T37PL9571-WAPPlugLink 500 Wireless N Adapter

Page 1 of 30 PlugLink 500 Wireless “N”Adapter User’s Guide PL9571-WAP 66-0377-01Rev.001 Page 2 of 30 © 2013 Asoka USA Corporation ALL RIGHTS RESERVED Notice: No part of this publication may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, or stored in a database or retrieval system for any purpose without the express written permission of Asoka USA Corporation. Asoka USA Corporation reserves the right to make changes to this user’s guide at any time without notice and assumes no responsibility for its use. Asoka USA products and services can only be ordered under the terms and conditions of Asoka USA Corporation's applicable agreements. All of the features described in this user’s guide may not be currently available. Refer to the most recent product announcement for information about feature and product availability. This user’s guide contains the most current information available at the time of publication. When new and/ or revised information becomes available, this entire user’s guide is updated and distributed to all registered users. Asoka, PlugLink, and the Asoka logo are registered trademarks or trademarks of Asoka USA Corporation. All company and product names mentioned herein are trademarks of their respective companies. Mention of third-party products is for informational purposes only and constitutes neither an endorsement nor a recommendation. Asoka USA Corporation assumes no responsibility with regard to the performance or use of these products. Revision Date Description 66-0377-01Rev.001 Jan 2013 draft Page 3 of 30 THE SPECIFICATIONS AND INFORMATION REGARDING THE PRODUCTS IN THIS MANUAL ARE SUBJECT TO CHANGE WITHOUT NOTICE. ALL STATEMENTS, INFORMATION, AND RECOMMENDATIONS IN THIS MANUAL ARE BELIEVED TO BE ACCURATE BUT ARE PRESENTED WITHOUT WARRANTY OF ANY KIND, EXPRESSED OR IMPLIED. USERS MUST TAKE FULL RESPONSIBILITY FOR THEIR APPLICATION OF ANY PRODUCTS. THE SOFTWARE LICENSE AND LIMITED WARRANTY FOR THE ACCOMPANYING PRODUCT ARE SET FORTH IN THE INFORMATION PACKET THAT SHIPPED WITH THE PRODUCT AND ARE INCORPORATED HEREIN BY THIS REFERENCE. IF YOU ARE UNABLE TO LOCATE THE SOFTWARE LICENSE OR LIMITED WARRANTY, CONTACT YOUR ASOKA REPRESENTATIVE FOR A COPY. The following information is for FCC compliance of Class B devices: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio-frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference, in which case users will be required to correct the interference at their own expense. Modifying the equipment without Asoka’s written authorization may result in the equipment no longer complying with FCC requirements for Class B digital devices. In that event, your right to use the equipment may be limited by FCC regulations, and you may be required to correct any interference or radio or television communications at your own expense. You can determine whether your equipment is causing interference by turning it off. If the interference stops, it was probably caused by the Asoka equipment or one of its peripheral devices. If the equipment causes interference to radio or television reception, try to correct the interference by using one or more of the following measures: ƒ Turn the television or radio antenna until the interference stops. ƒ Move the equipment to one side or the other of the television or radio. ƒ Move the equipment farther away from the television or radio. ƒ Plug the equipment into an outlet that is on a different circuit from the television or radio. (That is, make certain the equipment and the television or radio is on circuits controlled by difference circuit breakers or fuses.) Modifications to this product not authorized by Asoka could void the FCC approval and negate your authority to operate the product. NOTWITHSTANDING ANY OTHER WARRANTY HEREIN, ALL DOCUMENT FILES AND SOFTWARE OF THESE SUPPLIERS ARE PROVIDED “AS IS” WITH ALL FAULTS. ASOKA DISCLAIM ALL WARRANTIES, EXPRESSED OR IMPLED, INCLUDING, WITHOUT LIMITATION, THOSE OR MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OR ARISING FROM A COURSE OF DEALING, USAGE OR TRADE PRACTICE. IN THE EVENT SHALL ASOKA BE LIABLE FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL OR INCIDENTAL DAMAGES, INCLUDING, WITHOUT LIMITATION, LOST PROFITS OR LOSS OR DAMAGE TO DATA ARISING OUT OF THE USE OF INABILITY TO USE THIS MANUAL, EVEN IF ASOKA HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Page 4 of 30 Contact Information For more information about the PlugLink 500 Wireless “N” Adapter or any of Asoka’s other leading-edge solutions, please contact us using any of the following methods: • Voice calls: (408) 550-8167 - We welcome your calls Monday through Friday, from 9:00 am to 5:00 pm Pacific Time. Voice mail is available during non-business hours. • Email: If you prefer, you can send information requests to our e-mail address: [email protected]. • Web site: Our Web site contains valuable information about our products, solutions, and services. We encourage you to visit us at http://www.asokatech.com. Customer Service Available from: Monday through Friday, from 9:00 am to 5:00 pm Pacific Time, by calling (408) 550-8167 or through email at [email protected]. Technical Support Technical support is available Monday through Friday, from 8:00 am to 5:00 pm Pacific Time, by calling (408) 550-8173 or through email at [email protected]. Please provide the following information about the problem: • Product name and model. • System configurat…

Text truncated - open the document above for the full version.

