SZAOSI911PIIEmergency Helper Dialer (Transmitter)

PLEASE READ CAREFULLY Contents. Pg. 2 *Features, Emergency Dialer Components, and DISCLAIMER Pg. 3 *Precautions and Maintenance Pg. 4 *Names and Functions of each part Pg. 5 *Installation and Functioning test of the main unit Pg. 6 *Procedure for storing phone numbers and recording messages Pg. 7 *Procedure for storing phone numbers and recording messages continued Pg. 8 *Retrieving the setting contents, Description of Quick Function commands Pg. 9 *Operation Directions for 2 Way Communication Pg. 10 *Testing and Replacing Battery Pg. 11 * Specifications and Approvals Pg. 12 *Warranty and contact details 1 Features Congratulations, you have purchased a high quality Emergency Help Dialer (EHD) which is easy to program and lets you call for help when you cannot dial the phone yourself. When you are in need of help, gently, but firmly push the two red panic buttons of the wireless EHD pendant. Using your existing telephone line, the console when activated will receive the signal and dial up to 5 pre- set phone numbers and play the message you have recorded. If a call is not answered, then the console will sequentially move on to dialing the next number, until all 5 numbers have been called. On the unlikely event that none of the numbers called have answered the console will repeat this sequence once more. When a call is answered the receiver will hear your pre recorded voice message requesting immediate assistance. The console is programmed to recognize that the call is being answered by a live person. Emergency Dialer Components: 1. One main dialing console 2. One Wireless Waterproof Pendant 3. One AC/DC adaptor 4. One modular line cord 5. One rechargeable 9 volt battery 6. One plastic necklace 7. One wrist band 8. One owner’s manual Disclaimer: Under no circumstances should this Emergency Help Dialer (EHD) be solely relied upon in life threatening circumstances. Using EHD completely indemnifies the Manufacturer and/or its selling agents from any legal action for whatever reason. 2 Precautions & Maintenance 1. To reduce the risk of electric shock do not remove cover or back of the console. 2. Keep the product from being installed at places liable to dirt, high temperature, moisture and sun exposure, avoid heavy blows or dropping. 3. The placement of the main unit is closely related to its receiving range. To attain the best efficiency of application, try to avoid placing the main unit on electrical appliances (such as TV sets, computers, motors) as well as metal cabinets. It is also in appropriate to place it in the comer or on the floor. 4. This unit calls out and plays the message through a regular telephone set. If the telephone set has both Tone I Pulse dialing types, set it to "Tone". 5. Dialer will not work with a cordless phone that requires an AC adaptor when their is a power outage. You must use regular phone. 6. To have the surveillance feature, an answering machine will not operate or be able to receive any incoming messages. This is only for incoming calls and does not affect the 2 way communication on out going calls during the emergency operational phase. You can answer your phone during the ringing. I t will stop ringing after 5th ring and the surveillance mode will take affect. 3 Continued 4. Procedures for recording messages Procedure: * key + 6 key Message 20 seconds # key (1) Pick up the handset of the telephone that is connected to the dialer. Be Prepared to speak into the handset. (2) Press the "* " key and the number "6" key. You will hear a beep sound. Begin recording immediately after the beep. The recording time is 20 seconds. After completing the message recording, press the "#" key to confirm. The messages can be changed anytime based on the actual needs. Sample message: This is (your name) this is a medical emergency. Please send help. I live at (your Full address and apartment number (if applicable) and any other information that will be helpful in finding your address). Let the party know where your key is. For 2 way communication press the "*"' key and begin speaking, and to end call press the "#" key. 5. How to check your messages Press the "*" key and the number "7" key. Wait for a beep sound. Your message will be heard through the telephone handset after the beep. 6. Setting the password Procedures: * key + 8 key Password (4 digits) # key Example: If the password is 1234, press the "* " key first, then press the number "8" key, then press number 1 and 2 and 3 and 4 (4 digits) keys. Then press the "#" key to end. 7. Setting the time for two way hands-free voice communication Setting time is from 1 minute to 9 minutes. * key + 9 key minutes(1-9) # key Example: If the time is to be 3 minutes, press the "* '' key first, then press the number "9" key, then press the number "3" key, then press the "#" key to end. 7 Operation Directions 1. Application for an in-house call If you want to call upon someone inside of your home, push the "Call" (Yellow Button) on the wireless help caller. The dial console will give off a loud beep sound. 2. Application for an emergency call When there is an emergency and you need help, push both left and right red buttons together on the wireless help caller or push "Panic" button on the main unit for at least one second. This will activate the main unit dialer, and the dialer will dial out the emergency pre programmed numbers.. 3. Application for canceling an emergency call In case of mistaken informing or intended to cancel the emergency calling, just push the "Call" (Yellow Button) on the wireless help caller or push the "Panic" button on the main unit, and the main unit will stop the alarm right away. 4. Application for house surveillance If you intend to check the situation at home from outside, call your home phone number. The main unit will answer your call automatically after 5 rings. After your call has been answered by the main unit, it will make ten beep sounds. You must enter your 4 digit password within the ten beep soun…

