THGGIZMONDOMulti-Function Portable Games Device

gizmondo quick start guide gizmondo quick start guide gizmondo quick start guide introduction page 3 Welcome to gizmondo. in this booklet is all you need to know to get your device up and running quickly and easily. We don’t want anything getting in the way of you starting to use your gizmondo tm device, so in the following pages, we have provided you with an accessible guide to all your new system has to offer. By the time you have finished reading this you will be fully equipped to take complete advantage of the range of entertainment options the gizmondo tm device has in store. Then, if you are still inquisitive to find out more, in-depth detail, about specific functions you can take a look at the user guide on the cd enclosed in your pack. introduction gizmondo quick start guide content page 4 5. pack contents 6. What does each Button do? 8. get up and running 13. registering your device 22. piano keys 28. main menu 29. inserting an sd card 30. games 31. movies 35. music 38. messaging 46. gps 53. gps services 73. digital camera 76. contacts List 79. applications 85. Bluetooth tm 88. topping up your sim card 92. usB 93. mobile content services contents gizmondo quick start guide pack contents page 5 What should i find included in the gizmondo tm device pack? You should find the following included in your Gizmondo pack: 1. gizmondo tm device 2. device charger 3. Battery 4. gizmondo quick start user guide 5. CD-ROM featuring the In-Depth User Guide 6. SIM Card. We have provided you with a Vodaphone pre-pay SIM Card. 7. stereo Headphones 8. usB cable 9. sd card. pack contents What does each button do? gizmondo quick start guide tHe gizmondo tm device page 6 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. 13. 14. 15. 16. 17. 18. gizmondo quick start guide tHe gizmondo tm device page 7 1. d-pad: This control allows you to navigate quickly through the menus. 2. l-shift: When used in conjunction with one of the other control buttons the shift opens up many opportunities for multi-functionality. 3. home: By selecting this control button you will be immediately transported back to the main menu. 4. volume: This control allows you to adjust the volume of any music or media quickly and conveniently. 5. brightness: This gives the option to quickly and easily adjust the brightness of the image on the main screen. 6. alert: At Gizmondo we realize that the world we live in is not always as safe as we may hope, so we have incorporated an alert system into your device. see page 26 for further details. 7. poWer: An easily accessible on/off button to activate your Device. 8. reWind: This has various uses, including giving you the flexibility to backtrack through movies or music. 9. r menu: This conveniently placed button allows you quick and easy access to additional menus within the separate function areas of your device. 10. stop/back: This button allows you to navigate back through the different functions on your Gizmondo tm device, and provides you with a clear and easy way of stopping a movie or piece of music at any given point. . 11. fast forWard: This has various uses, including giving you the flexibility to move forward through movies or music, and scroll through your messages. 12. play/ accept: This acts like an enter key, allowing you to accept a function once you have selected it on the main screen. This will also, amongst other things, play music and movie files for you, read on for more details. 13. camera: The centralised position of the camera lens makes it easy to focus in on the subject of your photograph, whilst viewing the image on the main screen. 14. battery cover: An easy to remove cover to keep the battery protected. 15. poWer socket: This allows you to charge your Device efficiently by connecting it directly to a mains power supply. 16. usb socket: In order that you can take full advantage of your Gizmondo tm device, we have integrated a USB socket into the console so that you can plug your Device directly into your PC and use it in conjunction with microsoft® activesync. 17. stereo headphone socket: Allows you to enjoy your Gizmondo tm device without interruption 18. sd card slot: When you buy games or movies for your Gizmondo tm device they will come in the form of an sd memory card. get up and running to get your gizmondo tm device up and running you will need to carefully work through the step by step instructions, as outlined in the next 4 pages: 1. installing your sim card and battery 2. charging your battery 3. powering up the device gizmondo quick start guide get up and running page 8 installing your sim card and battery the sim card is enclosed in your pack. as a means of protection, it is attached to a credit card-sized piece of plastic. Carefully push the sim card away from the surrounding card, making sure that nothing comes into contact with its metal contacts. make sure the gizmondo tm device is switched off and the charger is disconnected. turn your gizmondo tm device over so it is facing front down. You will see that there is a battery cover at the back of the gizmondo tm device. remove this battery cover by releasing the catch. in the centre of the battery compartment you will see that there is a sim card holder. Lift sim card holder. 1. 2. 3. 4. 5. 6. gizmondo quick start guide instaLL sim and BatterY page 9 installing your sim card and battery slide the sim card into the holder. When installing the sim card be sure that you have the gold bars on the card facing into the gizmondo tm Device, so that they align with the six gold contacts within the body of the device. the cut away notch in the sim card should be facing towards the top left hand side of the gizmondo tm device. Lower the sim card holder back into the body of the gizmondo tm device. slide the silver metallic strip, which is across the sim card holder, upwards towards the top of the gizmondo tm device. place the battery inside the device, as shown in the diagram. make sure that the gold contacts on the batter…

Text truncated - open the document above for the full version.

