TBOPRFDV12Proxima RF Desktop

Highlighted Features: • FCC, CE and IC certified • RoHS compliant • Low profile • Small footprint: 11.5 cm x 7.7 cm x2.3 cm • Internal loop antenna • USB powered (no additional power supply required) • Multi-protocol RFID support including ISO15693, CryptoRF® and ISO14443 • Powerful, easy-to-use XML based API Plug and Play 13.56mHz Desktop RFID reader. The Proxima RF Desktop is a plug and play reader that increases RFID accessible. Unlike most RFID readers, the Proxima RF Desktop does not require further work to begin reading tags. Simply plug the reader into any Windows based USB port and to begin reading tags. This reader is ideal for quickly setting up any desktop based application, and can easily be embedded as a fixed or wall mounted for applications such as access control and maintenance scanning. Proxima RF Desktop HF RFID Reader 201 - 6272 East Boulevard Vancouver, BC Canada, V6M 3V7 T: +1 604 263 5529 ext. 4 F: +1 604 263 9925 www.applied-rfid.com Universal API Time to market is today’s competitive necessity. When OEMs want to provide additional product functionality, they need rapid development tools and a technology partner who can assist in getting their product to market quickly. Proxima RF™ Universal API is an easy XML based interface between the RFID Reader/Writer and your C++, .NET or Java application. This enables developers to quickly implement RFID with existing backend data systems while minimizing time to market. Proxima RF Desktop HF RFID Reader 201 - 6272 East Boulevard Vancouver, BC Canada, V6M 3V7 T: +1 604 263 5529 ext. 4 F: +1 604 263 9925 www.applied-rfid.com Installation 1. Installation 1.1 Connect the Proxima RF Desktop to your computer using the provided USB cable. 1.2 Your computer will recognize the Proxima RF Desktop and will install the appropriate drivers automatically. (If requested let your computer connect to the internet to search and download the appropriate drivers) NOTE: In case your computer cannot install the appropriate drivers automatically you may download them from the FTDI website: http://www.ftdichip.com/Drivers/VCP.htm 1.3 The Proxima RF Desktop is now ready to use. Your computer will recognize the reader as a USB Serial Port. You can verify this by navigating to: “Start->Control Panel->System->Hardware->Device Manager”. Note that there is a new entry under Ports called “USB Serial Port (COMX)”, where “COMX” refers to the virtual serial port assigned to the RFID reader. Proxima RF Desktop HF RFID Reader 201 - 6272 East Boulevard Vancouver, BC Canada, V6M 3V7 T: +1 604 263 5529 ext. 4 F: +1 604 263 9925 www.applied-rfid.com Warning: Changes or modifications not expressively approved by Applied RFID Solutions Inc. could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help.

December 01, 2009 Ultratech Engineering Labs, Inc. 3000 Bristol Circle Oakville, Ontario L6H 6G4 Subject: FCC Certification Application Testing under FCC PART 15, Subpart C - Unlicensed Low Power Transmitter operating in the frequency band 13.553-13.567 MHz. Product: Proxima RF Desktop Model No.: v1.2 FCC ID: TBOPRFDV12 Dear Sir/Madam As appointed agent for Applied RFID Solutions Inc., we would like to submit the application for certification of the above product. Please review all required documents uploaded to your E-Filing web site. If you have any queries, please do not hesitate to contact us. Yours truly, DHARMAJIT SOLANKI Dharmajit Solanki, Authorized Agent UltraTech Group of Labs FCC TCB & IC CB Ultratech’s Accreditations: 0685 91038 1309 46390-2049 NVLAP Lab Code 200093-0 SL2-IN-E-1119R Korea KCC-RRL CA2049 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected]

Annex 2 – External Photographs of PROXIMA RF DESKTOP, Model v1.2 Photo # 1 FCC ID: TBOPRFDV12 IC: 5988A-PRFDV12 Annex 2 – External Photographs of PROXIMA RF DESKTOP, Model v1.2 Photo # 2 FCC ID: TBOPRFDV12 IC: 5988A-PRFDV12

Applied RFID Solutions Inc. Proxima RF Desktop™ v1.2 FCC ID: TBOPRFDV12 IC: 5988A-PRFDV12 Applied RFID Solutions Inc. Proxima RF Desktop™ v1.2 FCC ID: TBOPRFDV12 IC: 5988A-PRFDV12 25.25mm 12.55mm Actual Size Location of label is in box on bottom of reader:

Annex 3 – Internal Photographs of PROXIMA RF DESKTOP, Model v1.2 Photo # 1 FCC ID: TBOPRFDV12 IC: 5988A-PRFDV12 Annex 3 – Internal Photographs of PROXIMA RF DESKTOP, Model v1.2 Photo # 2 FCC ID: TBOPRFDV12 IC: 5988A-PRFDV12 Annex 3 – Internal Photographs of PROXIMA RF DESKTOP, Model v1.2 Photo # 3 FCC ID: TBOPRFDV12 IC: 5988A-PRFDV12 Annex 3 – Internal Photographs of PROXIMA RF DESKTOP, Model v1.2 Photo # 4 FCC ID: TBOPRFDV12 IC: 5988A-PRFDV12 Annex 3 – Internal Photographs of PROXIMA RF DESKTOP, Model v1.2 Photo # 5 FCC ID: TBOPRFDV12 IC: 5988A-PRFDV12

