T3DR5000-OInfiNet Wireless 5.8 GHz Wireless Router

Copyright © 2004-2006 by InfiNet Wireless Limited. 1 Updated: 24 April 2006 InfiNet Wireless Router Quick start guide Copyright © 2004-2006 by InfiNet Wireless Limited. 2 Copyright © 2004-2006 by InfiNet Wireless Limited. All rights reserved. InfiNet Wireless Router Quick start guide Copyright © 2004-2006 by InfiNet Wireless Limited. i Table of contents FCC REGULATORY NOTICE....................................................................................................3 INDUSTRY CANADA REGULATORY NOTICE..........................................................................4 ANTENNA INSTALLATION AND OPERATION INFORMATION...............................................5 1. System Design..................................................................................................................5 2. Installation.......................................................................................................................5 3. Maximum Permissible Exposure..........................................................................................5 I. GETTING STARTED..........................................................................................................7 1. Scope of document...........................................................................................................7 Getting started..............................................................................................................7 Getting access to the router............................................................................................7 Point-to-point configuration.............................................................................................7 Point-to-multipoint configuration......................................................................................7 Performing outdoor testing.............................................................................................7 Connectors soldering schemes.........................................................................................7 2. Abbreviations...................................................................................................................7 3. Document marks..............................................................................................................8 4. Additional information.......................................................................................................8 II. GETTING ACCESS TO THE ROUTER.................................................................................9 1. PC/Laptop/LAN connection.................................................................................................9 Cabling (lab).................................................................................................................9 Accessing the router via Console....................................................................................10 Accessing the router via Ethernet...................................................................................12 2. Initial setup....................................................................................................................15 System parameters......................................................................................................15 Learning router’s capabilities.........................................................................................15 Radio module parameters configuration..........................................................................16 III. POINT-TO-POINT CONFIGURATION.............................................................................17 1. Routers configuration......................................................................................................17 2. Learning BS/CPE connection status...................................................................................19 Base Station table........................................................................................................19 CPE registration status..................................................................................................19 Checking radio connectivity...........................................................................................19 3. Providing PC/LAN connectivity..........................................................................................20 4. Link throughput test........................................................................................................22 IV. POINT-TO-MULTIPOINT CONFIGURATION..................................................................23 V. PERFORMING OUTDOOR TESTING...............................................................................24 1. Distance setting..............................................................................................................24 2. Learning link status/antenna alignment procedure..............................................................24 InfiNet Wireless Router Quick start guide Copyright © 2004-2006 by InfiNet Wireless Limited. ii VI. CONNECTORS SOLDERING SCHEMES...........................................................................27 1. Service cable connector soldering scheme.........................................................................27 2. Console cable connector for 5000-M and 5000-O soldering scheme......................................28 InfiNet Wireless Router Quick start guide Copyright © 2004-2006 by InfiNet Wireless Limited. 3 FCC Regulatory Notice A following FCC notice is applicable to models R5000-L, R5000-S and R5000-O models working in 5.725 – 5.825 GHz band Federal Communications Commission (FCC) statement Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial e…

Text truncated - open the document above for the full version.

