SPKCOPWRLAA802.11 a/g Mini-PCI Module

Wireless Module User Manual Version 1.1 February 2006 Ambient Corporation 79 Chapel Street Newton, MA 02458 USA Tel.: +1-617-332-0004 Fax: +1-617-332-7260 WWW: http://www.ambientcorp.com Email: [email protected] Ambient and the Ambient logo are trademarks of Ambient Corporation. © Copyright 2003-2005 Ambient Corporation. All rights reserved. Wireless Module User ManualImportant Information Doc. No. 06-0021-001 Rev. 1.1Page iii Ambient Corporation Proprietary & Confidential IMPORTANT INFORMATION DISCLAIMER OF WARRANTIES AMBIENT DISCLAIMS ALL WARRANTIES OF ANY KIND WITH RESPECT TO THE AMBIENT PRODUCT(S), EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO, ALL WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OF THIRD PARTY RIGHTS. IN NO EVENT SHALL AMBIENT, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES OR FOR THE LOSS OF PROFIT, REVENUE OR BUSINESS, PROPERTY DAMAGE, PERSONAL INJURY, LIABILITY, LOSS OF LIFE, LOSS OF USE OF DATA OR INTERRUPTION OF BUSINESS EVEN IF AMBIENT SHALL HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH LOSS OR DAMAGE. AMBIENT DOES NOT WARRANT THE FUNCTIONING OF THE AMBIENT PRODUCT(S) IN CONJUNCTION WITH SOFTWARE OR HARDWARE NOT PURCHASED, LICENSED, SUBLICENSED OR OTHERWISE APPROVED FOR USE WITH THE AMBIENT PRODUCT(S) BY AMBIENT, OR THAT THE OPERATION OF THE AMBIENT PRODUCT(S) WILL BE UNINTERRUPTED OR ERROR FREE. THE LIABILITY OF AMBIENT HEREUNDER SHALL IN NO EVENT EXCEED THE MAXIMUM AMOUNT PAID TO AMBIENT BY CUSTOMER FOR THE AMBIENT PRODUCT(S). COPYRIGHT NOTICE THIS DOCUMENT IS SUBJECT TO U.S. COPYRIGHT LAWS. YOU MAY NOT COPY, REPRODUCE OR TRANSMIT ANY PART OF THIS DOCUMENT WITHOUT THE EXPRESS WRITTEN PERMISSION OF AMBIENT. COPYING INCLUDES TRANSLATION INTO ANOTHER LANGUAGE OR FORMAT. Important InformationWireless Module User Manual Page ivDoc. No. 06-0021-001 Rev. 1.1 Ambient Corporation Proprietary & Confidential THIS PAGE INTENTIONALLY LEFT BLANK Wireless Module User ManualTable of Contents Doc. No. 06-0021-001 Rev. 1.1Page v Ambient Corporation Proprietary & Confidential Table of Contents 1.Regulatory Notice...............................................................................................................1 1.1Federal Communication Commission Interference Statement .................................1 1.2End Product Labeling ...............................................................................................2 1.3Manual Information That Must be Included ..............................................................2 2.Specifications .....................................................................................................................3 2.1General.....................................................................................................................3 2.2RF Information..........................................................................................................3 2.3Environmental...........................................................................................................4 2.4Physical Specifications .............................................................................................4 3.Installation ..........................................................................................................................5 3.1Module Installation....................................................................................................5 3.2Antenna Installation ..................................................................................................5 4.Software Configuration......................................................................................................7 5.Technical Support ..............................................................................................................9 Table of ContentsWireless Module User Manual Page viDoc. No. 06-0021-001 Rev. 1.1 Ambient Corporation Proprietary & Confidential 1. THIS PAGE INTENTIONALLY LEFT BLANK Wireless Module User ManualSection 1 - Regulatory Notices Doc. No. 06-0021-001 Rev. 1.1Page 1 Ambient Corporation Proprietary & Confidential 1. Regulatory Notice 1.1 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)this device may not cause harmful interference, and (2)this device must accept any interference received, including interference that may cause undesired operation. Caution:Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm betw…

Text truncated - open the document above for the full version.

