T3DR5000-SInfiNet Wireless 5.8 GHz Wireless Router

Infinet Wireless Limited
InfiNet Wireless 5.8 GHz Wireless Router - FCC ID T3DR5000-S - Infinet Wireless Limited
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Apr 25, 2006
Application Purpose
Original Equipment
Date of Application
Apr 25, 2006
Equipment Note
InfiNet Wireless 5.8 GHz Wireless Router
Frequency Range
5745.00000000 - 5825.00000000
Company
Infinet Wireless Limited
Country
Virgin Islands (British)

Documents & Files

Select a file to view

Users Manual

↗
↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗
↗

Operational Description

↗

RF Exposure Info

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Copyright © 2004-2006 by InfiNet Wireless Limited. 1 Updated: 24 April 2006 InfiNet Wireless Router Quick start guide Copyright © 2004-2006 by InfiNet Wireless Limited. 2 Copyright © 2004-2006 by InfiNet Wireless Limited. All rights reserved. InfiNet Wireless Router Quick start guide Copyright © 2004-2006 by InfiNet Wireless Limited. i Table of contents FCC REGULATORY NOTICE....................................................................................................3 INDUSTRY CANADA REGULATORY NOTICE..........................................................................4 ANTENNA INSTALLATION AND OPERATION INFORMATION...............................................5 1. System Design..................................................................................................................5 2. Installation.......................................................................................................................5 3. Maximum Permissible Exposure..........................................................................................5 I. GETTING STARTED..........................................................................................................7 1. Scope of document...........................................................................................................7 Getting started..............................................................................................................7 Getting access to the router............................................................................................7 Point-to-point configuration.............................................................................................7 Point-to-multipoint configuration......................................................................................7 Performing outdoor testing.............................................................................................7 Connectors soldering schemes.........................................................................................7 2. Abbreviations...................................................................................................................7 3. Document marks..............................................................................................................8 4. Additional information.......................................................................................................8 II. GETTING ACCESS TO THE ROUTER.................................................................................9 1. PC/Laptop/LAN connection.................................................................................................9 Cabling (lab).................................................................................................................9 Accessing the router via Console....................................................................................10 Accessing the router via Ethernet...................................................................................12 2. Initial setup....................................................................................................................15 System parameters......................................................................................................15 Learning router’s capabilities.........................................................................................15 Radio module parameters configuration..........................................................................16 III. POINT-TO-POINT CONFIGURATION.............................................................................17 1. Routers configuration......................................................................................................17 2. Learning BS/CPE connection status...................................................................................19 Base Station table........................................................................................................19 CPE registration status..................................................................................................19 Checking radio connectivity...........................................................................................19 3. Providing PC/LAN connectivity..........................................................................................20 4. Link throughput test........................................................................................................22 IV. POINT-TO-MULTIPOINT CONFIGURATION..................................................................23 V. PERFORMING OUTDOOR TESTING...............................................................................24 1. Distance setting..............................................................................................................24 2. Learning link status/antenna alignment procedure..............................................................24 InfiNet Wireless Router Quick start guide Copyright © 2004-2006 by InfiNet Wireless Limited. ii VI. CONNECTORS SOLDERING SCHEMES...........................................................................27 1. Service cable connector soldering scheme.........................................................................27 2. Console cable connector for 5000-M and 5000-O soldering scheme......................................28 InfiNet Wireless Router Quick start guide Copyright © 2004-2006 by InfiNet Wireless Limited. 3 FCC Regulatory Notice A following FCC notice is applicable to models R5000-L, R5000-S and R5000-O models working in 5.725 – 5.825 GHz band Federal Communications Commission (FCC) statement Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial e…

Text truncated - open the document above for the full version.

