SYAICR04Hand-held RFID reader for ISO tags with Bluetooth

Authorized Agent: Radiometrics Midwest Corporation (815) 293-0772 – [email protected] Block Diagram FCC ID: SYAICR04

Authorized Agent: Radiometrics Midwest Corporation (815) 293-0772 – [email protected] Confidentiality Letter FCC ID: SYAICR04

Authorized Agent: Radiometrics Midwest Corporation (815) 293-0772 – [email protected] External EUT Photographs FCC ID: SYAICR04 External View of Cane Reader Front View of Cane Reader Display

Authorized Agent: Radiometrics Midwest Corporation (815) 293-0772 – [email protected] ID Label/Location FCC ID: SYAICR04 • Material is to be permanent mylar • Text to be Black with Clear background • Adhesive to be permanent PSA adhesive • Size to be 1 x 2 inches The FCC Label as illustrated below will be located on the side of the circuit box above the handle. The label will be on the left side of circuit box when facing the display. The manual will contain a paragraph explaining the applicable FCC rules. Drawing of label - I.D.ology - FCC ID: SYAICR04 IC: 5678A-ICR04 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. and (2) This device must accept any interference received, including interference that may cause undesired operation. Serial Number: XXXXXXXX Made in USA

FCC Label Location

Radiometrics Midwest Corporation (815) 293-0772 – [email protected] Operational Description FCC ID: SYAICR04 This wireless reader handles most functions in an intuitive manner so that the same button that turns on the reader also links the wireless Bluetooth™ connection and activates the antenna to read, display, and store or transmit all tags. The EUT is an ISO reader; it reads all RFID tags, which are in compliance with the animal ISO 11784- 11785 protocol. The I.D.ology ISO-Cane Reader is a Class 1 unit that has a transmission link range of 330 feet. Even more important is that the ISO-Cane links automatically when power is applied and it can be deployed either as a point-to-point or a point-to-multipoint solution. The 134 kHz RFID reader is on CW for 60 mS and off for 20 mSec. The Antennas are inside the EUT and are permanently installed inside the EUT. Specifications RFID Reader Operating Frequency 134.2 kHz RFID Tag Protocol ISO 11784 & ISO 11785 Compliant tags RFID RF Power Ouput 0.4 Watts Bluetooth Transmission Carrier Frequency 2.4 to 2.4835 Giga Hertz hopping Bluetooth™ frequency Bluetooth Modulation Method GFSK, 1Mbps, 0.5BT Gaussian Bluetooth Transmission Power Class 1 (max 20dBm) SPP compatible Bluetooth Hopping 1600 hops/sec, 1MHz channel Bluetooth Receiving Signal Range -84 to -20dBm Bluetooth Receiving IF Frequency 1.5 MHz center frequency Physical Characteristics Length 16”-43” depending on options Width 3.5” Height 9” Weight 2 lbs to 3 lbs depending on options Environmental Characteristics Operating Temperature -10º to 75º C (+14º to +165º F) LCD Display stops functioning at 0º C but reader and link still work. Storage Temperature -20º to 75º C (-4º to +165º F) Relative Humidity 5% to 95% (non-condensing) Rain & Dust Resistance IP-64 compliant Drop Spec. Withstands 4’ drop 15 times onto concrete Power Battery Type Ni Metal Hydride 7.5v, (5 x 2000 mAh cells) Battery Life 12 to 18 hours, application dependant Recharging Time: 4 hours

