STCEX-1202QIP-VDSL Modem

Tellion, Inc.

Click to zoom

Application Details

Equipment Class: JBC - Part 15 Class B Computing Device/Personal Computer
Date of Grant: Aug 15, 2006
Application Purpose: Original Equipment
Date of Application: Jul 20, 2006
Equipment Note: IP-VDSL Modem
Company: Tellion, Inc.
Country: South Korea

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Manual of IP-VDSL EX-1202Q CAUTION: Changes or modifications not expressly approved by the manufacturer responsible for compliance could void the user’s authority to operate the equipment WA R N I N G This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. INFORMATION TO USER: This equipment has been tested and found to comply with the limit of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation; if this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: 1. Reorient / Relocate the receiving antenna. 2. Increase the separation between the equipment and receiver. 3. Connect the equipment into an outlet on a circuit difference from that to which the receiver is connected. 4. Consult the dealer or an experienced radio/TV technician for help G G |GtGGtG [Before Using this MODEM] jGiG G {GtGGGoGh GGGGltpVltjSGGGGG GGGGGGGhG This manual on IP-VDSL EX-1202Q MODEM describes how to install and operate it, your understanding and using for it is highly recommended. G G G |GtGGtG Contents 1. Product introduce 2. Packing contents confirmation of IP-VDSL EX-1202Q 3. Connect cables 4. System composition 5. Specification of IP-VDSL EX-1202Q G G G |GtGGtG 1.Introductions IP-VDSL EX-1202Q is MODEM providing very high speed Data Service and common Telephone Service to User through residential Telephone Line. IP-VDSL EX-1202Q is MODEM providing various Multimedia Service such as High Seed Internet connection. Internet Broad casting, Remote Diagnosis, Monitoring Conference, VoD etc.. 2.Accessories of IP-VDSL EX-1202Q wGGOyqTXXPG lGGOyqT[\PG tG hG tvkltG G G G |GtGGtG 3.Connect cables Caution: Confirmation of power switch off of EX-1202Q MODEM before connecting the cables. ØVDSL Line connection (VDSL PORT) Connecting the residential Telephone wire of using Telephone to Telephone Socket of wall and IP-VDSL VDSL Port. ØTelephone connection (PHONE PORT) Connecting RJ-11 Cable: Phone Cable (included Accessory) to Phone Port on EX-1202Q MODEM and Telephone. ØPC connection (LAN1/LAN2 PORT) Connecting Ethernet Cable: RJ-45 Cable (included Accessory) to LAN1/LAN2 Port on EX-1202Q MODEM and LAN1/LAN2 Card on P/C. ØPower Adapter connection (DC 5V 2A PORT) Connecting Power Adaptor Cable (included Accessory) to DC 5V 2A Input Port on EX-1202Q MODEM G G G |GtGGtG 4.System composition Ɣ Front NameLED Color Ability POWERGREENLighting on connecting to correct Power LAN2GREENLighting on connecting to P/C LAN1GREENLighting on connecting to P/C LINK (VDSL Link) GREENLighting on connecting to VDSL Link DATA (VDSL Data) GREENLighting on connecting to VDSL Link, Blinking on sending and receiving the Data. G G G |GtGGtG Ɣ Back NameUseDescriptions VDSLVDSL line PORT Sending and receiving the VDSL data and Connecting to Telephone socket on the wall. PHONETelephone connection PORT Connecting to Telephone through the micro filters. F.G Frame alarm Terminal for Frame Ground. LAN1Ethernet PORT Connecting to LAN card of the PC using the straight type LAN cable. LAN2Ethernet PORT Connecting to LAN card of the PC using the straight type LAN cable. DC 5V 2A Power input terminal Connecting Power Adaptor To MODEM. POWER Power switch Providing Power to MODEM. G G G G G G |GtGGtG G 5. Specification of IP-VDSL EX-1202Q ItemsSpecification VDSL standard z ETSI VDSL Standard z ITU ITU-T G.993.1 IEEE v Standard z IEEE 802.3 10Base-TX z IEEE 802.3u 100Base-TX Ethernet Interface z 10/100Base-TX (IEEE 802.3, Auto-negotiation) z Connector : RJ-45 VDSL Interface z Connector : RJ-11 POTS Interface Interface z Connector : RJ-11 Modulation Quadrature Amplitude Modulation (QAM) Transmission Full-duplex, Frequency Division Multiplexing (FDD) data Rate z Asymmetrical : 50/6Mbps ~ 1.5/0.4Mbps(M1) Band Plan z Plan998 PSD MASK ETSI, ANSI, ITU-T(G.993.1) VDSL Standards Upstream Power-back-off z Upstream Power-back-off Loopback zGGGGGGGG CPE Configuration VDSL z }kzsGhGGGG z hGGOXWVXWWiT{GhTuPGGG U G G G |GtGGtG Connector z Two RJ-11 Connector (LINE, PHONE) z Two RJ-45 Connector (LAN1, LAN2) z wV~GGOPGOkjG\}GYhP LED POWER, LAN2, LAN1, LINK, DATA lG z{aGWG¥G\W¶jGOGGPSGT[W¥^W¶jGOGPG zo aG\G¥G`WLG zGvmG tvkltG zkaGX]\GO~PGGZ[GOoPGGXY[GOoP z ~aGYWW wGG tvklt z Input: 100~240VAC, 50~60Hz, DC 5V/2A z lGG : 5 Watt (Max) G G G |GtGGtG Certification of guarantee uGGw 50M IP-VDSL MODEM uGGt IP-VDSL EX-1202Q Serial Number wGk pG 1 year Name Te l Address Customer E-Mail Regulations of compensation for user Damaged MODEM shall be compensated under the regulations of compensation for user Guarantee in detail 1. This product is made through strict quality control and test process. 2. 1 year warrantee shall be provided for user without case of no #3…

