T37PL9670-Q2PlugLink-ETH-500

PlugLink-ETH-500 User’s Guide PL9670-Q2 QUICKFIND LOCATOR Contact Information Getting Help Table of Contents Installation 66-0376-01Rev.001 2 of 38 © 2012 Asoka USA Corporation ALL RIGHTS RESERVED Notice: No part of this publication may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, or stored in a database or retrieval system for any purpose without the express written permission of Asoka USA Corporation. Asoka USA Corporation reserves the right to make changes to this user’s guide at any time without notice and assumes no responsibility for its use. Asoka USA products and services can only be ordered under the terms and conditions of Asoka USA Corporation's applicable agreements. All of the features described in this user’s guide may not be currently available. Refer to the most recent product announcement for information about feature and product availability. This user’s guide contains the most current information available at the time of publication. When new and/ or revised information becomes available, this entire user’s guide is updated and distributed to all registered users. All company and product names mentioned herein are trademarks of their respective companies. Mention of third-party products is for informational purposes only and constitutes neither an endorsement nor a recommendation. Asoka USA Corporation assumes no responsibility with regard to the performance or use of these products. Revision DateDescription 66-0376-01Rev.001 July. 2012Preliminary Release Changes in This Revision • Not applicable (preliminary release) 3 of 38 Contact Information For more information about the PlugLink-ETH-500 or any of Asoka’s other leading-edge solutions, please contact us using any of the following methods: z Voice calls: We welcome your calls Monday through Friday, from 9:00 am to 5:00 pm Pacific Time at (408) 550-8167. Voice mail is available during non-business hours. z Email: If you prefer, you can send information requests to our e-mail address: [email protected]. z Fax calls: You can also send your requests for information to our 24-hour fax number: (408) 884-2390. z Web site: Our Web site contains valuable information about our products, solutions, and services. We encourage you to visit us at http://www.asokatech.com. Getting Help Asoka USA backs its products with unparalleled customer service and technical support for our valued customers. Customer Service Customer service, the customer-satisfaction arm of Asoka USA, is available Monday through Friday, from 9:00 am to 5:00 pm Pacific Time, by calling (408) 550-8167 or emailing [email protected] Technical Support Technical support is available Monday through Friday, from 6:00 am to 6:00 pm Pacific Time, by calling (408) 550-8173 or through email at [email protected] . Please provide the following information about the problem: z Product name, model number, part number (if applicable) and serial number z System configuration, including a description of the devices connected to your PL9672 z The circumstances surrounding the error or failure z A detailed description of the problem and what has been done to try to solve it 4 of 38 Table of Contents 1 Simple Installation ...................................................................... 5 Package Contents ................................................................................................... 5 Types of Connections ............................................................................................. 5 Simple Connection (Peer to Peer) ............................................................................ 6 Simple Broadband Connection ................................................................................. 6 Other Connections .................................................................................................. 7 Finding a Suitable Location ..................................................................................... 7 Installing the Hardware .......................................................................................... 7 2 Advanced Configuration (Expert Users Only) ............................. 8 Installing the Software ............................................................................................ 8 3 Network Management ............................................................... 12 Viewing the Device Information (Profile) ................................................................. 12 Changing your device Name and Network Encryption Key (NEK) ............................... 13 DEVICE NETWORK ENCRYPTION KEY (NEK) .................................................................16 Resetting and Upgrading the PlugLink-ETH-500 ....................................................... 20 Prioritizing the Network Traffic ............................................................................... 21 Viewing the Network Statistics screen ..................................................................... 22 Viewing the Link screen ......................................................................................... 22 Viewing the LED screen ......................................................................................... 24 Rescanning your Powerline Network ....................................................................... 24 Manually Resetting the Firmware and Network ID (NID) .......................................... 25 4 Troubleshooting ........................................................................ 26 A Specifications ............................................................................ 28 B Components .............................................................................. 30 C Warranty ................................................................................... 34 D FCC Notice ...............................................................................…

Text truncated - open the document above for the full version.

