TFO-44012Cycle computer

CYCLECOMPUTING BEDIENUNGSANLEITUNG INSTRUCTION MANUAL MANUEL D ́INSTALLATION ET D ́UTILISATION MANUALE D ́INSTALLAZIONE E FUNZIONAMENTO INSTALACION Y OPERACIÓN MANUAL HANDLEIDING C1DS C2DS C3DS C4DS P01 *Watch out: old batteries require special disposal ** P02 Battery CLOSEOPENCLOSEOPEN P03 1-6 mm screw P04 OPENCLOSE P05 P06 AC-button WS in mm / inch 1x P07 P08 Tire size WS in mm KMH WS in inch MPH 47-305 16x1,75 1272 50,1 47-406 20x1,75 1590 62,6 34-540 24x1 3/8 1948 76,7 47-507 24x1,75 1907 75,1 23-571 26x1 1973 77,7 40-559 26x1,5 2026 79,8 44-559 26x1,6 2051 80,7 47-559 26x1,75 2070 81,5 50-559 26x1,9 2089 82,2 54-559 26x2,00 2114 83,2 57-559 26x2,125 2133 84,0 37-590 26x1 3/8 2105 82,9 20-571 26x3/4 1954 76,9 Tire size WS in mm KMH WS in inch MPH 32-630 27x1 1/4 2199 86,6 40-622 28x1,5 2224 87,6 47-622 28x1,75 2268 89,3 40-635 28x1 1/2 2265 89,2 37-622 28x1 3/8 2205 86,8 18-622 700x18C 2102 82,8 20-622 700x20C 2114 83,2 23-622 700x23C 2133 84,0 25-622 700x25C 2146 84,5 28-622 700x28C 2149 84,6 32-622 700x32C 2174 85,6 37-622 700x37C 2205 86,8 40-622 700x40C 2224 87,6 50 GB IMPORTANT! This information will help you understand how the digital transmission of your VDO computer works. You really must follow the initial set-up steps in the order described below. ATTENTION: At a break during your ride the receiver will be switched off after 30 minutes (battery consumption). Before continuing your ride you need to switch on the receiver again = press M-button IMPORTANT HINT for cell (mobile) phone brackets on the handlebar. The digital wireless transmission of you VDO DS computer is likely to be disturbed if you are operating a cell (mobile) phone too close to the computer. We highly recommend not mounting your phone on the handlebar. 51 GB IMPORTANT: General hint to read this manual: This manual is valid for all VDO Series-C models. Some functions and features are not available with all models. The “flag” icon on the beginning of a chapter indicates which model this chapter is relevant for. C1DS C2DS C3DS C4DS = valid for models C1DS, C2DS, C3DS & C4DS C3DS C4DS = valid for models C3DS & C4DS 52 GB C1DS C2DS C3DS C4DS Contents >>> P01 Please check package contents for its completeness: 1 VDO computer 1 VDO digital transmitter 2 Battery 3V CR2032 for the computer and transmitter 2 Battery door for the computer and transmitter 1 Handle bar mount 1 Fixing clamp 1 Spoke magnet 4 Cable ties to fix transmitter 53 GB C1DS C2DS C3DS C4DS Preface Congratulations! With your choice of a VDO cycle computer, you have decided to own the most advanced technology available. To enjoy the full potential of your computer and benefit from all the technical features, we recommend you thoroughly study this manual. You will find crucial hints for its operation as well as many more tips. We wish you many enjoyable rides and trips on your bike with your VDO cycle computer. CYCLE PARTS GMBH 54 GB C1DS C2DS C3DS C4DS Index part I 1.0 VDO DIGITAL SYTEM 1.1 Welcome to the club: your VDO-USER-CARD 1.2 Functions 1.3 Optional features 2. Installation 2.1 Battery installation (computer and transmitter) 2.2 Mounting sensor and magnet 2.3 Mounting cable and VDO any-size handlebar mount 2.4 TWIST-CLICK mounting of the computer 2.5 The 4-line VDO display 2.6 The VDO EMC-operating-system (Easy-Menu-Control) 2.7 Functions / menu structure Fundamental instructions to read this manual 3. Initial operation, AC-“auto-clear“ 3.1 Manual Transmitter Search – DIGI CONNECT RESET 55 GB C2DS C3DS 4 Basic settings 4.1 Language selection 4.2 Measuring and setting the wheel size(s) 4.3 Setting the clock 4.4 Setting the odometer 4.5 Changing wheel sizes from bike 1 to bike 2 4.6 Reset functions 5. Service-Interval-Indicator 6. Sleep-Mode 7. Cadence (optional) Index part II 8. Stopwatch Important hint: „>>> P04“ links at the begin- ning of a chapter are related to the respective picture in the picture book! 56 GB C3DS C4DS C4DS C1DS C2DS C3DS C4DS Index part III 9. NAVIGATOR functions Index part IV 10. Timing functions 10.1 Selecting timing functions 10.2 Timer/countdown programming 10.3 Timer/countdown/stop watch start/stop/reset 10.4 Additional countdown functions Index part V 11. Troubleshooting 12. Warranty disclaimer 13. Technical specifications 57 GB C1DS C2DS C3DS C4DS 1.0 VDO DIGITAL SYTEM Your VDO cycle computer operates on digitally coded, wireless transmission. Different from analogue radio transmission, data is digitally transmitted (data packages step-by-step). With your actual speed varying, the reading will change stepwise. Individual coding of the signals ensures that only data coming from your transmitter is processed. No interference with signals coming from transmitters other than yours. Very rarely, even digital transmission may be interfered by high-voltage power lines, mobile phone poles, remote controls (car doors openers, garage door openers). What happens when digital transmission is interfered with? - speed display will read zero (0) - trip distance stops counting - ride timer stops counting The digital VDO transmitter features an internal memory, that stores up to 45 sec of data at a speed of 20 KMH (12,5 MPH). At a rare interference, no data is lost! The related data pack- 58 GB ages are sent after, once the interference is over. Following data is immediately updated when the re-send data is received : - trip distance - riding time - average speed - maximum speed - odometer Hence, your current data may change erratically after a interference = Update of your computer. After a battery change, a new coding is automatically generated in the transmit- ter. The computer must learn this new coding. Therefore, you have to activate the manual transmitter search DIGI CONNECT RESET (3.1. Manual Transmitter Search – DIGI CONNECT RESET) 59 GB C1DS C2DS C3DS C4DS C1DS C2DS C3DS C4DS 1.1 The VDO-USER-CARD Welcome to the Club. With the purchase of this product, you have become a member of the VDO-USER Club. The VDO-USER-CARD gives…
