Model: DX2013F (Transmitter portion) Technical Description of Transmitter The transmitter operates at 49.860 MHz, and controls a receiver to move left, right, forward and backward. The circuit of the transmitter comprises of, 1. An Encoding keys consisting: LEFT, RIGHT, FORWARD, BACKWARD 2. An RF Oscillator consisting: Q2, X1 (49.860MHz crystal) 3. Filter consisting: C1, L1 4. An Encoder, Mixer and Amplifier consisting: U1 (TX-2), Q1 5. A Power Supply consisting: One 9V battery The transmitter uses an external, dedicated antenna. The nominal rated field strength is 79.6dBuV/m @ 3m Production tolerance of field strength is +/- 3dB Antenna gain is 0dBi

Analysis Report Report No.: 13071090HKG-001 The Equipment Under Test (EUT) is a portable transmitter of a RC Car operating at 49.86 MHz as dictated by a crystal. The EUT is powered by a 9.0 V DC source (1 x 9.0V battery). The EUT has a left / right control lever and a forward / backward control lever. After switching ON the EUT and the receiver of the RC Car, activating the control levers on the EUT can control the receiver moving forward, backward left and right directions. Antenna Type: External dedicated antenna Antenna Gain: 0dBi Nominal rated field strength: 79.6dBμV/m at 3m Maximum allowed field strength of production tolerance: +/- 3dB According to the KDB 447498: Based on the Maximum allowed field strength of production tolerance was 82.6dBμV/m at 3m in frequency 27.145MHz, thus; The EIRP = [(FS*D) ^2*1000 / 30] = 0.0546mW Conducted power = Radiated Power (EIRP) – Antenna Gain So; Conducted Power = 0.0546mW. The SAR Exclusion Threshold Level for 27.145MHz when the minimum test separation distance is < 50mm: = [474 * (1 + log100/f(MHz))]/2 = 371.2mW Since the above conducted output power is well below the SAR Exclusion threshold level, so the EUT is considered to comply with SAR requirement without testing.

RIG TEST GND BW FW TU SCSO VDD PC OSCO OSCI NC LEFT U1 TX-2 Q2 2SC945P Q1 8050 R3 180K SW1 R1 47K R5 330R R4 22K R2 100R R6 2K2 C5 106P X1 49.860M L3 1.0uH L2 5.6uH C8 104P D1 IN4148 C3 47P C10 104P C2 470P C4 18P C1 150P L1 1.0uH C7 473P LED1 FPRB BACK RIGHT LEFT ZD1 3V9 C9 332P R7 10 DX111445TX01 49MHZ 1 B- 9V 1 9V ANT
