SZV-PTM535UTemperature and Humidity Sensor with transmitter

EnOcean GmbH

Click to zoom

Application Details

Equipment Class: DSC - Part 15 Security/Remote Control Transmitter
Date of Grant: Sep 17, 2020
Application Purpose: Original Equipment
Date of Application: Sep 17, 2020
Equipment Note: Temperature and Humidity Sensor with transmitter
Frequency Range: 902.87500000 - 902.87500000
Company: EnOcean GmbH
Country: Germany

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

USER MANUAL PTM 535 / PTM 535U / PTM 535J – ENOCEAN TRANSMITTER MODULE © 2019 EnOcean | www.enocean.com F-710-017, V1.0 PTM 535 / 535J User Manual | v1.5 | September 2020 | Page 1/33 Patent protected: WO98/36395, DE 100 25 561, DE 101 50 128, WO 2004/051591, DE 103 01 678 A1, DE 10309334, WO 04/109236, WO 05/096482, WO 02/095707, US 6,747,573, US 7,019,241 Observe precautions! Electrostatic sensitive devices! PTM 535 / PTM 535U / PTM 535J EnOcean Transmitter Module 10.09.2020 USER MANUAL PTM 535 / PTM 535U / PTM 535J – ENOCEAN TRANSMITTER MODULE © 2019 EnOcean | www.enocean.com F-710-017, V1.0 PTM 535 / 535J User Manual | v1.5 | September 2020 | Page 2/33 REVISION HISTORY The following major modifications and improvements have been made to this document: Version Author Reviewer Date Major Changes 1.0 MKA MKA 23 May 2018 Initial Release 1.1 MK/CB CB 02 Aug 2018 Configuration set and functional block diagram updated, additional minor changes e.g. ARIB ID added, Tx range free field 300m 1.2 MK/CB CB 14 Sep 2018 Renamed Pad 13 from VCC to VCC_MODE, V+ for configuration only, hint for PTM Config help 1.3 MK/CB CB 21 Nov 2018 4.4 added strict sequence and tool re- quirements for configuration change, 2.3 added CFG test pin 1.4 MK/CB CB 27 May 2019 Document branding changed, 2.2 pin out image corrected 1.5 MK / MKA MH 10 Sep 2020 Figure 3: T1- T4 deleted, module image added, FCC information added Published by EnOcean GmbH, Kolpingring 18a, 82041 Oberhaching, Germany www.enocean.com, [email protected], phone +49 (89) 6734 6890 © EnOcean GmbH, All Rights Reserved Important! This information describes the type of component and shall not be considered as assured characteristics. No responsibility is assumed for possible omissions or inaccuracies. Circuitry and specifications are subject to change without notice. For the latest product specifica- tions, refer to the EnOcean website: http://www.enocean.com. As far as patents or other rights of third parties are concerned, liability is only assumed for modules, not for the described applications, processes and circuits. EnOcean does not assume responsibility for use of modules described and limits its liability to the replacement of modules determined to be defective due to workmanship. Devices or systems containing RF components must meet the essential requirements of the local legal authorities. The modules must not be used in any relation with equipment that supports, directly or indirectly, human health or life or with applications that can result in danger for people, animals or real value. Components of the modules are considered and should be disposed of as hazardous waste. Local government regulations are to be observed. Packing: Please use the recycling operators known to you. USER MANUAL PTM 535 / PTM 535U / PTM 535J – ENOCEAN TRANSMITTER MODULE © 2019 EnOcean | www.enocean.com F-710-017, V1.0 PTM 535 / 535J User Manual | v1.5 | September 2020 | Page 3/33 TABLE OF CONTENT 1 General description ........................................................................................ 5 1.1 Product description ........................................................................................ 5 1.2 Product variants ............................................................................................ 5 1.3 Technical data ............................................................................................... 6 1.4 Maximum ratings for input signals ................................................................... 6 1.5 Physical dimensions ....................................................................................... 6 1.6 Device drawing ............................................................................................. 7 1.7 Environmental conditions ............................................................................... 8 1.8 Ordering information ..................................................................................... 8 2 Functional description .................................................................................... 9 2.1 Functional Principle ........................................................................................ 9 2.2 Block diagram ............................................................................................... 9 2.3 Interface pin layout ..................................................................................... 10 2.4 Interface pin functionality ............................................................................. 11 3 Radio telegram format ................................................................................. 12 3.1 Standard mode ........................................................................................... 12 3.2 Enhanced security mode .............................................................................. 14 3.3 Switching between operation modes .............................................................. 15 3.4 Transmission timing ..................................................................................... 15 4 PTM 535 configuration ................................................................................. 16 4.1 PTM 535 configuration parameters ................................................................ 16 4.2 PTM 535 configuration interface .................................................................... 17 4.3 PTM 535 test point location ........................................................................... 17 4.4 Connection between Segger J-Link and PTM 535 ............................................. 18 4.4.1 Segger power supply (6-Pin interface) .................................................... 18 4.4.2 External power supply (4 pin configuration interface) ............................... 19 4.5 Required tools ............................................................................................. 20 4.6 Configuration setup ......................…

Text truncated - open the document above for the full version.

