter Bluetooth pairing. • JMGO App is a mobile application for multi-screen interaction with JMGO projector. Using JMGO App can help you obtain better projection experience. • Mobile phone for remote control—the mobile phone is also a remote control with JMGO App, and the projection remote control is more convenient. Download and Installation of "JMGO App" Product Figure Power Button Power on/off: The power button is a physical button, short press to power on or off. 1-4 HDMI Power Port USB HDMI(eARC) Laser Safety Standard: Class 1 in compliance with the IEC 60825-1:2014. The maximum output of laser radiation0.39mW Emission Wavelength: Blue: 455~475nm Red: 635~655nm Green: 515~535nm Product Laser Safety Parameters Safety Warning: Viewing direction Laser beam direction Screen 1-5 Class 1 Laser product Do not stare into the beam RG2 Complies with IEC 60825-1:2014 and IEC 62471-5:2015. CAUTION Google TV is the name of this device's software experience and a trademark of Google LLC. Google, YouTube and Google Cast are trademarks of Google LLC. Google Assistant is not available in certain languages and countries. Availability of services varies by country and language. This product contains a laser module. Do not disassemble or modify this module in a manner not specified in the manual without authorization. Failure to follow this guideline may result in personal injury. RG1 IEC 62471-5:2015. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement This projector complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device should be installed and operated with a minimum distance of 20cm between the radiator and user body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. FCC WARNING: This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made. This remote has been evaluated to meet general RF …

Text truncated - open the document above for the full version.

ShenzhenGUORENCertificationTechnologyServiceCo.,Ltd. 101#,BuildingK&BuildingT,TheSecondIndustrialZone,JiazitangCommunity, FenghuangStreet,GuangmingDistrict,Shenzhen,China FCCPART15SUBPARTCTESTREPORT FCCPART15.247 ReportReferenceNo........................: FCCID.................................................: GRCTR250804024-02 SMC-K970AO Compiledby (position+printedname+signature)..: TestingEngineerJimmyWang Supervisedby (position+printedname+signature)..: ProjectEngineerKelleyZhang Approvedby (position+printedname+signature)..: ManagerSamWang Dateofissue.........................................:Sep.10,2025 TestingLaboratoryName................: ShenzhenGUORENCertificationTechnologyServiceCo.,Ltd. Address.................................................: 101#,BuildingK&BuildingT,TheSecondIndustrialZone,Jiazitang Community,FenghuangStreet,GuangmingDistrict,Shenzhen, China Applicant’sname...............................: SHENZHENHOLATEKCO.,LTD. Address.................................................: #12,Building1,ChongwenPark,NanshanZhiyuan,3370LiuxianAve, NanshanDistrict,Shenzhen,China. Testspecification..............................: Standard ................................................ :FCCPart15.247 ShenzhenGUORENCertificationTechnologyServiceCo.,Ltd.Allrightsreserved. Thispublicationmaybereproducedinwholeorinpartfornon-commercialpurposesaslongasthe ShenzhenGUORENCertificationTechnologyServiceCo.,Ltd.isacknowledgedascopyrightownerand sourceofthematerial.ShenzhenGUORENCertificationTechnologyServiceCo.,Ltd.takesno responsibilityforandwillnotassumeliabilityfordamagesresultingfromthereader'sinterpretationofthe reproducedmaterialduetoitsplacementandcontext. Testitemdescription........................: SmartProjector TradeMark............................................: JMGO Manufacturer ......................................... : SHENZHENHOLATEKCO.,LTD. Model/Typereference.........................: J93-8K2 ListedModels......................................: J93-8K3,J93-8K0,J93-8K1,J93-8K4,J93-8K5,J93-8K6,J93-8K7,J93- 8K8,J93-8K9,J93-8KA,J93-8KB,J93-8KC,J93-8KD,J93-8KE,J93- 8KF,J93-8KG,J93-8KH,J93-8KI FirmwareVersion ................................. : 1.1.31.28 HardwareVersion................................: VerA Modulation...........................................: GFSK Frequency.............................................. From2402MHzto2480MHz Ratings ................................................... : DC24Vfromexternalcircuit Result.....................................................: PASS ReportNo.:GRCTR250804024-02Page 2 of 34 TESTREPORT EquipmentunderTest:SmartProjector Model/Type:J93-8K2 ListedModels:J93-8K3,J93-8K0,J93-8K1,J93-8K4,J93-8K5,J93-8K6,J93- 8K7,J93-8K8,J93-8K9,J93-8KA,J93-8KB,J93-8KC,J93-8KD,J93- 8KE,J93-8KF,J93-8KG,J93-8KH,J93-8KI Applicant : SHENZHENHOLATEKCO.,LTD. Address: #12,Building1,ChongwenPark,NanshanZhiyuan,3370Liuxian Ave,NanshanDistrict,Shenzhen,China. Manufacturer : SHENZHENHOLATEKCO.,LTD. Address: #12,Building1,ChongwenPark,NanshanZhiyuan,3370Liuxian Ave,NanshanDistrict,Shenzhen,China. TestResult:PASS Thetestreportmerelycorrespondstothetestsample. Itisnotpermittedtocopyextractsofthesetestresultwithoutthewrittenpermissionofthetest laboratory. ReportNo.:GRCTR250804024-02Page 3 of 34 Contents 1TESTSTANDARDS..............................................................................................................................4 2SUMMARY.................................................................................................................................................5 2.1GeneralRemarks..........................................................................................................................................5 2.2ProductDescription.....................................................................................................................................5 2.3EquipmentUnderTest.................................................................................................................................5 2.4ShortdescriptionoftheEquipmentunderTest(EUT).............................................................................5 2.5EUTconfiguration.........................................................................................................................................6 2.6EUToperationmode.....................................................................................................................................6 2.7BlockDiagramofTestSetup.......................................................................................................................6 