1 GSM Handset Avvio410 User’s Manual 2 UNPACKING Thank you for purchasing Avvio410. Check whether your phone comes eq uipped with all the necessary components, as shown in the figure below. If the product is defective or there is a component missing, immediately c ontact the office where you bought our phone. ■ The packing list contains: SN50 Handset Travel adaptor Battery (Li-ion) Headset User’s manual 3 CONTENTS 2 UNPACKING 4 4 • STK 3 CONTENTS 4 4 • PHONE BOOK 5 SAFETY INFORMATION 4 5 •• Search Conta ct 11 BEFORE YOU START 4 5 •• Add new contact 11 • PHONE ICONS 4 7 • WAP / WEB 1 2 • DESCRIPTION OF KEYS 4 7 •• Internet Service 1 5 • BACKLIGHT 4 8 •• Data Account 1 5 • BATTERY 4 8 •MULTIMEDIA 1 7 • NETWORK LINKING 4 8 •• Camera 1 8 • INSERT & REMOVE SIM 5 1 •• Image View 2 1 • INSERT & REMOVE MicroS D 5 1 •• Audio Player 2 2 • THE IDLE PROFILE 5 2 •• Sound Recorder 2 • CALL FUNCTIONS 5 •• FM radio 4 2 3 2 5 • CALL MENU 5 3 •• Schedule FM Record 2 7 • CALL HISTORY 5 3 •• Melody Composer 2 9 • KEY OPERATION 5 4 • ORGANIZER 3 0 • VIBRATOR MODE 5 4 •• Calendar 3 0 • SILENT MODE 5 5 •• Task 3 1 FUNCTION MENU 5 6 •• Alarm 3 1 • MESSAGING 5 6 •• World Clock 3 1 •• Instant Messaging 5 6 • SETTINGS 3 2 •• Email 5 6 •• Display Setup 3 7 •• SMS / MMS 5 6 •• Phone Setup 4 3 • GAMES 5 7 •• Call Settings 5 9 •• Network Setup 5 5 9 •• Security Setup 6 0 •• User Profiles 6 1 •• Shortcuts 6 1 •• Restore Factory Settings 6 1 • EXTRA 6 1 •• File Manager 6 2 •• Calculator 6 2 •• Currency Converter 6 3 •• Stopwatch 6 3 •• E-book Reader 6 4 MP3 AND MP4 INSTRUCTION 6 5 TROUBLESHOOTING 6 GLOSSARY 6 8 7 0 LIMITED WARRANTY STATEMENT SAFETY INFORMATION PERSONAL USE Operation of any radio equipment including mobile phones may interfere with the function of inadequately shielded medical devices such as hearing aids and pacemakers. Please consult the manufacturer of these devices or your physician before use. In oil depots and chemical factories where explosive gas or other products are stored, the user should pay close attention to the restriction on the use of mobile phone. Even if your phone is in the idle mode, it will still transmit radio frequency signals. Therefore, you must switch off when requested to do so. Note traffic safety. When you are driving, please do no use your mobile phone. 7 Stop on the side of the road when you do need to use it. Avoid making calls with your cellular phone in stormy weather. Safety Information related with children: ■ Be cautious of children swallowing the small parts such as the SIM card. ■ Prevent children from playing with your cell phone as toys. For example, behaviors like throwing, biting the phone, or immersing it into water should be avoided. ■ Do not let children less than 14 years old hang the phone around the neck. MOBILE PHONE USE Please use only the accessories or parts offered by the manufacturer or those authorized by the manufacturer. Use of unauthorized accessories might influence the performance of the phone. What‘s worse, your phone might get damaged and harm will be caused to your body. It might even violate the national regulations on the telecommunication terminal products. Do not use chemical products like cleaning solvents or detergents to clean your phone. It is recommended that you use slightly damp and static electricity proof cloth instead of cloth that is dry and easy to catch static electricity. Before cleaning, you should switch off your phone. Your mobile phone produces magnetic fields. Do not place it next to magnetic storage media such as computer diskettes. Operating your mobile phone close to other electrical equipment such as televisions, phones, radios and personal computers may cause interference and therefore influence the performance of your phone. Do not expose your mobile phone to strong sunlight, direct heat or any liquids in case of any damage. 8 Harsh handling behaviors such as throwing; beating which might damage the internal integrated circuit of the phone should be avoided. Please do not link it to other unnecessary equipments. Note! Non-professionals must not try to dissemble the phone. Phone Precautions! ■ Use your phone battery only for its intended purpose, and never use any battery charger which is damaged or worn out. ■ When you unplug your phone from its charger, grasp and pull the plug, not the power cord. ■ Do not use harsh chemicals, cleaning solvents, or strong detergents to clean your phone. Wipe it with a soft cloth slightly dampened in a mild soap-and-water solution. ■ Do not attempt to open the casing on your phone or its battery. ■ Always keep SIM card out of children‘s reach. ■ The work temperature is -10°C to +55°C BATTERY USE Do not short-circuit the battery terminals. This is dangerous and will damage the battery, produce heat and may cause a fire. Never dispose of batteries in a fire as it can cause explosion. Return waste batteries to your supplier or an approved recycling center. Do not dispose along with household wastes. Warning! If the battery case is broken, avoid contact with the contents. Wash contaminated skin with lots of water and seek medical attention. Battery Precautions! ■ Avoid dropping the cell phone. Dropping it, especially on a hard surface, can potentially cause damage to the phone and battery. If you suspect damage to the phone or battery, take it to a service 9 center for inspection. ■ Never use any charger or battery that is damaged in any way. ■ Use the battery only for its intended purpose. ■ If you use the phone near the network‘s base station, it uses less power; talk and standby time are greatly affected by the signal strength on the cellular network and the parameters set by the network operator. ■ Battery charging time depends on the remaining battery charge and the type of battery and charger used. The battery can be charged and discharged hundreds of times, but it will gradually wear out. When the operation time (talk time and standby time) is noticeably shorter than normal, …

Text truncated - open the document above for the full version.
