SWN-TD30URDOG TRAINING DEVICE

2 702T&B AVAILABLE IN 2-DOG SYSTEM: 2700T&B Owner's Manual Please read this manual thoroughly before operating the Dogtra 2700T&B or 2702T&B Training & Beeper e-collar. 1 2 3 IMPORTANT SAFETY AND PRODUCT INFORMATION WARNING Please read all safety and product information below before using your Dogtra product. Failure to follow these safety instructions could result in injury to you, your dog and others, or it could result in damage to your Dogtra product or other property. PRODUCT SAFETY Training Methods Dogtra products may be used with a variety of training methods. However, each dog may have a different reaction to training methods and to Dogtra products. Closely observe your dog when determining the right training method to use with your Dogtra product. Aggressive Dogs Do not use Dogtra products with aggressive dogs as such dogs may react adversely and cause injury to people or other dogs. Seek the assistance of a dog-training specialist or veterinarian when dealing with aggressive dogs. Children Dogtra products are not toys. Adult supervision and close attention are necessary when Dogtra products are used by or near children. PRODUCT DAMAGE Electrical Product Your Dogtra product contains electrical components and batteries. Do not use or keep your product near heat or flammable sources. Such use or storage may damage your product and/or cause fire, explosion, injury, or property damage. Medical Device Interference Dogtra products contain electrical and magnetic components that emit low level electromagnetic waves and radio frequencies. These electromagnetic waves or radio frequencies may interfere with pacemakers, defibrillators, or other medical devices. Consult your physician or medical device maker before using your medical device with a Dogtra product. If you think that your Dogtra product is interfering with your pacemaker, defibrillator, or other medical device, stop using the Dogtra product. Inadvertent Activation The digital microprocessor offers thousands of unique codes to eliminate frequency match-up with other Dogtra e-collars. The Constant button will automatically shut down after being held down for 12 seconds or more as a safety feature. UNAUTHORIZED USE Your Dogtra product should be used only in a humane manner to train and educate your dog. Dogtra products are not intended for use in any other manner nor are they intended for use with other animals or with humans. BAT TE RY Your Dogtra product contains batteries. Take care when removing and installing batteries as your fingers may get caught. Dispose of batteries as provided by your local regulations. Do not disassemble, crush, heat, or otherwise alter the battery as it may cause fire, injury or property damage. 4 5 CONTENTS AT A GLANCE .................................................................. MAIN FEATURES ............................................................. OVERVIEW ....................................................................... UNDERSTANDING YOUR TRAINING SYSTEM TURNING THE 2700T&B ON/OFF ....................... TRANSMITTER BUTTON FUNCTION .................. BEEPER SOUND ....................................................... BEEPER VOLUME ADJUSTMENT ......................... RECEIVER FITTING .................................................. FINDING THE RIGHT STIMULATION ................... FAMILIARIZING THE DOG TO THE BEEPER ..... MAXIMIZING THE DISTANCE ................................ LED INDICATOR ........................................................ CHARGING THE BATTERY ..................................... HANDHELD TRANSMITTER LCD .......................... ATTACHING THE BELT CLIP ................................... USING THE TEST LIGHT .......................................... GENERAL TRAINING TIPS ............................................ FCC WARNING STATEMENT ........................................ MAINTENANCE ............................................................... TROUBLESHOOTING GUIDE ....................................... WARRANTY AND REPAIR INFORMATION .............. 5 6 8 11 13 16 17 18 19 20 20 22 23 25 27 28 31 33 35 36 39 1. 2. 3. 4. 5. 6. 7. 8. 9. 10 11. 12. 13. AT A GLANCE Optional Accessories Auto Charger The auto charger for the 2700T&B has an input of 12-volts to 24-volts and has an output of 10-volts 1500mAh. European Charger Dogtra’s European chargers are designed for use with a 220 volt AC electrical outlet. To purchase accessories, please visit www.dogtra.com or call customer service at (888) 811-9111. Splitter Cable Test Light Battery Charger Belt Clip Receiver Owner's Manual Transmitter 6 7 • Easy-to-use, ergonomically fitted transmitter • Rheostat Dial that allows for gradual adjustments in stimulation intensity with no jumps between levels (0-127) • Two-dog models allow the trainer to control two different dogs from one transmitter • 1-mile range • 2 different stimulation types - Nick & Constant • High Performance Pager (HPP) vibration feature • Advanced Accelerometer Run/Point sensor • The freedom to choose between a high and low pitch beeper (single-dog unit only) • Three beeper modes - Run/Point, Point-Only, and Locate • Innovative beeper volume control that lets you select between 2 different pitches and 3 volume levels for each pitch • Combines the receiver with the beeper horn into one small, compact unit • 2-hour rapid charge lithium polymer batteries • IPX9K waterproof certified receiver and transmitter • No bothersome external antenna on the receiver M AI N FE ATU R E S • One-charging system allows the transmitter and receiver(s) to be charged at the same time • Easily visible blue LCD screen displays the exact level of stimulation that can be seen in the dark • A three bar battery life indicator and LED colored indicator to show the remaining battery life 8 9 OVERVIEW Nick Constant Rheostat Dial Antenna On/Off Button & Mode Belt Clip Battery Charging Receptacle & Rubber Plug On/Off Magnetic Red Dot LCD Screen Beeper Pitch Toggle Sw…