Cover Letter(s)

EnOcean GmbH Kolpingring 18a 82041 Oberhaching Germany Phone +49.89.67 34 689-0 Fax +49.89.67 34 689-50 [email protected] www.enocean.com Managing Director: Andreas Schneider, Peter Klein Registered Court Munich HRB 139781 VAT Reg.No. DE813355588 Account: HypoVereinsbank München No. 2440610 Bank Code 700 202 70 EnOcean GmbH Kolpingring 18a 82041 Oberhaching/Germany Armin Anders VP Business Development Phone +49 89 6734689-33 [email protected] Authority to Act as Agent FCC SUBJECT: FCC Application for “FCC ID: SZV-PTM535U” To Whom It May Concern: We, the undersigned, hereby authorize Jason Stewart of VPI Laboratories at 313 W. 12800 S,. Suite 311, Draper UT 84020 to act as our agent and on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by VPI Laboratories on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Sincerely, Armin Anders FEDERAL COMMUNICATIONS COMMISSION 7435 Oakland Mills Road Columbia, MD 21046 U.S.A. Date: September 4, 2020

Cover Letter(s)

EnOcean GmbH | Kolpingring 18a | 82041 Oberhaching | Germany FCC Confidentiality Request To Whom It May Concern: Pursuant to paragraphs 0.457(d) and 0.459 of the Commission’s rules (47 C.F.R.) and section 552(b)(4) of the Freedom of Information Act, EnOcean GmbH requests confidentiality for the following product(s): Applicant: EnOcean GmbH Model: PTM 535U FCC ID: SZV-PTM535U For the product(s) stated above, we request that the following information be held confidential. 1. Circuit diagram submitted as Equipment Authorization electronic Filing attachment: "PTM535U_schematics.pdf”. 2. Block diagram submitted as Equipment Authorization Electronic Filing attachment: “Block_diagram_PTM535U.png”. 3. Partlist submitted as Equipment Authorization Electronic Filing “PTM_535U_Partlist.pdf. 4. Operation description submitted as Equipment Authorization Electronic Filing “PTM 535U Operational Description.pdf” The above exhibits contain EnOcean GmbH trade secrets and proprietary information that could be of benefit to our competitors regarding the design of our product. This material is not customarily available to the general public and we request that it be withheld from public inspection. If you have any questions, please feel free to contact me. Sincerely, Armin Anders VP Business Development EnOcean GmbH Kolpingring 18a 82041 Oberhaching Germany www.EnOcean.com [email protected] Armin Anders VP Business Development T +49.89. 67 34 689 – 33 F +49 89. 67 34 689 – 55 [email protected] Date 04. Sep. 2020 Managing Director Andreas Schneider, Peter Klein Registered Court Munich HRB 139781 VAT Reg.No. DE813355588 Account HypoVereinsbank München IBAN DE19700202700002440610 BIC HYVEDEMMXXX Musterfirma Konstantin Mustermann Musterhausen 2 60329 Muster-Frankfurt Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 U.S.A.

External Photos

313 West 12800 South, Suite 311, Draper, UT 84020 • (801) 260-4040 PTM535U_IntPho.docx Page 1 of 3 PROPRIETARY Internal Photographs Photograph 1 – Front View of the Device Antenna 313 West 12800 South, Suite 311, Draper, UT 84020 • (801) 260-4040 PTM535U_IntPho.docx Page 2 of 3 PROPRIETARY Photograph 2 – Back View of the Device Antenna 313 West 12800 South, Suite 311, Draper, UT 84020 • (801) 260-4040 PTM535U_IntPho.docx Page 3 of 3 PROPRIETARY Photograph 3 – Example of Device mounted into an ECO200 Power Source Antenna