Copyright © 2004-2006 by InfiNet Wireless Limited. 1 Revision date: 24 April 2006 InfiNet Wireless R5000 Technical User Manual Copyright © 2004-2006 by InfiNet Wireless Limited. 2 Copyright © 2004-2006 by InfiNet Wireless Limited. All rights reserved. InfiNet Wireless R5000 Technical User Manual Copyright © 2004-2006 by InfiNet Wireless Limited. i Table of contents FCC REGULATORY NOTICE....................................................................................................V INDUSTRY CANADA REGULATORY NOTICE.........................................................................VI ANTENNA INSTALLATION AND OPERATION INFORMATION............................................VII 1. System Design................................................................................................................vii 2. Installation.....................................................................................................................vii 3. Maximum Permissible Exposure........................................................................................vii I. GETTING STARTED..........................................................................................................3 1. Scope of document...........................................................................................................3 Getting started..............................................................................................................3 Hardware description......................................................................................................3 Installation procedure.....................................................................................................3 Device configuration procedure.......................................................................................3 Link configuring.............................................................................................................3 Services, features and tools.............................................................................................3 Recommendations..........................................................................................................3 Supplementary information.............................................................................................4 2. General products description..............................................................................................4 3. Abbreviations...................................................................................................................5 4. Document marks..............................................................................................................5 5. Warranty terms................................................................................................................5 6. Additional information.......................................................................................................6 II. HARDWARE DESCRIPTION.............................................................................................7 1. Power supply unit (IDU)....................................................................................................7 Power supply unit exterior...............................................................................................7 2. R5000 series....................................................................................................................8 InfiNet Wireless R5000-O................................................................................................8 InfiNet Wireless R5000-S................................................................................................9 InfiNet Wireless R5000-L..............................................................................................10 III. INSTALLATION PROCEDURE.........................................................................................11 1. Installation preparations..................................................................................................11 Required components and accessories............................................................................11 Antenna placement......................................................................................................11 Antenna poles usage....................................................................................................12 Poles with Stretching....................................................................................................12 Wall Mounted Pole.......................................................................................................12 Antenna Poles Requirements.........................................................................................12 Grounding...................................................................................................................12 Antenna alignment.......................................................................................................13 InfiNet Wireless R5000 Technical User Manual Copyright © 2004-2006 by InfiNet Wireless Limited. ii Precaution measures....................................................................................................14 Service cable soldering procedure..................................................................................14 Connectors hermetic sealing..........................................................................................17 Tools to be available at the installation site.....................................................................18 2. InfiNet Wireless R5000-L and InfiNet Wireless R5000-O......................................................19 Installation guidelines...................................................................................................19 Wall mounting.........................................................................................................…

Text truncated - open the document above for the full version.

InfiNet Wireless, Ltd Palm Grove House, P.O. Box 438, Road Town, Tortola, British Virgin Islands 21/14a 5th Donskoi Proezd, Moscow, Russia, 119334, Phone: +7-495-784-73-12 - Fax: +7-495-952-57-22 Attn: Reviewing Engineer Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 RE: CONFIDENTIALITY REQUEST FOR R5000-O, FCC ID T3D R5000-O To Whom It May Concern: This letter serves as an official request for confidentiality under FCC Rule Section 0.459. We have requested that the operational/technical description, schematic diagrams, and block submitted with this application be withheld from public review. These items are held as proprietary and company confidential by the manufacture, and are not supplied as part of customer documentation. Additionally radios as supplied are sealed units and do not contain any user serviceable components. Opening of these radio units by a using organization invalidates FCC certification Please contact me if there is any information you may need. Sincerely, Robert H. Stubblebine, CEO Alexander Rapoport, COO Infinet Wireless LTD Palm Grove House P.O. Box 438 Road Town, Tortola British Virgin Islands +7-495-784-73-12 (ext. 1950) [Moscow] [email protected] . Page 1 of 1

InfiNet Wireless, Ltd Palm Grove House, P.O. Box 438, Road Town, Tortola, British Virgin Islands 21/14a 5th Donskoi Proezd, Moscow, Russia, 119334, Phone: +7-495-784-73-12 - Fax: +7-495-952-57-22 Attn: Reviewing Engineer Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Conformance labeling for R5000-O, T3D R5000-O To Whom It May Concern: This document contains a photograph of equipment labeling for the R5000-O wireless routers. Please contact me if there is any information you may need. Sincerely, Alexander Rapoport, COO Infinet Wireless LTD Palm Grove House P.O. Box 438 Road Town, Tortola British Virgin Islands +7-495-784-73-12 (ext. 1601) [Moscow] [email protected] Page 1 of 2 Figure One Equipment labels for R5000-O Page 2 of 2