2.8RelatedSubmittal(s)/Grant(s)...................................................................................................................6 2.9Modifications.................................................................................................................................................7 3TESTENVIRONMENT........................................................................................................................8 3.1Addressofthetestlaboratory....................................................................................................................8 3.2TestFacility...................................................................................................................................................8 3.3Environmentalconditions............................................................................................................................8 3.4Summaryofmeasurementresults..............................................................................................................9 3.5Statementofthemeasurementuncertainty..............................................................................................9 3.6EquipmentsUsedduringtheTest............................................................................................................10 4TESTCONDITIONSANDRESULTS......…

Text truncated - open the document above for the full version.

ID:SMC-K970AO TESTSEPUPphotosEUT ID:SMC-K970AO

、 Sample Confirmation Letter Supplier Name：SHENZHEN YINGJIACHUANG TECHNOLOGY ELECTRONIC CO. LTD Material Name: WiFi2 2.4G/5.8G Black FPC built-in Antenna（K970AO） Material No.： 23040352&YJC-6N273-B06 Material Description： WiFi2 2.4G/5.8G Black FPC built-in Antenna（K970AO） Version: _______A0______ Drawing Version：_______A0______ Supplier Approved This needs to be stamped, and each acknowledgment letter needs to be stamped with a riding seal. Shenzhen Holatek Approved R&D/Engineering Quality Approved Product Center R&D Supply-Chain Center Quality Management Department Yin FeiJie Yang YunGang Xiao Han Address：Building C, Hongyu Guangming Valley, No. 11, Shiwei Community, Matian Office, Guangming District, Shenzhen Phone：+86-755-27810060/23192199 Fax：+86-0755-27810057 第 2 页 共 15 页 Directory Page Content 1 Cover 2 Directory 3 Product drawings 4 Specification 5 Process Flow Diagram 6 BOM list 7 Performance testing reports 8 SGS Environmental Protection Report for Raw Materials 第 3 页 共 15 页 Product drawings： 第 4 页 共 15 页 Antenna technology parameters： Electrical Specifications Frequency Range 2400-2500/5150-5850MHz VSWR ＜1.92 Input Impedance 50 Ω Direction All Gain(2.4G) 1.8dBi Gain(5.1G) 3.4dBi Gain(5.4G) 3.4dBi Gain(5.8G) 3.3dBi Mechanical Specifications Cable Color Black Input connector XD Cable length 273mm(Total length) Working Temperature -20°C~+70°C Working Humidity 20%~80% Environmental performance test: Project Test condition Standard Storage Conditions In the absence of specified test temperature, humidity, air pressure is as follows: 1.Temperature is - 20 °C ~ + 70 °C 2.Relative humidity of 45% to 85% 3.Air pressure is 86 kpa to 106 kpa Electrical and mechanical properties is normal High and low temperature test Between 70 °C and -20 °C for 5 loops, then 1- 2 h under