SY5KORX433Remote Keyless Entry System (Receiver)

Continental Automotive Korea Ltd.

Click to zoom

Application Details

Equipment Class: CYY - Communications Receiver used w/Pt 15 Transmitter
Date of Grant: Jan 21, 2013
Application Purpose: Original Equipment
Date of Application: Jan 21, 2013
Equipment Note: Remote Keyless Entry System (Receiver)
Frequency Range: 433.92000000 - 433.92000000
Company: Continental Automotive Korea Ltd.
Country: South Korea

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Continental Automotive I BS PG3 WL Page 1 of 6 User Manual / Functional Description of RF Receiver module Type: SVI-KORX433(433.92MHz) Continental Automotive I BS PG3 WL Page 2 of 6 1. General information This Korean RF Receiver is used for RKE functions on vehicles. The receiver principle is super heterodyne PLL frequency synthesizer and designed for the reception of 1KHz Manchester codes with only FSK signal optimized. The Center frequency are 433.92MHz(5WY8231, NA). This receiver has oriented enhanced RF LNA characteristic to improve RF sensitivity instead of internal LNA part of InfineonTDA 522x provided.(removed internal LNA) The receiver module is best optimized SAW filter, External LNA and 1K data baud filtering for data band spectrum noise characteristic. This receiver has 9 leg’s(1.Antenna input, 2.GND- antenna, 3.LNA- power supply, 4.Vcc-power supply, 5.PWDN, 6.RSSI, 7.DATA-output, 8.GND, 9.MSL) which will be united to SRX PCB by wave soldering.( stick into main PCB by hand). 1.Operating temperature range -40 ºC < T < +85 ºC 2. Technical Data All data is specified at T= 25 °C (RT) and V CC = 5V 3. VCO – Frequency Frequency Variants VCO frequency Tolerance T=-40 ºC to +85 ºC 433.92MHz, 846.44MHz ± 90ppm 4. Input Sensitivity Input sensitivity at center frequency, BER 10 -2 (Vcc=5V)  FSK: fmod = 1 kHz square- wave +/-35KHz deviation. Variants Description Condition Typ min unit 5WY 8231 433.92MHz, FSK,1K FSK ,Fmod=1KHz-110 ≤ -107 dBm Continental Automotive I BS PG3 WL Page 3 of 6 4.1 Sensitivity Variation over temperature 4.2 FSK frequency-deviation Max .FSK deviation F= ±120 kHz Min. FSK deviation 1k variants F = ± 10 kHz For the min. sensitivity, under the degraded Freq-deviation less than 30 KHz, could be allowed within 3dB. 5. Current Consumption; V cc = 5 V (RT) (no RF – signal applied to the receiver input) 5.1 Current consumption  V cc = 5 V,  No RF signal applied at RF input 5.2 Active current (Switching High) with LNA @ T=25ºC (RT): FSK I s < 9.1 mA @T=-40 to +85°C FSK I s < 9.3 mA 5.3 Standby current (switching Low) with LNA @ T=-40 to +85°C I s < 5 μA The power supply is not ESD protected. This protection must be done on the main board (ECU). Sensitivity Variation T=-40 to 85°C: normal sense @ RM ≤ ±3dB Continental Automotive I BS PG3 WL Page 4 of 6 6. Schematic Block diagram 7. Physical Layout information 7.1 I/O pins layout KOR-baby-Rx I/O pin configuration 1- Antenna input 2- GND- antenna 3- LNA- power supply 4- Vcc-power supply 5- PWDN 6- RSSI 7- DATA-output 8- GND 9- MSEL 1 9 <Top side vieww> <Bottom side view> Continental Automotive I BS PG3 WL Page 5 of 6 8. Homologation labelling 8.1 Model name : SVI-KORX433 8.2 USA(433.92MHz) : SY5KORX433 8.3 CANADA(433.92MHz) : 8325A-KORX433 8.4 Homologation statement FCC Compliance Statement. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions : (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interferencethat may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Do Not Any changes or modifications to the equipment not expressly approved by the party responsible for compliance could void user’s authority to operate the equipment. Continental Automotive I BS PG3 WL Page 6 of 6 IC Compliance Statement. Le present appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisee aux deux conditions suivantes : (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioelectrique subi, meme si le brouillage est susceptible d’en compromettre le fonctionnement. This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

