SZ890BT2Irrigation Controller

Series 61XXX Battery Operated Irrigation Controller Installation and Operating Instructions Main Features (Not including "S" series*): • Independent programming of each individual valve • Weekly or cyclical programming • Up to 4 operations per day in weekly program mode • Irrigation duration 1 minute to 12 hours • Irrigation frequency starts from one day to once every thirty days in a cyclical program • Waterproof (IP68) • Rain off sensor option • Weather resistant • Irrigation duration modifiable as a function of percentage entered • Operation of one to 6 valves and a master valve • Computerized "manual" operation of individual valves • Sequential "manual" operation • Batteries: 9V alkaline batteries (not included) • Operation temperature -10° to 70° * "S" series features are detailed in chapter 8 2 Table of contents 1. Parts Identification 4 2. Manual-Mechanical Operation 4 3. Installing the controller in the irrigation system 5 3.1 Battery lnstallation 4. System Installation 6 4.1 Installing on the solenoid 4.2 Installing on the wall 4.3 Wiring the solenoids 4.4 Wiring the Solenoids 5. Programming the Irrigation Controller 10 5.1 Setting the Current Time and Day of the Week 5.2 Switching between AM/PM and 24 Hours Time Format 5.3 Valve Selection 5.4 Setting the Irrigation Duration 5.5 Selecting Days of the Week for Irrigation 5.6 Setting Irrigation Start Times 5.7 Example: Programming a Weekly Irrigation Schedule 6. Additional Functions 16 6.1 One-Time Irrigation 6.2 cyclical Irrigation 6.3 Setting the Day of the Week and Time For Cyclical and One- Time Irrigation Programs 6.4 Example: Programming a Cyclical Irrigation Schedule 6.5 ”Manual” Irrigation System Operation via the Irrigation Controller 6.6 Sequential “Manual” Operation of all the Valves 6.7 Suspension 6.8 Irrigation Duration Extended or Shortened by a Specified Percentage 3 7. Additional Displays 21 7.1 Valve in Wait Mode 7.2 Blinking Low Battery Warning 7.3 Permanent low battery warning 7.4 Missing Program Data 7.5 Sensor 8. Additional Instructions for “S” Series DC-1S, DC-4S, DC-6S 24 8.1 Irrigation Window In the Cyclical Program Mode 8.2 Opening an Irrigation Window after Start Time has passed 8.3 Sensor 9. Maintenance, Troubleshooting and Repairs 27 10. Additional Accessories and Products 28 10.1 General 10.2 Two-way (2W) Controllers 11. Limited warranty certificate 30 12. FCC WARNING ..................................................................31 4 5 1. Parts Identification 1. Cover 2. Controller display 3. push buttons 4. Adaptor 5. Solenoid 6. Mechanical operation lever 7. Hydraulic valve 8. Battery compartment cover 2. Manual-Mechanical Operation The irrigation valve can be opened and closed independent of the controller's operation by mechanical opening lever. Manual operation is useful when immediate irrigation is required, and the controller is not assembled yet. The lever has 3 positions: 1. AUTO – Mid position 2. CLOSE - Rotating clockwise 3. OPEN - Rotating counter clockwise NOTE - In normal working conditions, the lever should be in AUTO position. 6 3. Installing the controller in the irrigation system 3.1 Battery lnstallation a. Open the battery compartment cover (1). b. lnsert 9V batteries - (1 or 2, depends on model) (2). NOTE - AII the controller display elements appears briefly at the display, followed by a blinking "12:00". The controller is now ready to be programmed. Make sure to locate the battery compartment cover with the grip (see drawing) and then rotate the cover 1/8 of a turn to the right. Be sure to do so otherwise the battery cover pins might break. 7 4. System Installation The controller can be installed on the solenoid or on the wall. 4.1 Installing on the solenoid Place the controller (1) on the adaptor. Locate the solenoid adaptor (2) on top of the solenoid (3). Verify "Click" sound. NOTE - Assembly of a filter upstream of the valve is mandatory! 7 4.2 Installing on the wall a. Place the mounting plate (1) on the wall using 3 screws (2) not included. b. Remove bracket (3) from controller and slide onto the mounting plate. c. Press the controller (4) to the bracket. 8 4.3 Wiring the solenoids - 2 wires NOTE - Each zone requires a dedicated pair of wires from the controller. The controllers have red and black pairs of wires numbered for each valve. Notice there are 2 extra sets of wires. One set of wires (black and red) is stamped with the letter M representing the master valve, and one set of wires (yellow) with the letter S representing the rain sensor connection. Connect each of the controller wire sets (each with red and black) to each solenoid wire (red and black). Connect the red wire from the controller to the red wire on the solenoids and each of the black wires from the controller to each black wire on the solenoids using waterproof connectors. NOTE - If you install a master valve, it will open automatically with each valve. No special programming needed. NOTE - Do not strip the master valve or sensor wires unless using master valve or rain sensor. 9 4.4 Wiring the Solenoids - 3 wires ln the DC controllers connect the valves to the cables emerging from the controller according to the illustration and explanation below. Labeled cables (1) emerge from the controller. The end of each cable is protected by a cover that must be removed prior to connecting the cable. The cables are specifically designed to connect to Galcon DC type irrigation valves and solenoids (3). NOTE- The controller and its connections are waterproof. To safeguard the waterproof characteristics, compliance with the following is essential: • Do not remove protective covers from cables that are not connected to valves. Exposed cable ends can short-circuit with each other, with conducting bodies and in water. • Connect the cables to the valves (3) using the special waterproof connectors (2) supplied with the product. See illustration. 1. Cut away the covering from the controller cable (1) near the end of the cab…

