T6QQS150QWERTY PHONE

1 Tri-Band GSM/GPRS Handset QS100 User’s Manual 2 UNPACKING Thank you for purchasing QS100. Ch eck whether your phone comes equi pped with all the necessar y components, as shown in the figure below. If the product is defective or there is a component missing, immediately con tact the office where you bought our phone. ■ The packing list contains: QS100 Handset Travel adaptor Battery (Li-ion) Headset User’s manual 3 CONTENTS 2 UNPACKING 30 •• Copy All 3 CONTENTS 31 •• Delete 5 SAFETY INFORMATION 31 •• Caller Groups 11 BEFORE YOU START 31 •• Extra numbers 11 • PHONE ICONS 31 •• Phone Book Setting 11 • DESCRIPTION OF KEYS 33 • MULTIMEDIA 15 • BACKLIGHT 33 •• Image viewer 15 • BATTERY 33 •• Audio player 17 • NETWORK LINKING 34 •• Sound recorder 21 • INSERT & REMOVE 34 •• Melody composer THE MicroSD CARD 35 • CALL HISTORY 22 • THE IDLE PROFILE 38 • SETTINGS 22 • CALL FUNCTIONS 38 •• Display setup 26 • DISPLAY SCREEN 38 •• Phone setup 26 • KEY OPERATION 40 •• Call setting 26 • VIBRATOR MODE 41 •• Network setup 27 • SILENT MODE 41 •• Security setup 27 • CALL LOG 42 •• User profiles 27 • CALL MENU 43 • MESSAGING 29 FUNCTION MENU 43 •• Message 29 • PHONE BOOK 49 •• Chat 30 •• Quick search 49 •• Email 30 •• Search contact 55 •• Voice mail server 30 •• Add New Contact 55 •• Broadcast message 4 56 • FILE MANAGER 56 • ORGANIZER 56 •• Calendar 57 •• Task 57 •• Alarm 57 •• World clock 57 •• Synchronization 58 • SERVICES 58 •• INTERNET 59 •• Data account 59 •• Right Manager 59 •• Connection management 59 • EXTRAS 59 •• Fun & Game 59 •• Calculator 60 •• Unit converter 60 •• Currency converter 60 •• Stopwatch 60 •• E-Book reader 62 MP3 AND MP4 INSTRUCTION 63 TROUBLESHOOTING 66 GLOSSARY 68 LIMITED WARRANTY STATEMENT 5 SAFETY INFORMATION PERSONAL USE Operation of any radio equipment includ ing mobile phones may interfere with the function of inadequately shielded me dical devices such as hearing aids and pacemakers. Please consult the manufa cturer of these devices or your physician before use. In oil depots and chemical factories wh ere explosive gas or other products are stored, the user should pay close attent ion to the restriction on the use of mobile phone. Even if your phone is in the idle mode, it will still transmit radio frequency signals. Therefore, you must switch off when requested to do so. Note traffic safety. When you are driving, please do no use your mobile phone. Stop on the side of the ro ad when you do n eed to use it. Avoid making calls with your cellular phon e in stormy weather. Safety Information related with children: ■ Be cautious of children swallowing the small parts such as the SIM card. ■ Prevent children from playing with your cell phone as toys. For example, behaviors like throwing, biting the phone, or immersing it into water should be avoided. ■ Do not let children less than 14 years old hang the phone around the neck. MOBILE PHONE USE Please use only the accessories or part s offered by the manu facturer or those authorized by the manufacturer. Use of unauthorized accessories might influence the performance of the phone. What’s worse, your phone might get damaged and harm will be caused to your body. It might even violate the national regulations on the telecommunication terminal products. 6 Do not use chemical products like clea ning solvents or detergents to clean your phone. It is recommende d that you use slightly damp and static electricity proof cloth instead of cloth that is dry and easy to catch static electricity. Before cleaning, you should sw itch off your phone. Your mobile phone produces magnetic fiel ds. Do not place it next to magnetic storage media such as computer diskette s. Operating your mobile phone close to other electrical equipmen t such as televisions, phones, radios and personal computers may cause interf erence and therefore infl uence the performance of your phone. Using your phone with a 5 °C - 40 °C temperature and a 35% - 85% humidity. Do not expose your mobile phone to stro ng sunlight, direct heat or any liquids in case of any damage. Harsh handling behaviors such as thro wing; beating which might damage the internal integrated circuit of the phone should be avoided. Please do not link it to ot her unnecessary equipments. Phone shall only be connec ted to a USB interface of version 2.0 or higher. The connection to so called power USB is prohibited. Note! Non-professionals must not try to dissemble the phone. Phone Precautions! ■ Use your phone battery only for its intended purp ose, and never use any battery charger which is damaged or worn out. ■ When you unplug your phone from its charger, grasp and pull the plug, not the power cord. ■ Do not use harsh chemicals, cleaning solvents, or strong detergents to clean your phone. Wi pe it with a soft cloth slightly dampened in a mild soap-and-water solution. ■ Do not attempt to open the casi ng on your phone or its battery. 7 ■ Always keep SIM card out of children’s reach. BATTERY USE Do not short-circuit the ba ttery terminals. This is dangerous and will damage the battery, produce heat and may cause a fire. Never dispose of batteries in a fire as it can cause explos ion. Return waste batteries to your supplier or an appr oved recycling center. Do not dispose along with household wastes. Warning! If the battery case is broken, avoid contact with the contents. Wash contaminated skin with lots of wa ter and seek medical attention. Battery Precautions! ■ Avoid dropping the cell phone. Dropping it, especially on a hard surface, can potentiall y cause damage to the phone and battery. If you suspect damage to the phone or battery, take it to a service center for inspection. ■ Never use any charger or batter y that is damaged in any way. ■ Use the battery only for its intended purpose. ■ If you use the phone ne ar the network’s base station, it uses less power; talk and standb y time are greatly affe cted by the signal strength on the cellular network and the parameters set by the network operator. …

