TG3EP510Jam Transit Micro Sport Earbud

* page 1 of 7* HX -EP510 manual HoMedics, Inc. Address: 3000 Pontiac Trail, Commerce Township, MI48390, USA * page 2 of 7* Index 1. Specifications of the Product 1.1 Environmental Specifications 1.2 Mechanical Specifications 1.3 Cable Specifications 1.4 Electrical Specifications 1.5 Acoustic Specifications 2. Product drawing 2.1 Outside V iew 3. FCC &IC Statement * page 3 of 7* 1.Specifications of the products 1.1 Environmental Specifications All materials must be complied with ROHS, Reach, and California 65 environmental standard 1.2 Mechanical Specifications 1.2.1 Dimension：14.5 mm *23 mm *26.5 mm 1.2.2 Weight： 15 .3g（Ear buds only） 1.2.3 C harge Port：Micro USB 1.2.4 Main Board：Multi ple functional button . MFB : Power/off/pair/Vol+/Vol-/Play /pause/Call ect. 1.2.5 Test ing detail please refer to item 6 (Reliability testing) 1.3 Cable Specifications 1. 3.1 Cable : Flat reflecting cable , 4.0 *1. 4 mm , 9 groups of core wire , L=550mm 1.3 .2 Test spec refers to item 6 (Reliability Testing) 1.4 Electrical Specifi cations 1.4.1 Battery: Li-polymer battery, 3.7V, 120mAH (60 mA H *2) 1.4.2 Charge: DC5V, 100mAH 1.4.3 Bluetooth Spec. Bluetooth version：V4.0, support HSP、HFP、A2DP、AVRCP Device name: Transit Micro Sport Transmission Range (Hz)：2.40GHz~2.48GHz Distance: 10 meters RF radiate：Class II I ( -6dBm~+ 0dBm) Sensitivity of receiving：-85 dBm 1.4.4 User interface 1.4.4.1 Operation of play mode: * page 4 of 7* Power On： Press and hold MFB 1.5 s until the light turns blue , if there is already a device connected, automatically connect the previous device, otherwise enter pairing mode , the red and blue light blinks alternately. Power Off: Option1: When de vice is on , press and hold MFB 4 seconds, the LED will flash red for 1 second, Bluetooth Ear bud will shut down . Option 2 : When the two ear cup s touch together, it will shut down . Pair: 1. If you have paired your earbuds before, they wi ll automatically connect the previous device when turned on. If there ’s no previous device, it will enter pairing mode, the LED will flash red and blue, if connected, the LED flashes blue twice per 5 seconds 2. Press Vol+/Vol- simultaneously, disconnect current device and enter pairing mode again, the LED flash blue and red. Play: When it connect ed to device, press “Play” button to start playing music , b lue light flash es slowly per 7 seconds . Pause: When playing music, short press “ Play” button once to pause music , blue light flashes slowly per 5 second. Volume Up: Short press the up button once quickly. Your earbuds will sound a high pitched tone when you have reached their max imum volume . Volume Down: Short p ress the down button once quickly. Your earbuds will sound a low pitched tone when you have reached their minimum volume . Track Forward: press and hold the vol+ button 1 second Track Back: press and hold the vol - 2 button 1 second Voic e active: press and hold “Play” button 1s to a ctivat e mobile phone voice function, blue light flashes slowly per 5 second s; double click this button , to end the voice mode. Stand by: Under pair ing mode , if there is no device to connect, it goes into standb y state in 3 minutes Automatic Power off：In the standby mode , if there is no device to connect, it shut down automatically in 2 minutes. 1.4.4.2 Operation of call mode: Answer a call: When there’s an incoming call, press “ play ” button to answer the call. Toggles audio alter between phone and earphone when long press. Reject a call: When there’s an incoming call, press and hold “play ” button 1second to reject the call , back to current mode. End a call: Press and hold “play ” button to end an active call , back to current mode. * page 5 of 7* Second Call: When there’s a second incoming call, press "play" button access the second call , current call will be remained, and then press and hold the "Play" button 1s econd to switch between the second call and the previous call, short press "play" button to end the c urrent call. Volume Up: Short press the up button once quickly. Your earbuds will sound a high pitched tone when you have reached their max imum volume . Volume Down: Short p ress the down button once quickly. Your earbuds will sound a low pitched tone when you have reached their minimum volume . 1.4. 5 Working time: Stand by time: more than 120 Hours Play time： 10 Hours with 60% volume Talk time： 15 Hours Charging time：About 1 Hour 1.5 Acoustic specifications 1.5.1 Microphone Type: Omni- direction, Electret microphone. Sensitivity: -42 dB @1 K Hz, 2.5V Operating voltage: 2~10 V Frequency response：100 Hz~ 8K Hz Resistance：More than 2.2K Ohm 1.5.2 Speaker Unit Dimension: 6 mm Type: Dynamic, Fe-Fe -Be magnet, 9u diaphragm. Impedance: 32 Ohm The sound pressure level ( SPL): 98 dB +/-3 @ 1K Hz, 1mW input Frequency response： 20 Hz~ 15K Hz Power rating：4mW Power Maximum：10 mW * page 6 of 7* 2 Product Drawing： 2.1 Outside View * page 7 of 7* 3 FCC & IC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Co nnect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/…

Text truncated - open the document above for the full version.