ID Label/Location Info

LABELING REQUIREMENT Valid from: Creator: C21 – KV01 Revision: 1.1 31.08.2020 D. Purkovic PTM 535U Die in diesem Dokument enthaltenen Informationen sind Eigentum der EnOcean GmbH und als solche vertraulich zu behandeln. Ausnahmen bedürfen der Genehmigung durch autorisierte Mitarbeiter. Kopien dieses Dokumentes, die den anerkannten Verteilungssystemen entnommen wurden, sind unkontrollierte Dokumente, deren Anwendung jegliche Haftung ausschließt. Seite 1 von 2 General Current Step Code version und state is defined in: „C21_PTM535U_Cover_ sheet_manufacturing_data.docx“ Label for packaging The label should be based on labeling requirement document „Etikett für Verpackung_KV0001x”. Specific guidelines on the content: Field 05, Product name: PTM 535U Field 06, Revision (Step Code): See ‘C21_PTM535U_Cover_ sheet_manufacturing_data.docx’ Field 07, Order code: S3051-A535 Field 08, State code: See ‘C21_PTM535U_Cover_ sheet_manufacturing_data.docx’ Field 10, Quantity: See ‘C21_PTM535U_Cover_ sheet_manufacturing_data.docx’ Laser marking PCB assembler lasers bottom side of the PCB (in yellow reserved area) as shown in Figure 1 below: LABELING REQUIREMENT Valid from: Creator: C21 – KV01 Revision: 1.1 31.08.2020 D. Purkovic PTM 535U Die in diesem Dokument enthaltenen Informationen sind Eigentum der EnOcean GmbH und als solche vertraulich zu behandeln. Ausnahmen bedürfen der Genehmigung durch autorisierte Mitarbeiter. Kopien dieses Dokumentes, die den anerkannten Verteilungssystemen entnommen wurden, sind unkontrollierte Dokumente, deren Anwendung jegliche Haftung ausschließt. Seite 2 von 2 Figure 1. Area for laser markings on the bottom side of the PCB Table 1. Content of PCB markings Field Content Description 1 MODEL: PTM 535U xy A535–z dc Step Code „xy“ (z.B. DA) State Code „-z“ (z.B. -2); Date Code “dc” (z.B. 42/17) 2 FCC number and IC number FCC certification number: “FCC ID: SZV-PTM535U” IC certification number: “IC: 5713A-PTM535U” 3 DMC Data Matrix Code

Internal Photos

RF Exposure Info

313 West 12800 South, Suite 311, Draper, UT 84020 • (801) 260-4040 PTM535U_MPE.docx Page 1 of 1 PROPRIETARY 47 C.F.R. Part 1, Subpart I, Section 1.1310 47 C.F.R. Part 2, Subpart J, Section 2.1091 Maximum Permissible Exposure Calculations FCC ID: SZV-PTM535U EUT Device Category = General Population/Uncontrolled Exposure EUT consists of one ISM band radio transmitting operating at a frequency of: 902.875 MHz MPE Summary: According subpart 1.1307 (b)(1) and 2.1091 systems operating under the provisions of this section shall be operated in a manner that ensures the public is not exposed to RF energy level in excess of the communication guidelines. Limits for General Population/Uncontrolled Exposure Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm2) Averaging Time (Minutes) 0.3-1.34 614 1.63 *(100) 30 1.34-30 824/f 2.19/f *(180/f2) 30 30-300 27.5 0.073 0.2 30 300-1500 / / f/1500 30 1500-100,000 / / 1.0 30 f = frequency in MHz; * = Plane-wave equivalent power density Calculated Formulary: Predication of MPE limit at a given distance S = power density (in appropriate units, e.g. mW/cm 2 ) R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) PG = EIRP MPE and Limit are calculated as follows: f (MHz) Field Strength (dBuV/m) EIRP (mW) Power Density (mW/cm^2) Limit (mW/cm^2) ∆ 902.875 80.2 0.03 0.000006 0.6 0.59999 Result: The device meets FCC MPE limit at 20 cm for General Population/Uncontrolled Exposure as specified in 47 CRF §1.1310 and §2.1091.