Rubicon Communications, LP dba Netgate 111 Hekili Street, Suite A PMB 168, Kailua, HI 96734 (509) 280 8999 | (509) 267 2369 fax www.netgate.com ANTENNA SPECIFICATION ANT-8-OMNI-NF ANT-8-OMNI-RPNF (Special Order) Dipole Antennas for Base Stations with 8dBi Gain SUMMARY: This Omni antenna is designed to increase signal range and strength in a sphere shape. The package includes a high quality mounting kit which includes brackets, nuts, bolts and washers. It can be used to cover 360 degree pops. • Designed for wireless LAN communications • Mounts easily for indoor or outside applications • Suited for IEEE 802.11b/g wireless LANs • Made with high quality fiberglass material Technical information TECHNICAL INFORMATION: • Frequency: 2400-2500 MHz • Gain: 8 dBi • Polarization: Vertical • Vertical beamwidth: 15 degrees • SWR ≦1.5： 1 • Impedance: 50 Ohm • Length: 390 mm • Weight: 370 g • Standard Connector: N Female • Special Order Connector: RP-N Female Rubicon Communications, LP dba Netgate 111 Hekili Street, Suite A PMB 168, Kailua, HI 96734 (509) 280 8999 | (509) 267 2369 fax www.netgate.com Rubicon Communications, LP dba Netgate 111 Hekili Street, Suite A PMB 168, Kailua, HI 96734 (509) 280 8999 | (509) 267 2369 fax www.netgate.com H PLANE FIELD PATTERN Rubicon Communications, LP dba Netgate 111 Hekili Street, Suite A PMB 168, Kailua, HI 96734 (509) 280 8999 | (509) 267 2369 fax www.netgate.com E PLANE FIELD PATTERN Rubicon Communications, LP dba Netgate 111 Hekili Street, Suite A PMB 168, Kailua, HI 96734 (509) 280 8999 | (509) 267 2369 fax www.netgate.com NetGate Omni 8 dBi Antenna ANT-8-OMNI-NF

Curtis-Straus LLC 527 Great Road Littleton, Massachusetts 01460 Tel: 978.486.8880 Fax: 978.486.8828 Web: www.curtis-straus.com Worldwide Regulatory Approvals Experts ® February 8, 2006 RE: Ambient Modular Radio Application The purpose of this application is to obtain a full modular approval of the Senao NL-5354MP Plus Aries2 802.11a/b/g MINI PCI Wireless Module, (which was previously approved as a modular transmitter under FCC ID: NI3-AT53V216 by Senao International) with the addition of two external antennas: 1) Nearson portable rubber duck, Model: S181TR-2450R, and 2) Netgate omnidirectional, Model ANT-8-OMNI-NF. This approval is being sought by Ambient Corporation with a proposed FCC ID: SPKCOPWRLAA. The device is being installed by Ambient into their Wireless X-Node device which utilizes the above mentioned antennas. The original goal of the testing performed at the request of Ambient Corporation was to obtain certification of the entire assembly; with the Senao module installed in the X-Node enclosure. The aim of certification has now changed to obtaining a modular approval which would include the two additional antennas. Please note that the technical report was written based on obtaining a non-modular approval. However, it does conatain all of the tests data needed (in combination with the original Senao reports) to obtain a new modular approval with 2 additional antennas. The requirements for modular approval are addressed below. Since the modular transmitter has previously been granted approval by the manufacturer (FCC ID: NI3-AT53V216), and is physically unchanged but for the addition of external antennas, the following requirements are unaffected: 1) The modular transmitter must have its own RF shielding. 2) The modular transmitter must have buffered modulation/data inputs. 3) The modular transmitter must have its own power supply regulation The remaining requirements demand further comment: 4) The added antennas employ “unique” connectors to satisfy the requirements of 15.203 and 15.204(c). The module has a reverse TNC connector. The Nearson 2dBi whip comes with an optional reverse TNC connection to attach directly to the module port. The Netgate 8dBi antenna has a reverse N connector and attaches to the reverse TNC port through an extension cable. Since the module port and the antenna have non-standard connectors, only the cable and antennas specified by Ambient may be used. Curtis-Straus LLC 527 Great Road Littleton, Massachusetts 01460 Tel: 978.486.8880 Fax: 978.486.8828 Web: www.curtis-straus.com Worldwide Regulatory Approvals Experts ® 5) The module in its original application for modular approval was tested in a stand- alone configuration. In this application, the only further consideration is the effect of the addition of the antennas. The test configuration satisfies this consideration. 6) The module itself will be labeled with FCC ID: SPKCOPWRLAA. This will replace any label provided by the module manufacturer. 7) The Senao module is physically unchanged except for the addition of external antennas, and application for which it will be used is unchanged. Therefore the specific rules and operating requirements applicable to the transmitter are satisfied. See the statement in the Installation Manual regarding indoor operation in the 5.15- 5.25GHz range which is mandated by the Users Manual issued by Senao. 8) Attached is the original RF Exposure Report which shows that the module complied with the requirement with a 2dBi antenna. See the attached 8dBi RF Exposure Report which shows that the requirement is still met with the addition of the ANT-8- OMNI-NF. See also Amient’s Installation Manual which specifies the 20cm minimum seperation distance between the antenna and all persons. This warning was mandated by the original Senao module Users Manual.