Users Manual

Copyright © 2004-2006 by InfiNet Wireless Limited. 1 Revision date: 24 April 2006 InfiNet Wireless R5000 Technical User Manual Copyright © 2004-2006 by InfiNet Wireless Limited. 2 Copyright © 2004-2006 by InfiNet Wireless Limited. All rights reserved. InfiNet Wireless R5000 Technical User Manual Copyright © 2004-2006 by InfiNet Wireless Limited. i Table of contents FCC REGULATORY NOTICE....................................................................................................V INDUSTRY CANADA REGULATORY NOTICE.........................................................................VI ANTENNA INSTALLATION AND OPERATION INFORMATION............................................VII 1. System Design................................................................................................................vii 2. Installation.....................................................................................................................vii 3. Maximum Permissible Exposure........................................................................................vii I. GETTING STARTED..........................................................................................................3 1. Scope of document...........................................................................................................3 Getting started..............................................................................................................3 Hardware description......................................................................................................3 Installation procedure.....................................................................................................3 Device configuration procedure.......................................................................................3 Link configuring.............................................................................................................3 Services, features and tools.............................................................................................3 Recommendations..........................................................................................................3 Supplementary information.............................................................................................4 2. General products description..............................................................................................4 3. Abbreviations...................................................................................................................5 4. Document marks..............................................................................................................5 5. Warranty terms................................................................................................................5 6. Additional information.......................................................................................................6 II. HARDWARE DESCRIPTION.............................................................................................7 1. Power supply unit (IDU)....................................................................................................7 Power supply unit exterior...............................................................................................7 2. R5000 series....................................................................................................................8 InfiNet Wireless R5000-O................................................................................................8 InfiNet Wireless R5000-S................................................................................................9 InfiNet Wireless R5000-L..............................................................................................10 III. INSTALLATION PROCEDURE.........................................................................................11 1. Installation preparations..................................................................................................11 Required components and accessories............................................................................11 Antenna placement......................................................................................................11 Antenna poles usage....................................................................................................12 Poles with Stretching....................................................................................................12 Wall Mounted Pole.......................................................................................................12 Antenna Poles Requirements.........................................................................................12 Grounding...................................................................................................................12 Antenna alignment.......................................................................................................13 InfiNet Wireless R5000 Technical User Manual Copyright © 2004-2006 by InfiNet Wireless Limited. ii Precaution measures....................................................................................................14 Service cable soldering procedure..................................................................................14 Connectors hermetic sealing..........................................................................................17 Tools to be available at the installation site.....................................................................18 2. InfiNet Wireless R5000-L and InfiNet Wireless R5000-O......................................................19 Installation guidelines...................................................................................................19 Wall mounting.........................................................................................................…

Text truncated - open the document above for the full version.

Cover Letter(s)

InfiNet Wireless, Ltd Palm Grove House, P.O. Box 438, Road Town, Tortola, British Virgin Islands 21/14a 5th Donskoi Proezd, Moscow, Russia, 119334, Phone: +7-495-784-73-12 - Fax: +7-495-952-57-22 Attn: Reviewing Engineer Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 RE: CONFIDENTIALITY REQUEST FOR R5000-S, FCC ID T3D R5000-S To Whom It May Concern: This letter serves as an official request for confidentiality under FCC Rule Section 0.459. We have requested that the operational/technical description, schematic diagrams, and block diagrams submitted with this application be withheld from public review. These items are held as proprietary and company confidential by the manufacture, and are not supplied as part of customer documentation. Additionally radios as supplied are sealed units and do not contain any user serviceable components. Opening of these radio units by a using organization invalidates FCC certification Please contact me if there is any information you may need. Sincerely, Robert H. Stubblebine, CEO Alexander Rapoport, COO Infinet Wireless LTD Palm Grove House P.O. Box 438 Road Town, Tortola British Virgin Islands +7-495-784-73-12 (ext. 1950) [Moscow] [email protected] . Page 1 of 1