Block Diagram

InternalContinental Automotive Systems Corp.I BS PG3 WL Main ECU SVI-KORX433 block-diagram Dec. 26, 2012 1 Author, © Continental AG Dec. 26, 2012 SAW FILTER RECEIVER IC (TDA 5220) Data buffer CERAMIC FILTER 10.7MHz Crystal 13.23MHz RF LNA (Low Noise Amplifier) RF ANT INPUT (433.92MHz) through antenna FSK demodulator RF ANT GND Limiter Mixer Data filterData slicerPeak detector 433.92MHz 13.23MHz 10.7MHz 1KHz (PIN no. 1) (PIN no. 2) (PIN no. 7) (PIN no. 8) GND LNA (PIN no. 3) Vcc (PIN no. 4) PDWN (PIN no. 5) RSSI (PIN no. 6) DATA MSEL (PIN no. 9)

Cover Letter(s)

Continental Automotive Systems 29, Siemens-Road, Ichon-City Corporation Gyeonggi-do, Korea Date: December 17, 2012 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Continental Automotive Systems Corporation, hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project : - Product : Remote Keyless Entry System (Receiver) - Model name : SVI-KORX433 - FCC ID : SY5KORX433 We affirm that between SIEMIC and Continental Automotive Systems Corporation, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This authorization is valid until further written notice from the applicant. Sincerely Yours, Sung-Min Jang /Manager /Continental Automotive

Cover Letter(s)

Continental Automotive Systems 29, Siemens-Road, Ichon-City Corporation Gyeonggi-do, Korea FCC Confidentiality Request Letter Date: December 17, 2012 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia MD 21046 Subject: Permanent Confidentiality Request for FCC ID: SY5KORX433 We hereby request confidential treatment of information accompanying this application as outlined below:  Schematics The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely Yours, Sung-Min Jang /Manager /Continental Automotive Systems Corporation

External Photos

ID Label/Location Info

FCC/IC ID LABEL 1. FCC/IC ID label drawing 2. FCC/IC ID label location Continental Automotive Systems Corporation Model : SVI-KORX433 Made in Korea FCC ID : SY5KORX433 IC : 8325A-KORX433 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