23 rd August 2005 Telecommunication Certification Body RFI Global Services Ltd. Pavilion A Ashwood Park Basingstoke Hampshire RG23 8BG United Kingdom Subject: Certification Application FCC ID: THGGIZMONDO It is requested that the following information is to be held confidential on behalf of Gizmondo Europe Ltd. FCC Rules Part 0.459 refers. Exhibit Number of files Number of pages per file Schematics one (edphs) thirteen Exhibit Number of files Number of pages per file Block Diagram one (ede07b01) one This provides detailed information regarding the technical architecture of the product, in particular debug facility, Bluetooth, power supply, GSM, multimedia functionality and GPS. These are core functional components of the Gizmondo device, which makes it a unique within the market place. The architecture is deemed to be a trade secret and is only privileged to certain key company Stakeholders and system developers. These are internally based and such disclosure to outside partie(s) would conflict with company policy, intellectual property and overall intellectual security. The Gizmondo functionality has been designed within a small product size and therefore the intellectual architecture would be of extreme interest to competitors. As this product is deemed to be an individual entity within the market place, ie one in which provides such an array of functionality, allowing schematic and block system diagrams for public view would harm and have detrimental effects on the business strategy as well as the future financial product roadmap plan. Any technical data deemed to be of interest to the public is made accessible on the Gizmondo website. This in essence is a diluted version of the micro level information submitted to the FCC. Yours sincerely John Mack Test Programme Manager.

Internal Technical Documentation Operational Description of the Gizmondo Device The Gizmondo terminal is a high performance electronic gaming device that also features GPS and GSM to provide location based services. The design aim is for market leading games performance and multimedia functions combined with small size in order to make the Gizmondo attractive to children. Key applications and services supported are:- • 3D gaming including peer to peer gaming using Bluetooth and GPRS • Remote tracking of the Gizmondo and Location Based Services using GSM and GPS • Playback of Windows WMV video • MP3 and Windows WMA playback • Messaging; SMS and MMS messaging, Email • Digital Camera • IE Browser and content download • Smart Add enabled The chosen Operating System platform is Microsoft Windows CE.NET (version 4.2). This selection encompasses the operating kernel and some of the platform infrastructure. The user interface and applications are custom developed. The Gizmondo device works in conjunction to the network and server infrastructure, where additional services are stored and supplied. The Gizmondo terminal exists within the context of a network infrastructure and certain features interact heavily with that infrastructure. Operational Description Bluetooth Our product fully complies with the modulation system as described in BT specification v1.1. GSM Our product fully complies to PTCRB with the modulation system as defined in Annex G in TS 51.010 DC voltages and Currents into final radio amplifying device Bluetooth The supply voltage for the internal radio is 1.8V, as per data sheet for BC3-ROM. The total maximum current, including baseband, for the BC3-ROM is 33.82mA as per data sheet. GSM The supply voltage for the internal radio is VBAT, definied in Gizmondo PICS. The average current for the power amplifier in the PCS band is 162.5mA with one TX slot, if utilizing two TX slots this increases to 325mA. Means for determining and stabilising frequency, suppression of spurious radiation, limiting modulation, and limiting power Bluetooth This is described in detail in BT specification v1.1, which our product fully complies with. GSM This is described in detail in PTCRB TS 51.010, which our product fully complies with.