ModelFrequency,PolarizationGainBeamwidth °X-Pol.F/B RatioVSWR, Max NumberGHzdBi (nominal) -3dBRejection, dBdB(R.L., dB) 5.725 - 5.850 GHZ PARABOLICSUBSCRIBERANTENNAS FEATURES nAntenna diameters: • 1′(30 cm) • 1.5′(45 cm) • 2′(60 cm) • 3′(90 cm) • 4′(120 cm) • 6′(180 cm) nAntenna weights: • 1′15 lbs. (6.8kg) • 1.5′18 lbs. (8.3kg) • 2′22 lbs. (9.9kg) • 3′35 lbs. (15.8kg) • 4′60 lbs. (27.0kg) • 6′90 lbs. (40.5kg) nLightweight and rugged design nEasily installed nRF Connector Interface: Type “N” female nStandard color white: other colors available on request nRadome standard for 1′and 1.5′models, optional for all other models nDual Polarity models also available ELECTRICALSPECIFICATIONS(typical performance)* SP1-5.85.725 - 5.850Single22.511.7 17301.5:1 (14.0) SP1.5-5.85.725 - 5.850Single25.78.020311.5:1 (14.0) SP2-5.85.725 - 5.850Single28.56.228361.5:1 (14.0) SP3-5.85.725 - 5.850Single31.44.230381.5:1 (14.0) SP4-5.85.725 - 5.850Single34.83.030421.5:1 (14.0) SP6-5.85.725 - 5.850Single37.92.030441.5:1 (14.0) * All specifications subject to change without notice. Radio Waves, Inc. http://www.radiowavesinc.com

Radio Waves, Inc. http://www.radiowavesinc.com ModelFrequency,PolarizationGainBeamwidth -3dBX-Pol.F/B RatioVSWR, Max NumberGHzdBi (nominal) Az° El.°Rejection, dBdB(R.L., dB) 60°5.725 - 5.850 GHZ SECTORANTENNAS ELECTRICALSPECIFICATIONS(typical performance)* SEC-5V-60-185.725 - 5.850Vertical1860625>351.5:1 (14.0) * All specifications subject to change without notice. FEATURES nAntenna dimensions: • 25.5 x 8.5 x 7.5′′ (65 x 21.6 x 19 cm) nFlat panel design offers low windloads nLightweight and rugged design nEasily installed nRF Connector Interface: Type “N” female nPolarization: Vertical nStandard antenna mount accommodates a 2.5′′to 4.5′′diameter pipe nOptional 15° mechanical downtilt

90°5.725 - 5.850 GHZ SECTORANTENNAS FEATURES nAntenna dimensions • 25.5 x 8.5 x 7.5′′ (65 x 21.6 x 19 cm) nFlat panel design offers low windloads nLightweight and rugged design nEasily installed nRF Connector Interface: Type “N” female nPolarization • Plane Polarized (horizontal or vertical) nStandard antenna mount accommodates a 2.5′′to 4.5′′diameter pipe nOptional 15° mechanical downtilt ModelFrequency,PolarizationGainBeamwidth -3dBX-Pol.F/B RatioVSWR, Max NumberGHzdBi (nominal) Az° El.°Rejection, dBdB(R.L., dB) ELECTRICALSPECIFICATIONS(typical performance)* SEC-5V-90-175.725 - 5.850Vertical17.090625>351.5:1 (14.0) SEC-5H-90-175.725 - 5.850Horizontal17.090625>351.5:1 (14.0) *All specifications subject to change without notice. Radio Waves, Inc. http://www.radiowavesinc.com