Text truncated - open the document above for the full version.

Applicant Declaration QSF27-14-04 Rev 1.0 Rev. Feb 6, 2023 Page 1 of 1 Original Issue: Jan. 4, 2021 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name Dogtra Co., Ltd. Address 35, Namdongdong-ro 33beon-gil, Namdong-gu, Incheon 21694 Rep. of KOREA Grantee Code SWN FCC ID SWN-TD30UR Authorized Contact Name YongByeong Chae Contact Email [email protected] Contact Phone +82 32 812 2445 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO 17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has r ead, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Link to the Covered List: Covered List Dogtra Co., Ltd. ( “the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Dogtra Co., Ltd. ( “the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered list, established pursuant to §1.50002, as an entity producing “covered” equipment. Applicant Signature: Date:2023-02-16 Print Name: YongByeong Chae Title: Manager *NOTE: This declaration cannot be signed by an Agent, it s hall be signed by an authorized person listed in the FCC database

UNITED STATES DESIGNATED AGENT LETTER Date: 2023-02-14 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Applicant U.S. designated agent Company Name: Dogtra Co., Ltd. Company Name: Dogtra Company Grantee Code: SWN FRN: 0033422338 Contact Name: Yong Byeong, Chae Contact Name: Eui Jung Kim Address: 35, Namdongdong-ro 33beon- gil, Namdong-gu, Incheon, South Korea Address: 12322 Monarch St., City/Province/Zip: 21694 City/Province/Zip: Garden Grove, CA 92841 Telephone: +82-032-812-2445 Telephone: +1-310-534-0101 Fax: +82-32-812-2449 Fax: +1-310-534-9111 Email: [email protected] Email: [email protected] Applicable Equipment: FCC ID: <FCC ID: SWN-TD30UR> ATTN: Director of Certification: We, Dogtra Co., Ltd. and Dogtra Company understand and acknowledge the applicants consent and th e designated agent’s obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and e-mail of the designated agent listed above. We, Dogtra Co., Ltd. and Dogtra Company acknowledge the applicant’s acceptance of its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Applicant U.S. designated agent Name (Printed): Yong Byeong Chae Name (Printed): Eui Jung Kim Title: Associate manager Title: VP Signature: Signature:

Dogtra Co., Ltd . 35, Namdongdong-ro 33beon-gil, Namdong-gu, Incheon 21694 Rep. of KOREA July 20, 2022 F ederal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 T o Whom It May Concern: I , the undersigned, hereby authorize SGS Korea Co., Ltd. and hereafter referred to as SGS Korea, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by of SGS Korea Co., Ltd. on our behalf shall have the same effect as acts of our own. I , the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). I n authorizing SGS Korea as our agent, we still recognize that we are responsible to: a)c omply with the relevant provisions of the certification program; b )make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c)m ake claims regarding certification only in respect of the scope for which certification has been granted; d )do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e)u pon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f)u se certification only to indicate the products are certified as being in conformity with specified standards; g )endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h )ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; Dogtra Co., Ltd . 35, Namdongdong-ro 33beon-gil, Namdong-gu, Incheon 21694 Rep. of KOREA i)keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j)t ake appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k )document the actions taken. This authorization is valid until further written notice from the applicant. S incerely yours, N ame / Title : Yo n g-Byeong, Chae / Associate manager Company Name : Dogtra Co., Ltd.

Dogtra Co., Ltd. 35, Namdongdong-ro 33beon-gil, Namdong-gu, Incheon 21694 Rep. of KOREA July 20, 2022 Fe deral Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 Re quest of Confidentiality for FCC ID : SWN-TD30UR To Whom It May Concern: Pu rsuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, Dogtra Co., Ltd. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give Dogtra Co., Ltd. temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: CO NFIDENTIAL LIST Permanent 1 Block Diagram 2 Operational Descriptions 3 Schematics 4 - 5 - Short-Te r m 6 External Photos 7 Internal Photos 8 Te s t-Setup Photos 9 User’s Manual Th e Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely yours, Nam e / Title : Yong Byeong Chae / Associate manager Company Name : Dogtra Co., Ltd.

Dogtra Co., Ltd. 35, Namdongdong-ro 33beon-gil, Namdong-gu, Incheon 21694 Rep. of KOREA Letter of Declaration Product Equality July 20, 2022 We, as a manufacturer, hereby declare that our product has variant model names as listed below. Variant model is totally same as basic model but it differs in the authentication method that opens the door. Each model differences are described in the below table. Sincerely yours, Yong Byeong Chae / Associate manager Dogtra Co., Ltd. Tel: +82 32 812 2445 E-mail: [email protected] <2702T&B> <2700T&B> <T&B Dual> <STB Beep COLLAR>

External Photos of EUT Model name : 2702T&B Top view of EUT Bottom view of Main PCB Side view of EUT Front view of Main PCB Model name : 2702T&B Adapter

<Bottom view of Main PCB> ※ Due to the small size of the product, FCC warnings a re written in the User Manual.

Internal Photos of EUT Model name : 2702T&B ` Internal view of EUT Top view of PCB Bottom view of Main PCB

