T8O20102783Wireless Video Inspection Scope

Wireless Video Scope Snap-on 1 Visual Inspection Device BK5500 Wireless Video Scope Snap-on 3 Table of Contents General Safety Information.......................................................................................5 Work Area Safety ...................................................................................................5 Personal Safety ......................................................................................................5 Battery Precautions ................................................................................................5 Visual Inspection Device Use and Care .................................................................5 Service....................................................................................................................6 Specific Safety Information ......................................................................................6 FCC Compliance Statement...................................................................................6 FCC Interference Statement...................................................................................6 FCC Exposure Statement.......................................................................................7 PAL/SECAM Statement..........................................................................................7 Visual Inspection Device Safety .............................................................................7 Description, Specifications and Standard Equipment...........................................8 Description..............................................................................................................8 Specifications..........................................................................................................8 Standard Equipment ...............................................................................................9 Assembly ................................................................................................................9 To Install Batteries in either the Display Unit (3 AA) or the Handle (3 AA): ...........9 To connect the Imager to the Handle: ....................................................................9 Installing an Accessory.........................................................................................11 To connect the mirror: ..........................................................................................11 Tool and Work Area Setup......................................................................................11 Operating Instructions ............................................................................................11 Using the Display Unit and Imager.......................................................................11 To turn the Display Unit on: ..................................................................................11 To turn the Handle on:..........................................................................................12 To adjust the brightness of the LED light: ............................................................12 Typical Applications ..............................................................................................13 Instructions for the Video Out feature...................................................................13 Wireless Video Scope 4 Snap-on Transportation and Storage................................................................................... 14 Maintenance Instructions....................................................................................... 14 Snap-on Service Center Locations ....................................................................... 14 Troubleshooting...................................................................................................... 15 User serviceable repair parts................................................................................. 15 Warranty................................................................................................................... 15 Wireless Video Scope Snap-on 5 General Safety Information Read and understand all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious personal injury. SAVE THESE INSTRUCTIONS! Work Area Safety • Keep your work area clean and well lit. Cluttered benches and dark areas may cause accidents. • Do not operate electrical devices or visual inspection tool in explosive atmospheres, such as in the presence of flammable liquids, gases, or heavy dust. Electrical devices or visual inspection tools create sparks which may ignite the dust or fumes. • Do not use the visual inspection tool around corrosive chemicals. • Keep bystanders, children, and visitors away while operating visual inspection tool. Do not let visitors contact the unit. Personal Safety • Stay alert, watch what you are doing and use common sense. Do not use visual inspection tool while tired or under the influence of drugs, alcohol, or medications. A moment of inattention while operating tools may result in serious personal injury. • Do not overreach. Keep proper footing and balance at all times. Proper footing and balance enables better control of the tool in unexpected situations. • Use safety equipment. Always wear eye protection. Dust mask, non-skid safety shoes, hard hat, or hearing protection must be used for appropriate conditions. • Use proper accessories. Do not place this product on any unstable cart or surface. The product may fall causing serious injury to a person or serious damage to the product. • Prevent object and liquid entry. Never spill liquid of any kind on the video display unit. Liquid increases the risk of electrical shock and damage to the product. • Do not use this device for personal or medical use/inspection in any way. • The unit is not shock-resistant. Do not use it as a hammer or drop it. Battery Precautions …

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Revised wording (current) 1.0 2.0 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 2010-3-29 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, _______CRS ELECTRONIC(SHEN ZHEN) CO., LTD_ __ _hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product Name: Wireless Video Inspection Scope Model Name: BK5500W FCC ID: T8O20102783 We affirm that between SIEMIC and __ CRS ELECTRONIC (SHNE ZHEN) CO., LTD.___, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature Client’s name / title：Peter Kang/R&D Dep. Director Contact information / address: Fangmapu, Gui Hua Village, Guanlan, Shenzhen, Guang Dong Province,518110, China. CRS ELECTRONIC(SHEN ZHEN)CO.,LTD. Tel: +86-755-2808-2545 Fax:+ 86-755-2808-3309 Address: Fangmapu,Guihua Village,Guanlan, Shenzhen,Guangdong Province, 518110, China.

SCS-F19: Confidentiality Request Letter Rev 1.0 Nov 14, 2006 Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 SCS-F19: Confidentiality Request Letter Rev 1.0 Nov 14, 2006 2010-3-29 To: Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID:T8O20102783 We hereby request confidential treatment of information accompanying this application as outlined below: Long Term - Circuit Diagram - Block Diagram - Operational Description Short Term - EUT Internal Photo The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Client’s name / title: Peter Kang/R&D Dep.Manager Contact information / address: Fangmapu, Gui Hua Village, Guanlan, Shenzhen, Guang Dong Province, 518110,China CRS ELECTRONIC(SHEN ZHEN)CO.,LTD. Tel: +86-755-2808-2545 Fax:+ 86-755-2808-3309 Address: Fangmapu,Guihua Village,Guanlan, Shenzhen,Guangdong Province, 518110, China