Page 1 Page 2 Page 3

c A B C D 1 2 3 456 7 8 A B C D 12 3 4 5 6 7 8 01 DESIGN ENG: DOCUMENT NUMBER: 05-0036-001 CAD FILE: 05-0036-001 in said document. 2005 8.5 X11 in. SIZE: APPROVALS: DATE LABEL, WI-FI MODULE SHEET 1 OF 1 ANSI A SCALE: 2:1 1 .01 .XXXX .XX .XXX .005 .XXXX (mm) MILLIMETERS: (in) INCHES: PLACES: ANGULAR: 2-PLACES: QUALITY SYMBOLS: MM/DD/YY DO NOT SCALE DRAWING FINISH: MATERIAL: 3-PLACES: 4-PLACES: DECIMAL (UNLESS SPECIFIED) DOCUMENT UNITS: ENGLISH PROGRAM MGR: CHECKED BY: DRAWN BY: REVISION: TITLE: GENERAL TOLERANCES This document, furnished by Ambient Corp., is proprietary data and is delivered on the express condition that it is not to be disclosed, reproduced in whole or in part, or used for manufacture for anyone other than Ambient Corp. without its written consent, and that no right is granted to disclose or so use any information obtained .500 1.500 ECO HISTORY ECO/ECNREV.DESCRIPTIONCHANGED_BY_DATEAPPROVED_BY_DATE BRADY B-707 LASERTAB® MARKERS Technical Data Sheet TDS No. B-707 Effective Date: 01/27/2000 Description: B-707 is a white polyester film with a permanent acrylic pressure sensitive adhesive and a topcoat specifically formulated for laser printer toners. B-707 is recommended for telecommunications applications, computer housing units, rating plates and asset I.D. that require good solvent resistance and moderate to high temperature performance. B-707 is formulated specially for laser printers. The material offers high print resolution, good solvent resistance, smudge resistance, and moderate to high temperature performance. The adhesive is specifically formulated for rough and low surface energy surfaces. B-707 is a UL Recognized Component and CSA Accepted material when printed with designated laser printer toners. See UL File MH17154 and CSA Acceptance Record LS41833 for specific details. Details: Performance Properties tested on B-707. Samples laser printed with a Hewlett Packard LaserJet III. PHYSICAL PROPERTIES TEST METHODS AVERAGE RESULTS ThicknessASTM D 1000 -Substrate -Adhesive -Total 0.0026 inch (0.0660 mm) 0.0020 inch (0.0508 mm) 0.0046 inch (0.1168 mm) Adhesion to: -Stainless Steel -Textured ABS -Polypropylene -Painted Enamel -Powder Coated ASTM D 1000 20 minute dwell 24 hour dwell 20 minute dwell 24 hour dwell 20 minute dwell 24 hour dwell 20 minute dwell 24 hour dwell 20 minute dwell 24 hour dwell 53 oz/in (58 N/100 mm) 65 oz/in (71 N/100 mm) 16 oz/in (18 N/100 mm) 17 oz/in (19 N/100 mm) 29 oz/in (32 N/100 mm) 32 oz/in (35 N/100 mm) 58 oz/in (63 N/100 mm) 72 oz/in (79 N/100 mm) 42 oz/in (46 N/100 mm) 52 oz/in (57 N/100 mm) TackASTM D 2979 Polyken™ Probe Tack 1 second dwell 37 oz (1150 g) Drop ShearPSTC-7 (except use 1/2" x 1" sample) 42 hours Tensile Strength and Elongation ASTM D 1000 -Machine Direction -Cross Direction 39 lbs/in (683 N/100 mm), 77% 53 lbs/in (928 N/100 mm), 65% Dielectric StrengthASTM D 10007500 volts Page 1 of 3TDS - BRADY B-707 LASERTAB® MARKERS 1/23/2006http://www.bradyid.com/tds/tdsv1r0.nsf/1fcb2808abee6aff86256ced0071a750/54b9d9c49... Samples printed with a Hewlett Packard LaserJet III printer. Test was conducted at room temperature after 24 hour dwell. Testing consisted of 5 cycles of 10 minute immersions in the specified chemical reagent followed by 30 minute recovery periods. Ten cotton swab rubs wetted in the specified reagent after final immersion. Product testing, customer feedback, and history of similar products, support a customer performance expectation of at least two years from the date of receipt for this product as long as this product is stored in its original packaging in an environment below 80 degrees F and 60% RH . We are confident that our product will perform well beyond this time frame. However, it remains the responsibility of the user to assess the risk of using such product. We encourage customers to develop functional testing protocols that will qualify a product's fitness for use, in their actual applications. PERFORMANCE PROPERTIES TEST METHODS TYPICAL RESULTS High Service Temperature30 days at 267°F (130°C)No visible effect Low Service Temperature30 days at -40°F (-40°C)No visible effect Humidity Resistance30 days at 100°F (37°C), 95% R.H. No visible effect UV Light Resistance30 days in UV Sunlighter™ 100 No visible effect WeatherabilityASTM G 26 30 days in Xenon Arc Weatherometer No visible effect Salt Fog ResistanceASTM B 117 30 days in 5% salt fog solution chamber No visible effect PERFORMANCE PROPERTY CHEMICAL RESISTANCE CHEMICAL REAGENT SUBJECTIVE OBSERVATION OF VISUAL CHANGE APPEARANCE OF LABEL STOCK APPEARANCE OF LASER PRINTING Methyl Ethyl KetoneSlight adhesive oozePrinting removed 1,1,1-TrichloroethaneSlight adhesive oozePrinting removed TolueneSlight adhesive oozePrinting removed Freon® TMSSlight adhesive oozeNo visible effect Isopropyl AlcoholNo visible effectNo visible effect Mineral SpiritsNo visible effectNo visible effect JP-4 Jet FuelNo visible effectNo visible effect ASTM #3 OilNo visible effectNo visible effect Mil 5606 OilNo visible effectNo visible effect Skydrol® 500B-4No visible effectPrinting removed Super Agitene®No visible effectNo visible effect Deionized WaterNo visible effectNo visible effect 3% Alconox® DetergentNo visible effectNo visible effect 10% Sodium Hydroxide Solution No visible effectNo visible effect 10% Sulfuric Acid SolutionNo visible effectNo visible effect Trademarks: Alconox® is a registered trademark of Alconox Co. Freon® is a registered trademark of Du Pont de Nemours, E.I. and Company. LaserTab® is a registered trademark of Brady Worldwide, Inc. Polyken™ is a trademark of Testing Machines Inc. Skydrol® is a registered trademark of the Monsanto Company Sunlighter™ is a trademark of the Test Lab Apparatus Company Super Agitene® is a registered trademark of Graymills Corporation Page 2 of 3TDS - BRADY B-707 LASERTAB® MARKERS 1/23/2006http://www.bradyid.com/tds/tdsv1r0.nsf/1fcb2808abee6aff86256ced0071a750/54b9d9c49... ASTM: American Society for Testing and Materials (U.S.…