Test Report No. : F690501-RF-EMC000655 Page : 2 of 13 EMH7081-01A(2021.04.09)(1) A4(210mm*297mm) Contents 1. General Information ................................................................................................... 4 1.1 Client Information ................................................................................................ 4 1.2 Test Laboratory ................................................................................................... 4 1.3 General Information of E.U.T. ............................................................................. 4 1.4 Operating Modes and Conditions ........................................................................ 4 1.5 Peripheral Equipments ........................................................................................ 4 1.6 Cable List ............................................................................................................ 5 1.7 System Configurations ........................................................................................ 5 1.8 Test System Layout ............................................................................................ 5 1.9 Modifications/Notes ............................................................................................. 5 1.10 Applicable Standards for Testing ...................................................................... 5 1.11 Summary of Test Results .................................................................................. 5 2. Emission Test ............................................................................................................ 6 2.1 Test Results ........................................................................................................ 6 2.2 Test Method and Limits ....................................................................................... 6 2.2.1 Test Method ............................................................................................... 6 2.2.2 Test Limits .................................................................................................. 6 2.3 Conducted Disturbance ...................................................................................... 7 2.3.1 Test Equipments ........................................................................................ 7 2.3.2 Test Site ..................................................................................................... 7 2.3.3 Environment Conditions ............................................................................. 7 2.3.4 Test Results ............................................................................................... 8 2.4 Radiated Emission ............................................................................................ 10 2.4.1 Test Equipments ...................................................................................... 10 2.4.2 Test Site ................................................................................................... 10 2.4.3 Environment Conditions ........................................................................... 10 2.4.4 Test Results ............................................................................................. 11 Appendix A : Measurement Uncertainty ...................................................................... 13 Test Report No. : F690501-RF-EMC000655 Page : 3 of 13 EMH7081-01A(2021.04.09)(1) A4(210mm*297mm) Revision History Revision Report number Description 0 F690501-RF-EMC000655 Initial Test Report No. : F690501-RF-EMC000655 Page : 4 of 13 EMH7081-01A(2021.04.09)(1) A4(210mm*297mm) 1. General Information 1.1 Client Information Applicant Dogtra Co., Ltd. Applicant Address 35, Namdongdong-ro 33beon-gil, Namdong-gu, Incheon, Republic of Korea Manufacturer Dogtra Co., Ltd. Manufacturer Address 35, Namdongdong-ro 33beon-gil, Namdong-gu, Incheon, Republic of Korea 1.2 Test Laboratory Name and Address SGS Korea Co., Ltd. - Giheung Laboratory 35, Giheungdanji-ro 121beon-gil, Giheung-gu, Yongin-si, Gyeonggi-do, Republic of Korea - Gunpo Laboratory 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, 15807, Republic of Korea FCC Registration No. KR0150 Phone + 82 31 548 0710 Fax + 82 31 427 2370 e-mail [email protected] 1.3 General Information of E.U.T. Classification Specification Product Name DOG TRAINING DEVICE Model Name 2702T&B Alt. Model Name 2700T&B, T&B DUAL, STB BEEP COLLAR Model Differences - 2700T&B : No circuit difference with 2702T&B. 2702T&B is two of the EUT in box for sale, 2700T&B is one of the EUT is in box for sale. - T&B DUAL : No receiver circuit difference but transmitter has a difference with 2702T&B. - STB BEEP COLLAR : No circuit difference with 2702T&B. STB BEEP COLLAR is the receiver only in box for sale. Serial No. - EMI Classification Class B Test Voltage AC 120 V, 60 ㎐ Rated Power DC 10 V, 1.5 A Internal Clock Frequency 27.145 ㎒ H/W Version RevNTC S/W Version 2700TB_RxRev10 Function Dogs Remote Training and Beeper Collar 1.4 Operating Modes and Conditions Operating mode Operating Condition 1) Receiving Mode Receiving the signal from 2702T&B(Transmitter) 2) Charging Mode Charged state by AC/DC Adpater. 1.5 Peripheral Equipments Description Model Serial No. Manufacturer Note. DOG TRAINING DEVICE 2702T&B(Transmitter) - Dogtra Co., Ltd. Transmitter Test Report No. : F690501-RF-EMC000655 Page : 5 of 13 EMH7081-01A(2021.04.09)(1) A4(210mm*297mm) 1.6 Cable List Start END Cable Spec. Used core Name I/O Port Name I/O Port Length (m) Shield <Receiving Mode> 2702T&B (Transmitter) - EUT - - - - <Charging Mode> AC Source AC OUT AC/DC Adpater AC IN - - - AC/DC Adpater DC OUT EUT DC IN 1.4 Unshield - 1.7 System Configurations Description Model Serial No. Manufacturer Note AC/DC Adapter MKC-1001500S - Merryking - 19mm Trans - - - - Battery AE562438P6H - AEenergy - EP13 Trans - - - - PCB 2700T&B_RX_NTC Rev1.0 - - - Piezo - - - - 1.8 Test System Layout Test System Layout <Receivin…

Text truncated - open the document above for the full version.

Test setup Photos of EUT Model name : 2702T&B 1. RE test view of EUT 2. CE test view of EUT