Text truncated - open the document above for the full version.

910805 3 Outsource Industries, Inc. 10F/1, No. 175 Min Sheng E. Rd. Taipei, Taiwan R.O.C. Federal Communications Commission FCC ID: SZAOSI911PII Dear Sir: In accordance with 47 C.F.R. Section 0.459, we would like to request confidentiality on some exhibits we submitted for above application for the reason of trade secret. If those exhibits are available for public inspection, any person who once gets the information contained in those exhibits will be able to design and to make the same products very easily. This is a very serious problem and huge loss for us, because we did invest so much on it. Please be not made the Exhibit Types listed below routinely available for public inspection: Block Diagram and Schematics. By: By: Aaron Shrenker (Signature) (Printed) Title : President Applicant : Outsource Industries, Inc. Address : 10F/1, No. 175 Min Sheng E. Rd. Taipei, Taiwan R.O.C. Tel : 886-2-27568016 Fax: 886-2-27648940 Date : Feb. 1, 2005

1 Helen Zhao To:SS Cc:iris Subject:RE: Outsource Industries, Inc., FCC ID: SZAOSI911PII, Assessment NO.: AN05T4617, Notice#1 -----Original Message----- From: SS Sent: Thursday, March 17, 2005 1:13 AM To: Helen Zhao Cc: R00/??? Subject: Re: Outsource Industries, Inc., FCC ID: SZAOSI911PII, Assessment NO.: AN05T4617, Notice#1 Dear Helen, #1: Attached please find revised test report and schematics. The 433 MHz shown on the original schematics means the relating value for European version. For US the frequency is 315MHz only. #2: Attached please find revised confidentiality letter. Best regards, S. S. Liou -----Original Message----- From: Compliance Certification Services [mailto:[email protected]] Sent: Friday, March 04, 2005 11:30 AM To: Helen Zhao Subject: Outsource Industries, Inc., FCC ID: SZAOSI911PII, Assessment NO.: AN05T4617, Notice#1 Question #1: The schematic diagram shows both 315 MHz and 433MHz. The test plots also shows"CF step 433.572MHz", please explain what is the 433MHz for. Question #2: Confidentiality requests must reference Section 0.459 at a minimum because this section provides the authority for such a request. Referencing Section 0.457 is not mandatory but it is suggested because this section lists what information is normally held confidential in equipment authorization filings. Please revise your confidentiality letter accordingly. Best Regards, Helen Zhao The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to 2 the e-mail address listed below the name of the sender.

ETC Report No.:ET94R-01-094-01 FCC ID.: SZAOSI911PII Rev. No 1.0 CONSTRUCTED PHOTOS of EUT Front View of EUT Rear View of EUT

THIS DEVICE COMPLIES WITH PART 15 OF THE FCCRULES. OPERATIONS IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: ( 1 ) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND ( 2 ) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFEERENCE THAT MAY CAUSE UNDESRIED OPERATION Model : 911II FCC ID. : SZAOSI911PII 32mm 21mm

ETC Report No.:ET94R-01-094-01 FCC ID.: SZAOSI911PII Rev. No 1.0 CONSTRUCTED PHOTOS of EUT Internal View of EUT ETC Report No.:ET94R-01-094-01 FCC ID.: SZAOSI911PII Rev. No 1.0 CONSTRUCTED PHOTOS of EUT Component View of Main PCB Solder View of Main PCB

Specification and Approvals 1. Main console supply 12VDC plug adaptor/500mA 2. Console battery 9 volt Rechargeable battery 3. Wireless pendant operation range approximately 120 Feet in open space. The distance can vary in certain environments. The operation frequency is 315MHz.

