SPX-ACSP100BBEBluetooth GPS Speaker

8 English Turning On or Off 6 Pairing the product with a compatible phone 7 > Pairing 3 will create a unique and encrypted wireless link between two Bluetooth enabled devices. To use the speaker with other Bluetooth devices, both devices must be paired. When trying pairing, keep the product and the phone close-by. Before using the product Explains the basic operation and set-ups of your Bluetooth GPS Speaker. > Connect the product to the power source then press and hold the for 3 seconds. - The melody informing power-on rings. > Press and hold the for 3 seconds in idle mode to turn off. - The melody informing power-off rings. - If the product is turned on for the first time, the indicator light changes to BLUE-RED-PURPLE twice, then Solid BLUE light is on. Pair the product and phone while this status is continued for 2 minutes. - If the product is not connected to the phone or the GPS, it will be turned off automatically within 30 minutes. 9 English When being ready to be paired > When turning the speaker on for the first time after purchasing. > When pressing and holding for 3 seconds in Idle Mode. - Passkey or PIN is a secret code that needs to be entered on the phone in order to pair the mobile phone with a Bluetooth device. - If there is no Bluetooth device to be connected in 2 minutes, the BLUE indicator light flashes 2 times per 3 seconds (Idle Mode). In that case, press for 3 seconds to return to Pairing Mode. - Check the back of the product or the connected Bluetooth device information on the phone to find the B/D address of the product. (Refer to your phone’s user manual for further details.) 1. Solid BLUE light is on for 2 minutes if the speaker is ready to be paired. 2. Prepare your phone according to the phone’s user manual on Pairing. 3. Your phone will find “ SAMSUNG ACSP100BBE” and ask if you want to pair with it. 4. Enter passkey or PIN⁴= 0000 (4zeros). 5. Your phone and the product will be automatically connected if the pairing is completed. BLUE light flashes every 6 second if they are correctly connected (Stand-by mode) . - Depending on the phone type, the phone and the product may not be connected automatically after the pairing is completed. In this case, refer to the phone’s user guide to try connecting. 10 English Connecting after completing the pairing 8 To use the speaker with Bluetooth phone, pairing is necessary. Please make sure that two devices are paired before trying connecting, and if not, refer to 7. Pairing the product with compatible phone section for pairing. To connect from the phone > Follow your phone’s user guide. To connect from the speaker 1. Turn on the product by pressing for 3 seconds in Power OFF mode. - The product tries connecting automatically. - The BLUE indicator light flashes every 6 second if the connecting succeeds, and flashes every 3 second if fails. - Depending on the phone type, the phone and the product may not be connected automatically after the pairing is completed. In this case, try connecting by pressing for 2 seconds. 1. Press for 2 seconds. - If connected successfully, you can make or answer on the speaker. - The BLUE light will flash every 6 second if connected successfully. - If the connection fails, the BLUE indicator light will flash every 3 second, and the pop-up message which informs that the connection is failed displays on the phone. In this case, try connecting again from the beginning. To connect while the phone is turned on - If disconnected due to the distance limit between the phone and the product - If you exchange or restart the phone battery - To connect from the speaker, your phone and the speaker have had to be connected more than once. 11 English Making and answering a call 9 Using the product Explains how to use the various functions that the Bluetooth GPS Speaker provides. Redialing the last dialed number > Press . - The speaker makes a call to the last dialed number. - Depending on the phone type, the phone displays the latest calling list first, then makes a call to the last dialed number by pressing once again. Making a call > Make a call with your Bluetooth phone, then press and hold for 2 seconds if you hear dial tone on the phone. Answering a call > Press if the phone rings. - Press for 2 seconds to hang up the phone. - If your phone supports Auto Transfer Audio function, it switches the call from the phone to the product automatically. 12 English Switching the call between phone and speaker 11 > Press and hold for 3 seconds to switch the call to the phone while on call. > Press and hold for 3 seconds to switch the call to the speaker while on call. Rejecting a call 10 > Press for 2 seconds if the phone rings. - Available only when your phone supports incoming call rejecting function. Activating Call-Waiting function 12 > Press and hold for 2 seconds to activate Call-Waiting while on call. - Answers the second call while the current call remains on hold. > To deactivate Call-Waiting, press and hold for 2 seconds again. - Available only when your phone supports Call-Waiting function. 13 English Activating 3-way call function 13 3-way Call allows you to speak with 3 people in different places simultaneously. - Available only when your phone supports 3-way Call function. Adjusting the volume 14 > Move left or right to adjust the speaker volume while using . Muting an ongoing call 15 > Press and hold for 2 seconds to mute the microphone while on call. > Press or move left or right to unmute. 1. Press and hold for 2 seconds to activate Call-Waiting while on call. - Answers the second call while the current call remains on hold. 2. To invite the call on hold to 3-way Call, Press and hold for 2 seconds. - The volume has 8 steps in total, and the default setting is set to step 4. - Current volume setting is saved only when the speaker is turned off normally. If the power is unexpectedly turned off, the volume will go back to the default setting. - The volume will not be adjusted automatically even if you…

Text truncated - open the document above for the full version.