Text truncated - open the document above for the full version.

External Photos

1. FRONT 2. REAR

Internal Photos

INTERNAL PHOTO 1. MAIN 1.1 Front 1.2 Rear 2. Power 2.1 Front 2.2 LABEL

Operational Description

Tellion Inc. FCC ID STCEX-1202Q -Operational description- IP-VDSL EX-1202QV is Modem providing very high speed Data Service and common Telephone Service to User through residential Telephone Line. IP-VDSL EX-1202QV is Modem providing various Multimedia Service such as high seed Internet connection, Internet Broad casting, Remote Diagnosis, Monitoring Conference, VoD etc..

Test Report

Test Report for FCC Company name Address Telephone Product name Model No. Serial No. Test date Testing location Standard □ Class A ■ Class B Test resultOK □ Class A ■ Class B Test resultOK Tested by Reviewed by Abbreviation * Note - This test report is not permitted to copy partly without our permission - This test result is dependent on only equipment to be used - This test result based on a single evaluation of one sample of the above mentioned Report Number : ESTF150607-008 , Web : www. estech. co. kr Page 1 of 14 Report NumberESTF150607-008 Manufacturer Country of origin Applicant Product 20-Jul-06 IP-VDSL Modem EX-1202Q NONE Tellion,Inc KOREA Date of issue ESTECH. Co., Ltd. 97-1 Hoiuk-Ri Majang-Myon, Icheon-city, KyungKi-Do, Korea Test item ■ Conducted Emission ■ Radiated Emission FCC PART 15 2006 , ANSI C 63.4 2003 2006-05-17 ~ 2006-07-20 OK, Pass = Passed, Fail = Failed, N/A = not applicable Tellion,Inc 8th Fl, Leader's tower 60-15 Gasan-dong,Geumcheon- gu,Seoul,153-801,Korea 82-2-2026-7047 Measurement facility registration number Engineer J.H.Kim Engineering Manager J.M.Yang 94696 (Signature) (Signature) 3 4 5 6 8 8 8 9 10 10 10 11 12 14 Appendix 1. Spectral diagram Report Number : ESTF150607-008 , Web : www. estech. co. kr Page 2 of 14 5. Measurement of radiated emission ..................................................................... 5.1 Measurement equipment .............................................................................. Contents 1. Laboratory Information .................................................................................... 2. Descri ption of EUT .......................................................................................... 3. Test Standards ................................................................................................ 4. Measurement condition .................................................................................... 5.2 Environmental conditions .............................................................................. 5.3 Test data ................................................................................................... 7. Photographs of test setup ................................................................................. 8. Photographs of EUT .......................................................................................... 6. Measurement of conducted emission .................................................................. 6.1 Measurement equipment .............................................................................. 6.2 Environmental conditions .............................................................................. 6.3 Test data ................................................................................................... 