T6QGM819Quad-Band GSM 850/900/1800/1900 MHz Mobile Phone

KCMobile Co., Ltd.

Click to zoom

Application Details

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Date of Grant: Apr 26, 2007
Application Purpose: Original Equipment
Date of Application: Apr 26, 2007
Equipment Note: Quad-Band GSM 850/900/1800/1900 MHz Mobile Phone
Frequency Range: 1850.20000000 - 1909.80000000
Company: KCMobile Co., Ltd.
Country: South Korea

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Quad-band GSM/GPRS handset GM819 User Guide UNPACKING Thank you for purchasing GM819. Check whether your phone comes equipped with all the nec essary components, as shown in the figure below. If the product is defective or there is a comp onent missing, immediately contact the office where you bought our phone. 9 Phone 9 Li-ion Battery 9 USB type Travel Charger & USB Cable 9 Earphone 9 User Guide 9 Quick Reference Card CONTENTS 0...SAFETY INFORMATION 0...BEFORE YOU START 0...PHONE ICONS 0...DESCRIPTION OF KEYS 0...BACKLIGHT 0...BATTERY 0...NETWORK LINKING 0...INSERT & REMOVE THE T-FLASH CARD 0...THE IDLE PROFILE 0...CALL FUNCTIONS 0...DISPLAY SCREEN 0...KEY OPERATION 0...SILENT MODE 0...CALL LOG 0...CALL MENU 0...FUNCTION MENU 0...AUDIO PLAYER 0...VIDEO PLAYER 0...VIDEO RECORDER 0...CAMERA 0...PHONEBOOK 0...Quick Search 0...Search Entry 0...Add New Entry 0...Copy All 0...Delete 0...Caller Group 0...Extra Number 0...Settings 0...Caller Picture 0...Caller Ring Tone 0...Caller Video 0...Search by Location 0...Options 0...MESSAGE CENTER 0...Message 0...Chat 0...Voice Mail Server 0...Broadcast Message 0...CALL HISTORY 0...Missed Calls 0...Dialed Calls 0...Received Calls 0...Delete Call Log 0...Call Time 0...Call Cost 0...SMS Counter 0...GPRS Counter 0...ORGANIZER 0...Calendar 0...To Do List 0...Alarm 0...World Clock 0...FUN & GAME 0...Games 0...Themes 0...Stopwatch 0...SERVICES 0...SIM Tool Kit 0...WAP 0...Data Account 0...MULTIMEDIA 0...Image Viewer 0...Webcam 0...Photo Editor 0...Sound Recorder 0...Melody Compose 0...EXTRA 0...Calculator 0...Unit Converter 0...Currency Converter 0...Health 0...E-Book Reader 0...SETTINGS 0...Display Setup 0...Phone Setup 0...Call Setup 0...Network Setup 0...Security Setup 0...Sound Effect 0...Restore Factory Settings 0...Software Version 0...USER PROFILES 0...SHORTCUTS 0...FILE MANAGER 0...TEXT INPUT MODE 0...SPANISH/ENGLISH IUPUT MODE 0...Touch Screen Write Input Mode (Pen Editor) 0... Virtual Keyboard Input Mode 0... Input Mode Change 0...Symbols 0...MP3 AND MP4 INSTRUCTION 0...TROUBLESHOOTING 0...GLOSSARY 0...LIMITED WARRANTY STATEMENT SAFETY INFORMATION PERSONAL USE Operation of any radio equipment including mobile phones may interfere with the function of in adequately shielded medical devices such as hearing aids and pacemakers. You must consult t he manufacturer of these devices or your physician before use. In oil depots and chemical factories where explosive gas or other products are stored, the user should pay close attention to the restriction on the use of mobile phone. Even if your phone is i n the idle mode, it will still transmit radio frequency signals. Therefore, you must switch off wh en requested to do so. Note traffic safety. When you are driving, please do no use your mobile phone. Stop on the sid e of the road when you do need to use it. Avoid making calls with your cellular phone in storm y weather. Safety Information related with children: 9 Be cautious of children swallowing the small parts such as the SIM card 9 Prevent children from playing with your cell phone as toys. For example, behaviors l ike throwing, biting the phone, or immersing it into water should be avoided. 