EUT EXTERIOR PHOTO

Proposed Label Location On EUT EUT Bottom View/Proposed FCC ID LABEL location

EUT INSIDE PHOTO

Note: This report shall not be reproduced except in full, without the written approval of Sintek Laboratory CO., Ltd. This document may be altered or revised by Sintek Laboratory Co., Ltd. personnel only, and shall be noted in the revision section of the document. Page 1 of23 FCC 47 CFR PART 15 SUBPART C TEST REPORT For CRS ELECTRONIC(SHEN ZHEN) CO.,LTD. Wireless Video Inspection Scope Model: BK5500W Trade Name: Wireless Borescope Report No. : ST1003015F Prepared for CRS ELECTRONIC(SHEN ZHEN) CO.,LTD. Fangmapu,Guihua Village Gualan, Shenzhen Guangdong Province,518110 China Prepared by SINTEK LABORATORY CO., LTD. No. 7, XINSHIDAI INDUSTRIAL, GUANTIAN VILLAGE, SHIYAN TOWN, BAOAN DISTRICT, SHENZHEN, GUANGDONG, P.R.C. TEL: 86-755-27604866 FAX: 86-755-27608359 Page 2 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION............................................................................................. 3 2. EUT DESCRIPTION .................................................................................................................... 4 3. TEST METHODOLOGY ............................................................................................................. 5 3.1 EUT CONFIGURATION...................................................................................................................5 3.2 EUT EXERCISE...............................................................................................................................5 3.3 GENERAL TEST PROCEDURES........................................................................................................5 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS....................................................6 3.5 DESCRIPTION OF TEST MODES......................................................................................................6 4. INSTRUMENT CALIBRATION................................................................................................. 7 5. FACILITIES AND ACCREDITATIONS ................................................................................... 8 5.1 FACILITIES ..................................................................................................................................8 5.2 EQUIPMENT...................................................................................................................................8 5.3 LABORATORY ACCREDITATIONS AND LISTING.............................................................................8 6. SETUP OF EQUIPMENT UNDER TEST .................................................................................. 9 6.1 SETUP CONFIGURATION OF EUT....................................................................................................9 6.2 SUPPORT EQUIPMENT ............................................................................................................9 7. FCC PART 15.249 REQUIREMENTS...................................................................................... 10 7.1 BAND EDGES MEASUREMENT ...........................................................................................10 7.2 RADIATED EMISSIONS................................................................................................................14 7.3 POWER LINE CONDUCTED EMISSIONS........................................................................................21 8. APPENDIX 1 PHOTOGRPHS OF TEST SETUP ................................................................... 24 Page 3 1. TEST RESULT CERTIFICATION Applicant: CRS ELECTRONIC(SHEN ZHEN) CO.,LTD. Fangmapu,Guihua Village Gualan, Shenzhen Guangdong Province, 518110 China Equipment Under Test: Wireless Video Inspection Scope Tra de Na me : WIRELESS BORESCOPE Model: BK5500W Date of Test: Mar 25~Apr 6, 2010 Report No. : ST1003015F FCC ID : T8O20102783 APPLICABLE STANDARDS STANDARD TEST RESULT FCC Part 15 Subpart C No non-compliance noted We hereby certify that: The above equipment was tested by SINTEK LABORATORY CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4: 2003 and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 15.249. The test results of this report relate only to the tested sample identified in this report. Approved by: Reviewed by: Summary of Measurement Test Item Test Requirement Standard Paragraph Result Antenna Requirement FCC PART15 15.203 Compliance Conducted Emission FCC PART15 15.207 Not applicable Radiation Emission FCC PART15 15.209&15.249 Compliance Band edge Requirement FCC PART15 15.249 Compliance Page 4 2. EUT DESCRIPTION Product Wireless Video Inspection Scope Tra de Name WIRELESS BORESCOPE Model Number BK5500W Model Discrepancy N/A Power Supply DC 4.5V Frequency Range 2414 ~ 2468 MHz Antenna Specification The EUT’S antenna is integrated on the main PCB Number of Channels 4 Channels Antenna Requirement Requirement(s): 47 CFR §15.203 An intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. Antenna requirement must meet at least one of the following: a) Antenna must be permanently attached to the device. b) Antenna must use a unique type of connector to attach to the device. c) Device must be professionally installed. Installer shall be responsible for ensuring that the correct antenna is employed with the device. The EUT’S antenna is fixed on the main PCB / Gain: 0.21dBi Note: This submittal(s) (test report) is intended for FCC ID: T8O20102783 filing to comply with Section 15.249 of the FCC Part 15, Subpart C Rules. Page 5 3. TEST METHODOLOGY The tests documented in this report were performed in accordance with ANSI C63.4 and FCC CFR 47 2.1046, 2.1047, 2.1049, 2.1051, 2.1053, 2.1055, 2.1057, and 15.249. 3.1 EUT CONFIGURATION The EUT configuration for testing is instal…

Text truncated - open the document above for the full version.

TEST SETUP PHOTO