Text truncated - open the document above for the full version.

Page 1 Page 2 Page 3

FCC ID: SPKCOPWRLAA Antenna Gain = 8dBi = 6.31 (numeric) Distance = 20cm 802.11b Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm^2) Limit of Power Density (mW/cm^2) 1241252.4810.0658810621.0 6243757.5440.0722368061.0 11246254.9540.0689854971.0 802.11g (Normal mode) Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm^2) Limit of Power Density (mW/cm^2) 12412100.0000.1255331681.0 6243783.1760.1044134681.0 11246285.1100.1068412791.0 802.11g (Turbo mode) Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm^2) Limit of Power Density (mW/cm^2) 6243763.0690.0791725141.0 802.11a Frequency 5.15~5.35GHz (Normal mode) Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm^2) Limit of Power Density (mW/cm^2) 1518017.4580.021915581.0 4524017.5390.0220172621.0 5526017.3780.0218151541.0 8532015.2050.0190873181.0 802.11a Frequency 5.15~5.35GHz (Turbo mode) Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm^2) Limit of Power Density (mW/cm^2) 1521015.8490.0198957521.0 2525014.7570.018524931.0 3529014.4210.0181031381.0 FCC ID: SPKCOPWRLAA 802.11a Frequency 5.725~5.850GHz (Normal mode) Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm^2) Limit of Power Density (mW/cm^2) 9574510.0000.0125533171.0 11578510.7150.0134508791.0 13582510.2330.0128458091.0 802.11a Frequency 5.725~5.850GHz (Turbo mode) Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm^2) Limit of Power Density (mW/cm^2) 457607.9430.00997111.0 558006.9180.0086843851.0