Antenna Data Sheet MT-484032/NV Page 1 of 2 MT-484032/NV 5.15-5.875 GHz 17dBi Base Station Antenna Specifications MTI PART NUMBER MT – 484032/NV ELECTRICAL FREQUENCY RANGE 5.15-5.875 GHz GAIN 17 dBi (min) VSWR 1.7 : 1 (max) AZIMUTH BEAMWIDTH 90° ± 6° 13.5 dBi AZIMUTH BEAMWIDTH 57° ± 4° POLARIZATION Vertical ELEVATION BEAMWIDTH 7° (typ) AZIMUTH SIDELOBES LEVEL ETSI EN 302-085 V1.1.2 (2001-06) CS1-CS3 -25 dB @ ± 135° ELEVATION SIDELOBES LEVEL ETSI EN 302-085 V1.1.2 (2001-06) CS1-CS3 -12 dB (max) CROSS POLARIZATION ETSI EN 302-085 V1.1.2 (2001-06) CS1-CS3 -20 dB (max) F/B RATIO ETSI EN 302-085 V1.1.2 (2001-06) CS1-CS3 -30 dB (max) INPUT IMPEDANCE 50 (ohm) INPUT POWER 6W (max) LIGHTNING PROTECTION DC Grounded MECHANICAL DIMENSIONS (LxWxD) 530x260X11mm (max) WEIGHT 2.5 Kg (max) CONNECTOR N-Type female RADOME Plastic BASE PLATE Aluminum with chemical conversion coating OUTLINE DRAWING See page 2 MOUNTING KIT MT-120019 ENVIRONMENTAL TEST STANDARD DURATION TEMPERTURE NOTES LOW TEMPERATURE IEC 68-2-1 72 h -45°C - HIGH TEMPERATURE IEC 68-2-2 72 h +70°C - TEMP. CYCLING IEC 68-2-14 1 h -45°C +70°C 3 Cycles VIBRATION IEC 60721-3-4 30 min/axis - Random4M3 SHOCK MECHANICAL IEC 60721-3-4 - - 4M3 HUMIDITY ETSI EN300-2-4 T4.1E 144 h - 95% WATER TIGHTNESS IEC 529 - - IP67 SOLAR RADIATION ASTM G53 1000 h - - FLAMMABILITY UL 94 - - Class HB SALT SPRAY IEC 68-2-11 Ka 500 h - - ICE AND SNOW - - - 25mm Radial WIND SPEED SURVIVAL OPERATION - - - - 220 Km/h 160 Km/h Antenna Data Sheet MT-484032/NV Page 2 of 2 MTI group is certified according to ISO 9001 and ISO 14001. WAIVER! While the information contained in this document has been carefully compiled to the best of our present knowledge, it is not intended as presentation or warranty of any kind on our part regarding the fitness of the products concerned for any particular use or purpose and neither shall any statement contained herein be construed as a recommendation to infringe any industrial property rights or as a license to use any such rights. The fitness of each product for any particular purpose must be checked beforehand with our specialists. MTI Wireless Edge Ltd. 11 Hamelacha St. Afek Industrial Park Rosh Ha'ayin 48091, Israel Tel: +972-3-902-5050 Fax: +972-3-902-5051 www.mtiwe.com Document No: Issued: MT-484032/NV Uncontrolled Copy MT-484032/NV 5.15-5.875 GHz 17dBi Base Station Antenna Azimuth Radiation Pattern Midband Freq. 5.35 GHz Elevation Radiation Pattern Midband Freq. 5.35 GHz Dimensions [mm] Existing Antenna Versions MT-484032/NV With N – Type Female connector & DC grounding

