T9R-TAG3RFID Tag

Document: Fiche d’installation Distribution: Extérieur Non - Contrôlé Page: 1 de 1 Le présent document et les renseignements qui y sont contenus sont confidentiels et la propriété de TAG INC. et ne peuvent être utilisés ou divulgués sans le consentement préalable et écrit d'un officier de celles- ci. This document and the information contained therein are confidential and proprietary of TAG INC. and shall not be used or disclosed without the prior written consent of one of their officers. EVI-KIT1 Installation Sheet INSTALLATION PROCEDURE 1) The number of tags included with the kits may vary. It is recommended, whenever possible, to install half of the kits inside the vehicle and the other half outside. 2) A minimum of 1 (one) meter in between each tags shall be observed during the installation. 3) Installations should be done with long term durability in mind. The tags shall not be installed with parts or components that are likely to be replaced either with vehicle aging, rust, or minor accidents. As an example, bumpers and mirrors must be avoided since they are frequently replaced following a collision. 4) The installation can be done inside the compartments and/or the components of the vehicle, as long as the tag is not completely enclosed within a metallic space. 5) The authorized materials to affix the tags to the vehicle are the following: dum-dum, hockey tape, epoxy, spray glue such as “3M Spray Glue”. IT IS REQUIRED TO FIX THE TAGS CAREFULLY ON THE VEHICULE TO AVOID LOSING TAGS ON THE ROAD. 6) It is important to be creative in installing the kit. THE TAGS SHALL BE HIDDEN IN DIFFERENT PLACES FROM ONE VEHICULE TO ANOTHER. P LEASE AVOID 1) The tags should not be installed within an enclosed metallic container or space. For example, a drop-in installation in the frame of the vehicle must be avoided since it would inhibit signal propagation. 2) The enclosure of the tags must not be modified in any way. The components occupy all the space within the enclosure. Document: Fiche d’installation Distribution: Extérieur Non - Contrôlé Page: 1 de 2 Le présent document et les renseignements qui y sont contenus sont confidentiels et la propriété de TAG INC. et ne peuvent être utilisés ou divulgués sans le consentement préalable et écrit d'un officier de celles- ci. This document and the information contained therein are confidential and proprietary of TAG INC. and shall not be used or disclosed without the prior written consent of one of their officers. ****SAFETY GUIDELINE**** PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY Never install a tag in less than 20 centimeters from the occupant Document: Fiche d’installation Distribution: Extérieur Non - Contrôlé Page: 1 de 3 Le présent document et les renseignements qui y sont contenus sont confidentiels et la propriété de TAG INC. et ne peuvent être utilisés ou divulgués sans le consentement préalable et écrit d'un officier de celles- ci. This document and the information contained therein are confidential and proprietary of TAG INC. and shall not be used or disclosed without the prior written consent of one of their officers. Fiche d’installation du kit EVI-KIT1 PROCEDURE D’INSTALLATION (1) Le nombre de modules compris dans les kits peut varier. Il est important, dans la mesure du possible, d’installer la moitié des modules du kit a l’intérieur du véhicule et l’autre moitié a l’extérieur. (2) Les modules doivent être installés a une distance minimale de un (1) mètre l’un de l’autre. (3) Il est important de prévoir une installation efficace à long terme. Donc, les modules ne doivent pas être installer a des endroit ou dans des pièces qui risques de devoir être remplacer, soit avec l’usure normale du véhicule, la dégradation cause par la rouille ou en cas d’accident mineur. A titre d’exemple, les pare- chocs et les miroirs extérieurs sont à éviter car ils sont fréquemment remplacés à la suite d’accrochage sur les routes. (4) L’installation peut ce faire a l’intérieur des compartiments et/ou des composantes du véhicule : l’habitacle, les sièges, le coffre arrière, etc. (5) Les matériaux autorises pour fixer les modules au véhicule lors de l’installation sont les suivants : dum-dum, hockey tape, époxy, colle vaporisée de type « 3M Spray Glue ». IL EST IMPORTANT DE BIEN FIXER LES MODULES AFIN QU’ILS NE TOMBENT PAS EN COURS DE ROUTE. (6) Il est important d’être créatif lors de l’installation du kit. LES CACHETTES DOIVENT OBLIGATOIREMENT VARIEES D’UN VEHICULE À L’AUTRE. A EVITER (1) Ne jamais mélanger les modules d’un kit avec ceux d’un autre. (2) Les modules ne doivent pas être installe de façon a ce qu’ils soient encapsules dans une surface métallique. Par exemple, le Document: Fiche d’installation Distribution: Extérieur Non - Contrôlé Page: 1 de 4 Le présent document et les renseignements qui y sont contenus sont confidentiels et la propriété de TAG INC. et ne peuvent être utilisés ou divulgués sans le consentement préalable et écrit d'un officier de celles- ci. This document and the information contained therein are confidential and proprietary of TAG INC. and shall not be used or disclosed without the prior written consent of one of their officers. cadre du véhicule est à proscrire puisqu’il empêcherait la propagation des signaux. (3) Les boîtier des modules ne doivent pas être modifie d’aucune façon lors de l’installation. Les composantes occupent tout l’espace du boîtier. ****MISE EN GARDE**** P RECAUTIONS POUR EVITER TOUT RISQUE D’EXPOSITION AUX MICRO-ONDES Ne jamais installer un module à moins de 20 centimètres des occupants.