normal conditions, check the appearance quality. Size should meet the requirements and should satisfy the content with the electrical and mechanical properties Constant damp and hot resistance test 95 + / - 3% relative humidity, temperature test: 40 °C. Lasts 2 h after, try to take out the determination of electrical properties, within 5 min after try 1-2 h under article normal thing, check the appearance quality Size should meet the requirements and should satisfy the content with the electrical and mechanical properties vibration test Vibration frequency range: 10-55 Hz, vibration frequency range of displacement amplitude: 0.35 MM, acceleration amplitude: 50.0 M/S, sweep cycles: 30 times Electrical and mechanical properties is normal Fall down test 1 m high altitude in accordance with the perpendicular axis free drop 3 times Electrical and mechanical properties is normal 第 5 页 共 15 页 Process Flow Diagram Cut Cable/ Terminating Weld Test Quality inspection Packaging 第 6 页 共 15 页 BOM list FPC、Cable、Terminal、Heat shrinkable sleeve、Shockproof cotton、PE packaging bag、Carton 第 7 页 共 15 页 Performance testing reports： Antenna physical image： Antenna performance test chart: Frequency （MHZ） 2400 2450 2500 5150 5725 5850 VSWR（dB） 1.29 1.39 1.38 1.14 1.45 1.10 第 8 页 共 15 页 WIFI 2 and BT isolation test diagram WIFI 2 and WIFI 1 isolation test diagram Frequency （MHz） 2400 2450 2500 5150 5725 5850 WIFI1 and WIFI2 isolation (dB) -24 -25 -28 -42 -34 -32 WIFI2 and BT isolation (dB) -33 -41 -31 -30 -34 -36 第 9 页 共 15 页 2D、3D test data (WIFI 2)： Frequency Efficiency (%) Gain.(dBi) 2400MHz 48.91 1.79 2410MHz 48.84 1.80 2420MHz 47.8 1.48 2430MHz 47.72 1.63 2440MHz 47.39 1.80 2450MHz 46.98 1.67 2460MHz 46.67 1.63 2470MHz 46.61 1.69 2480MHz 46.98 1.62 2490MHz 46.61 1.72 2500MHz 48.53 1.64 5150MHz 38.73 3.40 5250MHz 37.4 3.20 5350MHz 39.08 3.20 5450MHz 38.43 3.40 5550MHz 36.77 3.37 5650MHz 39.62 3.40 5750MHz 37.34 3.21 5850MHz 38.97 3.30 Phi 0 2D: Phi 90 2D Theta 90 2D 第 10 页 共 15 页 3D 2400： 3D 2450： 3D 2500： 第 10 页 共 15 页 3D 5150： 3D 5500： 3D 5850： 第 11 页 共 15 页 OTA active test data： Item Measurement Band Channel Frequency Total 1 TRP WIFI_B (11M) 1 2412 15.81 2 TRP WIFI_B (11M) 6 2437 14.25 3 TRP WIFI_B (11M) 11 2462 15.12 4 TIS(EIRP) WIFI_B (11M) 1 2412 -83.4 5 TIS(EIRP) WIFI_B (11M) 6 2437 -82.13 6 TIS(EIRP) WIFI_B (11M) 11 2462 -83.74 7 TRP WIFI_G (54M) 1 2412 13.37 8 TRP WIFI_G (54M) 6 2437 13.79 9 TRP WIFI_G (54M) 11 2462 14.51 10 TIS(EIRP) WIFI_G (54M) 1 2412 -69.4 11 TIS(EIRP) WIFI_G (54M) 6 2437 -70.13 12 TIS(EIRP) WIFI_G (54M) 11 2462 -70.74 13 TRP WIFI_N_ISM (65M) 1 2412 13.43 14 TRP WIFI_N_ISM (65M) 6 2437 13.5 15 TRP WIFI_N_ISM (65M) 11 2462 13.52 16 TIS(EIRP) WIFI_N_ISM (65M) 1 2412 -68 17 TIS(EIRP) WIFI_N_ISM (65M) 6 2437 -69.66 18 TIS(EIRP) WIFI_N_ISM (65M) 11 2462 -68.56 19 TRP WIFI_A (54M) 36 5180 11.6 20 TRP WIFI_A (54M) 149 5745 12.19 21 TRP WIFI_A (54M) 165 5825 12.46 22 TIS(EIRP) WIFI_A (54M) 36 5180 -73.44 23 TIS(EIRP) WIFI_A (54M) 149 5745 -73.74 24 TIS(EIRP) WIFI_A (54M) 165 5825 -74.37 Material RoHS conformity declaration form This is to certify that the delivery to your company's components, raw materials, auxiliary materials used and the additives in the production engine ord with RoHS environmental requirements