Antenna Data Sheet MT-484033/NH Page 1 of 2 MT-484033/NH 5.15-5.875 GHz 16.5dBi Base Station Antenna Specifications MTI PART NUMBER MT – 484033/NH ELECTRICAL FREQUENCY RANGE 5.15-5.875 GHz GAIN 16.5 dBi (min) VSWR 1.7 : 1 (max) 13 dBi AZIMUTH BEAMWIDTH 60° ± 4° 13.5 dBi AZIMUTH BEAMWIDTH 57° ± 4° POLARIZATION Horizontal 3 dB ELEVATION BEAMWIDTH 11° (typ) AZIMUTH SIDELOBES LEVEL ETSI EN 302-085 V1.1.2 (2001-02) CS1-CS3 -25 dB @ ± 90° ELEVATION SIDELOBES LEVEL ETSI EN 302-085 V1.1.2 (2001-02) CS1-CS3 -12 dB (max) CROSS POLARIZATION ETSI EN 302-085 V1.1.2 (2001-02) TS1-TS3 -23 dB (max) F/B RATIO ETSI EN 302-085 V1.1.2 (2001-02) TS1-TS3 -30 dB (max) INPUT IMPEDANCE 50 (ohm) INPUT POWER 6W (max) LIGHTNING PROTECTION DC Grounded MECHANICAL DIMENSIONS (LxWxD) 350x150X30mm (max) WEIGHT 1.5 Kg (max) CONNECTOR Two N-Type female RADOME Plastic BASE PLATE Aluminum with chemical conversion coating OUTLINE DRAWING See page 2 MOUNTING KIT MT-120019 ENVIRONMENTAL TEST STANDARD DURATION TEMPERTURE NOTES LOW TEMPERATURE IEC 68-2-1 72 h -45°C - HIGH TEMPERATURE IEC 68-2-2 72 h +70°C - TEMP. CYCLING IEC 68-2-14 1 h -45°C +70°C 3 Cycles VIBRATION IEC 60721-3-4 30 min/axis - Random4M3 SHOCK MECHANICAL IEC 60721-3-4 - - 4M3 HUMIDITY ETSI EN300-2-4 T4.1E 144 h - 95% WATER TIGHTNESS IEC 529 - - IP67 SOLAR RADIATION ASTM G53 1000 h - - FLAMMABILITY UL 94 - - Class HB SALT SPRAY IEC 68-2-11 Ka 500 h - - ICE AND SNOW - - - 25mm Radial WIND SPEED SURVIVAL OPERATION - - - - 220 Km/h 160 Km/h Antenna Data Sheet MT-484033/NH Page 2 of 2 MTI group is certified according to ISO 9001 and ISO 14001. WAIVER! While the information contained in this document has been carefully compiled to the best of our present knowledge, it is not intended as presentation or warranty of any kind on our part regarding the fitness of the products concerned for any particular use or purpose and neither shall any statement contained herein be construed as a recommendation to infringe any industrial property rights or as a license to use any such rights. The fitness of each product for any particular purpose must be checked beforehand with our specialists. MTI Wireless Edge Ltd. 11 Hamelacha St. Afek Industrial Park Rosh Ha'ayin 48091, Israel Tel: +972-3-902-5050 Fax: +972-3-902-5051 www.mtiwe.com Document No: Issued: MT-484033/NH Uncontrolled Copy MT-484033/NH 5.15-5.875 GHz 16.5dBi Base Station Antenna Azimuth Radiation Pattern Midband Freq. 5.35 GHz Elevation Radiation Pattern Midband Freq. 5.35 GHz Dimensions [mm] Existing Antenna Versions MT-484033/NH With N – Type Female connector & DC grounding

Antenna Data Sheet MT-486001 Page 1 of 2 MT-486001 5.15-5.975 GHz 28dBi Subscriber Antenna Specifications MTI PART NUMBER MT – 486001 ELECTRICAL FREQUENCY RANGE 5.15-5.875 GHz GAIN 28 dBi (min) VSWR 1.7 : 1 (max) 3 dB BEAMWIDTH 4.5° (typ) POLARIZATION Linear (Vertical or Horizontal) SIDELOBES LEVEL ETSI EN 302 085 V1.1.2, (2001-02) TS1-TS5 CROSS POLARIZATION ETSI EN 302 085 V1.1.2, (2001-02) TS1-TS5 F/B RATIO -40dB (max) INPUT IMPEDANCE 50 (ohm) INPUT POWER 6W (max) LIGHTNING PROTECTION DC Grounded MECHANICAL DIMENSIONS (LxWxD) 600x600X50mm (max) WEIGHT 5 Kg (max) CONNECTOR N-Type Female RADOME Plastic BASE PLATE Aluminum with chemical conversion coating OUTLINE DRAWING See page 2 MOUNTING KIT MT-120019 ENVIRONMENTAL TEST STANDARD DURATION TEMPERTURE NOTES LOW TEMPERATURE IEC 68-2-1 72 h -45°C - HIGH TEMPERATURE IEC 68-2-2 72 h +70°C - TEMP. CYCLING IEC 68-2-14 1 h -45°C +70°C 3 Cycles VIBRATION IEC 60721-3-4 30 min/axis - Random4M3 SHOCK MECHANICAL IEC 60721-3-4 - - 4M3 HUMIDITY ETSI EN300-2-4 T4.1E 144 h - 95% WATER TIGHTNESS IEC 529 - - IP67 SOLAR RADIATION ASTM G53 1000 h - - FLAMMABILITY UL 94 - - Class HB SALT SPRAY IEC 68-2-11 Ka 500 h - - ICE AND SNOW - - - 25mm Radial WIND SPEED SURVIVAL OPERATION - - - - 220 Km/h 160 Km/h Antenna Data Sheet MT-486001 Page 2 of 2 MTI group is certified according to ISO 9001 and ISO 14001. WAIVER! While the information contained in this document has been carefully compiled to the best of our present knowledge, it is not intended as presentation or warranty of any kind on our part regarding the fitness of the products concerned for any particular use or purpose and neither shall any statement contained herein be construed as a recommendation to infringe any industrial property rights or as a license to use any such rights. The fitness of each product for any particular purpose must be checked beforehand with our specialists. MTI Wireless Edge Ltd. 11 Hamelacha St. Afek Industrial Park Rosh Ha'ayin 48091, Israel Tel: +972-3-902-5050 Fax: +972-3-902-5051 www.mtiwe.com Document No: Issued: MT-486001 Uncontrolled Copy MT-486001 5.15-5.975 GHz 28dBi Subscriber Antenna Azimuth Radiation Pattern Midband Freq. 5.35 GHz Elevation Radiation Pattern Midband Freq. 5.35 GHz Dimensions [mm] Existing Antenna Versions MT-486001 With N – Type Female connector & DC grounding