Bill of Materials PCB Assembly Part Number GZ203B104 Bill of Materials PCB Assembly Part Number GZ203B104 n t ID No’ = Giz00044 YELLOW donates changes from last revision Version 4.0 Item Flextronics Part Number Description Size Qty Component References Manufacturer Manuf. Part No. NO alts. Contact Vendor Contact Details FPN DESCRIPTION QTY MFR MPN REVISED MPN CAPACITOR CAPACITOR 1 TTL00000013 C X5R 6V3 10% 1U0 0603_CAP 27 C1-2; C15-16; C45-48; C80; C87-88; C100-102; C104; C122; C167; C171-173; C186-187; C205-206; C229; C236-237 ANY Flextronics Calchip (Patrik Nilsson ([email protected]) +44 2073841798) TTL00000013 C X5R 6V3 10% 1U0 0603_CAP 27 DARFON C1608X5R105KCT 2 TTL00000014 C X7R 16V 10% 10N 0402_CAP 12 C4-7; C9; C51; C53; C60; C106; C163; C234-235 ANY Flextronics Calchip (Patrik Nilsson ([email protected]) +44 2073841798) TTL00000014 C X7R 16V 10% 10N 0402_CAP 12 AVX 0402YC103KAT2A 3 TTL00000015 C COG 25V 5% 15P 0402_CAP 2 C12-13 ANY Flextronics Calchip (Patrik Nilsson ([email protected]) +44 2073841798) TTL00000015 C COG 25V 5% 15P 0402_CAP 2 AVX 04025A150JAT2A 4 TTL00000016 C X5R 6V3 10% 2U2 0603_CAP 2 C8; C50 ANY Flextronics Calchip (Patrik Nilsson ([email protected]) +44 2073841798) TTL00000016 C X5R 6V3 10% 2U2 0603_CAP 2 AVX 06036D225KAT2A 5 TTL00000017 C COG 25V 0.25PF 3P3 0402_CAP 2 C10; C200 ANY Flextronics Calchip (Patrik Nilsson ([email protected]) +44 2073841798) TTL00000017 C COG 25V 0.25PF 3P3 0402_CAP 2 SURGE SCM05C3R3CANCA 6 TTL00000018 C COG 25V 5% 10P 0402_CAP 2 C14; C199 ANY Flextronics Calchip (Patrik Nilsson ([email protected]) +44 2073841798) TTL00000018 C COG 25V 5% 10P 0402_CAP 2 SURGE SCM05C100JANCA 7 TTL00000019 C X7R 25V 10% 100N 0603_CAP 1 C17 ANY Flextronics Calchip (Patrik Nilsson ([email protected]) +44 2073841798) TTL00000019 C X7R 25V 10% 100N 0603_CAP 1 YAGEO CC0603KRX7R8BB104 8 TTL00000020 C X5R 10V 10% 100N 0402_CAP 46 C18-29; C31; C33; C40-41; C89; C97; C105; C107; C121; C127; C148; C150-151; C162; C174; C185; C188-191; C207; C210; C212-223 ANY Flextronics Calchip (Patrik Nilsson ([email protected]) +44 2073841798) TTL00000020 C X5R 10V 10% 100N 0402_CAP 46 AVX 0402ZD104KAT2A 9 TTL00000021 C X5R 6V3 10% 10U 0805_CAP 20 C30; C32; C38-39; C42-43; C75-76; C83-86; C91-92; C110; C154; C156-158; C176 ANY Flextronics Calchip (Patrik Nilsson ([email protected]) +44 2073841798) TTL00000021 C X5R 6V3 10% 10U 0805_CAP 20 DARFON C2012X5R106KCP 10 TTL00000022 C COG 25V 5% 680P 0603_CAP 2 C44; C93 ANY Flextronics Calchip (Patrik Nilsson ([email protected]) +44 2073841798) TTL00000022 C COG 25V 5% 680P 0603_CAP 2 YAGEO CC0603JRNPO9BN681(50V) 11 TTL00000023 C COG 25V 5% 1N0 0603_CAP 2 C49; C94 ANY Flextronics Calchip (Patrik Nilsson ([email protected]) +44 2073841798) TTL00000023 C COG 25V 5% 1N0 0603_CAP 2 DARFON C1608NPO102JFT 12 TTL00000024 C COG 25V 5% 47P 0402_CAP 1 C52 ANY Flextronics Calchip (Patrik