TG3-ST300Sand Table

1 www.homedics.com/register Your valuable input regarding this product will help us create the products you will want in the future. PLEASE TAKE A MOMENT NOW REGISTER YOUR PRODUCT AT: INSTRUCTION MANUAL AND WARRANTY INFORMATION 1-YEAR LIMITED WARRANTY IB-SANDTABLE L-02337, REV 1 SANDSCAPE 23 IMPORTANT SAFETY INSTRUCTIONS WHEN USING ELECTRICAL PRODUCTS, ESPECIALLY WHEN CHILDREN ARE PRESENT, BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE FOLLOWED, INCLUDING THE FOLLOWING: READ ALL INSTRUCTIONS BEFORE USING. DANGER – TO REDUCE THE RISK OF ELECTRIC SHOCK: • Always unplug the appliance from the electrical outlet immediately after using and before cleaning. • DO NOT reach for an appliance that has fallen into water. Unplug it immediately. WHAT COMES IN THE BOX 1. 1 x drift Bowl 2. 1 x Glass Top 45 WHAT COMES IN THE BOX 5. 1 x Sand Rake Tool 6. 1 x Adapter Power Cord WHAT COMES IN THE BOX 3. 1 x Metal Sphere 4. 2 x Bags of Sand (1 bag for 16", 2 bags for 21") 67 BUTTONS 1. Power Button • Short press play/pause ball • Long press lights and ball off 2. Light Button • Short press cycles through saved colors • Long press lights on/off 3. Power Port SET UP 1. Remove all protective materials over the felt surface inside your drift bowl. Pour one bag of sand into the center of the table and use the included sand rake to level the sand (does not need to be perfect). 2. Place the metal ball into the center of the table; it will find the magnet. If it does not find the magnet right away, the magnet will find the ball during the first design. 3. Place the glass foam side down on the top and center it. 4. Untie the power cord, connect the cord to the adapter, and insert the barrel jack into the back of the drift Sandscape. Then plug-in the 3-prong adapter plug to 120-volt househould electrical outlet. The lights will illuminate. 5. Download the drift Sandscape App from the app store. 6. Follow the instructions within the app for set up and get ready to drift. MAINTENANCE 1. Even out the sand. Over time, sand may build up on the outside of the sand surface. You can just use the included sand rake or any flat card to redistribute sand as needed. 2. You can clean the glass surface with any glass cleaner. 3. The product is built to give you 8 hours of continuous use. If it has stopped and you want to drift longer, restart in the app or short press the power button on the back of the unit. Power ButtonLight Button Power Port 89 FAQ 1. Why is the product louder at full speed? The higher speed is intended to quickly clear or find a specific design. It is recommended to use the product below 50% speed for optimal silence. 2. The ball moves slow in the center. Is this normal? Yes. The product is designed to maintain intricate designs even when the ball is moving in the center. 3. How do I stop the sand from bunching up around the outside over time? Occasionally, you may feel the need to pause the product, remove the metal ball, and level the sand. 4. Can I use other materials or sand? We only recommend using the drift sand included with the sandscape. This sand can also be purchased at homedics.com. 5. How do I reattach my metal ball to the magnet? Put the ball in the middle of the table and choose the “clean” design. This will pull the magnet under the table to the center and should reconnect with the ball. 6. To rest my product, do I pull the plug out of the wall or do I need to do something within the app? Long press the power button or press the power button within the app. 7. Why does my product stop midway through my playlist? Make sure that your phone is close enough to the table when choosing a new playlist to allow the new playlist to fully download. 8. What happens when I am outside of Bluetooth ® range? Will my drift still work? Your drift will continue running the playlist or current design. Depending on your settings, it will either stop or continue with the next design. 1011 FCC DISCLAIMER This device complies with Part 15 of the FCC Rules and Industry Canada licence-exempt RSS standard(s). Operation is subject to the following 2 conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. NOTE: HoMedics is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules and CAN ICES-3 (B)/ NMB-3 (B). These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help. This product has been tested and complies with the requirements for Federal Communication Commission, Part 15 and CAN ICES-3/NMB-3. Although this product is tested and complies with FCC, it may interfere with other devices. If this product is found to interfere with another device, separate the other device and this product. Conduct only the user maintenance found in this instruction manual. Other maintenance and servicing may…

Text truncated - open the document above for the full version.