Text truncated - open the document above for the full version.

External Photos 1. Front View of EUT 2. Back View of EUT 3. Side View of EUT

Label Label Location

KCMobile Co., Ltd. 3F., Seochoworld Officetel, 1355-3, SeoCho-Dong, SeoCho-Gu, Seoul 137-862, Korea TEL : 82-2-583-9888 FAX : 82-2-582-2992 Date: Feb 08, 2010 Equipment Authorization Division Office of Engineering and Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Ref: FCC ID: T6QQS150 Dear Sirs: KC Mobile Co., Ltd., requests acceptance of the labeling proposal described below for cell phone bearing FCC identifier T6QQS150. The subject cell phone are compact handheld models as shown in figure 1, authorized under 47CFR Part 22&24 for GSM mobile services. Figure 1. Because the majority of the cell phone housing is composed of display, speaker, operating controls, camera and a removable battery pack, there is extremely limited space available to attach the required label carrying the FCC identifier. Attaching the label to the battery pack is not acceptable because the battery pack is a removable item. For this reason, KC Mobile proposes placing the label carrying the FCC identifier inside the battery compartment as shown in figure 2. KCMobile Co., Ltd. 3F., Seochoworld Officetel, 1355-3, SeoCho-Dong, SeoCho-Gu, Seoul 137-862, Korea TEL : 82-2-583-9888 FAX : 82-2-582-2992 Figure 2. The consumer packaging for these models includes the battery pack as a separate item, NOT installed on the radio. As such, the FCC identifier will be readily visible to the user before the battery pack is installed and whenever the battery pack is removed or replaced. In this location, the label will also be protected from physical abuse and remain readable for the anticipated life of the device. The consumer packaging for these models is a "gift box" which does not allow the transceiver to be seen at time of purchase. In order to meet the requirements of 47CFR Part 2.925 (d), KC Mobile will add the FCC identifier "T6QQS150" to the outside of the consumer "gift box" packaging. Thank you for your attention to this matter. Yours Sincerely, Sung Kyu Lee Marketing manager