May 18th , 2006 Equipment Authorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: T9R-TAG3 Product Name: EVI-TAG3__ Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions’ rules, we hereby request that the following documents be held confidential: • Schematics • Bill of materials • Block diagram • Operational description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company as this product is security based. In addition, it might provide unjustified benefits to our competitors. Dated this 18 th Day ofMay 20 06 By: Jason M Gallovich Signature Printed Title: President On behalf of : Tag Inc. Telephone: 514.605.8241 #226

LABEL REQUIREMENTS RF IC & FCC This is a representation of our label for the EVI-TAG3: TAG: EVI-TAG3 IC: 6519A-TAG3 FCC ID: T9R-TAG3 ||||||||||||||||||||| |||| |||||||||||||||||| |||||||||||||| ||||||||||||||||| || BFIXB001 AID00004444 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Made in Canada *If label format is not in full scale, please indicate the dimensions of the label. Actual Dimensions: W: 1.500 inches H: 1.000 inches

Label Top ViewSide ViewBottom View

FCC Part 15 Subpart C, 15.247 : February 2005 Test Report: 6W65912 Applicant: Tag Inc. 134 Avro Street Montreal, QC H9P 2X8 Apparatus: EVI-TAG3 FCC ID: T9R-TAG3 In Accordance With: FCC Part 15 Subpart C, 15.247 FHSS System and Digitally Modulated Radiators 902-928MHz, 2400 - 2483.5 MHz, 5725-5850MHz Tested By: Nemko Canada Inc. 303 River Road Ottawa, Ontario K1V 1H2 Authorized By: Jin Xu, Wireless Specialist Date: May 25, 2006 Total Number of Pages: 27 Nemko Canada Inc. REPORT SUMMARY Report Number: 6W65912 FCC ID: T9R-TAG3 Specification: FCC Part 15 Subpart C, 15.247 Page 2 of 27 Report Summary These tests were conducted on a sample of the equipment for the purpose of demonstrating compliance with Part 15, Subpart C. Radiated tests were conducted in accordance with ANSI C63.4-2003. Radiated emissions are made on an open area test site. A description of the test facility is on file with the FCC. The assessment summary is as follows: Apparatus Assessed: EVI-TAG3 Specification: FCC Part 15 Subpart C, 15.247 Compliance Status: Complies Exclusions: None Non-compliances: None Report Release History: Original Release Author: Jason Nixon, Telecom Specialist Note that the results contained in this report relate only to the items tested and were obtained in the period between the date of initial receipt of samples and the date of issue of the report. This test report has been completed in accordance with the requirements of ISO/IEC 17025. Nemko Canada Inc. authorizes the applicant to reproduce this report provided it is reproduced in its entirety and for use by the company’s employees only. Any use which a third party makes of this report, or any reliance on or decisions to be made based on it, are the responsibility of such third parties. Nemko Canada Inc. accepts no responsibility for damages, if any, suffered by any third party as a result of decisions made or actions based on this report. Nemko Canada Inc. REPORT SUMMARY Report Number: 6W65912 FCC ID: T9R-TAG3 Specification: FCC Part 15 Subpart C, 15.247 Page 3 of 27 TABLE OF CONTENTS Report Summary......................................................................................................................................... 2 Section 1 : Equipment Under Test............................................................................................................. 4 1.1 Product Identification .................................................................................................................................4 1.2 Samples Submitted for Assessment............................................................................................................4 1.3 Theory of Operation ...................................................................................................................................4 1.4 Technical Specifications of the EUT ..........................................................................................................4 Section 2 : Test Conditions......................................................................................................................... 5 2.1 Specifications .............................................................................................................................................5 2.2 Deviations From Laboratory Test Procedures ............................................................................................5 2.3 Test Environment .......................................................................................................................................5 2.4 Test Equipment...........................................................................................................................................5 Section 3 : Observations ............................................................................................................................. 6 3.1 Modifications Performed During Assessment ............................................................................................6 3.2 Record Of Technical Judgements ...............................................................................................................6 3.3 EUT Parameters Affecting Compliance .....................................................................................................6 3.4 Test Deleted................................................................................................................................................6 3.5 Additional Observations .............................................................................................................................6 Section 4 : Results Summary ..................................................................................................................... 7 4.1 FCC Part 15 Subpart C : Test Results ........................................................................................................8 Appendix A : Test Results .......................................................................................................................... 9 Clause 15.209(a) Radiated Emissions within Restricted Bands ............................................................................9 Clause 15.247(a)(2) Systems using digital modulation techniques .....................................................................12 Clause 15.247(b)(3) Maximum peak output power of systems using digital modulation in the 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz bands ............................................................................................15 Clause 15.247(b)(4) Maximum peak output power .............................................................................................18 Clause 15.247(d) Radiated Emissions Not in Restricted Bands ..........................................................................19 Clause 15.247(e) Power Spectral Density for Digitally Modulated Devices...............................................…

Text truncated - open the document above for the full version.

Spurious Emissions Setup:
