SQT-RIPEX2-1ARadio modem and router

User manual . RipEX2 Radio modem & Router . fw 2.0.3.0 2021-05-18 version 1.12 www.racom.eu RACOM s.r.o.| Mirova 1283 |592 31 Nove Mesto na Morave | Czech Republic Tel.: +420 722 937 522 | E -mail: [email protected] Table of Contents Important Notice .................................................................................................................................. 7 1. Quick guide ..................................................................................................................................... 8 1.1. Bench testing ........................................................................................................................9 2. Product .......................................................................................................................................... 11 2.1. Dimensions .........................................................................................................................12 2.2. Connectors ......................................................................................................................... 15 2.3. Indication LEDs .................................................................................................................. 22 2.4. Ordering codes ................................................................................................................... 24 3. Accessories ................................................................................................................................... 27 4. Installation ..................................................................................................................................... 28 4.1. Mounting .............................................................................................................................29 4.2. Antenna installation ............................................................................................................ 33 4.3. Antenna feed line ............................................................................................................... 34 4.4. Grounding ...........................................................................................................................34 4.5. Connectors ......................................................................................................................... 34 4.6. Power supply ...................................................................................................................... 34 5. RipEX2 in detail .............................................................................................................................36 5.1. Bridge mode ....................................................................................................................... 36 5.1.1. Functionality example .............................................................................................. 37 5.1.2. Configuration examples ........................................................................................... 39 5.2. Router mode .......................................................................................................................40 5.2.1. Router - Base driven ................................................................................................ 40 5.2.2. Router - Flexible ...................................................................................................... 43 5.3. Combination of IP and serial communication ..................................................................... 47 5.3.1. Detailed Description ................................................................................................ 47 6. Web interface ................................................................................................................................ 49 6.1. Supported web browsers .................................................................................................... 51 6.2. Changes to commit ............................................................................................................ 51 6.3. Notifications ........................................................................................................................ 52 6.4. User menu .......................................................................................................................... 53 6.5. Help .................................................................................................................................... 53 6.6. Remote access ...................................................................................................................54 7. Settings ......................................................................................................................................... 56 7.1. Interfaces ............................................................................................................................56 7.1.1. Ethernet ................................................................................................................... 56 7.1.2. Radio ....................................................................................................................... 58 7.1.2.1. Radio channel parameters ........................................................................... 59 7.1.2.2. Transparent protocol (Bridge mode) ............................................................. 61 7.1.2.3. Base driven protocol (Router mode) ............................................................. 62 7.1.2.3.1. Radio protocol - Base station ............................................................. 63 7.1.2.3.2. Base station - List of Remote stations ............................................... 63 7.1.2.3.3. Radio protocol - Remote station ........................................................ 64 7.1.2.4. Flexible Protocol (router mode) .....................................................…

Text truncated - open the document above for the full version.

RACOM s.r.o. • Mirova 1283 • 592 31 Nove Mesto na Morave • Czech Republic Tel.: +420 722 937 522 • E-mail: [email protected] www.racom.eu TUV SUD BABT TCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL Subject: FCC ID: SQT-RIPEX2-1A, IC: 24993-RIPEX21A Dear Sir or Madam, We, Racom s. r. o. hereby authorize Eric Lifsey, Proffesional Testing (EMI) Inc., Tel. (512)244 3371 to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. This authorization expires on 31st of December 2021. Sincerely, Company Officer: Jiří Hruška Telephone number: +420 602 511 062 Email: [email protected] Nove Mesto na Morave, Czech Republic Date: 2021, April 6th Jiří Hruška, CEO Manufacturer’s authorization