Nilsson ([email protected]) +44 2073841798) TTL00000024 C COG 25V 5% 47P 0402_CAP 1 ROHM MCH155A470JK 13 TTL00000025 C COG 25V 5% 100P 0402_CAP 3 C54; C202-203 ANY Flextronics Calchip (Patrik Nilsson ([email protected]) +44 2073841798) TTL00000025 C COG 25V 5% 100P 0402_CAP 3 SURGE SCM05C101JANCA 14 TTL00000026 C X7R 10V 10% 470P 0402_CAP 6 C55-59; C64 ANY Flextronics Calchip (Patrik Nilsson ([email protected]) +44 2073841798) TTL00000026 C X7R 10V 10% 470P 0402_CAP 6 AVX 0402ZC471KAT2A 15 TTL00000027 C COG 25V 5% 330P 0402_CAP 2 C70; C211 ANY Flextronics Calchip (Patrik Nilsson ([email protected]) +44 2073841798) TTL00000027 C COG 25V 5% 330P 0402_CAP 2 DARFON C1005NPO331JFT 16 TTL00000028 C COG 25V 5% 33P 0402_CAP 1 C71 ANY Flextronics Calchip (Patrik Nilsson ([email protected]) +44 2073841798) TTL00000028 C COG 25V 5% 33P 0402_CAP 1 SURGE SCM05C330JANCA 17 TTL00000029 C COG 25V 5% 18P 0402_CAP 5 C72; C98-99; C165-166 ANY Flextronics Calchip (Patrik Nilsson ([email protected]) +44 2073841798) TTL00000029 C COG 25V 5% 18P 0402_CAP 5 ROHM MCH155A180JK 18 TTL00000030 C COG 25V 5% 12P 0402_CAP 2 C73-74 ANY Flextronics Calchip (Patrik Nilsson ([email protected]) +44 2073841798) TTL00000030 C COG 25V 5% 12P 0402_CAP 2 SURGE SCM05C120JANCA 19 TTL00000031 C X5R 6V3 20% 4U7 0603_CAP 4 C78; C103; C153; C225 ANY Flextronics Calchip (Patrik Nilsson ([email protected]) +44 2073841798) TTL00000031 C X5R 6V3 20% 4U7 0603_CAP 4 AVX 06036D475MAT2A 20 TTL00000032 C X7R 16V 10% 47N 0402_CAP 2 C79; C149 ANY Flextronics Calchip (Patrik Nilsson ([email protected]) +44 2073841798) TTL00000032 C X7R 16V 10% 47N 0402_CAP 2 DARFON C1005X7R473KET 21 TTL00000033 C COG 25V 5% 56P 0402_CAP 38 C81-82; C96; C108-109; C118-119; C168; C175; C182-184; C192-195; C198; C231-232; C238-239; C242-244; C247; C249-257;C260;C262;C265-266 ANY Flextronics Calchip (Patrik Nilsson ([email protected]) +44 2073841798) TTL00000033 C COG 25V 5% 56P 0402_CAP 38 ROHM MCH155A560JK 22 TTL00000034 C DIELECTRIC 3V3 20% 220M CAP_ELNA_DS 1 C113 ANY DSK3R3H224HL Q ACAL Richard Cooper ([email protected]) +44 1252 858609 TTL00000034 C DIELECTRIC 3V3 20% 220M CAP_ 1 ELNA DSK3R3H 2 23 TTL00000035 C COG 25V 5% 150P 0402_CAP 1 C120 ANY Flextronics Calchip (Patrik Nilsson ([email protected]) +44 2073841798) TTL00000035 C COG 25V 5% 150P 0402_CAP 1 SURGE SCM05C151JANCA 24 TTL00000036 C X7R 10V 10% 220N 0603_CAP 1 C124 ANY Flextronics Calchip (Patrik Nilsson ([email protected]) +44 2073841798) TTL00000036 C X7R 10V 10% 220N 0603_CAP 1 DARFON C1608X7R224KDT 25 TTL00000037 C X5R 16V 10% 1U0 0603_CAP 3 C125-126; C204 ANY Flextronics Calchip (Patrik Nilsson ([email protected]) +44 2073841798) TTL00000037 C X5R 16V 10% 1U0 0603_CAP 3 AVX 0603YD105KAT2A 26 TTL00000038 C X7R 25V 10% 1N0 0402_CAP 1 C128 ANY Flextronics Calchip (Patrik Nilsson (p…

Text truncated - open the document above for the full version.