9 Do not let children less than 14 years old hang the phone around the neck. MOBILE PHONE USE Please use only the accessories or parts offered by the manufacturer or those authorized by th e manufacturer. Use of unauthorized accessories might influence the performance of the phone. What’s worse, your phone might get damaged and harm will be caused to your body. It might even violate the national regulations on the telecommunication terminal products. Do not use chemical products like cleaning solvents or detergents to clean your phone. It is rec ommended that you use slightly damp and static electricity proof cloth instead of cloth that is d ry and easy to catch static electricity. Before cleaning, you should switch off your phone. Your mobile phone produces magnetic fields. Do not place it next to magnetic storage media s uch as computer diskettes. Operating your mobile phone close to other electrical equipment su ch as televisions, phones, radios and personal computers may cause interference and therefore influence the performance of your phone. Do not expose your mobile phone to strong sunlight, direct heat or any liquids in case of any d amage. Harsh handling behaviors such as throwing; beating which might damage the internal integrate d circuit of the phone should be avoided. Please do not link it to other unnecessary equipments. Note! Non-professionals must not try to dissemble the phone. Phone Precautions! 9 Use your phone battery only for its intended purpose, and never use any battery charger which is damaged or worn out. 9 When you unplug your phone from its charger, grasp and pull the plug, not the power cord. 9 Do not use harsh chemicals, cleaning solvents, or strong detergents to clean your phone. Wipe it with a soft cloth slightly dampened in a mild soap-and-water solution. 9 Do not attempt to open the casing on your phone or its battery. 9 Always keep SIM card out of children’s reach. BATTERY USE Do not short-circuit the battery terminals. This is dangerous and will damage the battery, produ ce heat and may cause a fire. Never dispose of batteries in a fire as it can cause explosion. Return waste batteries to your su pplier or an approved recycling center. Do Not dispose along with household wastes. Warning! If the battery case is broken, avoid contact with the contents. Wash contaminated s kin with lots of water and seek medical attention. Battery Precautions! 9 Avoid dropping the cell phone. Dropping it, especially on a hard surface, can potenti ally cause damage to the phone and battery. If you suspect damage to the phone o r battery, take it to a service center for inspection. 9 Never use any charger or battery that is damaged in any way. 9 Use the battery only for its intended purpose. 9 If you use the phone near the network’s base station, it u…

