T8QSN1000AXTPMS transmitter

1 Precautions.......................................................................................2 Location of controls and outlook....................................................4 RECEIVER MODULE DESCRIPTION..............................................................4 SENSOR DESCRIPTION............................................................................5 RECEIVER MODULE INSTALLATION INSTRUCTIONS.........................................5 THE INSTALLATION OF TIRE PRESSURE SENSORS...........................................6 SENSOR RUNS OUT OF BATTERY SENSOR POWER SHORTAGES...........................9 ANTI-THEFT TOOL FOR SENSOR (OPTIONAL) ..............................................10 SETTING ADVANCED............................................................................12 Trouble shooting............................................................................13 Product package content..............................................................14 Product specification.....................................................................15 2 Precautions 1. Please double confirm if sensors are fitted tightly. If necessary, please spreading soap water on the valve stem to check any air leakage. 2. If tire pressure is getting down or dropping quickly, please stop car immediately to find out if tire is deflated or another other problem is happening. 3. Many environmental factors cause tire pressure rise and down as well. For example, hot weather or warm tire will lead rising tire pressure. 4. It is natural that tire pressure will decrease by days but not caused by the installation of tire pressure monitoring system. TYREDOG TPMS can response with its real figure of pressure. 5. Please don’t mix your sensor with other systems’, as each system has its separate unique identified number of sensor, or the mixed sensor won’t activate. 6. Reinstall the sensor battery. After removing the sensor battery, conduct discharge advanced motion to the sensors, this purpose is to reset the sensor. 7. Notice: The changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 8. IMPORTANT NOTE: To comply with the FCC RF exposure compliance requirements, no change to the antenna or the device is permitted. Any change to the 3 antenna or the device could result in the device exceeding the RF exposure requirements and void user’s authority to operate the device. 9. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 4 Location of controls and outlook Receiver Module Description Power Input Connector Signal Input Terminal Receiver module body PIN1:VDD PIN5:GND PIN1:VDD PIN5:GND PIN9:RX PIN8:TX 5 Sensor description Receiver Module Installation Instructions Receiver module can be powered through the PC, then the information can be received, as below: Receiver Module Receiver module and the PC can be supplied power through the power cord, then the information can be received, as below: Valve stem connection Sensor battery cover 6 The installation of tire pressure sensors As each sensor has its own position, you have to make sure its pre-set position. When inserting batteries in every sensors please don’t mix up sensor caps and every sensors have own positions and sensors map could give guidance for user to install. Here is sensor map: (1) means “ Front Left Tire ”. (2) means “ Front Rear Tire”. (3) means “ Rear Left Tire ”. (4) means “ Rear Right Tire ”. Note: Make sure sensor body won’t mix up with other sensor cap. 1 2 3 4 7 Insert batteries in sensors ①Take away sensor cap in anti-clockwise direction. ② Insert lithium battery and make sure battery polarity correct when insert it. ③ Fit sensor cap in a clockwise direction. + 8 Note: Please refer to “sensor map” to make sure the right position of each sensor and please don’t mix up sensor caps either. You will find either sensor cap and sensor body have marks to remind user of its position. Note: Due to the sensor consumes very small battery power, so that the remaining battery power could be retained for some time, in the process of resetting the battery and cause malfunctions. Battery replacement is recommended, should be discharged on the sensor, please follow these steps: A. Could use metal objects, such as coins, keys... etc., into the sensor at the same time touching the battery metal holder and yellow color area (battery holders negative), to achieve the power discharge. As shown in the photo. B. Then re-insert the lithium battery into sensor. Take 1st for example １ (１) Battery spring Coins 9 Sensor runs out of battery sensor power shortages Sensors for the electronic detection devices, requires the use of power-driven functions. If the Sensor appears sensor power shortages, the warning of low battery will be sent by the receiver module, please replace the sensor lithium batteries, in order to collect accurate tire information. 10 Anti-theft tool for sensor (Optional) Anti–theft tool is designed to prevent the possibility of sensors being taken away. Users can decide if it is needed or not. ①Put anti-theft fixed ring onto valve stem. ② Install sensors onto valve stem. Don’t install sensors by brute force. Valve Hex socket screw Anti-theft fixed ring Sensor 11 ③ Adjust the anti-theft fixed ring position to install it with sensor in place firmly. ④ Put the hex socket screw onto the anti-theft fixed ring. (Please don’t exert excessively to damage the valve.) ⑤ When four tire pressure sensors are installed, please check with detergent water if the tire pressure sensors and tire valve is completely fitted without any air leakage. (Spread detergent water on the valve stem.) The anti-theft tool can be decided to install or not. If not, step…