Operational Description Bluetooth Our product fully complies with the modulation system as described in BT specification v1.1. GSM Our product fully complies to PTCRB with the modulation system as defined in Annex G in TS 51.010 DC voltages and Currents into final radio amplifying device Bluetooth The supply voltage for the internal radio is 1.8V, as per data sheet for BC3-ROM. The total maximum current, including baseband, for the BC3-ROM is 33.82mA as per data sheet. GSM The supply voltage for the internal radio is VBAT, definied in Gizmondo PICS. The average current for the power amplifier in the PCS band is 162.5mA with one TX slot, if utilizing two TX slots this increases to 325mA. Means for determining and stabilising frequency, suppression of spurious radiation, limiting modulation, and limiting power Bluetooth This is described in detail in BT specification v1.1, which our product fully complies with. GSM This is described in detail in PTCRB TS 51.010, which our product fully complies with.

TEST REPORT FROM RFI GLOBAL SERVICES LTD Test of: Gizmondo Europe Limited. GZ020. To: OET Bulletin 65 Supplement C: (2001-01) Measurements were performed on the DASY4 System Test Report Serial No: RFI/SARE3/RP46498JD05A Supersedes Test Report Serial No: RFI/SARE2/RP46498JD05A This Test Report Is Issued Under The Authority Of Andrew Brown, Operations Manager: Grant Taylor P.P on behalf of Andrew Brown. Tested By: Nirav Modi Checked By: Scott D'Adamo Report Copy No: PDF01 Issue Date: 09 August 2005 Test Dates: 06 June 2005 It should be noted that the standard, OET Bulletin 65 Supplement C: (2001-01) is not listed on RFI’s current UKAS schedule and is therefore “not UKAS accredited”. This report may be reproduced in full. Partial reproduction may only be made with the written consent of RFI Global Services Ltd The results in this report apply only to the sample(s) tested. RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI/SARE3/RP46498JD05A Page 2 of 48 Issue Date: 09 August 2005 Test Of: Gizmondo Europe Limited. GZ020. To: OET Bulletin 65 Supplement C: (2001-01) This page has been left intentionally blank. RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI/SARE3/RP46498JD05A Page 3 of 48 Issue Date: 09 August 2005 Test Of: Gizmondo Europe Limited. GZ020. To: OET Bulletin 65 Supplement C: (2001-01) Table of Contents 1. Client Information .............................................................................................................4 2. Equipment Under Test (EUT) ...........................................................................................5 3. Deviations from the Test Specification.........................................................................10 4. Operation of the EUT During Testing............................................................................11 5. Summary of Test Results ...............................................................................................12 6. Measurements, Examinations and Derived Results ....................................................13 7. SAR Measurement System.............................................................................................16 8. SAR Safety Limits ...........................................................................................................17 9. Details of SAR Evaluation ..............................................................................................18 10. Evaluation Procedures .................................................................................................19 11. System Validation .........................................................................................................20 12. Simulated Tissues ........................................................................................................21 13. Tissue Parameters ........................................................................................................22 14. DASY4 Systems Specifications ...................................................................................23 15. Validation Results – 1800 MHz Band (Body) ..............................................................24 16. Measurement Uncertainty ............................................................................................25 