Curtis-Straus is accredited by the American Association for Laboratory Accreditation for the specific scope of accreditation under Certificate Number 1627-01. This report may contain data and engineering opinions which are not covered by the A2LA accreditation. ____________________________________________________________ Curtis-Straus • 527 Great Road • Littleton, MA • TEL (978) 486-8880 • FAX (978) 486-8828 page 1 of 26 Test Report Report No EF0700-1 Client Ambient Corporation Aron Viner Address 79 Chapel Street Newton, MA 02458 Phone 617-332-0004 Items tested PLC Access Node Standards FCC 47 CFR Part 15 Class B emissions requirements (USA) Test Dates September 20-21, 2005 Results As detailed within this report Prepared by Evan Gould – Test Engineer Authorized by Michael Buchholz – EMC Manager Issue Date 12/2/05 Conditions of Issue This Test Report is issued subject to the conditions stated in the ‘Terms and Conditions’ section on page 22 of this report. Test Report for Ambient Corporation • Report No. EF0700-1 November 22, 2005 ______________________________________________________________________ ____________________________________________________________ Curtis-Straus • 527 Great Road • Littleton, MA • TEL (978) 486-8880 • FAX (978) 486-8828 page 2 of 26 Contents Contents .................................................................................................................................... 2 Summary ................................................................................................................................... 3 Product Tested - Configuration Documentation ........................................................................ 4 Compliance Statement .............................................................................................................. 5 Modifications Required for Compliance..................................................................................... 5 Test Results .............................................................................................................................. 6 Test Configuration Photographs................................................................................................ 8 Test Descriptions..................................................................................................................... 11 Radiated Emissions Testing Overview ................................................................................ 11 Line Conducted Emissions Overview .................................................................................. 14 Test Equipment Used .............................................................................................................. 17 Jurisdictional Labeling and Required Instruction Manual Inserts ............................................ 19 FCC Requirements .............................................................................................................. 19 Terms and Conditions ............................................................................................................. 22 A2LA Accreditation.................................................................................................................. 24 Form Final Report REV 16-SEP-05 (DW) Test Report for Ambient Corporation • Report No. EF0700-1 November 22, 2005 ______________________________________________________________________ Release Control Record Issue No. Reason for change Date Issued 1 Ori ginal Release November 22, 2005 _____________________________________________________________ Curtis-Straus • 527 Great Road • Littleton, MA • TEL (978) 486-8880 • FAX (978) 486-8828 page 3 of 26 Summary On September 20-21, 2005 we tested the PLC Access Node for compliance with the following requirements: EMC Emissions: • FCC 47 CFR Part 15 Class B emissions requirements (USA) Registration numbers for all open area test sites can be found in the Test Equipment Used Section starting on page 17. We found that the product met the above requirements with modification (see Modifications Required for Compliance section on page 5). Aron Viner from Ambient Corporation was present during the testing. The test sample was received in good condition. Test Report for Ambient Corporation • Report No. EF0700-1 November 22, 2005 ______________________________________________________________________ _____________________________________________________________ Curtis-Straus • 527 Great Road • Littleton, MA • TEL (978) 486-8880 • FAX (978) 486-8828 page 4 of 26 Product Tested - Configuration Documentation EUT Configuration Work Order: F0700 Company: Ambient Corporation Company Address: 79 Chapel Street Newton, MA 02458 Contact: Aron Viner Person Present: Aron Viner MNSN EUT: 90-000X-XXXXN0532-0131 EUT Description: PLC Access Node EUT Max Fre quency: 22.755MHz (aside from radio card) Support Equipment: MNSN PLC Access Node90-000X-XXXXN0534-0158 IBM ThinkpadT4155274-OEM-0011903-00107 EUT Cables: QtyShielded?LengthFerrites AC Power1Yes2mNo AC Power (alternate)1No10ft1/2 loop 0431164181 coax3Yes30ftNo Cat-51Yes6ftNo Antennas: P/NFreqGain Nearson 181TR-2450R2.4 & 5GHz ranges2dBi (2.4GHz) 0dBi (5GHz) Netgate (alternate) NT-8-OMNI-NF2.4-2.5GHz8dBi Unpopulated EUT Ports: QtyReason console1redundant Software / Operating Mode Description: EUT was operating in two differ modes to simulate indoor and outdoor configurations. Test Report for Ambient Corporation • Report No. EF0700-1 November 22, 2005 ______________________________________________________________________ _____________________________________________________________ Curtis-Straus • 527 Great Road • Littleton, MA • TEL (978) 486-8880 • FAX (978) 486-8828 page 5 of 26 Compliance Statement TEST RESULT STANDARD TEST LEVEL MARGIN COMMENTS Radiated Emissions PASS FCC CFR 47 Part 15 Class B -1.0dB @ 900.1MHz AC Mains Conducted Emissions PASS FCC CFR 47 Part 15 Class B -11.7dB @ 12.6MHz Modifications Required for Compliance Eit…