ID Label/Location Info

InfiNet Wireless, Ltd Palm Grove House, P.O. Box 438, Road Town, Tortola, British Virgin Islands 21/14a 5th Donskoi Proezd, Moscow, Russia, 119334, Phone: +7-495-784-73-12 - Fax: +7-495-952-57-22 Attn: Reviewing Engineer Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Conformance labeling for R5000-S, T3D R5000-S To Whom It May Concern: This document contains a photograph of equipment labeling for the R5000-S wireless routers. Please contact me if there is any information you may need. Sincerely, Alexander Rapoport, COO Infinet Wireless LTD Palm Grove House P.O. Box 438 Road Town, Tortola British Virgin Islands +7-495-784-73-12 (ext. 1601) [Moscow] [email protected] Page 1 of 2 Figure One Equipment labels for R5000-S Page 2 of 2

Operational Description

Antenna Data Sheet MT-485028/N Page 1 of 2 MT-485028/N 5.15-5.875 GHz 22dBi Subscriber Antenna Specifications MTI PART NUMBER MT – 485028/N ELECTRICAL FREQUENCY RANGE 5.15-5.875 GHz GAIN 21.5 dBi (min) @ 5.15-5.25 GHz 22 dBi (min) @ 5.25-5.875 VSWR 1.9 : 1 @ 5.15-5.25 GHz 1.7 : 1 @ 5.25-5.875 GHz 3 dB BEAMWIDTH AZIMUTH ELEVATION 9° (typ) 9° (typ) POLARIZATION Linear (Vertical or Horizontal) SIDELOBES LEVEL ETSI EN 302-085 V1.1.2 (2001-02) TS1-TS3 CROSS POLAR DISCRIMINATION -28 dB CROSS POLARIZATION ETSI EN 302-085 V1.1.2 (2001-02) TS1-TS3 F/B RATIO -35 dB (max) INPUT IMPEDANCE 50 (ohm) INPUT POWER 6W (max) LIGHTNING PROTECTION DC Grounded MECHANICAL DIMENSIONS (LxWxD) 305x305X15mm (max) WEIGHT 1.2 Kg (max) CONNECTOR N-Type Female RADOME Plastic BASE PLATE Aluminum with chemical conversion coating OUTLINE DRAWING See page 2 MOUNTING KIT MT-120018 ENVIRONMENTAL TEST STANDARD DURATION TEMPERTURE NOTES LOW TEMPERATURE IEC 68-2-1 72 h -45°C - HIGH TEMPERATURE IEC 68-2-2 72 h +70°C - TEMP. CYCLING IEC 68-2-14 1 h -45°C +70°C 3 Cycles VIBRATION IEC 60721-3-4 30 min/axis - Random4M3 SHOCK MECHANICAL IEC 60721-3-4 - - 4M3 HUMIDITY ETSI EN300-2-4 T4.1E 144 h - 95% WATER TIGHTNESS IEC 529 - - IP67 SOLAR RADIATION ASTM G53 1000 h - - FLAMMABILITY UL 94 - - Class HB SALT SPRAY IEC 68-2-11 Ka 500 h - - ICE AND SNOW - - - 25mm Radial WIND SPEED SURVIVAL OPERATION - - - - 220 Km/h 160 Km/h Antenna Data Sheet MT-485028/N Page 2 of 2 MTI group is certified according to ISO 9001 and ISO 14001. WAIVER! While the information contained in this document has been carefully compiled to the best of our present knowledge, it is not intended as presentation or warranty of any kind on our part regarding the fitness of the products concerned for any particular use or purpose and neither shall any statement contained herein be construed as a recommendation to infringe any industrial property rights or as a license to use any such rights. The fitness of each product for any particular purpose must be checked beforehand with our specialists. MTI Wireless Edge Ltd. 11 Hamelacha St. Afek Industrial Park Rosh Ha'ayin 48091, Israel Tel: +972-3-902-5050 Fax: +972-3-902-5051 www.mtiwe.com Document No: Issued: MT-485028/N Uncontrolled Copy MT-485028/N 5.15-5.875 GHz 22dBi Subscriber Antenna Azimuth Radiation Pattern Midband Freq. 5.47 GHz Elevation Radiation Pattern Midband Freq. 5.47 GHz Dimensions [mm] Existing Antenna Versions MT-485028/N With N – Type Female connector & DC grounding