Text truncated - open the document above for the full version.

Galcon Bakarim Agricultural Cooperative Society, Ltd Statement Galcon Bakarim Agricultural Cooperative Society, Ltd Product: Irrigation Controller FCC ID: SZ890BT2 Model: 6104BT2, TAMAR – Is Marketed as Series 61XXX(BT)X (TAMAR is internal name) All models are all identical in interior structure, electrical circuits and components, and just model names and color are different for the marketing requirement. Your assistance on this matter is highly appreciated. Yours sincerely, signature : name / title : Bari Anvi / Electronics Engineer Contact information / address: Kibbutz Kfar Blum 1215000 Israel

C5266091_X8_Ed.1 1/1 Letter of Authorization Galcon Bakarim Agricultural Cooperative Society, Ltd Company: Galcon Bakarim Agricultural Cooperative Society, Ltd Address: Kibbutz Kfar Blum 1215000 Israel Product Name: Irrigation Controller Model Number: 6104BT2, TAMAR – Is Marketed as Series 61XXX(BT)X (TAMAR is internal name) FCC Identifier: SZ890BT2 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Bari Anvi Date: 2021.3.8 Title: Electronics Engineer Signature of applicant:

C5266091_X10_Ed.1 1/1 Galcon Bakarim Agricultural Cooperative Society, Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2021-3-8 Subject: Request for Confidentiality FCC ID: SZ890BT2 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality ID Label/Location No No Attestation Statement No No External Photos No Block Diagram Schematics Test Report No No Test Setup Photos No User’s Manual Internal Photos Parts List / Tune Up RF Exposure Info Operational Description Cover Letter(s) No No SDR Software / Security Info No Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Bari Anvi Title: Electronics Engineer

