SXO-OLV1Ollie Robotic Gaming System

USER MANUAL 1 Product Information Guide This Important Product Information Guide contains safety, handling, disposal, recycling, and regulatory information as well as the limited warranty for Ollie . Read all safety information and operating instructions before using Ollie to avoid injury or harm. For a downloadable version of the Ollie User and Product Guides, visit www.gosphero.com/manuals. IMPORTANT SAFETY AND HANDLING INFORMATION Read the following warning before you or your child play with Ollie . Failing to do so may cause injury. CAUTION: To reduce the risk of damage or injury, do not attempt to remove Ollie's shell; please refer all non-routine servicing questions to Orbotix. No user-serviceable parts are contained inside. CALIFORNIA PROPOSITION 65 WARNING: THIS PRODUCT CONTAINS CHEMICALS KNOWN TO THE STATE OF CALIFORNIA TO CAUSE CANCER AND BIRTH DEFECTS OR OTHER REPRODUCTIVE HARM. General • Read all safety and operating instructions before operating Ollie. • Retain the safety and operating instructions for future reference. • Follow all operating and use instructions. • Do not attempt to service Ollie yourself. Refer all non-routine servicing to Orbotix. Seizure, Blackouts and Eyestrain A small percentage of people may be susceptible to blackouts or seizures (even if they have never had one before) when exposed to flashing lights or light patterns such as when playing games or watching video. If you have experienced seizures or blackouts or have a family history of such occurrences, you should consult a physician before playing video games or watching videos. Discontinue use of Ollie and your smart device controller and consult a physician if you experience headaches, blackouts, seizures, convulsion, eye or muscle twitching, loss of awareness, involuntary movement, or disorientation. To reduce risk of headaches, blackouts, seizures, and eyestrain, avoid prolonged use, hold your smart device controller some distance from your eyes, use Ollie in a well-lit room, and take frequent breaks. Repetitive Injury When you perform repetitive activities such as playing games on your smart device controller, you may experience occasional discomfort in your hands, arms, shoulders, neck, or other parts of your body. Avoid excessive play. It is recommended that parents monitor their children for appropriate play. Take frequent breaks and if you have discomfort during or after such use, stop use and see a physician. WARNING: Choking Hazards Ollie has small parts inside its shell, which may present a choking hazard to small children and pets. Keep Ollie and its accessories away from small children. Keeping Ollie Within Acceptable Temperatures Operate and store Ollie in a place where the temperature is between 0º and 40º C (32º to 104º F). Low or high-temperature conditions might temporarily shorten battery life or cause Ollie to temporarily stop working properly. Avoid dramatic changes in temperature or humidity when using Ollie, as condensation may form on or within Ollie. Don’t leave Ollie in your car, because temperatures in parked cars can exceed this range. When you’re using Ollie or charging the battery, it is normal for Ollie to get warm. The exterior of Ollie functions as a cooling surface that transfers heat from inside the unit to the cooler air outside. Use and Maintenance WARNING: Ollie is not suitable for use by children under 8 years of age. Never: • Abuse, throw, drop, puncture, violently kick or step on Ollie. This can damage the robot and compromise its safe operation. • Operate Ollie in dangerous, hazardous or public areas where use is not permitted (high voltage power lines, train stations, airports, trains). Check whether use of Ollie is permitted before using it in public areas or public transport. USER MANUAL 2 Always: • Keep Ollie in sight at all times when operating it to avoid injuries or damages to people, animals or property. • Ensure that no one is standing nearer than 1 yard (1 meter) from Ollie when in operation and that you keep a safe distance between the ball and people, animals and property. • Periodically examine Ollie for potential hazards such as cracked, damaged or otherwise broken parts. In the event of such damage, do not use Ollie until it can be replaced or repaired. • Drive Ollie on suitable surfaces. Although Ollie can drive on a variety of surfaces, it works best on smooth, flat and hard surfaces (such as carpet, tile wood floors, and concrete). Battery Warning • Lithium Polymer batteries are extremely hazardous and liable to cause serious injuries to persons or property. The user accepts liability for the use of a Lithium Polymer battery. As the manufacturer and the distributor cannot ensure the battery is used correctly (charging, discharging, storage, etc.), they cannot be held liable for damages caused to persons or property. • In the event of battery leakage, avoid the liquid coming into contact with skin and eyes. In case of contact with the skin, wash copiously with soap and water. In case of contact with the eyes, rinse copiously with cold water and consult a doctor. If you notice a suspicious smell or noise or observe smoke around the charger, disconnect it immediately. • Non-compliance with the instructions below could result in gas being given off, fire, electric shock or an explosion. Charging • Examine the charger regularly for damage to the cord, plug, enclosure or other parts. The toy shall only be used with a transformer for toys. Never use a damaged charger or power adapter. Use only supplied Power Adapter; Model: PA1005-120DIB050 12vDC 500mA if misused can cause electrical shock. • Never charge a leaky battery or one that has been damaged. Do not use the Ollie charger to charge any other battery than the provided rechargeable battery. • Do not charge the battery near inflammable materials or on an inflammable surface (carpet, wooden flooring, wooden furniture, etc.) or conducting surface. Do not leave Ollie unattended during charging.…

Text truncated - open the document above for the full version.