RF Exposure Info

InfiNet Wireless LTD Test Equipment R5000-S CFR Title 47, Part 15, Subpart C MET Report: EMCS18330B S-FCC247 © 2006, MET Laboratories, Inc. Page 32 of 59 Electromagnetic Compatibility Criteria for Intentional Radiators § 15.247(b) Peak Power Output and RF Exposure RF Exposure Requirements: §1.1307(b)(1) and §1.1307(b)(2): Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s guidelines. RF Radiation Exposure Limit: §1.1310: As specified in this section, the Maximum Permissible Exposure (MPE) Limit shall be used to evaluate the environmental impact of human exposure to radiofrequency (RF) radiation as specified in Sec. 1.1307(b), except in the case of portable devices which shall be evaluated according to the provisions of Sec. 2.1093 of this chapter. MPE Limit Calculation: EUT’s operating frequencies @ 5725 - 5850 MHz ; highest conducted power = 23.0 dBm (peak) therefore, Limit for Uncontrolled exposure: 1 mW/cm 2 or 10 W/m 2 EUT maximum antenna gain = 22 dBi. Equation from page 18 of OET 65, Edition 97-01 S = PG / 4πR 2 or R = √PG / 4πS where, S = Power Density (1 mW/cm 2 ) P = Power Input to antenna (200.0mW) G = Antenna Gain (158.4 numeric) R = (200.0*158.4/ 4*3.14*1.0) 1/2 = (31697.8 / 12.56) 1/2 = 50.2cm

Test Report

MET Laboratories, Inc. Safety Certification - EMI - Telecom Environmental Simulation 33439 WESTERN AVENUE ! UNION CITY, CALIFORNIA 94587 ! PHONE (510) 489-6300 ! FAX (510) 489-6372 The Nation’s First Licensed Nationally Recognized Testing Laboratory February 17, 2006 InfiNet Wireless LTD Palm Grove House P.O. Box 438 Road Town, Tortola British Virgin Islands Dear Dmitry Okorokov, Enclosed is the Telecom test report for compliance testing of the InfiNet Wireless LTD, R5000-S as tested to the requirements of Title 47 of the CFR, Ch. 1 (10-1-03 ed.), Part 15, Subpart B for a Class B Digital Device. Thank you for using the services of MET Laboratories, Inc. If you have any questions regarding these results or if MET can be of further service to you, please feel free to contact me. Sincerely yours, MET LABORATORIES, INC. Boonmanus Seelapasay Documentation Department Reference: (\InfiNet Wireless LTD\EMCS18330B S-FCC-15247) Certificates and reports shall not be reproduced except in full, without the written permission of MET Laboratories, Inc. While use of the National Voluntary Laboratory Accreditation Program (NVLAP) letters or the NVLAP Logo, the Standards Council of Canada Logo, or the Nationally Recognized Testing Laboratory (NRTL) Letters in this report reflects MET Accreditation under these programs, these letters, logo, or statements do not claim product endorsement by NVLAP or any Agency of the U.S. Government. This letter of transmittal is not a part of the attached report. InfiNet Wireless LTD R5000-S CFR Title 47, Part 15, Subpart C MET Report: EMCS18330B S-FCC15247 © 2006, MET Laboratories, Inc. Page ii of vii Electromagnetic Compatibility Criteria Test Report for the InfiNet Wireless LTD R5000-S Verified under the FCC Certification Rules contained in Title 47 of the CFR, Part 15.247, Subpart C for Intentional Radiators MET Report: EMCS18330B S-FCC247 February 17, 2006 Prepared For: InfiNet Wireless LTD Palm Grove House P.O. Box 438 Road Town, Tortola British Virgin Islands Prepared By: MET Laboratories, Inc. 4855 Patrick Henry Drive, Building 6 Santa Clara, California 95054 InfiNet Wireless LTD R5000-S CFR Title 47, Part 15, Subpart C MET Report: EMCS18330B S-FCC15247 © 2006, MET Laboratories, Inc. Page iii of vii Electromagnetic Compatibility Criteria Test Report for the InfiNet Wireless LTD R5000-S Tested Under the FCC Certification Rules contained in Title 47 of the CFR, Part 15.247, Subpart C for Intentional Radiators Shawn McMillen Boonmanus Seelapasay Electromagnetic Compatibility Lab Documentation Department Engineering Statement: The measurements shown in this report were made in accordance with the procedures indicated, and the emissions from this equipment were found to be within the limits applicable. I assume full responsibility for the accuracy and completeness of these measurements, and for the qualifications of all persons taking them. It is further stated that upon the basis of the measurements made, the equipment tested is capable of operation in accordance with the requirements of Part 15.407, of the FCC Rules under normal use and maintenance. Tony Permsombut Electromagnetic Compatibility Lab InfiNet Wireless LTD R5000-S CFR Title 47, Part 15, Subpart C MET Report: EMCS18330B S-FCC15247 © 2006, MET Laboratories, Inc. Page iv of vii Report Status Sheet Revision Report Date Reason for Revision ∅ February 17, 2006 Initial Issue. InfiNet Wireless LTD Table of Contents R5000-S CFR Title 47, Part 15, Subpart C MET Report: EMCS18330B S-FCC15247 © 2006, MET Laboratories, Inc. Page v of vii Table of Contents I. Executive Summary .................................................................................................................................................1 A. Purpose of Test ...................................................................................................................................................2 B. Executive Summary ............................................................................................................................................2 II. Equipment Configuration .......................................................................................................................................3 A. Overview.............................................................................................................................................................4 B. References...........................................................................................................................................................5 C. Test Site ..............................................................................................................................................................6 D. Description of Test Sample.................................................................................................................................6 E. Equipment Configuration....................................................................................................................................9 F. Support Equipment .............................................................................................................................................9 G. Ports and Cabling Information ............................................................................................................................9 H. Mode of Operation............................................................................................................................................10 I. Method of Monitoring EUT Operation .............................................................................................................10 J. Modifications ....................................................................................................................................................10 a) Modifications to EUT.....................................................................................…