Proxima RF Desktop Model No.: v1.2 FCC ID: TBOPRFDV12 Applicant: Applied RFID Solutions Inc. 201-6272 East Boulevard Vancouver, BC Canada, V6M 3V7 In Accordance With FEDERAL COMMUNICATIONS COMMISSION (FCC) PART 15, SUBPART C Unlicensed Low Power Transmitter operating in the band 13.553-13.567 MHz UltraTech's File No.: ARFID002_FCC15.225 This Test report is Issued under the Authority of Tri M. Luu, Professional Engineer, Vice President of Engineering UltraTech Group of Labs Date: December 01, 2009 Report Prepared by: Dharmajit Solanki Tested by: Hung Trinh, RFI Test Technician Issued Date: December 01, 2009 Test Dates: November 23 to 27, 2009 ƒ The results in this Test Report apply only to the sample(s) tested, and the sample tested is randomly selected. ƒ This report must not be used by the client to claim product endorsement by NVLAP or any agency of the US Government. UltraTech 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected], Email: [email protected] Korea KCC-RRL 91038 1309 46390-2049 NVLAP Lab Code 200093-0 SL2-IN-E-1119R CA2049 FCC PART 15, SUBPART C, Sec. 15.225 - UNLICENSED LOW POWER TRANSMITTER Page 2 Proxima RF Dekstop, Model No.: v1.2 FCC ID: TBOPRFDV12 ULTRATECH GROUP OF LABS File #: ARFID002_FCC15.225 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 December 01, 2009 Tel. #: 905-829-1570, Fax. #: 905-829-8050, Email: [email protected] , Website: http://www.ultratech-labs.com All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) TABLE OF CONTENTS EXHIBIT 1. INTRODUCTION .................................................................................................................................. 3 1.1. SCOPE ................................................................................................................................................................. 3 1.2. RELATED SUBMITAL(S)/GRANT(S).............................................................................................................. 3 1.3. NORMATIVE REFERENCES ............................................................................................................................ 3 EXHIBIT 2. PERFORMANCE ASSESSMENT ....................................................................................................... 4 2.1. CLIENT INFORMATION................................................................................................................................... 4 2.2. EQUIPMENT UNDER TEST (EUT) INFORMATION ..................................................................................... 4 2.3. EUT’S TECHNICAL SPECIFICATIONS .......................................................................................................... 5 2.4. LIST OF EUT’S PORTS...................................................................................................................................... 5 2.5. ANCILLARY EQUIPMENT............................................................................................................................... 5 2.6. GENERAL TEST SETUP.................................................................................................................................... 6 EXHIBIT 3. EUT OPERATING CONDITIONS AND CONFIGURATIONS DURING TESTS ........................ 7 3.1. CLIMATE TEST CONDITIONS ........................................................................................................................ 7 3.2. OPERATIONAL TEST CONDITIONS & ARRANGEMENT FOR TESTS ..................................................... 7 EXHIBIT 4. SUMMARY OF TEST RESULTS ........................................................................................................8 4.1. LOCATION OF TESTS....................................................................................................................................... 8 4.2. APPLICABILITY & SUMMARY OF EMC EMISSION TEST RESULTS ...................................................... 8 4.3. MODIFICATIONS INCORPORATED IN THE EUT FOR COMPLIANCE PURPOSES................................ 8 EXHIBIT 5. MEASUREMENTS, EXAMINATIONS & TEST DATA FOR EMC EMISSIONS ....................... 9 5.1. TEST PROCEDURES ......................................................................................................................................... 9 5.2. MEASUREMENT UNCERTAINTIES ............................................................................................................... 9 5.3. MEASUREMENT EQUIPMENT USED: ........................................................................................................... 9 5.4. COMPLIANCE WITH FCC PART 15 – GENERAL TECHNICAL REQUIREMENTS ................................ 10 5.5. AC POWER LINE CONDUCTED EMISSIONS [§15.107(A) & 15.207(A)].................................................. 11 5.6. 20 DB BANDWIDTH........................................................................................................................................ 14 5.7. FIELD STRENGTH OF EMISSIONS INSIDE & OUTSIDE THE PERMITTED BAND 13.553-13.567 MHZ @ 10 METERS, FCC 15.225(A) ....................................................................................................................... 15 5.8. FREQUENCY STABILITY @ FCC §15.225(E) .............................................................................................. 17 EXHIBIT 6. MEASUREMENT UNCERTAINTY ................................................................................................. 19 6.1. RADIATED EMISSION MEASUREMENT UNCERTAINTY ....................................................................... 19 EXHIBIT 7. MEASUREMENT METHODS........................................................................................................... 20 7.1. GENERAL TEST CONDITIONS ..................................…

Text truncated - open the document above for the full version.

Annex 1 – Photographs of Test Setup Page 1 PROXIMA RF DESKTOP, Model v1.2 FCC ID: TBOPRFDV12 IC: 5988A-PRFDV12 Photo #1: Radiated Emissi ons, Orthogonal Position #1 Annex 1 – Photographs of Test Setup Page 2 PROXIMA RF DESKTOP, Model v1.2 FCC ID: TBOPRFDV12 IC: 5988A-PRFDV12 Photo #2: Radiated Emissi ons, Orthogonal Position #1 Annex 1 – Photographs of Test Setup Page 3 PROXIMA RF DESKTOP, Model v1.2 FCC ID: TBOPRFDV12 IC: 5988A-PRFDV12 Photo #3: Radiated Emissi ons, Orthogonal Position #2 Annex 1 – Photographs of Test Setup Page 4 PROXIMA RF DESKTOP, Model v1.2 FCC ID: TBOPRFDV12 IC: 5988A-PRFDV12 Photo #4: Radiated Emissi ons, Orthogonal Position #3
