TAPMC-STW1303AInduction Cooker

Before using your new product, please read these instructions to prevent any damage. USER GUIDE 4-Pie ce Inductio n Cooktop Set NS-IC87BK6 NS-IC87BK6_15-0397_MAN_V2_ENG.fm Page 1 Thur sday, May 21, 2015 8:14 AM 2 Insignia 4-Piece Induction Cooktop Set www.insigniaproducts.com Insignia 4-Piece Induction Cooktop Set Contents Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 IMPORTANT SAFEGUARDS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Main features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Using your cooktop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Understanding the cooktop functions . . . . . . . . . . . . . . . . . . . . . . . 9 Locking and unlocking your cooktop . . . . . . . . . . . . . . . . . . . . . . .10 Cleaning and maintaining your cooktop . . . . . . . . . . . . . . . . . . . . . . . . .11 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12 Legal notices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12 ONE-YEAR LIMITED WARRANTY - INSIGNIA . . . . . . . . . . . . . . . . . . . . . . .15 Introduction Congratulations on your purchase of a high-quality Insignia product. Your NS-IC87BK6 represents the state of the art in induction cooktop design and is designed for reliable and trouble-free performance. IMPORTANT SAFEGUARDS When using electrical appliances, basic safety precautions should always be followed, including the following: READ ALL INSTRUCTIONS. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN This symbol indicates that dangerous voltage constituting a risk of electric shock is present within your cooktop. This symbol indicates that there are important operating and maintenance instructions in the literature accompanying your cooktop. NS-IC87BK6_15-0397_MAN_V2_ENG.fm Page 2 Thursday, May 21, 2015 8:14 AM 3 Insignia 4-Piece Induction Cooktop Set www.insigniaproducts.com 1The surface will retain heat from the cookware. Please do not touch the cooking area. 2To protect against fire, electric shock and injury to persons do not immerse cord, plugs, or the cooktop in water or other liquid. 3Close supervision is necessary when any appliance is used by or near children. 4Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or taking off parts, and before cleaning the cooktop. 5Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions, or has been damaged in any manner. Return appliance to the nearest authorized service facility for examination, repair or adjustment. 6The use of accessory attachments not recommended by the appliance manufacturer may result in fire, electric shock or injury to persons. 7This electrical appliance is not recommended for use outdoors. 8Do not let the cord hang over the edge of a table or counter, or touch hot surfaces. 9Do not place on or near a hot gas or electric burner, or in a heated oven. 10To disconnect, turn any control to “off,” then remove the plug from the wall outlet. 11Do not use the appliance for other than its intended use. 12Do not attempt to modify or extend the power cord of this appliance. 13Do not handle the plug with wet hands. This could result in an electric shock. 14Unplug the power cord by holding the plug, never by pulling the cord. 15This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug is intended to fit into a polarized outlet only one way. If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not attempt to modify the plug in any way. 16Extreme caution must be used when moving an appliance containing hot oil or other hot liquids. 17Household Use Only. 18Do not cook on a broken cooktop – If the cooktop should break, cleaning solutions and spills may penetrate the broken cook-top and create a risk of electric shock. 19Be careful when you clean the cooktop – If a wet sponge or cloth is used to wipe spills on a hot cooking surface, be careful to avoid steam burn. Also, some cleaners can produce noxious fumes if applied to a hot surface. NS-IC87BK6_15-0397_MAN_V2_ENG.fm Page 3 Thursday, May 21, 2015 8:14 AM 4 Insignia 4-Piece Induction Cooktop Set www.insigniaproducts.com 20Do not place metallic objects, such as knives, forks, spoons, and lids, on the cooktop, because they can get hot. SAVE THESE INSTRUCTIONS WARNING Electric Shock Hazard Failure to follow these instructions can result in electric shock, fire, or death. Additional safety concerns 1Never heat foods in sealed containers, such as compressed products, cans, or coffee pots, to avoid explosion caused by heat expansion. 2Do not directly rinse this cooktop under water. Do not spill water or soup into the internal parts of the cooktop. 3To avoid affecting product performance and to prevent injury, do not heat empty pots. When in use, do not leave the appliance without supervision for a long time. When leaving the appliance without supervision, make sure there is enough water in the pot. 4To avoid accidents, do not use the cooktop on a gas stove (the magnetic lines can heat the metal parts of the gas stove). 5Do not heat iron items on the cooktop to avoid danger caused by high temperatures. 6The cookware provided for the cooktop can only be used for the cooktop. This cookware cannot be used on both …

Text truncated - open the document above for the full version.