7.11.14 Federal Communications Commission 445 12 th Street SW Washington, DC 20554 Subject: Limited Agency Agreement Re: We, Orbotix Inc, hereby authorized Intertek Testing Services to act as our agent for the purpose of preparing application for FCC ID number SXO-OLV1 under all applicable parts of the FCC rules and regulations. The effective date of this limited agency agreement is 7.11.14. The limited agency agreement expires on 7.11.14 unless sooner terminated or extended by written notice to Intertek Testing Services and the Federal Communications Commission. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. The applicant is not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 U.S.C. 862, and no party to the application is subject to a denial of federal benefits pursuant to that section. If you have any questions or comments, please do not hesitate to contact me. Sincerely,

External Photographs FCC ID: SXO-OLV1 IC: 10016A-OLV1

Internal Photographs FCC ID: SXO-OLV1 IC: 10016A-OLV1 Front of USB PCB Back of USB PCB Motor PCB Main Board Front Main PCB Back

EMC Report for Orbotix, Inc. dba Sphero on Ollie Model Number: 1B01 File: 101691132MPK-002 Page 1 of 55 TEST REPORT Report Number: 101691132MPK-002 Project Number: G101691132 August 07, 2014 Testing performed on Ollie Model: 1B01 FCC ID: SXO-OLV1 IC: 10016A-OLV1 to FCC Part 15 Subpart C (15.247) Industry Canada RSS-210 Issue 8, Annex 8 FCC Part 15, Subpart B Industry Canada ICES-003 For Orbotix, Inc. dba Sphero Test Performed by: Test Authorized by: Intertek 1365 Adams Court Menlo Park, CA 94025 USA Orbotix, Inc. dba Sphero 4772 Walnut St., Suite 206 Boulder, CO 80301 USA Prepared by: Date: August 07, 2014 Minh Ly Reviewed by: Date: August 07, 2014 Krishna K Vemuri This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to copy or distribute this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. This report must not be used to claim product endorsement by A2LA, NIST nor any other agency of the U.S. Government. EMC Report for Orbotix, Inc. dba Sphero on Ollie Model Number: 1B01 File: 101691132MPK-002 Page 2 of 55 Report No. 101691132MPK-002 Equipment Under Test: Ollie Trade Name: Ollie Model Number: 1B01 Serial Numbers: MPK14071809032-002 (Radiated Sample) MPK1407111108-002 (Conducted Sample) Applicant: Orbotix, Inc. dba Sphero Contact: Kate Chouinard Address: Orbotix, Inc. dba Sphero 4772 Walnut St., Suite 206 Boulder, CO 80301 Country USA Tel. Number: (720) 295-7829 Email: [email protected] Applicable Regulation: FCC Part 15 Subpart C (15.247) Industry Canada RSS-210 Issue 8, Annex 8 FCC Part 15, Subpart B Industry Canada ICES-003 Date of Test: July 14 – July 25, 2014 We attest to the accuracy of this report: Minh Ly Project Engineer Krishna K Vemuri EMC Senior Staff Engineer EMC Report for Orbotix, Inc. dba Sphero on Ollie Model Number: 1B01 File: 101691132MPK-002 Page 3 of 55 TABLE OF CONTENTS 1.0 Summary of Tests .......................................................................................................................... 5 2.0 General Information ...................................................................................................................... 6 2.1 Product Description ............................................................................................................ 6 2.2 Related Submittal(s) Grants ................................................................................................ 7 2.3 Test Facility ........................................................................................................................ 7 2.4 Test Methodology ............................................................................................................... 7 2.5 Measurement Uncertainty ................................................................................................... 7 3.0 System Test Configuration ............................................................................................................ 8 3.1 Support Equipment ............................................................................................................. 8 3.2 Block Diagram of Test Setup .............................................................................................. 8 3.5 Mode of Operation during Test........................................................................................... 9 3.5 Modifications Required for Compliance ............................................................................ 9 3.6 Additions, Deviations and Exclusions from Standards ....................................................... 9 4.0 Measurement Results ................................................................................................................... 10 4.1 6-dB Bandwidth and Occupied Bandwidth ...................................................................... 10 4.1.1 Requirement ......................................................................................................... 10 4.1.2 Procedure ............................................................................................................. 10 4.1.3 Test Result ........................................................................................................... 10 4.2 Maximum Peak Conducted Output Power at Antenna Terminals .................................... 17 4.2.1 Requirement ......................................................................................................... 17 4.2.2 Procedure ............................................................................................................. 17 4.3.3 Test Result ........................................................................................................... 17 4.3 Maximum Power Spectral Density ................................................................................... 21 4.3.1 Requirement ......................................................................................................... 21 4.3.2 Procedure ............................................................................................................. 21 4.3.3 Test Result ........................................................................................................... 21 4.4 Unwanted Conducted Emissions .............…

Text truncated - open the document above for the full version.

Setup Photographs FCC ID: SXO-OLV1 IC: 10016A-OLV1 Radiated Emissions (Transmit mode ) Radiated Emissions (Receiver mode and Digital Parts) AC Line Conducted Emissions AC Line Conducted Emissions
