T5P-AIA100Pool alarm system for aquatic centers to alert first responders.

BY RJE TECHNOLOGIES, INC. Users Manual RJE TECHNOLOGIES, INC. 15375 Barranca Parkway I-112 • Irvine, CA 92618 • Phone 949-943-3349 Email: [email protected] • Website: www.rjetechnologies.com Aquatic Incident Alert Users Manual Components: Needed for installation: • Power Drill • Screwdriver • Level AIAI 100 Basewith AC adapter AIAI 150 Receiverwith adapter AIAI 200 Repeaterwith adapter Alarm Power B attery BY RJE TECHNOLOGIES, INC. Repeater BY RJE TECHNOLOGIES, INC. Alarm PowerBattery BY RJE TECHNOLOGIES, INC. Reset Screw antenna into side of base Suggested installation sites The AIAI 100 Basemust see the pool and is suitable for outdoors instal- lation. The base has a siren and will alarm when activated by SOS sensors. Should be wall mounted 5 feet above ground level. It must be plugged into an AC outlet. The AIAI 150 Receiverhas a siren and should be placed where first responders can hear it. It must be plugged into a USB port or and AC outlet. The AIAI 200 Repeater200 Repeater can be wall mounted and should be placed in a location to extend range of signal if needed. The Repeater does not have a siren and is used strictly to extend the range to the receiver. It must be plugged into an AC outlet. Introduction RJE Technologies, Inc Aquatic Incident Alert is a commercial pool alarm system designed to alert responders when the life guard has entered the water. SOS sensors are placed on the life guard’s tube and activated by a water switch. The system is designed to work in large facilities and has an optional repeater to extend range if necessary. Installation Each components has an antennae that must be screwed on. The Base and Repeater come with hardware to wall mount 5 feet above ground level. The receiver can sit on a desk or shelf and has a USB cord and power adapter. Operation Once the components are mounted and plugged in the system is ready to use. SOS sensors on the life guards’ tube will activate the alarm when they are in the water. The system will alarm at the Base and Receiver. To stop the alarm, the SOS sensor must be wiped off and the reset button on the Base is pushed to rearm the system. The alarm cannot be stopped at the First Responder location Receiver. The Repeater does not alarm nor can it stop the alarm. The power light on the Base and Receiver will always be on when the system is plugged in and the alarm light will flash when activated. The battery indicator on the base and receiver will flash when the battery in the SOS sensor is low. Be sure to push the reset button on the Base after an alarm. This places the system back into armed mode. SOS sensors must be dry to discontinue the alarm. Federal Communications Commission (FCC) Notice Model: AIA100 (Aquatic Incident Alert) FCC ID: T5P-AIA100 This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by RJE Technologies, Inc. could void the users authority to operate the equipment. Email: [email protected] • Website: www.rjetechnologies.com BY RJE TECHNOLOGIES, INC.

This report contains a total of 44 pages and may be reproduced in full only. Partial reproduction may only be done with the written consent of CKC Laboratories, Inc. RJE Technologies, Inc. EMC TEST REPORT FOR Pool Safety Alarm Model: Aquatic Incident Alert (Safety Turtle) AIA100 Tested To The Following Standards: FCC Part 15 Subpart C Section(s) 15.207 & 15.249 Report No.: 97475-4 Date of issue: September 1, 2015 This test report bears the accreditation symbol indicating that the testing performed herein meets the test and reporting requirements of ISO/IEC 17025 under the applicable scope of EMC testing for CKC Laboratories, Inc. We strive to create long-term, trust based relationships by providing sound, adaptive, customer first testing services. We embrace each of our customers’ unique EMC challenges, not as an interruption to set processes, but rather as the reason we are in business. Page 2 of 44 Report No.: 97475-4 TABLE OF CONTENTS Administrative Information .......................................................................................................................... 3 Test Report Information ............................................................................................................................................ 3 Report Authorization ................................................................................................................................................. 3 Test Facility Information ............................................................................................................................................ 4 Software Versions ...................................................................................................................................................... 4 Site Registration & Accreditation Information .......................................................................................................... 4 Summary of Results ................................................................................................................................................... 5 Modifications During Testing ..................................................................................................................................... 5 Conditions During Testing.......................................................................................................................................... 5 Equipment Under Test ............................................................................................................................................... 6 FCC Part 15 Subpart C ................................................................................................................................... 7 15.207 AC Conducted Emissions ................................................................................................................................ 7 15.215(c) 20dB Occupied Bandwidth ...................................................................................................................... 16 15.31(e) Voltage Variations ..................................................................................................................................... 21 15.249(a) Field Strength of Fundamental ................................................................................................................ 25 15.249(a)(d) Field Strength of Spurious Emissions and Band Edge ......................................................................... 31 Supplemental Information .......................................................................................................................... 43 Measurement Uncertainty ...................................................................................................................................... 43 Emissions Test Details .............................................................................................................................................. 43 Page 3 of 44 Report No.: 97475-4 ADMINISTRATIVE INFORMATION Test Report Information REPORT PREPARED FOR: REPORT PREPARED BY: RJE Technologies, Inc. 15375 Barranca Parkway I-112 Irvine, CA 92618 Morgan Tramontin CKC Laboratories, Inc. 5046 Sierra Pines Drive Mariposa, CA 95338 Representative: Corinne Zemla Project Number: 97475 Customer Reference Number: 11071 DATE OF EQUIPMENT RECEIPT: August 26, 2015 DATE(S) OF TESTING: August 26 - 27, 2015 Report Authorization The test data contained in this report documents the observed testing parameters pertaining to and are relevant for only the sample equipment tested in the agreed upon operational mode(s) and configuration(s) as identified herein. Compliance assessment remains the client’s responsibility. This report may not be used to claim product endorsement by A2LA or any government agencies. This test report has been authorized for release under quality control from CKC Laboratories, Inc. Steve Behm Director of Quality Assurance & Engineering Services CKC Laboratories, Inc. Page 4 of 44 Report No.: 97475-4 Test Facility Information Our laboratories are configured to effectively test a wide variety of product types. CKC utilizes first class test equipment, anechoic chambers, data acquisition and information services to create accurate, repeatable and affordable test results. TEST LOCATION(S): CKC Laboratories, Inc. 110 Olinda Place Brea, CA 92823 Software Versions CKC Laboratories Proprietary Software Version EMITest Emissions 5.02.00 Immunity 5.00.07 Site Registration & Accreditation Information Location CB # TAIWAN CANADA FCC JAPAN Brea A US0060 SL2-IN-E-1146R 3082D-1 90473 A-0147 Brea D US0060 SL2-IN-E-1146R 3082D-2 100638 A-0147 Page 5 of 44 Report No.: 97475-4 SUMMARY OF RESULTS Standard / Specification: FCC Part 15 Subpart C Test Procedure Description Modifications* Results 15.207 Conducted Emissions Mod. 1 Pass 15.215(c) 20dB Occupied Bandwidth Mod. 1 Pass 15.31(e) Voltage Variations Mod. 1 Pass…

Text truncated - open the document above for the full version.

X-Axis Y-Axis Z-Axis