of the restrictions on the use of hazardous substances directive (RoHS directive 2011/65 / EC) About components used raw materials, packaging materials, auxiliary materials and additives used in the production process such as composition of the report is as follows： Component /Part Name Material Composition ICP report # Test Org. Test Date Content of harmful substances (ppm) PASS? Cd Pb Hg Cr 6+ PBB PBDE PASS FPC Ink ETR24902229M01 SGS 24/09/23 ND ND ND ND ND ND PASS Copper SHAEC24027480901 SGS 24/12/06 ND ND ND ND ND ND PASS FPC SHAEC24028809006 SGS 24/12/20 ND ND ND ND ND ND PASS Wire Series Coaxial Cables NGBPC24007471212 SGS 24/12/23 ND ND ND ND ND ND PASS Terminal Copper CANEC24029407216 SGS 25/01/08 ND 4 ND ND ND ND PASS Au plating A2240410234101001E CTI 24/07/16 ND ND ND ND ND ND PASS Rubber core ETR24705772 CTI 24/08/05 ND ND ND ND ND ND PASS Environm entally friendly Tin wire Environmen tally friend…

Text truncated - open the document above for the full version.

Sample Confirmation Letter Supplier Name：SHENZHEN YINGJIACHUANG TECHNOLOGY ELECTRONIC CO. LTD Material Name: WiFi1 2.4G/5.8G Black FPC built-in Antenna（K970AO） Material No.： 23040351&YJC-6N350-B09 Material Description： / Version: _______A0______ Drawing Version：_______A0______ Supplier Approved This needs to be stamped, and each acknowledgment letter needs to be stamped with a riding seal. Shenzhen Holatek Approved R&D/Engineering Quality Approved Product Center R&D Supply-Chain Center Quality Management Department Yin FeiJie Yang YunGang Xiao Han Address：Building C, Hongyu Guangming Valley, No. 11, Shiwei Community, Matian Office, Guangming District, Shenzhen Phone：+86-755-27810060/23192199 Fax：+86-0755-27810057 第 2 页 共 15 页 Directory Page Content 1 Cover 2 Directory 3 Product drawings 4 Specification 5 Process Flow Diagram 6 BOM list 7 Performance testing reports 8 SGS Environmental Protection Report for Raw Materials 第 3 页 共 15 页 Product drawings： 第 4 页 共 15 页 Specification： Electrical Specifications Frequency Range 2400-2500/5150-5850MHz VSWR ＜1.92 Input Impedance 50 Ω Direction All Gain(2.4G) 1.9 dBi Gain(5.1G) 3.4 dBi Gain(5.8G) 3.4 dBi Mechanical Specifications Cable Color Black Input connector XD Cable length 350mm (Total Length) Working Temperature -20°C~+70°C Working Humidity 20%~80% Environmental performance test: Project Test condition Standard Storage Conditions In the absence of specified test temperature, humidity, air pressure is as follows: 1.Temperature is - 20 °C ~ + 70 °C 2.Relative humidity of 45% to 85% 3.Air pressure is 86 kpa to 106 kpa Electrical and mechanical properties is normal High and low temperature test Between 70 °C and -20 °C for 5 loops, then 1- 2 h under normal conditions, check the appearance quality. Size should meet the requirements and should satisfy the content with the electrical and mechanical properties Constant damp and hot resistance test 95 + / - 3% relative humidity, temperature test: 40 °C. Lasts 2 h after, try to take out the determination of electrical properties, within 5 min after try 1-2 h under article normal thing, check the appearance quality Size should meet the requirements and should satisfy the content with the electrical and mechanical properties vibration test Vibration