RACOM s.r.o. • Mirova 1283 • 592 31 Nove Mesto na Morave • Czech Republic Tel.: +420 722 937 522 • E-mail: [email protected] www.racom.eu FEDERAL COMMUNICATIONS COMMISSION Racom s r.o. Authorization & Evaluation Division Mírová 1283 7435 Oakland Mills Road Nové Město na Moravě Columbia, MD 21046 592 31 U.S.A. Czech Republic Subject: Request for withholding from public disclosure documents pursuant to an application for certification of FCC ID: SQT-RIPEX2-1A. Dear Sir/Madam, We, Racom s r.o., would like to request that the • schematic diagrams (09a_mbk2_135-175MHz_v2_sch.pdf, 09b_MBM6_noaescpu_v4_sch), • system block diagram (07_BlockDiagram_RipEX2-1A.pdf) • bills of materials (08a_BOM_mbk2_135-175MHz_v2.pdf, 09b_MBM6_noaescpu_v4_sch.pdf) • operational description (03_Operational_description_RipEX2-1A.pdf) submitted with the application for certification be withheld from public disclosure as per Section 0.459 of FCC Rules. This request is made under the provisions of Section 0.457(d) of the Commission's Rules, and Section 552(b)(4) of the Freedom of Information Act. These sections authorize as a withholding from public inspection materials which would be privileged as a matter of law if retained by the person submitting them, and materials which would not customarily be released to the public by that person. If you have any queries, please do not hesitate to contact Racom s r.o. Nove Mesto na Morave, Czech Republic Date: 2021, April 6 th Jiří Hruška, CEO

FEDERAL COMMUNICATIONS COMMISSION Racom s r.o. Authorization & Evaluation Division Mírová 1283 7435 Oakland Mills Road Nové Město na Moravě Columbia, MD 21046 592 31 U.S.A. Czech Republic Subject: FCC ID: SQT-RIPEX2-1A Dear Sir/Madam, The attached documents constitute a formal submission and application for Equipment authorization for the RipEX2-1A radiomodem pursuant to the FCC Part 90 rules. The RipEX2-1A device contains software to allow communication within the below mentioned frequency bands (MHz). 150.800 – 156.2475 157.1875 – 161.575 161.7750 – 161.9625 162.0375 – 170.000 Programming of transmit frequencies can only be performed by the manufacturer or by authorized service or maintenance personnel. Operator cannot directly program the transmit frequencies using the normally accessible external controls. There is no field tune-up procedure. All adjustments are software controlled and are pre-set at the factory and can only be changed by the manufacturer or by authorized service or maintenance personnel. We, RACOM s r.o. are aware of the FCC rules and that is a violation of rules for the device to operate on unauthorized frequencies. This device is designed to operate in 6.25, 12.5, 25 kHz channel spacings under Part 90 rules. This equipment is capable of supporting a minimum data rate of 4800 bits per second per 6.25 kHz of channel bandwidth. This letter serves as supplementary evidence and attestation for the frequency banding authorization application. If you have any queries, please do not hesitate to contact Racom s r.o. Sincerely Jiří Hruška, CEO Nove Mesto na Morave, Czech Republic Date: May 17th, 2021 RACOM s.r.o. • Mirova 1283 • 592 31 Nove Mesto na Morave • Czech Republic Tel.: +420 722 937 522 • E-mail: [email protected] www.racom.eu

Side 1 of 6 Side 2 of 6 Side 3 of 6 Side 4 of 6 Side 5 of 6 Side 6 of 6 ***

Side 2 of 6

S/N: 2002273823 RACOM s.r.o., Mirova 1283 592 31 Nove Mesto na Morave Made in Czech Republic www.racom.eu Type:RipEX2-1 Code:RipEX2-1A-N-E TX,RX freq: 146–174 MHz RF Power: 10W Power:10-30V max. 6A FCC ID:SQT-RIPEX2-1A IC:24993-RIPEX21A