HoMedics, Inc. 3000 Pontiac Trail，Commerce Township，MI48390, USA Confidentiality Letter To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: TG3EP510 Product: Jam Transit Micro Sport Earbud Model: HX-EP510, HX-EP510XX We hereby request confidential treatment of information accompanying this application as outlined below: Block Diagram Schematics Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, signature : name / title: Diane Zalac / Quality Manager address: 3000 Pontiac Trail，Commerce Township，MI48390, USA

M/N: HX-EP510 FCC ID:TG3EP510 Label location

Antenna location

FCC ID: TG3EP510 Keyway Testing Technology Co., Ltd. Report No. 15KWE02137F Page 1 of 25 FCC TEST REPORT(Bluetooth) for HoMedics, Inc. Jam Transit Micro Sport Earbud Model Number: HX-EP510, HX-EP510XX FCC ID: TG3EP510 Prepared for : HoMedics, Inc. Address : 3000 Pontiac Trail, Commerce Township, MI48390, USA Prepared by : Keyway Testing Technology Co., Ltd. Address : Buliding 1, Baishun Industrial Zone, Zhangmutou Town, Dongguan, Guangdong, China Tel: 86-769-8718 2258 Fax: 86-769-8718 1058 Report No. : 15KWE02137F Date of Test : Feb. 8~12, 2015 Date of Report : Feb. 13, 2015 FCC ID: TG3EP510 Keyway Testing Technology Co., Ltd. Report No. 15KWE02137F Page 2 of 25 TABLE OF CONTENTS Test Report Declaration Page 1. TEST SUMMARY ........................................................................................................................ 4 2. GENERAL PRODUCT INFORMATION........................................................................................ 4 2.1. Product Function .................................................................................................................. 4 2.2. Description of Device (EUT) ................................................................................................. 4 2.3. Difference between Model Numbers..................................................................................... 4 2.4. Independent Operation Modes ............................................................................................. 4 2.5. Test Supporting System ....................................................................................................... 4 2.6. Test Facilities ....................................................................................................................... 5 2.7. List of Test and Measurement Instruments ........................................................................... 6 3. TEST SET-UP AND OPERATION MODES ................................................................................. 7 3.1. Principle of Configuration Selection ...................................................................................... 7 3.2. Block Diagram of Test Set-up ............................................................................................... 7 3.3. Test Operation Mode and Test Software .............................................................................. 7 3.4. Special Accessories and Auxiliary Equipment ...................................................................... 7 3.5. Countermeasures to Achieve EMC Compliance ................................................................... 7 3.6. Test Environment: ................................................................................................................ 7 4. EMISSION TEST RESULTS ........................................................................................................ 8 4.1. Conducted Emission at the Mains Terminals Test ................................................................ 8 4.2. Radiated Emission Test...................................................................................................... 11 5. 20DB OCCUPY BANDWIDTH ................................................................................................... 18 5.1. Limits.................................................................................................................................. 18 5.2. Test setup .......................................................................................................................... 18 6. BAND EDGE COMPLIANCE TEST ........................................................................................... 20 6.1. Limits.................................................................................................................................. 20 6.2. Test setup .......................................................................................................................... 20 7. ANTENNA REQUIREMENTS .................................................................................................... 21 7.1. Limits.................................................................................................................................. 21 7.2. Result ................................................................................................................................. 21 8. PHOTOGRAPHS OF TEST SET-UP ......................................................................................... 22 9. PHOTOGRAPHS OF THE EUT ................................................................................................. 24 FCC ID: TG3EP510 Keyway Testing Technology Co., Ltd. Report No. 15KWE02137F Page 3 of 25 Keyway Testing Technology Co., Ltd. Applicant: Address: HoMedics, Inc. 3000 Pontiac Trail, Commerce Township, MI48390, USA Manufacturer: Address: Cirque Audio Technology Co., Ltd No 2, Road Beiyiheng, Huangjiabao Industrial Park, Shipai Town, Dongguan City, China E.U.T: Jam Transit Micro Sport Earbud Model Number: HX-EP510, HX-EP510XX Trade Name: Serial No.: ------ Date of Receipt: Feb. 8, 2015 Date of Test: Feb. 8~12, 2015 Test Specification: FCC Part 15, Subpart C Section 15.249: 2014 ANSI C63.4:2009 RSS-210 Issue 8 December 2010 RSS-Gen Issue 4 November 2014 Test Result: The equipment under test was found to be compliance with the requirements of the standards applied. Issue Date: Feb. 13, 2015 Tested by: Reviewed by: Approved by: William Huang / Engineer Andy Gao / Supervisor Jade Yang/ Supervisor Other Aspects: None. Abbreviations: OK/P=passed fail/F=failed n.a/N=not applicable E.U.T=equipment under tested This test report is based on a single evaluation of one sample of above mentioned products. It is not permitted to be duplicated in extracts without written approval of Keyway Testing Technology Co., Ltd. FCC ID: TG3EP510 Keyway Testing Technology Co., Ltd. Report No. 15KWE02137F Page 4 of 25 1. TEST SUMMARY Test Items…

Text truncated - open the document above for the full version.

Radiated Emission Conducted Emission