Internal Photos

Test Report

http://www.emc2000.co.kr EMCComplianceLtd.480-5 Sin-dong, Yeongtong-gu, Suwon-city, Gyeonggi-do, 443-390, Korea TEL: 82 31 336 9919FAX: 82 505 299 8311 This test report shall not be reproduced, except in full, without the written approval. FCC ID: SY5KORX433 Report No.: EMC-2013/066 Page: 2 of 22 Contents 1. Applicant information .................................................................................................................................... 3 2. Laboratory information ................................................................................................................................. 4 3. Test system configuration............................................................................................................................... 5 3.1 Operation environment ..................................................................................................................... 5 3.2 Measurement Uncertainty ................................................................................................................. 6 4. Description of E.U.T. ...................................................................................................................................... 7 4.1 General information .......................................................................................................................... 7 4.2 Product description ........................................................................................................................... 7 4.3 Auxiliary equipments ........................................................................................................................ 7 4.4 Test configuration ............................................................................................................................. 8 4.5 Operating conditions......................................................................................................................... 8 5. Summary of test results .................................................................................................................................. 9 5.1 Summary of EMI emission test results ............................................................................................. 9 6. Test results ..................................................................................................................................................... 10 6.1 Radiated Emission .......................................................................................................................... 10 7. E.U.T. photographs ....................................................................................................................................... 14 http://www.emc2000.co.kr EMCComplianceLtd.480-5 Sin-dong, Yeongtong-gu, Suwon-city, Gyeonggi-do, 443-390, Korea TEL: 82 31 336 9919FAX: 82 505 299 8311 This test report shall not be reproduced, except in full, without the written approval. FCC ID: SY5KORX433 Report No.: EMC-2013/066 Page: 3 of 22 1. Applicant information Applicant:Continental Automotive Systems Corporation Address:29, Siemens-Road, Icheon-City, Gyeonggi-Do, 467-080, Korea Telephone:+82-31-645-4864 Fax:+82-31-637-0371 E-mail:[email protected] Contact name:Jang Sung Min Manufacturer:Continental Automotive Systems Corporation Address:29, Siemens-Road, Icheon-City, Gyeonggi-Do, 467-080, Korea Telephone:+82-31-645-4864 Fax:+82-31-637-0371 E-mail:[email protected] Contact name:Jang Sung Min http://www.emc2000.co.kr EMCComplianceLtd.480-5 Sin-dong, Yeongtong-gu, Suwon-city, Gyeonggi-do, 443-390, Korea TEL: 82 31 336 9919FAX: 82 505 299 8311 This test report shall not be reproduced, except in full, without the written approval. FCC ID: SY5KORX433 Report No.: EMC-2013/066 Page: 4 of 22 2. Laboratory information Address EMC compliance Ltd. 480-5 Sin-dong, Yeongtong-gu, Suwon-city, Gyeonggi-do, 443-390, Korea Telephone Number: 82 31 336 9919 Facsimile Number: 82 505 299 8311 FCC CAB.: KR0040 VCCI Registration No.: R-3327, G-198, C-3706, T-1849 Industry Canada Registration No.: 8035A KOLAS NO.: 231 SITE MAP EMCcompliance Suwon city http://www.emc2000.co.kr EMCComplianceLtd.480-5 Sin-dong, Yeongtong-gu, Suwon-city, Gyeonggi-do, 443-390, Korea TEL: 82 31 336 9919FAX: 82 505 299 8311 This test report shall not be reproduced, except in full, without the written approval. FCC ID: SY5KORX433 Report No.: EMC-2013/066 Page: 5 of 22 3. Test system configuration 3.1 Operation environment TemperatureHumidityPressure Chamber(10ｍ): 22 °C30 % R.H.- Test site These testing items were performed following locations; Test itemTest site Conducted EmissionShielded Room Radiated Emission 10ｍChamber http://www.emc2000.co.kr EMCComplianceLtd.480-5 Sin-dong, Yeongtong-gu, Suwon-city, Gyeonggi-do, 443-390, Korea TEL: 82 31 336 9919FAX: 82 505 299 8311 This test report shall not be reproduced, except in full, without the written approval. FCC ID: SY5KORX433 Report No.: EMC-2013/066 Page: 6 of 22 3.2 Measurement Uncertainty All measurements involve certain levels of uncertainties, especially in field of EMC. The factors contributing to uncertainties are test receiver, cable loss, antenna factor calibration, Antenna directivity, antenna factor variation with height, antenna phase center variation, antenna frequency interpolation, measurement distance variation, site imperfection, mismatch, and system repeatability. Based on CISPR 16-4-2, the measurement uncertainty level with a 95 % confidence level was applied. Conducted emission measurement (C.L: Approx 95 %, k = 2) Shielded Room (CE#1) 9㎑~ 150㎑: ± 3.82㏈ 150㎑~ 30㎒: ± 3.43㏈ Shielded Room (CE#2) 9㎑~ 150㎑: ± 3.82㏈ 150㎑~ 30㎒: ± 3.43㏈ Shielded Room (CE#3) 9㎑~ 150㎑: ± 4.00㏈ 150㎑~ 30㎒: ± 3.63㏈ Radiated Emission measurement (C.L: Approx 95 %, k = 2) 10ｍChamber (#F4) 30㎒~ 300㎒ 3 m: + 4.56㏈, - 4.58㏈ 10 m: + 4.56㏈, - 4.56㏈ 300㎒~ 1 000㎒ 3 m: + 4.84㏈, - 4.85㏈ 10 m: + 4.71㏈,…

Text truncated - open the document above for the full version.

Test Setup Photos