RF Board, Top RF Board, Bottom Logic Board, Top Logic board bottom ***

Page 1 of 4 Maximum Permissible Exposure (MPE) Evaluation according to the OET Bulletin 65 (Edition 97-01) Evaluated equipment: The RipEX2 radio modem for data transmission in the 135 – 175 MHz frequency range Developed: Ing. Michal Voráček Date: 28.1.2021 Pages: 4 Page 2 of 4 Evaluated equipment The RipEX2 radio modem is designed for bi-directional data transfer in a radio frequency channel assigned from the specified frequency range. When transmitting, it generates an angle modulated, continuous, constant-envelope radio-frequency signal on the output (antenna) connector. The transmitted signal spectral width is limited to a single channel and never exceeds the respective channel spacing, which is 300 or 250 or 200 or 150 or 100 or 50 or 25 kHz or 12,5 kHz or 6,25 kHz. The maximum nominal output radio-frequency (RF) power of the RipEX2 radio modem is 10 Watts. The output RF power variation in extreme conditions is guaranteed by the manufacturer to stay within -3,0 dB to +2.0 dB limits. The RipEX2 radio modem main specifications for a frequency range around 160 MHz are in Table 1. Table 1 – RipEX2 radio modem main technical parameters Parameter Value Frequency range from 135 MHz to 175 MHz Channel spacing 6,25 / 12,5 / 25 / 50 / 100 / 150 /200 / 250 / 300 kHz Channel setting method software Supply voltage (nominal) 13,8 V Supply voltage range 10 V to 30 V Operating temperature range -40 °C to +70 °C Current consumption: Reception: Transmission 1W: Transmission 10W: 580 mA 1,1 A 3,6 A Configurable RF output power range from 0,1 W to 10 W Antenna connector TNC RF output impedance 50 ohm The RipEX2 radio modem is connected to the antenna by a coaxial cable. Since the antenna may be connected by a very short cable, the cable loss shall be considered negligible in the calculation. The main parameters of recommended antennas are listed in Table 2. These are parameters specified by the respective manufacturers. The antennas listed in Table 2 are supplied with the RipEX2 radio modem upon request. Page 3 of 4 MPE Calculations According to the OET Bulletin 65 (Edition 97-01) R= √ P.G 4.π.S Where: S=Power density (in appropriate units, e.g. mW/cm2) P=Power input to antenna (in appropriate units, e.g., mW) G=Power gain of the antenna in the direction of interest relative to an isotropic radiator R=Distance to the centre of radiation of the antenna (appropriate units, e.g., cm) Tx Frequency = 160 MHz The exposure at the lowest frequency of the operating range make the worst case, since the limits given in §1.1310 of the FCC Rules increase with frequency (in the frequency range applicable to the evaluated equipment) whereas the radiation from RipEX2 radio modem will be constant. Maximum peak power = 42.0 (dBm) The maximum peak power is calculated as the nominal maximum power increased by the margin allowed by the applicable FCC standard (+2dB) Antenna gain = 2.15 (dBi) The antenna gain of the half-wave dipole is considered as the worst-case scenario. The areas of exposure never lie in the direction of the main lobe of the transmitting antenna. In fact, the higher the gain of the antenna is, the lower the radiation in the directions relevant for exposure evaluation will be. S = 368/1500 = 0.245 [mW/cm2] The FCC limit for exposure of general population / uncontrolled exposure at 160 MHz Page 4 of 4 P = 15850 [mW] The numerical value of maximum TX power G = 1.64 The numerical value of half-wave dipole gain The worst case scenario also assumes 100% duty cycle. Though the equipment assessed allows for that, it never happens in reality thanks to the packet-oriented transmission environment. Calculated minimum separation distance from antenna, where the limit for general public / uncontrolled exposure is met, is: Ru = 92 cm The distance, where the limit for occupation / controlled exposure is met, is: Rc = 41 cm The distance, where the limits are met for typical directional and omni directional antennas typically used with RipEX2 radio modem. For directional antennas is safe distance validate in direction side of main beam, where is maximum energy emitted by antenna. 135 - 175 MHz/ 2m band - 10 Watt RF power Antenna code Antenna description Gain G (dBi) Gain G (-) Distance where the FCC limits is met for General Population/Uncontrolled Exposure (cm) Occupational/Controlled Exposure (cm) OV138.1 single dipole 4.6 2.9 152.1 53.1 OV138.2 stacked double dipole 7.6 5.8 214.8 75.0 SA138.3 3 elemet directional Yagi 8 6.3 225.0 78.5 SA138.5 5 elemet directional Yagi 10 10.0 283.2 98.8 Table #1 – The distance where the FCC limits are met for typical antennas Conclusion: It is safe to assume that members of general public will never be present in the distance Ru (or lower) to a fixed installation of antenna of the evaluated equipment. Equally it is safe to assume that e.g. a member of staff performing mast maintenance will spend only negligible fractions of time in the Rc (or lower) distance to the transmitting antenna (the Rc distance actually corresponds with the physical size of the antenna itself). Consequently, in our opinion, the operation of the evaluated equipment would not make a significant environmental effect.