frequency range: 10-55 Hz, vibration frequency range of displacement amplitude: 0.35 MM, acceleration amplitude: 50.0 M/S, sweep cycles: 30 times Electrical and mechanical properties is normal Fall down test 1 m high altitude in accordance with the perpendicular axis free drop 3 times Electrical and mechanical properties is normal 第 5 页 共 15 页 第 6 页 共 15 页 Process Flow Diagram Cut Cable/ Terminating Weld Test Quality inspection Packaging 第 7 页 共 15 页 BOM list FPC、Cable、Terminal、Heat shrinkable sleeve、Shockproof cotton、PE packaging bag、Carton 第 8 页 共 15 页 Performance testing reports： Antenna physical image： Antenna performance test chart： Frequency （MHZ） 2400 2450 2500 5150 5725 5850 VSWR（dB） 1.75 1.49 1.49 1.43 1.43 1.36 第 9 页 共 15 页 WIFI 1 and WIFI 2 isolation test diagram WIFI 1 and BT isolation test diagram Frequency （MHz） 2400 2450 2500 5150 5725 5850 WIFI1 and BT isolation (dB) -40 -36 -36 -44 -37 -39 WIFI1 and WIFI2 isolation (dB) -24 -25 -28 -42 -34 -32 第 10 页 共 15 页 2D、3D test data (WIFI 1)： Frequency Efficiency (%) Gain.(dBi) 2400MHz 47.12 1.73 2410MHz 46.18 1.81 2420MHz 47.04 1.78 2430MHz 48.77 1.65 2440MHz 50.55 1.70 2450MHz 49.28 1.77 2460MHz 47.34 1.90 2470MHz 46.75 1.63 2480MHz 45.81 1.68 2490MHz 46.39 1.87 2500MHz 47.33 1.77 5150MHz 35.81 3.36 5250MHz 34.76 3.40 5350MHz 35.03 3.37 5450MHz 36.3 3.40 5550MHz 37.84 3.29 5650MHz 35.05 3.30 5750MHz 36.03 3.40 5850MHz 37.72 3.20 Phi 0 2D : Phi 90 2D Theta 90 2D 第 11 页 共 15 页 3D 2400： 3D 2450： 3D 2500： 第 10 页 共 15 页 3D 5150： 3D 5500： 3D 5850： 第 11 页 共 15 页 OTA active test data： Item Measurement Band Channel Frequency Total 1 TRP WIFI_B (11M) 1 2412 15.81 2 TRP WIFI_B (11M) 6 2437 14.25 3 TRP WIFI_B (11M) 11 2462 15.12 4 TIS(EIRP) WIFI_B (11M) 1 2412 -83.4 5 TIS(EIRP) WIFI_B (11M) 6 2437 -82.13 6 TIS(EIRP) WIFI_B (11M) 11 2462 -83.74 7 TRP WIFI_G (54M) 1 2412 13.39 8 TRP WIFI_G (54M) 6 2437 13.79 9 TRP WIFI_G (54M) 11 2462 14.51 10 TIS(EIRP) WIFI_G (54M) 1 2412 -69.4 11 TIS(EIRP) WIFI_G (54M) 6 2437 -70.13 12 TIS(EIRP) WIFI_G (54M) 11 2462 -70.74 13 TRP WIFI_N_ISM (65M) 1 2412 13.43 14 TRP WIFI_N_ISM (65M) 6 2437 13.5 15 TRP WIFI_N_ISM (65M) 11 2462 13.52 16 TIS(EIRP) WIFI_N_ISM (65M) 1 2412 -68 17 TIS(EIRP) WIFI_N_ISM (65M) 6 2437 -69.66 18 TIS(EIRP) WIFI_N_ISM (65M) 11 2462 -68.56 19 TRP WIFI_A (54M) 36 5180 11.6 20 TRP WIFI_A (54M) 149 5745 12.19 21 TRP WIFI_A (54M) 165 5825 12.46 22 TIS(EIRP) WIFI_A (54M) 36 5180 -73.44 23 TIS(EIRP) WIFI_A (54M) 149 5745 -73.74 24 TIS(EIRP) WIFI_A (54M) 165 5825 -74.37 Material RoHS conformity declaration form This is to certify that the delivery to your company's components, raw materials, auxiliary materials used and the additives in the production engine ord with RoHS environmental requirements of the restrictions on the use of hazardous substances directive (RoHS directive 2011/65 / EC) About components used raw materials, packaging materials, auxiliary materials and additives used in the production process such as composition of the report is as follows： Component /Part Name Material Composition ICP report # Test Org. Test Date Content of harmful substances (ppm) PASS? Cd Pb Hg Cr 6+ PBB PBDE PASS FPC Ink ETR24902229M01 SGS 24/09/23 ND ND ND ND ND ND PASS Copper SHAEC24027480901 SGS 24/12/06 ND ND ND ND ND ND PASS FPC SHAEC24028809006 SGS 24/12/20 ND ND ND ND ND ND PASS Wire Series Coaxial Cables NGBPC24007471212 SGS 24/12/23 ND ND ND ND ND ND PASS Terminal Copper CANEC24029407216 SGS 25/01/08 ND 4 ND ND ND ND PASS Au plating A2240410234101001E CTI 24/07/16 ND ND ND ND ND ND PASS Rubber core ETR24705772 CTI 24/08/05 ND ND ND ND ND ND PASS Environm entally friendly Tin wire Environmen tally friendly Tin wire SZXPC25000282511 SGS 25/02/27 ND 71 ND ND ND ND PASS …