Test Report

313 West 12800 South, Suite 311 Draper, UT 84020 (801) 260-4040 Test Report Certification FCC ID SZV-PTM535U Equipment Under Test PTM 535U Test Report Serial No V053114_02 Date of Test July 15, 2020 Report Issue Date July 16, 2020 Test Specifications: Applicant: FCC Part 15, Subpart C EnOcean GmbH Kolpingring 18A Oberhaching 82041 Germany 313 West 12800 South, Suite 311, Draper, UT 84020 • (801) 260-4040 V053114_02_PTM_535U_FCC_C.docx Page 2 of 29 PROPRIETARY Certification of Engineering Report This report has been prepared by VPI Laboratories, Inc. to document compliance of the device described below with the requirements of Federal Communications Commission (FCC) Part 15, Subpart C. This report may be reproduced in full. Partial reproduction of this report may only be made with the written consent of the laboratory. The results in this report apply only to the sample tested. Applicant EnOcean GmbH Manufacturer EnOcean GmbH Brand Name EnOcean Model Number PTM 535U FCC ID SZV-PTM535U On this 15 th day of July 2020, I, individually and for VPI Laboratories, Inc., certify that the statements made in this engineering report are true, complete, and correct to the best of my knowledge, and are made in good faith. Although NVLAP has accredited the VPI Laboratories, Inc. EMC testing facilities, this report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. VPI Laboratories, Inc. Tested by: Norman P. Hansen Reviewed by: Benjamin N. Antczak 313 West 12800 South, Suite 311, Draper, UT 84020 • (801) 260-4040 V053114_02_PTM_535U_FCC_C.docx Page 3 of 29 PROPRIETARY Revision History Revision Description Date 01 Original Report Release July 16, 2020 02 Revision to the model number. September 8, 2020 313 West 12800 South, Suite 311, Draper, UT 84020 • (801) 260-4040 V053114_02_PTM_535U_FCC_C.docx Page 4 of 29 PROPRIETARY Table of Contents 1 Client Information ................................................................................................................................. 5 1.1 Applicant ....................................................................................................................................... 5 1.2 Manufacturer ................................................................................................................................. 5 2 Equipment Under Test (EUT) ............................................................................................................... 6 2.1 Identification of EUT .................................................................................................................... 6 2.2 Description of EUT ....................................................................................................................... 6 2.3 EUT and Support Equipment ........................................................................................................ 6 2.4 Interface Ports on EUT ................................................................................................................. 6 2.5 Modification Incorporated/Special Accessories on EUT .............................................................. 6 2.6 Deviation from Test Standard ....................................................................................................... 6 3 Test Specification, Methods and Procedures ........................................................................................ 7 3.1 Test Specification .......................................................................................................................... 7 3.2 Methods & Procedures .................................................................................................................. 7 3.3 Test Procedure ............................................................................................................................ 10 4 Operation of EUT During Testing ...................................................................................................... 11 4.1 Operating Environment ............................................................................................................... 11 4.2 Operating Modes ......................................................................................................................... 11 4.3 EUT Exercise Software ............................................................................................................... 11 5 Summary of Test Results .................................................................................................................... 12 5.1 FCC Part 15, Subpart C .............................................................................................................. 12 5.2 Result .......................................................................................................................................... 12 6 Measurements, Examinations and Derived Results ............................................................................ 13 6.1 General Comments ...................................................................................................................... 13 6.2 Test Results ................................................................................................................................. 13 6.3 Sample Field Strength Calculation ............................................................................................. 20 7 Test Procedures and Test Equipment .................................................................................................. 21 7.1 Radiated Emissions ..................................................................................................................... 21 7.2 Equipment Calibration ................................................................................................................ 22 7.3 Measurement Uncertainty ...............................................…

Text truncated - open the document above for the full version.

Test Setup Photos

313 West 12800 South, Suite 311, Draper, UT 84020 • (801) 260-4040 PTM535U_Tsup.docx Page 1 of 6 PROPRIETARY Test Set Up Photographs Radiated Photograph 1: Front View Radiated Emissions, Below 1000 MHz Worst Case Configuration Photograph 2: Back View Radiated Emissions, Below 1000 MHz Worst Case Configuration 313 West 12800 South, Suite 311, Draper, UT 84020 • (801) 260-4040 PTM535U_Tsup.docx Page 2 of 6 PROPRIETARY Photograph 3: Front View Radiated Emissions Worst Case – Above 1000 MHz Configuration Photograph 4: Back View Radiated Emissions Worst Case – Above 1000 MHz Configuration 313 West 12800 South, Suite 311, Draper, UT 84020 • (801) 260-4040 PTM535U_Tsup.docx Page 3 of 6 PROPRIETARY Photograph 5: Vertical Configuration Photograph 6: Flat Configuration 313 West 12800 South, Suite 311, Draper, UT 84020 • (801) 260-4040 PTM535U_Tsup.docx Page 4 of 6 PROPRIETARY Photograph 7: On Edge Configuration 313 West 12800 South, Suite 311, Draper, UT 84020 • (801) 260-4040 PTM535U_Tsup.docx Page 5 of 6 PROPRIETARY Reference Test Set Up Photographs Photograph 8: Reference Photo of Test Setup for Emissions Below 30 MHz Photograph 9: Reference Photo of Test Setup for Emissions From 30 MHz to 1000 MHz 313 West 12800 South, Suite 311, Draper, UT 84020 • (801) 260-4040 PTM535U_Tsup.docx Page 6 of 6 PROPRIETARY Photograph 10: Reference Photo of Test Setup for Emissions Above 1000 MHz