FCC TEST REPORT 47 CFR FCC Part 15 Subpart B FCC ID..............................................: Report Reference No......................: T37PL9670-Q2 TRE12080099 R/C:84088 Compiled by ( position+printed name+signature)..: File administrators Tim Zhang Supervised by ( position+printed name+signature)..: Test Engineer Eric Zhang Approved by ( position+printed name+signature)..: Manager Wenliang Li Date of issue.....................................: Sep 18, 2012 Testing Laboratory Name..............: Shenzhen Huatongwei International Inspection Co., Ltd Address ............................................: Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name............................: ASOKA Shenzhen Limited. Address ............................................: Room 1701,17/F., Fiyta Hi Tech Building, Gao-Xin Rd, South, Shenzhen , P R China Test specification: Standard ...........................................: 47 CFR FCC Part 15 Subpart B - Unintentional Radiators ANSI C63.4: 2009 TRF Originator..................................: Shenzhen Huatongwei International Inspection CO., Ltd Master TRF.......................................: Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: PlugLink-ETH-500 Trade Mark .......................................: / Model/Type reference.......................: PL9670-Q2 Operation Frequency........................: From 2MHz to 70MHz Listed Models ..................................: / Result................................................: Positive Report No.: TRE12080104 Page 2 of 26 Issued: 2012-09-18 FCC ID: T37PL9670-Q2 Shenzhen Huatongwei International Inspection Co., Ltd T E S T R E P O R T Test Report No. : TRE12080099 Sep 18, 2012 ______________________________________________________________________________________________ Date of issue Equipment under Test : PlugLink-ETH-500 Model /Type : PL9670-Q2 Listed Models : / Applicant : ASOKA Shenzhen Limited. Address : Room 1701,17/F., Fiyta Hi Tech Building, Gao-Xin Rd, South, Shenzhen , P R China Manufacturer : Asoka USA Corporation Address : 2620 Augustine Drive Suite 230,Santa Clara City,CA 95054 Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: TRE12080104 Page 3 of 26 Issued: 2012-09-18 FCC ID: T37PL9670-Q2 Shenzhen Huatongwei International Inspection Co., Ltd Contents 1. TEST STANDARDS .................................................................. 4 2. SUMMARY............................................................................. 5 2.1. General Remarks 5 2.2. Equipment Under Test 5 2.3. Short description of the Equipment under Test (EUT) 5 2.4. EUT operation mode 5 2.5. Related Submittal(s) / Grant (s) 5 2.6. Modifications 5 2.7. Configuration of Tested System 6 3. TEST ENVIRONMENT............................................................... 7 3.1. Address of the test laboratory 7 3.2. Test Facility 7 3.3. Environmental conditions 8 3.4. Statement of the measurement uncertainty 8 3.5. Equipments Used during the Test 8 4. TEST CONDITIONS AND RESULTS ............................................ 10 4.1. Conducted Emissions Test 10 4.2. Radiated Emission Test 16 5. TEST SETUP PHOTOS OF THE EUT .......................................... 22 6. EXTERNAL AND INTERNAL PHOTOS OF THE EUT ....................... 24 Report No.: TRE12080104 Page 4 of 26 Issued: 2012-09-18 FCC ID: T37PL9670-Q2 Shenzhen Huatongwei International Inspection Co., Ltd 1. TEST STANDARDS The tests were performed according to following standards: 47 CFR FCC Part 15 Subpart B - Unintentional Radiators ANSI C63.4: 2009 – American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40GHz Report No.: TRE12080104 Page 5 of 26 Issued: 2012-09-18 FCC ID: T37PL9670-Q2 Shenzhen Huatongwei International Inspection Co., Ltd 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : Aug 24, 2012 Testing commenced on : Aug 24, 2012 Testing concluded on : Sep 18, 2012 2.2. Equipment Under Test Power supply system utilised Power supply voltage : z 120V / 60 Hz ○ 115V / 60Hz ○ 12 V DC ○ 24 V DC ○ Other (specified in blank below) / 2.3. Short description of the Equipment under Test (EUT) The EUT PlugLink-ETH-500 is an In-House BPL device. For more details, refer to the user’s manual of the EUT. Sample Type: Prototype 2.4. EUT operation mode The EUT has been tested under typical operating condition. 2.5. Related Submittal(s) / Grant (s) This submittal(s) (test report) is intended for FCC ID: T37PL9670-Q2 filing to comply with the FCC Part 15, Subpart B Rules. 2.6. Modifications No modifications were implemented to meet testing criteria. Report No.: TRE12080104 Page 6 of 26 Issued: 2012-09-18 FCC ID: T37PL9670-Q2 Shenzhen Huatongwei International Inspection Co., Ltd 2.7. Configuration of Tested System Configuration of Tested System Equipment Used in Tested System No. Equipment Manufacturer Model No. Serial No. Notes 1 PC DELL DIMENSION E520 1RNN42X 2 Notebook PC DELL D600 CN-0X2034-48643-428-1379 3 PlugLink-ETH- 500 ASOKA PL9670-Q2 / 2.8. Product Information As the product operation frequency band from 2MHz to 70MHz.we choose two products to test conduted emission for operation difference frequencies,the two product…

Text truncated - open the document above for the full version.