Text truncated - open the document above for the full version.

ReportNo.:GRCTR250804024-03Page 51 of 65 802.11nHT20 CH01CH06 30MHz-1GHz30MHz-1GHz 1GHz-25GHz1GHz-25GHz ReportNo.:GRCTR250804024-03Page 52 of 65 802.11nHT20802.11nHT40 CH11CH03 30MHz-1GHz30MHz-1GHz 1GHz-25GHz1GHz-25GHz ReportNo.:GRCTR250804024-03Page 53 of 65 802.11nHT40 CH06CH09 30MHz-1GHz30MHz-1GHz 1GHz-25GHz1GHz-25GHz ReportNo.:GRCTR250804024-03Page 54 of 65 802.11axHE20 CH01CH06 30MHz-1GHz30MHz-1GHz 1GHz-25GHz1GHz-25GHz ReportNo.:GRCTR250804024-03Page 55 of 65 802.11axHE20802.11axHE40 CH11CH03 30MHz-1GHz30MHz-1GHz 1GHz-25GHz1GHz-25GHz ReportNo.:GRCTR250804024-03Page 56 of 65 802.11axHE40 CH06CH09 30MHz-1GHz30MHz-1GHz 1GHz-25GHz1GHz-25GHz ReportNo.:GRCTR250804024-03Page 57 of 65 Band-edgeMeasurementsforRFConductedEmissions: Ant1 802.11b LeftbandedgeRightbandedge 802.11g LeftbandedgeRightbandedge ReportNo.:GRCTR250804024-03Page 58 of 65 802.11nHT20 LeftbandedgeRightbandedge 802.11nHT40 LeftbandedgeRightbandedge ReportNo.:GRCTR250804024-03Page 59 of 65 802.11axHE20 LeftbandedgeRightbandedge 802.11axHE40 LeftbandedgeRightbandedge ReportNo.:GRCTR250804024-03Page 60 of 65 Ant2 802.11b LeftbandedgeRightbandedge 802.11g LeftbandedgeRightbandedge ReportNo.:GRCTR250804024-03Page 61 of 65 802.11nHT20 LeftbandedgeRightbandedge 802.11nHT40 LeftbandedgeRightbandedge ReportNo.:GRCTR250804024-03Page 62 of 65 802.11axHE20 LeftbandedgeRightbandedge 802.11axHE40 LeftbandedgeRightbandedge ReportNo.:GRCTR250804024-03Page 63 of 65 4.7AntennaRequirement StandardApplicable Forintentionaldevice,accordingtoFCC47CFRSection15.203: Anintentionalradiatorshallbedesignedtoensurethatnoantennaotherthanthatfurnishedbythe responsiblepartyshallbeusedwiththedevice.Theuseofapermanentlyattachedantennaorofanantenna thatusesauniquecouplingtotheintentionalradiator,themanufacturermaydesigntheunitsothatabroken antennacanbereplacedbytheuser,buttheuseofastandardantennajackorelectricalconnectoris prohibited. FCCCFRTitle47Part15SubpartCSection15.247(c)(1)(I): (i)Systemsoperatinginthe2400-2483.5MHzbandthatisusedexclusivelyforfixed.Point-to-pointoperations mayemploytransmittingantennaswithdirectionalgaingreaterthan6dBiprovidedthemaximumconducted outputpoweroftheintentionalradiatorisreducedby1dBforevery3dBthatthedirectionalgainofthe antennaexceeds6dBi. TestResult: Themaximumgainofantennawas1.90dBifor2.4GHzWIFIAnt1,themaximumgainofantennawas1.80 dBifor2.4GHzWIFIAnt2. Remark:Theantennagainisprovidedbythecustomer,ifthedataprovidedbythecustomerisnotaccurate, ShenzhenGUORENCertificationTechnologyServiceCo.,Ltd.doesnotassumeanyresponsibility. ReportNo.:GRCTR250804024-03Page 64 of 65 5TestSetupPhotosoftheEUT ReportNo.:GRCTR250804024-03Page 65 of 65 6PhotosoftheEUT ReferencetothetestreportNo.GRCTR250804024-01. **********************EndofReport**********************