FCC ID: T37PL9571-WAP Date: 2013.02.22 We, ASOKA USA Corporation doesn’t provide any controls or software to allow the operation outside of the USA frequency band when we sell this product in USA. Sincerely, Xia Mingyao Vice president of Engineering, China ASOKA USA Corporation Tel:86-0756-8696161 86-0755-33631972

.

FCC TEST REPORT 47 CFR FCC Part 15 Subpart B FCC ID..............................................: Report Reference No......................: T37PL9571-WAP TRE1209009502 R/C:82725 Compiled by ( position+printed name+signature)..: File administrators Tim Zhang Supervised by ( position+printed name+signature)..: Test Engineer Eric Zhang Approved by ( position+printed name+signature)..: Manager Wenliang Li Date of issue.....................................: Feb 19, 2013 Testing Laboratory Name..............: Shenzhen Huatongwei International Inspection Co., Ltd Address ............................................: Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name............................: ASOKA Shenzhen Limited. Address ............................................: Room 1701,17/F., Fiyta Hi Tech Building, Gao-Xin Rd, South, Shenzhen , P R China Test specification: Standard ...........................................: 47 CFR FCC Part 15 Subpart B - Unintentional Radiators ANSI C63.4: 2009 TRF Originator..................................: Shenzhen Huatongwei International Inspection CO., Ltd Master TRF.......................................: Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: PlugLink 500 Wireless “N” Adapter Trade Mark .......................................: / Model/Type reference.......................: PL9571-WAP Operation Frequency........................: From 2MHz to 70MHz Listed Models ..................................: / Result................................................: Positive Report No.: TRE1209009502 Page 2 of 22 Issued: 2013-02-19 FCC ID: T37PL9571-WAP Shenzhen Huatongwei International Inspection Co., Ltd T E S T R E P O R T Test Report No. : TRE1209009502 Feb 19, 2013 ______________________________________________________________________________________________ Date of issue Equipment under Test : PlugLink 500 Wireless “N” Adapter Model /Type : PL9571-WAP Listed Models : / Applicant : ASOKA Shenzhen Limited. Address : Room 1701,17/F., Fiyta Hi Tech Building, Gao-Xin Rd, South, Shenzhen , P R China Manufacturer : Asoka USA Corporation Address : 2620 Augustine Drive Suite 230,Santa Clara City,CA 95054 Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: TRE1209009502 Page 3 of 22 Issued: 2013-02-19 FCC ID: T37PL9571-WAP Shenzhen Huatongwei International Inspection Co., Ltd Contents 1. TEST STANDARDS .................................................................. 4 2. SUMMARY............................................................................. 5 2.1. General Remarks 5 2.2. Equipment Under Test 5 2.3. Short description of the Equipment under Test (EUT) 5 2.4. EUT operation mode 5 2.5. Related Submittal(s) / Grant (s) 5 2.6. Modifications 5 2.7. Configuration of Tested System 6 2.8. Product Information 6 3. TEST ENVIRONMENT............................................................... 7 3.1. Address of the test laboratory 7 3.2. Test Facility 7 3.3. Environmental conditions 8 3.4. Statement of the measurement uncertainty 8 3.5. Equipments Used during the Test 8 4. TEST CONDITIONS AND RESULTS ............................................ 10 4.1. Conducted Emissions Test 10 4.2. Radiated Emission Test 16 5. TEST SETUP PHOTOS OF THE EUT .......................................... 22 Report No.: TRE1209009502 Page 4 of 22 Issued: 2013-02-19 FCC ID: T37PL9571-WAP Shenzhen Huatongwei International Inspection Co., Ltd 1. TEST STANDARDS The tests were performed according to following standards: 47 CFR FCC Part 15 Subpart B - Unintentional Radiators ANSI C63.4: 2009 – American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40GHz Report No.: TRE1209009502 Page 5 of 22 Issued: 2013-02-19 FCC ID: T37PL9571-WAP Shenzhen Huatongwei International Inspection Co., Ltd 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : Sep 25, 2012 Testing commenced on : Sep 25, 2012 Testing concluded on : Feb 19, 2013 2.2. Equipment Under Test Power supply system utilised Power supply voltage : z 120V / 60 Hz ○ 115V / 60Hz ○ 12 V DC ○ 24 V DC ○ Other (specified in blank below) / 2.3. Short description of the Equipment under Test (EUT) The EUT PlugLink 500 Wireless “N” Adapter is an In-House BPL device. For more details, refer to the user’s manual of the EUT. Sample Type: Prototype 2.4. EUT operation mode The EUT has been tested under typical operating condition. 2.5. Related Submittal(s) / Grant (s) This submittal(s) (test report) is intended for FCC ID: T37PL9571-WAP filing to comply with the FCC Part 15, Subpart B Rules. 2.6. Modifications No modifications were implemented to meet testing criteria. Report No.: TRE1209009502 Page 6 of 22 Issued: 2013-02-19 FCC ID: T37PL9571-WAP Shenzhen Huatongwei International Inspection Co., Ltd 2.7. Configuration of Tested System Configuration of Tested System Equipment Used in Tested System No. Equipment Manufacturer Model No. Serial No. Notes 1 PC DELL DIMENSION E520 1RNN42X 2 Notebook PC DELL D600 CN-0X2034-48643-428-1379 3 PlugLink 500 Wireless “N” Adapter ASOKA PL9571-WAP / 2.8. Product Information As the product operation frequency band from 2MHz to 70MHz.we choose two products to test conduted emission for …