Internal Photos

Report No.: SZ09120118E02 Page 2 of 16 TABLE OF CONTENTS 1. TEST CERTIFICATION ........................................................................................................... 3 2. GENERAL INFORMATION .................................................................................................... 4 2.1 EUT Description ......................................................................................................................... 4 2.2 Test Standards and Results........................................................................................................ 5 2.3 Facilities and Accreditations ..................................................................................................... 6 2.3.1 Facilities ................................................................................................................................... 6 2.3.2 Test Environment Conditions ................................................................................................... 6 2.3.3 Measurement Uncertainty ........................................................................................................ 6 3. TEST CONDITIONS SETTING............................................................................................... 7 3.1 Test Mode .................................................................................................................................... 7 3.2 Test Setup and Equipments List ............................................................................................... 9 3.2.1 Conducted Emission ................................................................................................................. 9 3.2.2 Radiated Emission .................................................................................................................. 10 4. 47 CFR PART 15B REQUIREMENTS .................................................................................. 11 4.1 Conducted Emission................................................................................................................. 11 4.1.1 Requirement ........................................................................................................................... 11 4.1.2 Test Description ...................................................................................................................... 11 4.1.3 Test Result .............................................................................................................................. 11 4.1.3.1 GSM Test Mode ........................................................................................................................ 11 4.1.3.2 USB Test Mode ......................................................................................................................... 12 4.2 Radiated Emission .................................................................................................................... 14 4.2.1 Requirement ........................................................................................................................... 14 4.2.2 Test Description ...................................................................................................................... 14 4.2.3 Test Result .............................................................................................................................. 14 Change History Issue Date Reason for change 1.0 February 24, 2010 First edition Report No.: SZ09120118E02 Page 4 of 16 2. GENERAL INFORMATION 2.1 EUT Description EUT Type ....................... Qwerty phone Model Name ................... QS150 Serial No. ....................... (n.a, marked #1 by test site) Hardware Version ........... Revision_02 Software Version ............ MAUI.09A.W09.36.MP.V5.F1 Modulation Type ............ GMSK Power Supply ................. Battery Model Name: 14N6001(A01) Brand name: DESAY BATTERY Capacitance: 1000mAh Rated voltage: 3.7V Manufacturer: DESAY BATTERY Manufacturer Address: NO.16ZONE, ZHONGKAI, HIGH&TECHNOLOGY DEVELOPMENT ZONE, HUIZHOU, GUANGDONG, GHINA Ancillary Equipment 1 ... AC Adapter (Charger for Battery) Model Name: STA-P12ER Brand Name: SUNLIN ELE. Serial No.: (n.a. marked #1 by test site) Rated Input: 96-264V, 200mA Rated Output: 5.1V, 700mA Manufacturer: SUNLIN ELE. Manufacturer Address: 913-3 HO KE-DONG, DONG AN-GU, AU YANG-CITY KYUN GI-DO, KOREA Note 1: The EUT is a GSM/GPRS Mobile Phone; it supports GSM 850MHz, 1800MHz and 1900MHz. GSM 850MHz and 1900MHz are tested in this report. Note 2: The EUT is equipped with a T-Flash card slot; equipped with a special port which can be connected to the ancillary equipments supplied by the manufacturer e.g. the AC adapter and the USB adapter cable, and the EUT can worked as storage. Note 3: For a more detailed description, please refer to Specification or User’s Manual supplied by the applicant and/or manufacturer. Report No.: SZ09120118E02 Page 5 of 16 2.2 Test Standards and Results The objective of the report is to perform testing according to 47 CFR Part 15 Subpart B: No. Identity Document Title 1 47 CFR Part 15 (10-1-05 Edition) Radio Frequency Devices Test detailed items/section required by FCC rules and results are as below: No. Section Description Result 1 15.107 Conducted Emission PASS 2 15.109 Radiated Emission PASS NOTE: The tests were performed according to the method of measurements prescribed in ANSI C63.4 2003. Report No.: SZ09120118E02 Page 6 of 16 2.3 Facilities and Accreditations 2.3.1 Facilities Shenzhen Electronic Product Quality Testing Center Morlab Laboratory is a testing organization accredited by China National Accreditation Service for Conformity Assessment (CNAS) according to ISO/IEC 17025. The accreditation certificate number is L1659. All measurement facilities used to collect the measurement data are located at Electronic Testing Building, Shahe Road, Xili, Nanshan District, Shenzhen 518055 CHINA. The test site is constr…

Text truncated - open the document above for the full version.

Test Setup Photos 1. CE 2. RE
