TAZ-ASD766REMOTE and PLAYCHUK� MINI

Front Electronics (H.K.) Ltd.

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Jul 28, 2011
Application Purpose: Original Equipment
Date of Application: Jul 28, 2011
Equipment Note: REMOTE and PLAYCHUK� MINI
Frequency Range: 2402.00000000 - 2480.00000000
Company: Front Electronics (H.K.) Ltd.
Country: Hong Kong

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

REMOTE & PLAYCHUK™ MINI USER MANUAL Congratulations on your purchase of the ICON Remote & Playchuk™ Mini for Wii™. The contents of this package include: •1 Remote for Wii •1 Playchuk™ for Wii •1 Wrist Strap •1 Warranty Card •1 User Manual Before using this product, please attach the wrist strap to the end of the Remote. Function Diagram: Battery Instructions: • Open the battery compartment located on the back of the Remote • Insert the 2 AAA batteries, ensuring correct polarity (see figure 2) • Close the Remote battery compartment (see figure 3) Synchronization: • Press the “POWER” button on the top left hand side of the Remote to switch it on • Synchronize the Remote with the Wii™ console o Press the “SYNC” button located on the Wii™ console (see figure 4) o Press the “SYNC” button located on the Remote (see figure 5) PUSH SYNC Standby Mode: The Remote will automatically enter standby mode when not in use for a period of time. To exit standby mode, press any button on the Remote. Playchuk™ Instructions: When game play requires the Playchuk™, please connect the Playchuk™ to the Remote using the appropriate connection slot. (see figures 6 & 7) Troubleshooting Tips: Remote not working: • Change the batteries in the Remote • Remote may be in standby mode (refer to Standby Mode Instructions) • Ensure the Remote is properly synchronized with the Wii™ console • Refer to the Wii™ console Instruction Manual for more troubleshooting tips Playchuk™ not working: • Ensure the Playchuk™ is properly connected to the Remote (refer to Playchuk™ Instructions) • Refer to the Wii™ console Instruction Manual for more troubleshooting tips WARNING: We recommend taking fifteen‐minute breaks for every hour played. If, at any time, you feel joint pain in your hands, wrists, elbows or elsewhere, stop playing until the symptoms disappear and see your doctor. USE THE WRIST STRAP. Game play can involve rapid or vigorous motion. Please use the wrist strap to prevent losing your grip on the controller and causing damage to the Remote or surrounding objects, or injury to other people. WEAR THE WRIST STRAP WHEN ONE IS PROVIDED. • Make sure all players use the wrist strap and that the strap is secure. • When sharing a Remote between multiple players, make sure each person uses the wrist strap properly. • Wearing the wrist strap will prevent you from accidentally dropping or throwing the Remote during game play, which could damage the Remote or surrounding objects, or cause injury to other people. DO NOT LET GO OF THE CONTROLLER DURING GAME PLAY. • Read the Instruction booklet for the game you are playing and follow all game control instructions for correct use of the Remote or accessory controllers. • Hold the Remote securely and avoid excessive motion, as it may cause you to let go of the Remote and may break the wrist strap. • If your hands become moist, stop and dry your hands. ALLOW ADEQUATE ROOM AROUND YOU DURING GAME PLAY. 1. Stay at least three (3) feet away from the television. 2. As you may move around during game play, make sure objects and other people are out of your range of movement or arm motion to prevent damage or injury. Important Safeguards & Precautions: • This unit is for indoor use only • Do not expose to dust, direct sunlight, wet weather conditions, high humidity, high temperature • Do not expose the unit to splashing, dripping rain or moisture • Do not immerse in liquid • Do not disassemble • Do not use if the equipment is damaged • Never carry the unit by the cable • For external cleaning, use a soft, clean, cloth only This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ‐ Reorient or relocate the receiving antenna. ‐ Increase the separation between the equipment and receiver. ‐ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ‐ Consult the dealer or an experienced radio/TV technician for help. FCC ID: TAZ‐ASD766 MADE IN CHINA FCC STATEMENT 1. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, (2) This device must accept any interference received, including interference that may cause undesired operation. 2. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. ©2010 Alliance Sales & Distribution, Inc. All Rights Reserved. All other trademarks, brands and names are the property of their respective owners. TÉLÉCOMMANDE ET MANUEL DE L’UTILISATEUR PLAYCHUK MC Toutes nos félicitations pour avoir acheté la télécommande ICON et Playchuk MC pour Wii MC . Cet emballage comprend : 1 – Télécommande pour Wii MC 1 – Playchuk pour Wii MC 1 – Dragonne 1 – Carte de garantie 1 – Manuel de l’utilisateur Avant d’utiliser ce produit, veuillez fixer la dragonne à l’extrémité de la télécommande. Diagramme de Fonction : Insertion des piles : • Ouvrir le compartiment des piles situé à l’arrière de la télécommande. • Insérer 2 piles AA en veillant à ce que la polarité soit conforme (figure 2). • Fermer le compartiment des piles de la télécommande (figure 3). Synchronisation : • Appuyer sur le bouton « POWER » dans le coin supérieur gauche de la tél…

Text truncated - open the document above for the full version.

Attestation Statements

Front Electronics (H.K.) Ltd. Date: 2011-07-26 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD FCC ID: TAZ-ASD766 To Whom It May Concern: This letter is to ascertain that Front Electronics (H.K.) Ltd. Product REMOTE and PLAYCHUK™ MINI has been the units used for conducting FCC compliance testing, the DoC part will be tested by FCC recognized test lab. If you have any question or concerns, pls. contact us. Sincerely, Client’s signature: Client’s name / title: CHUI MK / Director of Marketing Contact information / address: Tel: (852) 2420 2588 Email: [email protected] Address: Rm 2919, Asia Trade Centre, 79 Lei Muk Road, Kwai Chung

Cover Letter(s)

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 Revised wording (current) 1.0 2.0 Sept–25-2007 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 Front Electronics (H.K.) Ltd. Date: 2011-07-26 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Front Electronics (H.K.) Ltd. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product: REMOTE and PLAYCHUK™ MINI Model No.: ASD766, FEL-2813, FEL-2814 We affirm that between SIEMIC and Front Electronics (H.K.) Ltd. any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature: Client’s name / title: CHUI MK / Director of Marketing Contact information / address: Tel: (852) 2420 2588 Email: [email protected] Address: Rm 2919, Asia Trade Centre, 79 Lei Muk Road, Kwai Chung

Cover Letter(s)

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 1.0 2.0 August – 11 - 2008 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 2.0 Front Electronics (H.K.) Ltd. Date: 2011-07-26 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Confidentiality Request regarding application for certification of FCC ID: TAZ-ASD766 We hereby request confidential treatment of information accompanying this application as outlined below: - Schematics - Block Diagram - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature: Client’s name / title: CHUI MK / Director of Marketing Contact information / address: Tel: (852) 2420 2588 Email: [email protected] Address: Rm 2919, Asia Trade Centre, 79 Lei Muk Road, Kwai Chung