Text truncated - open the document above for the full version.

Cover Letter(s)

KCMobile Co., Ltd. 3F., Seochoworld Officetel, 1355-3, SeoCho-Dong, Seocho-Gu, Seoul 137-862, Korea Date: Apr. 5, 2007 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road, Columbia, MD 21046, U.S.A. Subject: Authorization Letter FCC ID: T6QGM819 Part 22/24 Certification Quad-Band GSM Phone(GSM850/ GSM900/ DCS1800/PCS1900) – Prototype To whom it may concern: We, the undersigned. hereby authorized HYUNDAI Calibration & Certification Technologies Co., Ltd. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these manners. Any and all acts carried out by HYUNDAI Calibration & Certification Technologies Co., Ltd. on our behalf shall have the same effect as acts of our own. This authorization is valid until Dec. 31, 2007. Sincerely Yours, Daewon Seo / Marketing manager KCMobile Co., Ltd.

Cover Letter(s)

Request for Confidentiality PHOENIX TESTLAB GmbH Date: 2007. 4. 5 Product Certification Königswinkel 10 D 32825 Blomberg RE: Certification Application FCC ID: T6QGM819 Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rule, the applicant hereby requests confidential treatment of information accompanying this application as outlined below: CONFIDENTIAL AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram 2 Operational Descriptions 3 Parts Lists and Tune-Up Procedure CONFIDENTIAL 4 Schematics 5 External Photos 6 Internal Photos 7 Test-Setup Photos SHORT-TERM CONFIDENTIAL 8 User’s Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to rule 0.457, disclosure od this application and all accompanying documentation will not be made before the date of the GRANT for this application ́. Thank you for your attention in this matter. Applicant’s Company : KC Mobile Co., Ltd. address : 3F., Seochoworld Officetel, 1355-3, SeoCho-Dong, Seocho-Gu, Seoul 137-862, Korea Signature : Job Title and Dept. : Daewon Seo / Marketing manager Ersteller: U. Rodemeier Revision: 03 Erstelldatum: 03.08.01 Datum: 4.10.2006 Seite 1 von 1

External Photos

ID Label/Location Info

Internal Photos

Report No.: HCT-SAR07-0405 FCC ID:T6QGM819 DATE: Apr. 11, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr of 10 H. INTERNAL PHOTOGRAPHS Report No.: HCT-SAR07-0405 FCC ID:T6QGM819 DATE: Apr. 11, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr of 10 INTERNAL PHOTO Report No.: HCT-SAR07-0405 FCC ID:T6QGM819 DATE: Apr. 11, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr of 10 INTERNAL PHOTO Report No.: HCT-SAR07-0405 FCC ID:T6QGM819 DATE: Apr. 11, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr of 10 INTERNAL PHOTO Report No.: HCT-SAR07-0405 FCC ID:T6QGM819 DATE: Apr. 11, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr of 10 INTERNAL PHOTO Report No.: HCT-SAR07-0405 FCC ID:T6QGM819 DATE: Apr. 11, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr of 10 INTERNAL PHOTO Report No.: HCT-SAR07-0405 FCC ID:T6QGM819 DATE: Apr. 11, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr of 10 INTERNAL PHOTO Report No.: HCT-SAR07-0405 FCC ID:T6QGM819 DATE: Apr. 11, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr of 10 INTERNAL PHOTO Report No.: HCT-SAR07-0405 FCC ID:T6QGM819 DATE: Apr. 11, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr of 10 INTERNAL PHOTO Report No.: HCT-SAR07-0405 FCC ID:T6QGM819 DATE: Apr. 11, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr of 10 INTERNAL PHOTO Report No.: HCT-SAR07-0405 FCC ID:T6QGM819 DATE: Apr. 11, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr of 10 INTERNAL PHOTO Report No.: HCT-SAR07-0405 FCC ID:T6QGM819 DATE: Apr. 11, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr of 10 INTERNAL PHOTO Report No.: HCT-SAR07-0405 FCC ID:T6QGM819 DATE: Apr. 11, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr of 10 INTERNAL PHOTO Report No.: HCT-SAR07-0405 FCC ID:T6QGM819 DATE: Apr. 11, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr of 10 INTERNAL PHOTO Report No.: HCT-SAR07-0405 FCC ID:T6QGM819 DATE: Apr. 11, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr of 10 INTERNAL PHOTO Report No.: HCT-SAR07-0405 FCC ID:T6QGM819 DATE: Apr. 11, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr of 10 INTERNAL PHOTO