PTI Project 22234-15 RACOM s.r.o. RipEX2-1A Data Transceiver 135.000 to 175.000 MHz Wireless Certification Report FCC Part 90 and IC RSS-119 Prepared for: RACOM s.r.o. Mirova cp. 1283 592 31 Nove Mesto na Morave Czech Republic By Professional Testing (EMI), Inc. 1601 North A.W. Grimes Blvd., Suite B Round Rock, Texas 78665 23 Apr 2021 Reviewed by Written by Larry Finn Chief Technical Officer Eric Lifsey EMC Engineer RACOM s.r.o. – RipEX2-1A 22234-15 Professional Testing (EMI) Inc. Page 2 of 59 Revision History Revision Number Description Date Draft 02 Added RE equipment list; fixed 0463 DMM in other equipment lists. 23 Apr 2021 Final01 14 May 2021 Corrections: None. RACOM s.r.o. – RipEX2-1A 22234-15 Professional Testing (EMI) Inc. Page 3 of 59 Table of Contents Revision History ............................................................................................................................................................ 2 Certificate of Compliance ............................................................................................................................................. 5 1.0 Introduction .......................................................................................................................................................... 6 1.1 Scope ............................................................................................................................................................... 6 1.2 EUT Description ............................................................................................................................................. 6 1.3 EUT Operation ................................................................................................................................................ 6 1.4 Modifications to Equipment ............................................................................................................................ 7 1.5 Test Site .......................................................................................................................................................... 7 1.6 Applicable Documents .................................................................................................................................... 7 1.7 Test Setup Diagram ......................................................................................................................................... 7 1.8 Emission Designators ...................................................................................................................................... 8 Conducted Output Power .............................................................................................................................................. 9 1.9 Procedure ........................................................................................................................................................ 9 1.10 Criteria ....................................................................................................................................................... 9 1.11 Results ........................................................................................................................................................ 9 1.12 Calculated Attenuation and Spurious Limits Beyond Authorized Bandwidth ........................................... 9 2.0 Emission Mask ................................................................................................................................................... 10 2.1 Procedure ...................................................................................................................................................... 10 2.2 Criteria .......................................................................................................................................................... 10 2.3 Results ........................................................................................................................................................... 10 2.3.1 Mask C ................................................................................................................................................ 11 2.3.2 Mask D ................................................................................................................................................ 18 2.3.3 Mask E ................................................................................................................................................. 24 3.0 Spurious Emissions at Antenna Terminals ........................................................................................................ 31 3.1 Procedure ...................................................................................................................................................... 31 3.2 Criteria .......................................................................................................................................................... 31 3.3 Results ........................................................................................................................................................... 31 3.3.1 Transmit Mode, Bottom Channel ........................................................................................................ 32 3.3.2 Transmit Mode, Middle Channel ......................................................................................................... 32 3.3.3 Transmit Mode, Top Channel .............................................................................................................. 33 4.0 Field Strength of Radiated Spurious Emissions ................................................................................................. 34 4.1 Procedure ...................................................................................................................................................... 34 4.2 Criteria .....…

Text truncated - open the document above for the full version.

22234 Test Setup Photos Page 1 of 2 Radiated Emissions up to 1 GHz, Front Radiated Emissions up to 1 GHz, Back Radiated Emissions above 1 GHz, Front Radiated Emissions above 1 GHz, Back Conducted Antenna Port Measurements Power, Bandwidth, Mask, Spurious Transmit Transient Frequency Behavior 22234 Test Setup Photos Page 2 of 2 Frequency Stability, Chamber Frequency Stability, EUT ***