FKA Distributing Co., LLC Date: 5/20/2021 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: TG3-ST300 To whom it may concern: We, the undersigned, hereby authorize SGS-CSTC Standards Technical Services Co., Ltd. (SGS) Guangzhou branch and Kobe Jian in SGS-CSTC Standards Technical Services Co., Ltd. (SGS) Guangzhou branch to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with FKA Distributing Co., LLC. This authorization is valid until further written notice from the applicant. Name (Printed): Mark Straight Title: Senior Project Engineer Signature: On behalf of Company: FKA Distributing Co., LLC

FKA Distributing Co., LLC To: SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia United States From: FKA Distributing Co., LLC 3000 N. Pontiac Trail Commerce Township, Michigan, 48390, United States Regarding: Confidentiality Request regarding application for FCC ID: TG3-ST300 LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. Sincerely, Name (Printed): Mark Straight Title: Senior Project Engineer Signature: On behalf of Company: FKA Distributing Co., LLC

SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Declaration Applicant Legal Business Name FKA Distributing Co., LLC Address 3000 N. Pontiac TrailCommerce Township, 48390, Michigan, United States Grantee Code TG3 FCC ID TG3-ST300 Authorized Contact Name Mark Straight Contact Email [email protected] Contact Phone 2488633001 Extension: 1390 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Applicant Signature: Date:5/20/2021 Print Name: Mark Straight Title: Senior Project Engineer *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database Applicant Declaration Rev:0.0

External Photo

FCC ID:TG3-ST300 IC:20834-ST300 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Model: ST-300 Rated Voltage:12V Rated Current: 2A Made in China R70mm ST-300-CE 11 ST-300-BK 11 70X70mm :50