Text truncated - open the document above for the full version.

FCC ID: N13-AT53V216 Report No.: RF921215R02AIssued: April 16, 2004 Reference No.: RF921215R02 1 FCC TEST REPORT REPORT NO.: RF921215R02A MODEL NO.: NL-5354MP Plus Aries2 RECEIVED: November 12, 2003 TESTED: November 12, 2003 ~ April 16, 2004 APPLICANT: SENAO INTERNATIONAL CO., LTD. ADDRESS: 2F, No. 531 CHUNG CHENG RD., HSIN-TIEN, TAIPEI, TAIWAN, R. O. C. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 47 14 th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 206 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA FCC ID: N13-AT53V216 Report No.: RF921215R02AIssued: April 16, 2004 Reference No.: RF921215R02 2 Table of Contents 1CERTIFICATION ......................................................................................................7 2SUMMARY OF TEST RESULTS ..............................................................................8 3GENERAL INFORMATION.....................................................................................10 3.1GENERAL DESCRIPTION OF EUT.......................................................................10 3.2DESCRIPTION OF TEST MODES......................................................................... 11 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS ........................................12 3.4DESCRIPTION OF SUPPORT UNITS ...................................................................13 3.5CONFIGURATION OF SYSTEM UNDER TEST ....................................................13 4TEST TYPES AND RESULTS (FOR PART 802.11b & 802.11g) ............................14 4.1CONDUCTED EMISSION MEASUREMENT .........................................................14 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT.......................................14 4.1.2 TEST INSTRUMENTS............................................................................................14 4.1.3 TEST PROCEDURES ............................................................................................15 4.1.4 DEVIATION FROM TEST STANDARD ..................................................................15 4.1.5 TEST SETUP .........................................................................................................16 4.1.6 EUT OPERATING CONDITIONS ...........................................................................16 4.1.7 TEST RESULTS .....................................................................................................17 4.2RADIATED EMISSION MEASUREMENT ..............................................................23 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT............................................23 4.2.2 TEST INSTRUMENTS............................................................................................24 4.2.3 TEST PROCEDURES ............................................................................................25 4.2.4 DEVIATION FROM TEST STANDARD ..................................................................25 4.2.5 TEST SETUP .........................................................................................................26 4.2.6 EUT OPERATING CONDITIONS ...........................................................................26 4.2.7 TEST RESULTS .....................................................................................................27 4.36dB BANDWIDTH MEASUREMENT .....................................................................36 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT ...................................................36 4.3.2 TEST INSTRUMENTS............................................................................................36 4.3.3 TEST PROCEDURE...............................................................................................37 4.3.4 DEVIATION FROM TEST STANDARD ..................................................................37 4.3.5 TEST SETUP .........................................................................................................37 4.3.6 EUT OPERATING CONDITIONS ...........................................................................37 4.3.7 TEST RESULTS .....................................................................................................38 FCC ID: N13-AT53V216 Report No.: RF921215R02AIssued: April 16, 2004 Reference No.: RF921215R02 3 4.4MAXIMUM PEAK OUTPUT POWER .....................................................................47 4.4.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT......................47 4.4.2 INSTRUMENTS....................…