RF Exposure Info

SAR TEST REPORT HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD EUT Type: Quad-Band GSM Phone(GSM850/ GSM900/ DCS1800/PCS1900) GPRS Class 10 and GPRS mode class B(GPRS and GSM, but not simultaneously) FCC ID: T6QGM819 Model: GM819 Trade Name KC Mobile Co., Ltd. Date of Issue: Apr.11, 2007 Test report No.: HCT-SAR07-0405 Test Laboratory: HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNKI-DO, 467-701,KOREA TEL: +82 31 639 8518 FAX: +82 31 639 8525 Applicant : KC Mobile Co., Ltd. 3F., Seochoworld Officetel, 1355-3, Seocho-Dong, Seocho-Gu, Seoul 137-862, Korea Tel: 82-2-583-9888 Fax: 82-2-582-2992 E-Mail: [email protected] Testing has been carried out in accordance with: 47CFR §2.1093 FCC OET Bulletin 65(Edition 97-01), Supplement C (Edition 01-01) ANSI/ IEEE C95.1 – 2005 IEEE 1528-2003 Test result: The tested device complies with the requirements in respect of all parameters subject to the test. The test results and statements relate only to the items tested. The test report shall not be reproduced except in full, without written approval of the laboratory. Signature Report prepared by: Ki-Soo Kim Manager of Product Compliance Team Report No.: HCT-SAR07-0405 FCC ID:T6QGM819 DATE: Apr. 11, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr 2 of 79 Table of Contents 1. INTRODUCTION.......................................................................................................................................... 2. DESCRIPTION OF DEVICE ......................................................................................................................... 3. DESCRIPTION OF TEST EQUIPMENT ...................................................................................................... 3.1 SAR MEASUREMENT SETUP 3.2 DASY E-FIELD PROBE SYSTEM 3.3 PROBE CALIBRATION PROCESS 3.4 SAM Phantom 3.5 Device Holder for Transmitters 3.6 Brain & Muscle Simulating Mixture Characterization 3.7 SAR TEST EQUIPMENT 4. SAR MEASUREMENT PROCEDURE ..................................................................................................... 5. DESCRIPTION OF TEST POSITION ....................................................................................................... 5.1 HEAD POSITION 5.2 Body Holster/Belt Clip Configurations 6. MEASUREMENT UNCERTAINTY ........................................................................................................... 7. ANSI/ IEEE C95.1 - 2005 RF EXPOSURE LIMITS .................................................................................. 8. SYSTEM VERIFICATION ......................................................................................................................... 8.1 Tissue Verification 8.2 System Validation 9. SAR TEST DATA SUMMARY ................................................................................................................... 9.1 Measurement Results (GSM850 Head SAR Touch) 9.2 Measurement Results (GSM850 Head SAR Tilt) 9.3 Measurement Results (GSM1900 Head SAR Touch) 9.4 Measurement Results (GSM1900 Head SAR Tilt) 9.5 Measurement Results (GSM850 Body SAR) 9.6 Measurement Results (GSM1900 Body SAR) 10. CONCLUSION ........................................................................................................................................ 11.REFERENCES ........................................................................................................................................ Attachment 1. – SAR Test Plots.................................................................................................................... Attachment 2. – Dipole Validation Plots........................................................................................................ Attachment 3. – Probe Calibration Data....................................................................................................... Attachment 4. – Dipole Calibration Data...................................................................................................... Report No.: HCT-SAR07-0405 FCC ID:T6QGM819 DATE: Apr. 11, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr 3 of 79 1. INTRODUCTION The FCC has adopted the guidelines for evaluating the environmental effects of radio frequency radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices. [1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-2005 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. (c) 1992 by the Institute of Electrical and Electronics Engineers, Inc., New York, New York 10017.[2] The measurement procedure described in IEEE/ANSI C95.3-1992 Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields - RF and Microwave[3] is used for guidance in measuring SAR due to the RF radiation exposure from the Equipment Under Test (EUT). These criteria for SAR evaluation are similar to those recommended by the National Council on Radiation Protection and Measurements (NCRP) in Biological Effects and Exposure Criteria for Radio frequency Electromagnetic Fields,” NCRP Report No. 86 (c) NCRP, 1986, Bethesda, MD 20814.[4] SAR is a measure of the rate of energy absorption due to exposure to an RF transmitting source. SAR values have been related to threshold levels for potential biological hazards. SAR Definition Specific Absorption Rate (SAR) is defined as …

Text truncated - open the document above for the full version.

RF Exposure Info

KCMobile Co., Ltd. 3F., Seochoworld Officetel, 1355-3, SeoCho-Dong, Seocho-Gu, Seoul 137-862, Korea Date: Apr. 5, 2007 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road, Columbia, MD 21046, U.S.A. Subject: User's Manual RF Exposure Warning Statement FCC ID: T6QGM819 Part 22/24 Certification Quad-Band GSM Phone(GSM850/ GSM900/ DCS1800/PCS1900) – Prototype Gentlemen: KCMobile Co., Ltd. hereby confirms that the attached RF exposure warning page will be readily visible to the user, and will be placed at a prominent location in the front section of the user's manual. Should you have any questions or comments concerning the above, please do not hesitate contact me. Sincerely Yours, Daewon Seo / Marketing manager KCMobile Co., Ltd.