YOUNGBO ENGINEERING INC. www.youngboeng.com Federal Communications Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD21046 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission's Rules (47 C.F.R) and Section §552(b)(4) of the Freedom of Information Act, YOUNGBO ENGINEERING INC. requests confidentiality for the following products: FCC ID Number Product Type / Model SPX-ACSP100BBE Bluetooth GPS Speaker / ACSP100BBE For the product stated above, we request that the following information be held confidential: 1) Schematic diagrams 2) Bill of materials (Part List) 3) Block Diagram No other items submitted as part of the equipment authorization filing process are deemed confidential. The above exhibits contain YOUNGBO ENGINEERING INC. trade secrets and proprietary information that could be of benefit to our competitors regarding the design of our products. This material is not customarily available to the general public and we request that it be withheld from public inspection. Sincerely, Cheol Yong Kim / Expert Research Engineer [email protected] 20-2, Sinhang-ri, Dunpo-myeon, Asan-si, Chungcheongnam-do, Korea #336-873 TEL: +82-41-537-1268, FAX: +82-41-537-1193 http://www.youngboeng.com

SK TECH CO., LTD. Page 1 of 3 SKT SKTTRT-060307-007 FCC ID: SPX-ACSP100BBE External Photographs of EUT <Photograph 1: Front View> SK TECH CO., LTD. Page 2 of 3 SKT SKTTRT-060307-007 FCC ID: SPX-ACSP100BBE <Photograph 2: Rear View> SK TECH CO., LTD. Page 3 of 3 SKT SKTTRT-060307-007 FCC ID: SPX-ACSP100BBE <Photograph 3: Cigarette Adapter & GPS>

FCC ID Label Location & Sample LABEL LOCATION: Label is attached on the REAR of the product LABEL Drawing: LABEL LOCATION

SK TECH CO., LTD. Page 1 of 2 SKT SKTTRT-060307-007 FCC ID: SPX-ACSP100BBE Internal Photographs of EUT <Photograph 1: Front View> SK TECH CO., LTD. Page 2 of 2 SKT SKTTRT-060307-007 FCC ID: SPX-ACSP100BBE <Photograph 2: Rear View>

Antenna description Model Name ALA931C4 Manufacturer AMOTECH CO., LTD. App. Type BT-GPS_SPK (Model ACSP100BBE) Dimension (L × W × D) 9.0mm ×3.0mm × 1.2mm Picture of the antenna Radiation Pattern

Operational Description This product, ACSP100BBE, is a Bluetooth device. The product operates in 2400 to 2483.5 MHz band. The channel is represented by a pseudo-random hopping sequence through the 79 channels. The channel is divided into time slots, with a nominal slot length of 625μs, where each slot corresponds to different RF hop frequencies. The nominal hop rate is 1600 hops/s. The control signals and data in the Bluetooth Chipset are modulated and processed and then pass the PA in it. They will be transmitted from ANT through the BALUN FILTER to another Bluetooth device. The RF signal from other Bluetooth devices is received via ANT. And they go through BALUN FILTER into the chip. They are magnified by internal LNA in the chip. The power settings and crystal trim are stored in EEPROM. The product is powered from a Li-ion battery and uses an integral SMD chip antenna. No external ground is required.