ReportNo.:GRCTR250804024-03Page 43 of 65 802.11nHT20802.11nHT40 CH11CH03 30MHz-1GHz30MHz-1GHz 1GHz-25GHz1GHz-25GHz ReportNo.:GRCTR250804024-03Page 44 of 65 802.11nHT40 CH06CH09 30MHz-1GHz30MHz-1GHz 1GHz-25GHz1GHz-25GHz ReportNo.:GRCTR250804024-03Page 45 of 65 802.11axHE20 CH01CH06 30MHz-1GHz30MHz-1GHz 1GHz-25GHz1GHz-25GHz ReportNo.:GRCTR250804024-03Page 46 of 65 802.11axHE20802.11axHE40 CH11CH03 30MHz-1GHz30MHz-1GHz 1GHz-25GHz1GHz-25GHz ReportNo.:GRCTR250804024-03Page 47 of 65 802.11axHE40 CH06CH09 30MHz-1GHz30MHz-1GHz 1GHz-25GHz1GHz-25GHz ReportNo.:GRCTR250804024-03Page 48 of 65 Ant2 802.11b CH01CH06 30MHz-1GHz30MHz-1GHz 1GHz-25GHz1GHz-25GHz ReportNo.:GRCTR250804024-03Page 49 of 65 802.11b802.11g CH11CH01 30MHz-1GHz30MHz-1GHz 1GHz-25GHz1GHz-25GHz ReportNo.:GRCTR250804024-03Page 50 of 65 802.11g CH06CH11 30MHz-1GHz30MHz-1GHz 1GHz-25GHz1GHz-25GHz

ReportNo.:GRCTR250804024-03Page 29 of 65 802.11axHE20802.11axHE40 CH01CH03 CH06CH06 CH11CH09 ReportNo.:GRCTR250804024-03Page 30 of 65 4.56dBBandwidth Limit Fordigitalmodulationsystems,theminimum6dBbandwidthshallbeatleast500kHz TestProcedure Thetransmitteroutputwasconnectedtothespectrumanalyzerthroughanattenuator.Thebandwidthofthe fundamentalfrequencywasmeasuredbyspectrumanalyzerwithRBW:1%-5%oftheEBWandVBW: 3*RBW.The6dBbandwidthisdefinedasthetotalspectrumthepowerofwhichishigherthanpeakpower minus6dB. TestConfiguration EUTSPECTRUM ANALYZER TestResults Ant1 TypeChannel 6dBBandwidth (MHz) Limit(KHz)Result 802.11b 018.240 ≥500Pass 068.240 118.200 802.11g 0115.560 ≥500Pass 0616.120 1116.400 802.11nHT20 0117.000 ≥500Pass 0617.240 1117.360 802.11nHT40 03 35.680 ≥500Pass 06 35.200 09 35.680 802.11axHE20 0118.760 ≥500Pass 0618.680 1118.800 802.11axHE40 03 37.200 ≥500Pass 06 36.240 09 37.360 ReportNo.:GRCTR250804024-03Page 31 of 65 Ant2 TypeChannel 6dBBandwidth (MHz) Limit(KHz)Result 802.11b 018.240 ≥500Pass 068.200 118.200 802.11g 0115.800 ≥500Pass 0616.120 1116.160 802.11nHT20 0116.680 ≥500Pass 0617.480 1117.400 802.11nHT40 0335.200 ≥500Pass0635.360 0935.520 802.11axHE20 0118.280 ≥500Pass 0618.480 1118.640 802.11axHE40 0337.360 ≥500Pass0637.440 0937.280 Note: 1)Measuredpeakpowerspectrumdensityatdifferencedatarateforeachmodeandrecordedworstcase foreachmode. 2)Testresultsincludingcableloss; 3)Worstcasedataat1MbpsatIEEE802.11b;6MbpsatIEEE802.11g;6.5MbpsatIEEE802.11nHT20; 13.5MbpsatIEEE802.11nHT40;8.6MbpsatIEEE802.11axHE20;17.2MbpsatIEEE802.11axHE40. Pleaserefertofollowingplots; ReportNo.:GRCTR250804024-03Page 32 of 65 Ant1 802.11b802.11g CH01CH01 CH06CH06 CH11CH11 ReportNo.:GRCTR250804024-03Page 33 of 65 802.11nHT20802.11nHT40 CH01CH03 CH06CH06 CH11CH09 ReportNo.:GRCTR250804024-03Page 34 of 65 802.11axHE20802.11axHE40 CH01CH03 CH06CH06 CH11CH09 ReportNo.:GRCTR250804024-03Page 35 of 65 Ant2 802.11b802.11g CH01CH01 CH06CH06 CH11CH11 ReportNo.:GRCTR250804024-03Page 36 of 65 802.11nHT20802.11nHT40 CH01CH03 CH06CH06 CH11CH09 ReportNo.:GRCTR250804024-03Page 37 of 65 802.11axHE20802.11axHE40 CH01CH03 CH06CH06 CH11CH09 ReportNo.:GRCTR250804024-03Page 38 of 65 4.6Out-of-bandEmissions Limit Inany100kHzbandwidthoutsidethefrequencybandinwhichthespreadspectrumordigitallymodulated intentionalradiatorisoperating,theradiofre…

Text truncated - open the document above for the full version.