Test Report

HYUNDAI CALIBRATION & CERTIFICATION TECH. CO., LTD. PRODUCT COMPLIANCE DIVISION SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr CERTIFICATE OF COMPLIANCE FCC Part 24, 22 Certification EUT Type: Quad-Band GSM Phone(GSM850/ GSM900/ DCS1800/PCS1900)– Prototype GPRS class 10 and GPRS mode class B (GPRS and GSM, but not simultaneously) Tx Frequency: 824.20 – 848.80 MHz (GSM850) / 1850.20 – 1909.80 MHz (GSM1900) Rx Frequency: 869.20 – 893.80 MHz (GSM850) / 1930.20 – 1989.80 MHz (GSM1900) Max. RF Output Power: 0.791 W ERP GSM850 (28.98 dBm) / 0.769 W EIRP GSM1900 (28.86 dBm) Trade Name/Model(s): KC Mobile / GM819 FCC Classification: Licensed Portable Transmitter Held to Ear (PCE) Application Type: Certification FCC Rule Part(s): §22 Subpart H, §24 Subpart E, §2 Maximum SAR: 0.963 W/kg GSM850 Head SAR / 0.648 W/kg GSM850 Body SAR 0.655 W/kg GSM1900 Head SAR / 0.309 W/kg GSM1900 Body SAR Antenna Specifications: Manufacturer: KWANG HYUN AIRTECH MODEL: KH-GMQI-KCM001 (Length= 43.08 mm) Emission Designator(s): 300KGXW (GSM) This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in 2.947. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Hyundai C-Tech Co., Ltd. Certifies that no party to this application has been denied FCC benefits pursuant to section 5301 of the Anti- Drug Abuse Act of 1998, 21 U.S. C. 853(a) Report prepared by : Ki-Soo Kim Manager of Product Compliance Team This report only responds to the tested sample and may not be reproduced, except in full, without written approval of the HCT Co., Ltd. KC Mobile Co., Ltd. 3F., Seochoworld Officetel, 1355-3, Seocho-Dong, Seocho-Gu, Seoul 137-862, Korea Date of Issue: April 11, 2007 Test Report No.: HCT-SAR07-0405 Test Site: HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. FCC ID : APPLICANT : T6QGM819 KC Mobile Co., Ltd. Report No.: HCT-SAR07-0405 FCC ID:T6QGM819 DATE: Apr. 11, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr of 28 Table of Contents A: COVER LETTER(S) B: ATTESTATION STATEMENT(S) C: TEST REPORT 1.1 SCOPE -------------------------------------------------------------------------- 2.1 INTRODUCTION ------------------------------------------------------------- 3.1 INSERTS------------------------------------------------------------------------- 4.1 DESCRIPTION OF TESTS------------------------------------------------- 5.1 EFFECTIVE RADIATED POWER OUTPUT -------------------------- 6.1 EQUIVALENT ISOTROPIC RADIATED POWER--------------------- 7.1 RADIATED MEASUREMENTS------------------------------------------- 8.1 FREQUENCY STABILITY ------------------------------------------------- 9.1 PLOTS OF EMISSIONS---------------------------------------------------- 10.1 LIST OF TEST EQUIPMENT -------------------------------------------- 11.1 SAMPLE CALCULATIONS ---------------------------------------------- 12.1 CONCLUSION---------------------------------------------------------------- D: TEST PLOTS E: FCC ID LABEL & LOCATION F: TEST SETUP PHOTOGRAPHS G: EXTERNAL PHOTOGRAPHS H: INTERNAL PHOTOGRAPHS I: ANTENNA SPECIFICATION J: BLOCK DIAGRAM (S) K: CIRCUIT DIAGRAMS L: PARTS LIST M: OPERATIONAL DESCRIPTION N: USER’S MANUAL O: SAR MEASUREMENT REPORT P: SAR TEST SETUP PHOTOGRAPHS Q: TUNE-UP PROCEDURE 3 4 5 6-14 15 16 17-22 22-24 25 26 27 28 Report No.: HCT-SAR07-0405 FCC ID:T6QGM819 DATE: Apr. 11, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr of 28 MEASUREMENT REPORT 1.1 SCOPE Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. General Information • FCC ID: T6QGM819 • EUT Type: Quad-Band GSM Phone(GSM850/ GSM900/ DCS1800/PCS1900)– Prototype • Trade Name: KC Mobile Co., Ltd. • Model(s): GM819 • Serial Number(s): T6QGM81920070401 • Tx Frequency: 824.20 – 848.80 MHz (GSM850) 1850.20 – 1909.80 MHz (GSM1900) • Rx Frequency: 869.20 – 893.80 MHz (GSM850) 1930.20 – 1989.80 MHz (GSM1900) • Application Type: Certification • FCC Classification: Licensed Portable Transmitter Held to Ear (PCE) • FCC Rule Part(s): §22 Subpart H, §24 Subpart E, §2 • Modulation(s): GSM • Αntenna Type: Intenna • Date(s) of Tests: Apr. 10, 2007 • Place of Tests: Hyundai C-Tech. EMC Lab. Icheon-Si, Kyounki-Do, KOREA • Report Serial No.: HCT-SAR07-0405 Company Name: KC Mobile Co., Ltd. Address: 3F., Seochoworld Officetel, 1355-3, Seocho-Dong, Seocho-Gu, Seoul 137-862, Korea Attention: Daewon Seo - Marketing Manager Tel. / Fax : 82-2-583-9888 / 82-2-582-2992 E-Mail : [email protected] Report No.: HCT-SAR07-0405 FCC ID:T6QGM819 DATE: Apr. 11, 2007 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr of 28 2.1 INTRODUCTION EUT DESCRIPTION The KC Mobile Co., Ltd. Quad -Band GSM Phone. Its basic purpose is used for communications. It transmits from (824.20 – 848.80 MHz (GSM850), 1850.20 – 1909.80 MHz (GSM1900)) and receives from (869.20 – 893.80MHz (GSM850), 1930.20 – 1989.80 MHz (GSM1900)). The RF power is rated at GSM850 (0.791 W), GSM1900 (0.769 W). MEASURING INSTRUMENT CALIBRATION The measuring equi…