SK TECH CO., LTD. Page 1 of 38 SKT SKTTRT-060307-007 FCC ID: SPX-ACSP100BBE Certificate of Compliance Test Report No.: SKTTRT-060307-007 NVLAP CODE: 200220-0 Applicant: YOUNGBO ENGINEERING INC. Applicant Address: 20-2, Sinhang-ri, Dunpo-myeon, Asan-si, Chungcheongnam-do, Korea #336-873 Manufacturer: YOUNGBO ENGINEERING INC. Manufacturer Address: 20-2, Sinhang-ri, Dunpo-myeon, Asan-si, Chungcheongnam-do, Korea #336-873 Device Under Test: Bluetooth GPS Speaker FCC ID: SPX-ACSP100BBE Model No.: ACSP100BBE Receipt No.: SKTEU06-0109 Date of receipt: February 25, 2006 Date of Issue: March 7, 2006 Location of Testing: SK TECH CO., LTD. 820-2, Wolmoon-Ri, Wabu-Up, Namyangju-Si, Kyunggi-Do, Korea Test Procedure: ANSI C63.4, FCC Public Notice DA 00-705 (March 2000) Test Specification: 47CFR, Part 15 Rules Equipment Class: DSS - Part 15 Spread Spectrum Transmitter Test Result: The above-mentioned device has been tested and passed. Tested & Reported by: Jong-Soo, Yoon 2006.03.07 Approved by: Jae-Kyung, Bae 2006.03.07 Signature Date Signature Date Other Aspects: - Abbreviations: · OK, Pass = passed · Fail = failed · N/A = not applicable ☞ •This test report is not permitted to copy partly without our permission. •This test result is dependent on only equipment to be used. •This test result is based on a single evaluation of one sample of the above mentioned. •This test report must not be used to claim product endorsement by NVLAP or any agency of the U.S Government. • We certify that this test report has been based on the measurement standards that is traceable to the national or International standards. NVLAP Lab. Code: 200220-0 SK TECH CO., LTD. Page 2 of 38 SKT SKTTRT-060307-007 FCC ID: SPX-ACSP100BBE >> CONTENTS << 1. GENERAL ············································································································· 4 2. TEST SITE ············································································································ 4 2.1 Location ········································································································· 4 2.2 List of Test and Measurement Instruments ···················································· 5 2.3 Test Date ········································································································ 5 2.4 Test Environment ··························································································· 5 3. DESCRIPTION OF THE EQUIPMENT UNDER TEST ········································· 6 3.1 Rating and Physical Characteristics ······························································ 6 3.2 Equipment Modifications ················································································ 6 3.3 Submitted Documents ···················································································· 6 4. MEASUREMENT CONDITIONS ··········································································· 7 4.1 Description of test configuration ···································································· 7 4.2 List of Peripherals ·························································································· 7 4.3 Uncertainty ····································································································· 7 5. TEST AND MEASUREMENTS ············································································· 8 5.1 ANTENNA REQUIREMENT ·········································································· 8 5.1.1 Regulation ······························································································· 8 5.1.2 Result ······································································································ 8 5.2 MAXIMUM PEAK OUTPUT POWER ···························································· 9 5.2.1 Regulation ······························································································· 9 5.2.2 Test Procedure ························································································ 9 5.2.3 Test Results ····························································································· 9 Table 1: Measured values of the Maximum Peak Output Power (Conducted) ····· 9 Figure 1: Plot of the Maximum Peak Output Power (Conducted) ······················10 5.3 CARRIER FREQUENCY SEPARATION ····················································· 12 5.3.1 Regulation ····························································································· 12 5.3.2 Test Procedure ······················································································ 12 5.3.3 Test Results ··························································································· 12 Table 2: Measured values of the Carrier Frequency Separation (Conducted) ···12 Figure 2: Plot of the Carrier Frequency Separation (Conducted) .....................13 5.4 20dB CHANNEL BANDWIDTH ·································································· 15 5.4.1 Regulation ····························································································· 15 5.4.2 Test Procedure ······················································································ 15 5.4.3 Test Results ··························································································· 15 Table 3: Measured values of the 20dB Channel Bandwidth (Conducted) ··········15 Figure 3: Plot of the 20dB Channel Bandwidth (Conducted) ···························16 SK TECH CO., LTD. Page 3 of 38 SKT SKTTRT-060307-007 FCC ID: SPX-ACSP100BBE 5.5 NUMBER OF HOPPING CHANNELS ························································ 18 5.5.1 Regulation ····························································································· 18 5.5.2 Test Procedure ······················································································ 18 5.5.3 Test Results ···················································…

Text truncated - open the document above for the full version.

SK TECH CO., LTD. Page 1 of 2 SKT SKTTRT-060307-007 FCC ID: SPX-ACSP100BBE Test set up photos <Conducted RF power measurement> SK TECH CO., LTD. Page 2 of 2 SKT SKTTRT-060307-007 FCC ID: SPX-ACSP100BBE <Radiated Emissions – Front View> <Radiated Emissions – Rear View>