Internal Photo v

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Report No.: GZCR210402015305 Page: 1 of 8 FCC ID: TG3-ST300 Kobe Jian EMC Laboratory Manager RF EXPOSURE EVALUATION REPORT Application No.: GZCR2104020153AT Applicant:FKA Distributing Co., LLC Address of Applicant:3000 N. Pontiac Trail, Commerce Township, Michigan, 48390, United States Manufacturer:FKA Distributing Co., LLC Address of Manufacturer:3000 N. Pontiac Trail, Commerce Township, Michigan, 48390, United States Factory:Electrical Appliance Branch of Zhangzhou Easepal Industrial Corporation Address of Factory:No.36 Longkun Road, Hongjian Village, Jiaomei Town, Zhangzhou Taiwanese Investment Zone, Fujian China Equipment Under Test (EUT): EUT Name:Sand Table Model No.: ST-300 Standard(s) : 47 CFR Part 1.1310 KDB447498D01 General RF Exposure Guidance v06 Date of Receipt: 2021-04-20 Date of Test: 2021-04-25 to 2021-04-28 Date of Issue: 2021-06-25 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Report No.: GZCR210402015305 Page: 2 of 8 Revision Record VersionChapterDateModifierRemark 012021-06-25Original Authorized for issue by: Tested By Jim LiProject Engineer Reviewed By Ricky LiuReviewer SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Report No.: GZCR210402015305 Page: 3 of 8 2Contents Page 1Cover Page...............................................................................................................................................1 2Contents....................................................................................................................................................3 3General Information.................................................................................................................................4 3.1Details of E.U.T.................................................................................................................................4 3.2Test Location.....................................................................................................................................4 3.3Test Facility.......................................................................................................................................5 3.4Deviation from Standards..................................................................................................................5 3.5Abnormalities from Standard Conditions...........................................................................................5 4Technical Requirements Specification..................................................................................................6 4.1RF Exposure Evaluation....................................................................................................................6 4.1.1Limit & Test Method......................................................................................................................6 4.1.2Test Data and Test Result............................................................................................................7 5EUT Constructional Details (EUT Photos).............................................................................................8 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Report No.: GZCR210402015305 Page: 4 of 8 3General Information 3.1Details of E.U.T. Power supply: DC 12 V powered by SWITCHING ADAPTER: Model No.:GQ48-120400-E1 Input:100-240V ~ 50/60Hz, 1.5A Max Output:12.0V, 4.0A, 48.0W Cable(s): AC mains input cable:3 wires, 3.6m, unshielded. DC output cable: 2 wires, 1.2m, unshielded. Function:Sand Table with BLE function Operation Frequency:2402MHz to 2480MHz Modulation Type:GFSK Number of Channels:40 Channel Spacing:2MHz Antenna Type:Integral Antenna Antenna Gain:0dBi declared by applicant. Software Version:SV01 Hardware Version:HW01 Testing Software:CMOSTEK.exe Sample NO.:KS2103310001 Power Setting-1 dBm cannot be changed by user 3.2Test Location All tests were performed at: SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen Branch No. 1 Workshop, M-10, Middle Section, Science & Technology Park, Shenzhen, Guangdong, China. 518057. Tel: +86 755 2601 2053Fax: +86 755 2671 0594 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Report No.: GZCR210402015305 Page: 5 of 8 3.3Test Facility The test facility is recognized, certified, or accredited by the following organizations: ● NVLAP (Lab Code: 200611-0) SGS-CSTC Standards Technical Services Co., Ltd., Guangzhou EMC Laboratory is accredited by the National Voluntary Laboratory Accreditation Program (NVLAP/NIST). NVLAP Code: 200611-0. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. ● ACMA SGS-CSTC Standards Technical Services Co., Ltd., EMC Laboratory can also perform testing for the Australian/New Zealand Regulatory Compliance Mark (RCM). ● SGS UK(Certificate No.: 32), SGS-TUV SAARLAND and SGS-FIMKO Have approved SGS-CSTC Standards Technical Services Co., Ltd., EMC Laboratory as a supplier of EMC TESTING SERVICES and SAFETY TESTING SERVICES. ● CNAS (Lab Code: L0167) SGS-CSTC Standards Technical Services Co., Ltd., EMC Laboratory has been assessed and in compliance with CNAS-CL01:2018 accreditation criteria for testing laboratories (identical to ISO/IEC 17025:2017 General Requirements) for the Competence of Testing Laboratories. ● FCC Recognized Accredited Test Firm(Registration No.: 486818) SGS-CSTC Standards Technical Services Co., Ltd., EMC Laboratory has been accredited and fully described in a report filed with the (FCC) Federal Communications Commission. The acceptance letter from the FCC is maintained in our files. Designation Number: CN5016, Test Firm Registration Number: 486818. ● ISED (Registration No.: 4620B, CAB identifier: CN0052) SGS-CSTC Standards Te…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch EMC-TRF-01 Rev 1.0 Report No.: GZCR210402015304 Page: 1 of 64 FCC ID: TG3-ST300 Kobe Jian EMC Laboratory Manager TEST REPORT Application No.: GZCR2104020153AT Applicant: FKA Distributing Co., LLC Address of Applicant: 3000 N. Pontiac Trail, Commerce Township, Michigan, 48390, United States Manufacturer: FKA Distributing Co., LLC Address of Manufacturer: 3000 N. Pontiac Trail, Commerce Township, Michigan, 48390, United States Factory: Electrical Appliance Branch of Zhangzhou Easepal Industrial Corporation Address of Factory: No.36 Longkun Road, Hongjian Village, Jiaomei Town, Zhangzhou Taiwanese Investment Zone, Fujian China Equipment Under Test (EUT): EUT Name: Sand Table Model No.: ST-300 Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2021-04-20 Date of Test: 2021-04-25 to 2021-05-11 Date of Issue: 2021-07-29 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. EMC-TRF-01 Rev 1.0 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Report No.: GZCR210402015304 Page: 2 of 64 Revision Record Version Chapter Date Modifier Remark 01 2021-07-29 Original Authorized for issue by: Jim Li/Project Engineer Ricky Liu/Reviewer EMC-TRF-01 Rev 1.0 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Report No.: GZCR210402015304 Page: 3 of 64 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Conducted Peak Output Power ANSI C63.10 (2013) Section 11.9.1 47 CFR Part 15, Subpart C 15.247(b)(3) Pass Minimum 6dB Bandwidth ANSI C63.10 (2013) Section 11.8.1 47 CFR Part 15, Subpart C 15.247a(2) Pass Power Spectrum Density ANSI C63.10 (2013) Section 11.10.2 47 CFR Part 15, Subpart C 15.247(e) Pass Conducted Band Edges Measurement ANSI C63.10 (2013) Section 11.13.3.2 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions ANSI C63.10 (2013) Section 11.11 47 CFR Part 15, Subpart C 15.247(d) Pass Radiated Emissions which fall in the restricted bands ANSI C63.10 (2013) Section 6.10.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions ANSI C63.10 (2013) Section 6.4,6.5,6.6 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Note: E.U.T./EUT means Equipment Under Test. Pass means the test result passed the test standard requirement, please find the detailed decision rule in the report relative section. EMC-TRF-01 Rev 1.0 SGS-CSTC Standards Technical Services Co., Ltd. Guangzhou Branch Report No.: GZCR210402015304 Page: 4 of 64 3 Contents Page 1 Cover Page ................................................................................................................................................ 1 2 Test Summary ........................................................................................................................................... 3 3 Contents .................................................................................................................................................... 4 4 General Information .................................................................................................................................. 6 4.1 Details of E.U.T. ................................................................................................................................. 6 4.2 Description of Support Units .............................................................................................................. 6 4.3 Measurement Uncertainty .................................................................................................................. 6 4.4 Test Location ...................................................................................................................................... 7 4.5 Test Facility ........................................................................................................................................ 7 4.6 Deviation from Standards ................................................................................................................... 8 4.7 Abnormalities from Standard Conditions ........................................................................................... 8 4.8 Duty cycle of the EUT ........................................................................................................................ 8 5 Equipment List .......................................................................................................................................... 9 6 Radio Spectrum Technical Requirement ............................................................................................. 12 6.1 Antenna Requirement ...................................................................................................................... 12 6.1.1 Test Requirement: ....................................................................................................................... 12 6.1.2 Conclusion ................................................................................................................................... 12 7 Radio Spectrum Matter Test Results .................................................................................................... 13 7.1 Conducted Peak Output Power........................................................................................................ 13 7.1.1 E.U.T. Operation .......................................................................................................................... 13 7.1.2 Test Mode Description ..............................................................…

Text truncated - open the document above for the full version.

Test Setup Photo v Conducted Emissions at AC Power Line (150kHz-30MHz) RF Conducted Test Setup Radiated Spurious Emissions & Radiated Emissions which fall in the restricted bands