Text truncated - open the document above for the full version.

Test Report

Text truncated - open the document above for the full version.

Contact Information

Applicant

Sung Kyu Lee(Marketing manager)

[email protected]82-2-583-9888Fax: 82-2-582-2992

Technical Contact

HCT CO., LTD.Sung-Ko Hong

[email protected]82-31-639-8518

SAN 136-1, AMI-RI , BUBAL-EUP, · South Korea

Non-Technical Contact

HCT CO., LTD.Keun-ho Park

[email protected]82-31-639-8518

Test Firm

HCT Co., LTDSang Lee

[email protected]82-31-645-6420Fax: 82-31-645-6401

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
2	24E	1.85 GHz - 1.91 GHz	769.00 mW	300KGXW	2.5 ppm

Confidentiality

Long Term

Grant Notes

Power listed is ERP for part 22 and EIRP for part 24. This device contains functions that are not operational in U.S Territories. This filing is only applicable for US operations. SAR compliance for body-worn operating configurations is limited to belt-clips, holsters or similar accessories that have no metallic component in the assembly and must provide a minimum separation distance of 1.5 cm between the device and the body. End-users must be provided with the appropriate information for satisfying RF exposure compliance. Highest reported SAR values are: Part 22 - Head: 0.963 W/kg, Body: 0.648 W/kg and Part 24 - Head: 0.655 W/kg, Body: 0.309 W/kg;