Appendix 1. Test Equipment Used ....................................................................................27 Appendix 2. SAR Distribution Scans ................................................................................28 Appendix 3. Test Configuration Photograph....................................................................29 Appendix 4. Calibration Data .............................................................................................31 Appendix 5. Photographs of EUT ......................................................................................33 Test Report Serial No: RFI/SARE3/RP46498JD05A Supersedes Test Report Serial No: RFI/SARE2/RP46498JD05A RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI/SARE3/RP46498JD05A Page 4 of 48 Issue Date: 09 August 2005 Test Of: Gizmondo Europe Limited. GZ020. To: OET Bulletin 65 Supplement C: (2001-01) 1. Client Information Company Name: Gizmondo Europe Limited. Address: 1 Meadow Gate Avenue Farnborough Business Farnborough Hampshire GU14 6FG Contact Name: Mr J Mack Test Laboratory Company Name: RFI Global Services Ltd Address: Ewhurst Park Ramsdell Basingstoke Hampshire RG26 5RQ. Contact Name: Mr A Brown RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI/SARE3/RP46498JD05A Page 5 of 48 Issue Date: 09 August 2005 Test Of: Gizmondo Europe Limited. GZ020. To: OET Bulletin 65 Supplement C: (2001-01) 2. Equipment Under Test (EUT) The following information (with the exception of the date of receipt) has been supplied by the client: 2.1. Identification of Equipment Under Test (EUT) Brand Name: Gizmondo Model Name or Number: GZ020 (Build 1.0.0001) IMEI Number: 350390011249597 FCC Identification: THGGIZMONDO Serial Number: G1F050140007 Battery Date Code: 0505 Country of Manufacture: China Date of Receipt: 08 April 2005 2.2. Accessories Description: AC / DC Adaptor Brand Name: Gizmondo Model Name or Number: None Stated Unique Type Identification: FW7650 / 151967 Serial Number: 4504B Battery Serial Number: Not Applicable Country of Manufacture: China Date of Receipt: 08 April 2005 Description: USB Data Cable Brand Name: None Stated Model Name or Number: None Stated Unique Type Identification: None Stated Serial Number: None Stated Battery Serial Number: Not Applicable Country of Manufacture: None Stated Date of Receipt: 08 April 205 RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI/SARE3/RP46498JD05A Page 6 of 48 Issue Date: 09 August 2005 Test Of: Gizmondo Europe Limited. GZ020. To: OET Bulletin 65 Supplement C: (2001-01) Accessories (Continued) Description: Personal Handsfree (PHF) Brand Name: Gizmondo Model Name or Number: None Stated Unique Type Identification: None Stated Serial Number: None Stated Batte…

Text truncated - open the document above for the full version.

TEST REPORT FROM RFI GLOBAL SERVICES LTD Test of: Gizmondo Europe Limited Gizmondo GZ020 Handheld Console To: FCC Part 24: 2004 (Subpart E) Test Report Serial No: RFI\MPTE1\RP46498JD06A This Test Report Is Issued Under The Authority Of Andrew Brown, Operations Manager: Tested By: Steven Wong Checked By: Tony Henriques Report Copy No: PDF01 Issue Date: 16 August 2005 Test Dates: 15 March 2005 to 16 June 2005 This report is issued in Adobe Acrobat portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. This report may be copied in full. The results in this report apply only to the sample(s) tested. RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI\MPTE1\RP46498JD06A Page 2 of 46 Issue Date: 16 August 2005 Test of: Gizmondo Europe Limited Gizmondo GZ020 Handheld Console To: FCC Part 24: 2004 (Subpart E) This page has been left intentionally blank. RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI\MPTE1\RP46498JD06A Page 3 of 46 Issue Date: 16 August 2005 Test of: Gizmondo Europe Limited Gizmondo GZ020 Handheld Console To: FCC Part 24: 2004 (Subpart E) Table of Contents 1. Client Information .............................................................................................................4 2. Equipment Under Test (EUT) ...........................................................................................5 3. Test Specification, Methods and Procedures ................................................................9 4. Deviations from the Test