Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
T-Max AP-900 Installation Instructions Rev 11/04 001-1000-0028 Thank you for purchasing a T-Max AP-900 wireless communication system! This system operates in the 902 MHz to 928 MHz Industrial, Scientific, and Medical (ISM) band as regulated by the Federal Communications Commission (FCC). The following is included in you T-Max AP-900 installation kit: 1 – T-Max AP-900 Module 1 – RJ-11 Communication Cable 1 – Installation instructions. You will also need the following to install your T-Max AP-900 unit: 1. Assembly instructions for the tanning unit (tanning bed, booth, or front desk controller). 2. Mounting hardware as directed in the tanning unit assembly instructions. To install: 1. Connect the RJ-11 communication cable to the T-Max AP-900 module on the end opposite the antenna. 2. Connect the opposite end of the RJ-11 communication cable to the tanning unit as prescribed by the tanning unit manufacture’s assembly instructions. 3. Mount the T-Max AP-900 module with the antenna positioned in an upright orientation. Please note, the T-Max AP-900 module may need to be repositioned to obtain the best signal strength. Changing operating frequency: In rare circumstances the operating frequency may need to be adjusted in your T-Max AP-900 module due to other RF devices interfering with the T-Max communication system. This is easily accomplished, but ALL T-Max AP-900 modules within the salon MUST be adjusted for correct operation. For this reason, Applied Digital Technical Support must be contacted for instructions regarding this adjustment. If you have poor communications, or tanning units are producing E7 errors on the front desk controller, contact Applied Digital Technical Support for further assistance. FCC Compliance Information: This device contains no user serviceable parts and may only be repaired by authorized personnel. Changes or modifications not expressly approved by Applied Digital, Inc. could void the user’s authority to operate the equipment.
November 18, 2004 Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Telephone 888.472.2424 Fax 352.472.2030 Applicant: Applied Digital, Inc. 2131 N. State Highway 265 BRANSON, MO 65616-9842 FRN 0011 7067 51 Re: Confidentiality of schematics Equipment: Low Power transmitter FCC ID: SOF AP-900 Gentlemen: It is requested that the information contained in the block diagrams, operational description, parts list, and schematics of the application be held confidential per Section 0.459. Please use this information in obtaining a grant of certification for the transceiver model number AP-900. In support of this request, we submit the following: 1. Identification of the specific information for which confidential treatment is sought: The materials set fourth in the Operational Description, Block Diagram, Parts List, Internal PCB layout exhibit, and Schematics, are those for which confidentiality is sought. 2. Identification of the Commission proceeding in which the information was submitted or a description of the circumstances giving rise to the submission: The proceeding is that involving the application for equipment authorization (certification) under FCC ID No: SOF AP-900 3. Explanation of the degree to which the information is commercial or financial, or contains a trade secret or is privileged: This material includes a detailed theory of operation and circuit diagrams, (schematics, part list, PCB layout diagrams, and Block diagrams). As such this material is treated as highly confidential business information and is not subject to public view. Should you require any further information, please contact the undersigned. Thank you for your consideration in this matter. Sincerely, Scot Rogers Rogers Labs, Inc. ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 Phone / Fax (913) 837-3214
ROGERS LABS, INC. Applied Digital, Inc. 4405 W. 259th Terrace MODEL: AP-900 Louisburg, KS 66053 Test #: 041025B FCC ID#: SOF AP-900 Phone/Fax: (913) 837-3214 Test to: FCC Parts 2 and 15.249 Page 1 of 1 SOF AP900 ExtPho.doc 11/18/2004 External photographs for SOF AP-900.
ROGERS LABS, INC. Applied Digital, Inc. 4405 W. 259th Terrace MODEL: AP-900 Louisburg, KS 66053 Test #: 041025B FCC ID#: SOF AP-900 Phone/Fax: (913) 837-3214 Test to: FCC Parts 2 and 15.249 Page 1 of 1 SOF AP900 ID Label.doc 11/18/2004 Label Location and information for SOF AP-900. FCC ID: SOF AP-900 “This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.”