1. Laboratory Information 1.1 General 1.2 Test Lab. Corporation Name : ESTECH Co. Ltd Head Office : Rm 1015, World Venture Center II, 426-5, Gasan-dong, Geumcheon-gu, Seoul, Korea (Safety & Telecom. Test Lab) EMC Test Lab : 58-1 Osan-Ri, GaNam-Myon, YeoJoo-Gun, KyungKi-Do, Korea 97-1 Hoiuk-Ri Majang-Myon, Icheon-city, KyungKi-Do, Korea 1.3 Official Qualification(s) MIC : Granted Accreditation from Ministry of Information & Communication for EMC, Safety and Telecommunication KOLAS : Accredited Lab By Korea Laboratory Accreditation Schema base on CENELEC requirements FCC : Filed Laboratory at Federal Communications Commission VCCI : Granted Accreditation from Voluntary Control Council for Interference from ITE This EUT (Equipment Under Test) has been shown to be capable of compliance with the applicable technical standards and is tested in accordance with the measurement procedures as indicated in this report.ESTECH Lab attests to accuracy of test data. All measurement reported herein were performed by ESTECH Co., Ltd. ESTECH Lab assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Report Number : ESTF150607-008 , Web : www. estech. co. kr Page 3 of 14 2. Description of EUT 2.1 Summary of Equipment Under Test NONE: Model Number : EX-1202Q Serial Number : Manufacturer : Country of origin : Rating : Receipt Date : 2.2 General descriptions of EUT Using Freq. : 25MHz Report Number : ESTF150607-008 , Web : www. estech. co. kr Page 4 of 14 IP-VDSL Modem NONE Tellion,Inc KOREA INPUT: 100~240V 50/60Hz OUTPUT:DC 5.0V ,2A 2006-05-17 3. Test Standards Test Standard : FCC PART 15 (2006) Test Method : ANSI C 63.4 (2003) This standard sets forth uniform methods of measurement of radio-frequency (RF) signals and noise emitted from both unintentional and intentional emitters of RF energy in the frequency range 9 kHz to 40 GHz. Methods for the measurement of radiated and AC power-line conducted radio noise are covered and may be applied to any such equipment unless otherwise specified by individual equipment requirements. These methods cover measurement of certain decides that deliberately radiate energy, such as intentional emitters, but does not cover licensed transmitters. This standard is not intended for certification/approval of avionic equipment or for industrial, scientific, and medical (ISM) equipment These method apply to the measurement of individual units or systems comprised of multiple units This Standard sets out the regulations under which an intentional, unintentional, or incidental radiator may be operated without an individual license. It also contains the technical specifications, administrative requirements and other conditions relating to the marketing of Part 15 devices. Report Number : ESTF150607-008 , Web : www. estech. co. kr Page 5 of 14 4. Measurement Condition 4.1 EUT Operation. 4.2 Configuration and Peripherals * The EUT was in the following operation mode during all testing * The operational conditions of the EUT was determined by the manufacturer according to the typical use of the EUT with respect to the expected hightest level of emission …

Text truncated - open the document above for the full version.

Test Setup Photos

TEST SETUP PHOTO 1. Conducted Emission setup photo 1.1. Front 1.2. Rear 2. Radiated Emission setup photo 2.1 Front 2.2. Rear