Specification.........................................................................10 5. Operation of the EUT during Testing ............................................................................11 6. Summary of Test Results ...............................................................................................12 7. Measurements, Examinations and Derived Results ....................................................13 8. Measurement Uncertainty ..............................................................................................34 9. Measurement Methods ...................................................................................................35 Appendix 1. Test Equipment Used ....................................................................................43 Appendix 2. Test Configuration Drawings........................................................................44 RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI\MPTE1\RP46498JD06A Page 4 of 46 Issue Date: 16 August 2005 Test of: Gizmondo Europe Limited Gizmondo GZ020 Handheld Console To: FCC Part 24: 2004 (Subpart E) 1. Client Information Company Name: Gizmondo Europe Limited Address: 1 Meadow Gate Avenue Farnborough Business Park Farnborough Hampshire GU14 6FG Contact Name: Mr John Mack RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI\MPTE1\RP46498JD06A Page 5 of 46 Issue Date: 16 August 2005 Test of: Gizmondo Europe Limited Gizmondo GZ020 Handheld Console To: FCC Part 24: 2004 (Subpart E) 2. Equipment Under Test (EUT) The following information (with the exception of the Date of Receipt) has been supplied by the client: 2.1. Identification of Equipment Under Test (EUT) Model Name: Gizmondo Model Number: GZ020 IMEI Number: 350390011249597 FCC ID Number: THGGIZMONDO Serial Number: G1F050140007 Country of Manufacture: China Date of Receipt: 15 March 2005 2.2. Accessories The following accessories were supplied with the EUT: Description: AC Charger Brand Name: Gizmondo Model Number: FW7650/151967 Serial Number: None Stated Cable Length and Type: 2m co-axial Connected to Port: DC Input Description: Earphones Brand Name: Gizmondo Model Name or Number: None Stated Serial Number: Not Applicable Cable Length and Type: 1.0m 3 Core Connected to Port: Earphone Description: USB Cable Brand Name: None Stated Model Name or Number: AWM 2725 Serial Number: E148114-D Cable Length and Type: 1.8m, AWM Connected to Port: USB port of EUT RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI\MPTE1\RP46498JD06A Page 6 of 46 Issue Date: 16 August 2005 Test of: Gizmondo Europe Limited Gizmondo GZ020 Handheld Console To: FCC Part 24: 2004 (Subpart E) 2.3. Description of EUT The equipment under test is a games console with GSM 1900 capabilities (no voice function), Bluetooth* and GPS capabilities. * The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by RFI Global Services Ltd. is under license. Other trademarks and trade names are those of their respective owners. 2.4. Modifications Incorporated in EUT During the course of testing the EUT was not modified. RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI\MPTE1\RP46498JD06A Page 7 of 46 Issue Date: 16 August 2005 Test of: Gizmondo Europe Limited Gizmondo GZ020 Handheld Console To: FCC Part 24: 2004 (Subpart E) 2.5. Additional Information Related to Testing Power Supply Requirement: Nominal 110 V 60 Hz AC Mains supply via AC charger. Internal battery supply of 3.7 Volts. Intended Operating Environment: Within GSM network coverage (for GSM 1900 operation) Equipment Category: Portable Type of Unit: Transceiver Transmit Frequency Range: 1850.2 MHz to 1909.8 MHz Channel ID Channel Number Channel Frequency (MHz) Bottom 512 1850.2 Middle 660 1879.8 Transmit Channels Tested: Top 810 1909.8 Receive Frequency Range: 1930.2 MHz to 1989.8 MHz Channel ID Channel Number Channel Frequency (MHz) Bottom 512 1930.2 Middle 660 1960.0 Receive Channels Tested: Top 810 1989.8 Maximum Peak Power Output (EIRP) 25.6 dBm 2.6. Port Identification Port Description Type/Length 1 Enclosure - 2 USB 1.8 m, AWM 3 3.5 mm Stereo for headphones 1.0 m, 3 Core 4 SD Card - 5 DC Input 2.0m, co-axial RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI\MPTE1\RP46498JD06A Page 8 of 46 Issue Date: 16 August 2005 Test of: Gizmondo Europe Limited Gizmondo GZ020 Ha…