ROGERS LABS, INC. Applied Digital, Inc. 4405 W. 259th Terrace MODEL: AP-900 Louisburg, KS 66053 Test #: 041025B FCC ID#: SOF AP-900 Phone/Fax: (913) 837-3214 Test to: FCC Parts 2 and 15.249 Page 1 of 2 SOF AP900 IntPhoto.doc 11/18/2004 Internal photographs for SOF AP-900. Transmitter printed Circuit Board ROGERS LABS, INC. Applied Digital, Inc. 4405 W. 259th Terrace MODEL: AP-900 Louisburg, KS 66053 Test #: 041025B FCC ID#: SOF AP-900 Phone/Fax: (913) 837-3214 Test to: FCC Parts 2 and 15.249 Page 2 of 2 SOF AP900 IntPhoto.doc 11/18/2004 Power supply photographs
ENGINEERING TEST REPORT FOR APLLICATION of GRANT of CERTIFICATION FOR CFR 47, PART 15C - INTENTIONAL RADIATORS Paragraph 15.249 Low Power License Exempt Intentional Radiator For APPLIED DIGITAL, INC. 2131 N. State Highway 265 Branson, MO 65616-9842 David Boone, DATA TRANSMITTER Model: AP-900 Frequency Range 902-928 MHz FCC ID#: SOF AP-900 Test Date: October 25, 2004 Certifying Engineer: Scot D. Rogers ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 Phone: (913) 837-3214 FAX: (913) 837-3214 This report shall not be reproduced except in full, without the written approval of the laboratory. This report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S. Government. ROGERS LABS, INC. 4405 West 259 th Terrace Louisburg, KS 66053 Phone / Fax (913) 837-3214 NVLAP Accredited Laboratory NVLAP Lab Code: 200087-0 ROGERS LABS, INC. Applied Digital, Inc. 4405 W. 259th Terrace MODEL: AP-900 Louisburg, KS 66053 Test #: 041025B FCC ID#: SOF AP-900 Phone/Fax: (913) 837-3214 Test to: FCC Parts 2 and 15c (15.249) Page 2 of 24 Applied Digital SOFAP900 TstRpt.doc 11/18/2004 TABLE OF CONTENTS FORWARD:.....................................................................................................................3 1) APPLICABLE STANDARDS & TEST PROCEDURES...........................................3 2.1033(b) Application for Certification....................................................................................................4 2) EQUIPMENT TESTED.............................................................................................5 3) EQUIPMENT FUNCTION AND TESTING PROCEDURES.....................................5 4) EQUIPMENT AND CABLE CONFIGURATIONS.....................................................5 Conducted Emission Test Procedure............................................................................................................5 Radiated Emission Test Procedure:.............................................................................................................6 5) LIST OF TEST EQUIPMENT...................................................................................6 6) UNITS OF MEASUREMENTS.................................................................................7 7) TEST SITE LOCATIONS.........................................................................................7 8) SUBPART B – UNINTENTIONAL RADIATORS.....................................................8 Conducted EMI.............................................................................................................................................8 Radiated EMI..............................................................................................................................................10 Data: Conducted Emissions (7 Highest Emissions).....................................................................................13 Data: General Radiated Emissions from EUT (6 Highest Emissions).........................................................13 Summary of Results for Conducted Emissions...........................................................................................14 Summary of Results for Radiated Emissions..............................................................................................14 Statement of Modifications and Deviations................................................................................................14 9) SUBPART C - INTENTIONAL RADIATORS.........................................................15 15.203 Antenna Requirements....................................................................................................................15 15.205 Restricted Bands of Operation........................................................................................................15 Data: Emissions in Restricted Bands..........................................................................................................16 Summary of Results for Radiated Emissions in Restricted Bands:...........................................................16 15.209 Radiated Emissions Limits; General Requirements.......................................................................17 Radiated EMI.............................................................................................................................................17 Data: General Radiated Emissions from EUT (Highest Emissions)............................................................18 Summary of Results for Radiated Emissions:............................................................................................18 15.249 Operation in the Band 902-928 MHz..............................................................................................18 Data: Radiated Emissions from Intentional Radiator...................................................................................20 Summary of Results for Radiated Emissions of Intentional Radiator.......................................................20 Statement of Modifications and Deviations................................................................................................20 NVLAP Accredited Laboratory NVLAP Lab Code: 200087-0 ROGERS LABS, INC. Applied Digital, Inc. 4405 W. 259th Terrace MODEL: AP-900 Louisburg, KS 66053 Test #: 041025B FCC ID#: SOF AP-900 Phone/Fax: (913) 837-3214 Test to: FCC Parts 2 and 15c (15.249) Page 3 of 24 Applied Digital SOFAP900 TstRpt.doc 11/18/2004 FORWARD: The following is submitted for consideration in obtaining a Grant of Certification for a Low Power License Exempt Intentional Radiator operating under CFR Paragraph 15.249. Name of Applicant: APPLIED DIGITAL, INC. 2131 N. State Highway 265 Branson, MO 65616-9842 Model: AP-900 transceiver. FCC I.D.: SOF AP-900. Frequency Range: 902-928 MHz. Operating Power: 94 dBmV/m at 3 meters distance. 1) Applicable Standards & Test Procedures a) In accordance with the Feder…
Text truncated - open the document above for the full version.
ROGERS LABS, INC. Applied Digital, Inc. 4405 W. 259th Terrace MODEL: AP-900 Louisburg, KS 66053 Test #: 041025B FCC ID#: SOF AP-900 Phone/Fax: (913) 837-3214 Test to: FCC Parts 2 and 15.249 Page 1 of 1 SOF AP900 Test setup Photos.doc 11/18/2004 Test Setup photographs for SOF AP-900. ROGERS LABS, INC. Applied Digital, Inc. 4405 W. 259th Terrace MODEL: AP-900 Louisburg, KS 66053 Test #: 041025B FCC ID#: SOF AP-900 Phone/Fax: (913) 837-3214 Test to: FCC Parts 2 and 15.249 Page 2 of 1 SOF AP900 Test setup Photos.doc 11/18/2004
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 903 MHz - 927 MHz | - |
User RF Link
Equipment Class
DXX - Part 15 Low Power Communication Device Transmitter