Parabolic Dish Antenna 5 GHz Operation Features • High Gain 28 dBi, 29 dBi Antenna (2 Frequency Ranges Available) • Adjustable tilt pole mount • Vertical or Horizontal Polarization • Type N Female Connector • DC Grounded for lightning protection • Rugged, Lightweight and Waterproof Applications • 5.8 GHz ISM Band Applications • 802.11a Wireless Data • 5.3GHz UNII Band Applications • Long Distance Backhaul Data Links • Point to Point Data Links • Building to Building High Speed Links Description The Parabolic Dish Antenna systems offered by Pacific Wireless are constructed of an aluminum alloy dish with powder coat paint finish for excellent mechanical, electrical and environmental performance. The parabolic reflector is made with a special one-step molding technology which achieves excellent consistency and long term stability. They come complete with universal galvanized steel, powder coat paint mounting system for pole mount applications. Because of its’ superb electrical performance and mechanical stability, the parabolic dish antenna can be used in a wide variety of high performance 5GHz wireless applications. An optional Fiberglass Radome is available for added environmental protection. Specifications Parameter Min Typ Max Units Frequency Range DA58 DA57 DA53 5725 5470 5150 5850 5725 5350 MHz Gain DA58 DA57 DA53 29 28 28 dBi Input Return Loss (S 11 ) -14 dB VSWR 1.5:1 3db Beam Angle 6 Deg Cross Pole -32 dB Front to Back 25 dB Side Lobe -28 dB Impedance 50 OHM Input Power 100 W Pole Diameter (OD) 1.5 (38) 3.0 (76) Inch (mm) Operating Temperature -40 +70 Deg C Rated Wind Velocity 125 mph Focal Length 10 (254) Inch (mm) Weight 11 (5) Lbs (Kg) Dimensions (Dia) 25.5 (648) Inch (mm) PAWDA5 100 MPH 125 MPH 100 MPH w/ ½”Radial Ice 113 177 115 w/Radome 100 MPH 125 MPH 100 MPH w/ ½”Radial Ice 75 116 78 Wind Loading PAW DA5 ...DATA SHEET... PAWDA5 Specifications Subject to Change Without Notice PAWDA5 Spec Rev 5 9-June-04 Page 2 Antenna Patterns Notes: • All shipments F.O.B. Bluffdale, UT 84065 • All antennas carry a 2 Year Warranty System Ordering: DA58-29 29dBi 5.725GHz to 5.850GHz Parabolic Dish Antenna DA57-28 28dBi 5.470GHz to 5.725GHz Parabolic Dish Antenna DA53-28 28dBi 5.150GHz to 5.350GHz Parabolic Dish Antenna DA5 RADOME Radome Kit for Parabolic Dish Antenna For further information contact: Pacific Wireless 14575 South Center Point Way Bluffdale, UT 84065 TEL (801) 572-3024 FAX (801) 572-3025 www.pacwireless.com Optional Fiberglass Radome