Rev. No 1.0 FCC Part 15 EMI TEST REPORT of E.U.T. : EMERGENCY HELP DIALER (Transmitter) FCC ID. : SZAOSI911PII MODEL : 911II Working Frequency : 315MHz for APPLICANT : Outsource Industries, Inc. ADDRESS : 10F/1, No. 175 Sec. 5 Min Sheng E. Rd. Taipei, Taiwan R.O.C. Test Performed by ELECTRONICS TESTING CENTER, TAIWAN NO. 34, LIN 5, DING FU TSUN, LINKOU HSIANG TAIPEI HSIEN, TAIWAN, R.O.C. Tel : (02)26023052 Fax : (02)26010910 http://www.etc.org.tw ; e-mail: [email protected] Report Number : ET94R-01-094-01 ETC Report No.:ET94R-01-094-01 FCC ID.: SZAOSI911PII Rev. No 1.0 TEST REPORT CERTIFICATION Applicant : Outsource Industries, Inc. 10F/1, No. 175 Sec. 5 Min Sheng E. Rd. Taipei, Taiwan R.O.C. Manufacturer : HOMPET ENTERPRISE CO., LTD. No. 24, Alley 5, Lane 289, Chwang Ching Rd., Taipei, Taiwan, R.O.C. Description of EUT : a) Type of EUT : EMERGENCY HELP DIALER (Transmitter) b) Trade Name : HOMPET c) Model No. : 911II d) FCC ID : SZAOSI911PII e) Working Frequency : 315MHz f) Power Supply : DC 12V, 500mA Regulation Applied : FCC Rules and Regulations Part 15 Subpart C (2003) I HEREBY CERTIFY THAT; The data shown in this report were made in accordance with the procedures given in ANSI C63.4 and the energy emitted by the device was founded to be within the limits applicable. I assume full responsibility for accuracy and completeness of these data. Note : 1. The results of the testing report relate only to the items tested. 2. The testing report shall not be reproduced except in full, without the written approval of ETC. Issued Date : Feb. 23, 2005 Test Engineer : ( Mic Chen ) Approve & Authorized Signer : Will Yauo, Manager EMC Dept. II of ELECTRONICS TESTING CENTER, TAIWAN ETC Report No.:ET94R-01-094-01 FCC ID.: SZAOSI911PII Rev. No 1.0 Table of Contents Page 1. GENERAL INFORMATION.....................................................................................................................................................1 1.1 PRODUCT DESCRIPTION...........................................................................................................................................................1 1.2 CHARACTERISTICS OF DEVICE................................................................................................................................................1 1.3 TEST METHODOLOGY..............................................................................................................................................................1 1.4 TEST FACILITY..........................................................................................................................................................................1 2. DEFINITION AND LIMITS.......................................................................................................................................................2 2.1 DEFINITION................................................................................................................................................................................2 2.2 RESTRICTED BANDS OF OPERATION.....................................................................................................................................2 2.3 LIMITATION...............................................................................................................................................................................2 2.4 LABELING REQUIREMENT.......................................................................................................................................................4 2.5 USER INFORMATION.................................................................................................................................................................4 3 SYSTEM TEST CONFIGURATION.........................................................................................................................................5 3.1 JUSTIFICATION..........................................................................................................................................................................5 3.2 DEVICES FOR TESTED SYSTEM...............................................................................................................................................5 4. RADIATED EMISSION MEASUREMENT.............................................................................................................................6 4.1 APPLICABLE STANDARD.........................................................................................................................................................6 4.2 MEASUREMENT PROCEDURE..................................................................................................................................................6 4.3 TEST DATA.................................................................................................................................................................................8 4.4 FIELD STRENGTH CALCULATION........................................................................................................................................10 4.5 ACTIVATE TIME......................................................................................................................................................................10 4.6 CALCULATION OF DUTY FACTOR.......................................................................................................................................10 4.7 RADIATED TEST EQUIPMENT...............................................................................................................................................15 4.8 MEASURING INSTRUMENT SETUP.......................................................................................................................................15 4.9 RADIATED MEASUREMENT PHOTOS.....................................................................................................…

Text truncated - open the document above for the full version.

ETC Report No.:ET94R-01-094-01 FCC ID.: SZAOSI911PII Rev. No 1.0 Radiated Measurement Photos