Declaration on model difference 产品差异声明 Page 1 of 1 page We the undersigned hereby confirm that any of our production units bearing the following model numbers are identical in circuitry and electrical, mechanical and physical construction; the only differences is model no. for trading purpose. 我们在下面签名并据此确认:以下产品型号之间的差异仅为型号不同，其它设计完全相同。 „ Production name 产品名称 Trade name 商标 Model no. 型号 Induction Cooker N/A MC-STW1303, NS-IC87BK6 Confirmed by . Authorized Signature: 授权人签字

Label Location Label Location Label 1 label 2 55*35mm 55*35mm 40*15mm

Internal Photos

TRF NO. FCC15/A Page 1 of 27 Report No.: ES150513110E Ver.1.0 Test Report On Behalf of Guangdong MD Consumer Electric Manufacturing Co., Ltd Induction Cooker Model No.: MC-STW1303, NS-IC87BK6 FCC ID: TAPMC-STW1303A Report Number : ES150513110E Date of Test : May 13, 2015 to June 12, 2015 Date of Report : June 12, 2015 Prepared for : Guangdong MD Consumer Electric Manufacturing Co., Ltd Address : 19 Sanle Road, Beijiao Shunde, Foshan, Guangdong, China Prepared by : SHENZHEN EMTEK CO., LTD. Address : Bldg 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China Tel: (0755) 26954280 Fax: (0755) 26954282 TRF NO. FCC15/A Page 2 of 27 Report No.: ES150513110E Ver.1.0 TABLE OF CONTENT Test Report Description Page 1. SUMMARY OF TEST RESULT ............................................................................................. 5 2. GENERAL INFORMATION ................................................................................................... 6 2.1. DESCRIPTION OF DEVICE (EUT) ................................................................................................................ 6 2.2. DESCRIPTION OF SUPPORT DEVICE ........................................................................................................ 6 2.3. DESCRIPTION OF TEST FACILITY .............................................................................................................. 6 2.4. MEASUREMENT UNCERTAINTY ................................................................................................................. 7 3. MEASURING DEVICE AND TEST EQUIPMENT ................................................................. 8 3.1. FOR POWER LINE CONDUCTED EMISSION MEASUREMENT ................................................................ 8 3.2. FOR RADIATED EMISSION MEASUREMENT ............................................................................................. 8 4. POWER LINE CONDUCTED EMISSION MEASUREMENT ................................................ 9 4.1. BLOCK DIAGRAM OF TEST SETUP ............................................................................................................ 9 4.2. MEASURING STANDARD ............................................................................................................................. 9 4.3. POWER LINE CONDUCTED EMISSION LIMITS (CLASS B) ....................................................................... 9 4.4. EUT CONFIGURATION ON MEASUREMENT .............................................................................................. 9 4.5. OPERATING CONDITION OF EUT ............................................................................................................. 10 4.6. TEST PROCEDURE ..................................................................................................................................... 11 4.7. MEASURING RESULTS ............................................................................................................................... 11 5. RADIATED EMISSION MEASUREMENT ........................................................................... 14 5.1. BLOCK DIAGRAM OF TEST SETUP .......................................................................................................... 14 5.2. MEASURING FREQUENCY RANGE .......................................................................................................... 14 5.3. RADIATED EMISSION LIMITS (CLASS B) .................................................................................................. 15 5.4. EUT CONFIGURATION ON MEASUREMENT ............................................................................................ 15 5.5. OPERATING CONDITION OF EUT ............................................................................................................. 15 5.6. TEST PROCEDURE .................................................................................................................................... 15 5.7. MEASURING RESULTS .............................................................................................................................. 15 6. PHOTOGRAPHS ................................................................................................................ 20 6.1. PHOTOS OF CONDUCTED EMISSION MEASUREMENT ........................................................................ 20 6.2. PHOTOS OF RADIATION EMISSION MEASUREMENT ............................................................................ 21 APPENDIX (Photos of EUT) (5 Pages) TRF NO. FCC15/A Page 3 of 27 Report No.: ES150513110E Ver.1.0 TEST REPORT DESCRIPTION Applicant : Guangdong MD Consumer Electric Manufacturing Co., Ltd Manufacturer : Guangdong MD Consumer Electric Manufacturing Co., Ltd Trade Mark : N/A EUT : Induction Cooker Model No. : MC-STW1303, NS-IC87BK6 (Note: These models are identical in circuitry and electrical, mechanical and physical construction; the only differences is model no. for trading purpose. We prepare MC-STW1303 for test, and the worst result recorded in the report.) Power Supply : AC 120V, 60Hz 1300W Measurement Procedure Used: FCC Rules and Regulations Part 18: 2015 & MP-5: 1986 The device described above is tested by SHENZHEN EMTEK CO., LTD. to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The measurement results are contained in this test report and SHENZHEN EMTEK CO., LTD. is assumed full of responsibility for the accuracy and completeness of these measurements. Also, this report shows that the EUT (Equipment Under Test) is technically compliant with the FCC requirements. This report applies to above tested sample only and shall not be reproduced in part without written approval of SHENZHEN EMTEK CO., LTD. Date of Test : May 13, 2015 to June 12, 2015 Test by : Tester/King Kong Prepared by : Yaping Shen/Editor Approved & Authorized Signer : Lisa Wang/…

Text truncated - open the document above for the full version.

Setup photos LINE CONDUCTED EMISSION TEST RADIATED EMISSION TEST