Galcon Kfar Blum 1215000 Israel Made in Israel TYPE: 6104BT2 FCC ID: SZ890BT2 Battery power:9VDC Alkaline This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. manufacture: Galcon Bakarim Agricultural Cooperative Society, Ltd

antenna BT RF chipset location

Report No.: TW2009310E File reference No.: 2020-12-16 Applicant: Galcon Bakarim Agricultural Cooperative Society, Ltd Product: Irrigation Controller Model No.: 6104BT2, TAMAR – Is Marketed as Series 61XXX(BT)X (TAMAR is internal name) Brand Name: N/A Test Standards: FCC Part 15.249 Test result: It is herewith confirmed and found to comply with the requirements set up by ANSI C63.4&FCC Part 15 Subpart C, Paragraph 15.249 regulations for the evaluation of electromagnetic compatibility Approved By Jack Chung Manager Dated: December 16, 2020 Results appearing herein relate only to the sample tested The technical reports is issued errors and omissions exempt and is subject to withdrawal at SHENZHEN TIMEWAY TESTING LABORATORIES Zone C, 1st Floor, Block B, Jun Xiang Da Building, Zhongshan Park Road West, Tong Le Village, Nanshan District, Shenzhen, China Tel (755) 83448688, Fax (755) 83442996, E-Mail:[email protected] Report No.: TW2009310E Page 2 of 43 Date: 2020-12-16 The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the SHENZHEN TIMEWAY TESTING LABORATORIES. It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the SHENZHEN TIMEWAY TESTING LABORATORIES. to his customer. Supplier or others persons directly concerned. SHENZHEN TIMEWAY TESTING LABORATORIES. will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The SHENZHEN TIMEWAY TESTING LABORATORIES. reserves the rights to withdraw it and to adopt any other remedies which may be appropriate. Special Statement： The testing quality ability of our laboratory meet with "Quality Law of People's Republic of China" Clause 19. The testing quality system of our laboratory meet with ISO/IEC-17025 requirements, which is approved by CNAS. This approval result is accepted by MRA of APLAC. Our test facility is recognized, certified, or accredited by the following organizations: CNAS-LAB Code: L2292 The EMC Laboratory has been assessed and in compliance with CNAS-CL01 accreditation criteria for testing Laboratories (identical to ISO/IEC 17025:2005 General Requirements) for the Competence of testing Laboratories. FCC-Registration No.: 744189 The EMC Laboratory has been registered and fully described in a report filed with the (FCC) Federal Communications commission. The acceptance letter from the FCC is maintained in our files. Registration No.: 744189. Industry Canada (IC) —Registration No.:5205A The EMC Laboratory has been registered by Certification and Engineering Bureau of Industry Canada for radio equipment testing with Registration No.: 5205A. A2LA (Certification Number:5013.01) The EMC Laboratory has been accredited by the American Association for Laboratory Accreditation (A2LA). Certification Number:5013.01 Report No.: TW2009310E Page 3 of 43 Date: 2020-12-16 The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the SHENZHEN TIMEWAY TESTING LABORATORIES. It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the SHENZHEN TIMEWAY TESTING LABORATORIES. to his customer. Supplier or others persons directly concerned. SHENZHEN TIMEWAY TESTING LABORATORIES. will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The SHENZHEN TIMEWAY TESTING LABORATORIES. reserves the rights to withdraw it and to adopt any other remedies which may be appropriate. Test Report Conclusion Content 1.0 General Details ............................................................................................. 4 1.1 Test Lab Details............................................................................................. 4 1.2 Applicant Details.............................................................................................. 4 1.3 Description of EUT .......................................................................................... 4 1.4 Submitted Sample............................................................................................. 4 1.5 Test Duration................................................................................................... 4 1.6 Test Uncertainty................................................................................................ 4 1.7 Test By......................................................................................................... 5 2.0 List of Measurement Equipment......................................................................... 6 3.0 Technical Details.......................................................................................... 7 3.1 Summary of Test Results.................................................................................... 7 3.2 Test Standards................................................................................................. 7 4.0 EUT Modification............................................................................................. 7 5.0 Power Line Conducted Emission Test..................................................................... 8 5.1 Schematics of the Test....................................................................................... 8 5.2 Test Method and Test Procedure............................................................................ 8 5.3 Configuration of the EUT.........................…

Text truncated - open the document above for the full version.