Text truncated - open the document above for the full version.

Test Setup Photos

Electromagnetic Compatibility InfiNet Wireless LTD Equipment Configuration R5000-S CFR Title 47, Part 15, Subpart C MET Report: EMCS18330B S-FCC247 © 2006, MET Laboratories, Inc. Page 15 of 59 Conducted Emission Limits Test Setup Photograph 2. Conducted Emissions Test Setup Electromagnetic Compatibility InfiNet Wireless LTD Equipment Configuration R5000-S CFR Title 47, Part 15, Subpart C MET Report: EMCS18330B S-FCC247 © 2006, MET Laboratories, Inc. Page 18 of 59 Radiated Emission Limits Test Setup Photograph 3. Radiated Emission Limits Test Setup InfiNet Wireless LTD Test Equipment R5000-S CFR Title 47, Part 15, Subpart C MET Report: EMCS18330B S-FCC247 © 2006, MET Laboratories, Inc. Page 24 of 59 Conducted Emission Limits Test Setup Photograph 4. Conducted Emissions Test Setup

Contact Information

Applicant

Robert H. Stubblebine(CEO)
[email protected]+7-495-784-73-12Fax: +7-492-784-73-12

Test Firm

MET LaboratoriesAlvin Ilarina
[email protected]408-919-3774Fax: 1234567890

Technical Specifications

#Rule PartsFrequency RangePower Output
115C5.75 GHz - 5.83 GHz200.00 mW
Confidentiality
Long Term
Grant Notes
Power Output listed is conducted. This device must be professionally installed. Marketing to the General Public is prohibited. Only the antenna(s) tested in this filing may be used with the transmitter. The use of an antenna other than shown in the filing requires a permissive change. The antennas used for this transmitter must be installed to provide a separation distance of at least 50.2 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End -users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