Horizontally Polarized Sector Antennas 5400 to 5850 MHz Operation Features • Horizontally Polarized • 90 deg 17dBi and 120 deg 16dBi models • Type N Female Integrated Connector • Extremely Rugged for long service life in extreme environments • Completely Weatherproof Applications • 5.8GHz U-NII Band Applications • Base Station Antennas • Point to Multi-point Systems • 802.11a Applications Description The Horizontally Polarized Sector antenna systems offered by Pacific Wireless are constructed of UV stable ABS plastic radomes and heavy galvanized brackets for long service life in the most demanding conditions. The Horizontal Polarization allows for reduced interference potential in systems which are installed in areas with high levels of vertically polarized RF noise or where the system manager wants to avoid potential future problems with interference. The super heavy duty bracket system is easy to install and adjust for up to 30 deg of downtilt. Specifications Parameter Model Min Typ Max Units Frequency Range SAH57 5400 5750 MHz SAH58 5725 5850 MHz Input Return Loss (S 11 ) -14 dB VSWR 1.5:1 Impedance 50 OHM Input Power 100 W Pole Diameter (OD) 1” (25) 2.5” (64) Inch (mm) Operating Temperature -40 +70 Deg C Model SAH5x-90-xx SAH5x-120-xx Gain SAH57 17 dBi 16dBi SAH58 17 dBi 16dBi Horizontal Beam Width 90 deg 120 deg Vertical Beam Width 8 deg Polarization Horizontal Front to Back >25 dB Mechanical Downtilt 30 deg Weight 10 Lb (4.5kg) HPOL Sector SAH5 ...DATA SHEET... SAH5 Specifications Subject to Change Without Notice SAH5x Spec Rev 4 29-Jul-05 Page 2 Dimensions (LxWxH) 31” x 6.5” x 2.5” (790 x 165 x 51mm) Antenna Patterns at 5.750GHz Notes: • All shipments F.O.B. Pacific Wireless Bluffdale, UT 84065 • All antennas carry a 2 Year Warranty System Ordering: SAH5… - …… - …… For further information contact: Wind Loading Model Sq. In 100MPH 125MPH SAH5x 182 45.5 lb 71.1 lb Pacific Wireless 14575 South Centerpoint Way Bluffdale, UT 84065 TEL (801) 572-3024 FAX (801) 572-3025 www.pacwireless.com Antenna Gain 17 = 17dBi 16 = 16dBi Horizontal Beamwidth 90 = 90deg 120 = 120deg SAH5x-90-xx E-Plane SAH5x-120-xx E-Plane Top Bracket Bottom Bracke t Frequency 7 = 5400-5750MHz 8 = 5725-5850MHz

TA-5705H-14-90 Sector 5725-5875 MHz 0 90 180 2700-3-6-10 -15 -20 -30 dB 0 90 180 2700-3-6-10 -15 -20 -30 dB Typical mid band values. (For details , contact factory) E-PlaneH-Plane The TA-5705H-14-90 is a horizontally polarized 90 degree sectoral antenna. The antenna consists of a printed dipole array enclosed in an aluminum base with a UV stabilized radome for superior weatherability. The antenna is at DC ground to aid in lightning protection. 2.25 in. (57mm) 6 lb. (2.72 kg) 125 mph (200 km/h) 96 lb. (43.5 kg) 0+/-16 degrees 0.75 - 2.0 in. (19 - 51 mm) Depth: Weight (incl. Clamps): Rated Wind Velocity: Hor. Thrust at rated wind: Mechanical Tilt: Mounting (O.D.): Mechanical Specifications Length: 24.5 in. (622 mm) Width: 9.0 in. (229 mm) Plated Copper on PCB Irridited aluminum Gray UV stabilized ASA Aluminum and stainless steel Radiating Elements: Reflector: Radome: Clamps: Materials 5725-5875 MHz 16.5 dBi min. 1.5:1 25 dB min. Horizontal 5 Watts 5 degrees 90 degrees 20 dB min. 50 ohms nominal N female Frequency Range: Gain: VSWR: Front to Back Ratio: Polarization: Power Rating: H-Plane Beamwidth: E-Plane Beamwidth: Cross Pol. Discrimination: Impedance: Termination: Electrica…