Radiometrics Midwest Corporation (815) 293-0772 – www.radiomet.com Page 1 of 28 Electromagnetic Compatibility Test Report Tests Performed on an I.D.-ology Handheld RFID Reader, Model ISO Cane Reader Radiometrics Document RP-5399 Product Detail: FCC ID: SYAICR04 Equipment type: Low power Transmitter Test Standards: US CFR Title 47, Chapter I, FCC Part 15 Subpart C FCC Part 15 CFR Title 47: 2004 Industry Canada RSS-210, Issue 5 as required for Category I Equipment This report concerns: Original Grant for Certification FCC Part 15.247 & 15.209 Tests Performed For: Test Facility: I.D.-ology 1324 West Clairemont Ave. Eau Claire, WI 54701 Radiometrics Midwest Corporation 12 East Devonwood Romeoville, IL 60446 Phone: (815) 293-0772 e-mail: [email protected] Test Date(s): (Month-Day-Year) Jan 19 to Feb 10, 2005 Document RP-5399 Revisions: Rev. Issue Date Affected Pages Revised By Authorized Signature for Revision 0 February 15, 2005 1 March 1, 2005 3, 10-12, 14 Joseph Strzelecki RADIOMETRICS MIDWEST CORPORATION - EMC Test Report Testing of the I.D.-ology, Model ISO Cane Reader, Handheld RFID Reader for Animal ISO Tags RP-5399 Rev. 0 Page 2 of 28 Table of Contents 1 ADMINISTRATIVE DATA........................................................................................................................3 2 TEST SUMMARY AND RESULTS.........................................................................................................3 2.1 RF Exposure Compliance Requirements.......................................................................................4 3 EQUIPMENT UNDER TEST (EUT) DETAILS.......................................................................................4 3.1 EUT Description..............................................................................................................................4 3.2 Related Submittals..........................................................................................................................4 4 TESTED SYSTEM DETAILS.................................................................................................................4 4.1 Tested System Configuration..........................................................................................................4 4.2 Special Accessories........................................................................................................................4 4.3 Equipment Modifications..................................................................................................................5 5 TEST SPECIFICATIONS AND RELATED DOCUMENTS....................................................................5 6 RADIOMETRICS’ TEST FACILITIES.....................................................................................................5 7 DEVIATIONS AND EXCLUSIONS FROM THE TEST SPECIFICATIONS............................................5 8 CERTIFICATION....................................................................................................................................6 9 TEST EQUIPMENT TABLE...................................................................................................................6 10 TEST SECTIONS................................................................................................................................6 10.1 AC Conducted Emissions; Section 15.207...................................................................................6 10.2 Carrier Frequency Separation.......................................................................................................8 10.3 Number of Hopping Frequencies...................................................................................................9 10.4 Time of Occupancy (Dwell Time)...............................................................................................10 10.5 Occupied Bandwidth (20 dB)......................................................................................................12 10.6 Peak Output Power.....................................................................................................................14 10.7 Band-edge Compliance of RF Conducted Emissions................................................................15 10.8 Spurious RF Conducted Emissions............................................................................................17 10.9 Spurious Radiated Emissions (Restricted Band).......................................................................23 10.9.1 Radiated Emissions Field Strength Sample Calculation......................................................24 10.9.2 Spurious Radiated Emissions Test Results (Restricted Band)...........................................25 10.10 Magnetic Field Measurements and Decay Factor Calculations................................................27 10.10.1 Magnetic Field Radiated Emissions Results (0.009 to 30 MHz)........................................27 10.11 Card Reader Occupied Bandwidth (20 dB)..............................................................................28 Notice: This report must not be reproduced (except in full) without the written approval of Radiometrics Midwest Corporation. RADIOMETRICS MIDWEST CORPORATION - EMC Test Report Testing of the I.D.-ology, Model ISO Cane Reader, Handheld RFID Reader for Animal ISO Tags RP-5399 Rev. 0 Page 3 of 28 1 ADMINISTRATIVE DATA Equipment Under Test: An I.D.-ology, Handheld RFID Reader for Animal ISO Tags Model: ISO Cane Reader; Serial Number: None This will be referred to as the EUT in this Report Date EUT Received at Radiometrics: (Month-Day-Year) Test Date(s): (Month-Day-Year) Jan 19, 2005 Jan 19 to Feb 10, 2005 Test Report Written By: Test Witnessed By: Joseph Strzelecki Senior EMC Engineer The tests were not witnessed by I.D.-ology Radiometrics’ Personnel Responsible for Test: Test Report Approved By Joseph Strzelecki Senior EMC Engineer NARTE EMC-000877-NE Chris W. Carlson Director of Engi…

Text truncated - open the document above for the full version.

Authorized Agent: Radiometrics Midwest Corporation (815) 293-0772 – [email protected] Test Setup Photographs FCC ID: SYAICR04 Photograph of Radiated Emissions Test Setup Authorized Agent: Radiometrics Midwest Corporation (815) 293-0772 – [email protected] Photograph of Conducted Emissions Test Setup Photographs of Antenna Conducted Emissions Test Setup Authorized Agent: Radiometrics Midwest Corporation (815) 293-0772 – [email protected]
