TLN-CSLAA2 Bottle Wine Bar (27.145MHz Transmitter)

READ AND SAVE THESE IMPORTANT SAFETY INSTRUCTIONS BEFORE USING THIS APPLIANCE: When using an electrical appliance, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: 1. Use this appliance only as described in this manual. Other uses not recommended may cause fire, electric shock or personal injury. 2. This product is intended for household use ONLY and not for commercial industrial or outdoor use. 3. To protect against electric shock, do not immerse unit, plug or cord in water or spray with liquids. 4. Close supervision is necessary when any appliance is used by or near children. 5. Unplug the appliance from the outlet when not in use, when moving from one location to another and before cleaning. 6. To disconnect the appliance, grip the plug and pull it from the wall outlet. Never pull by the cord. 7. Do not operate the appliance in the presence of explosive and/or flammable fumes. 8. Do not place the appliance or any of its parts near an open flame, cooking or other heating appliance. 9. Do not operate the appliance with a damaged cord or plug, if the product malfunctions, or if it is dropped or damaged in any manner. 10. The use of attachments not recommended by the manufacturer may be hazardous. 11. Place the unit on a dry level surface. 12. Do not operate if the housing is removed or damaged. 13. A loose fit between the AC outlet (receptacle) and plug may cause overheating and a distortion of the plug. Contact a qualified electrician to replace loose or worn outlet. 14. This appliance is designed to be free standing only, and should not be recessed or built-in (fully recessed). 15. Locate the unit away from direct sunlight and sources of heat (stove, heater, radiator, etc.). Direct sunlight will affect / alter the outside color of the appliance. WARNING: To reduce the risk of fire, electric shock or personal injury, unplug or disconnect the appliance from the power supply before servicing. SAVE THESE INSTRUCTIONS FOR FUTURE USE Save time and money. Before you call for service, check the Troubleshooting Guide at the back of this manual. It lists causes of minor operating problems that you can correct yourself. WC202-7 Manual.indd 18/22/2006 11:15:04 PM Warning: Changes or modifications to this unit not expressly approved by the part responsible could void the user’s authority to operate the equipment Unpacking the unit: 1. Remove the exterior and interior packing. 2. Check to be sure you have all the following parts: a. One (1) wine bar with Perfect-Temp system b. One (1) instruction manual c. Two (2) wireless temperature probes d. One detachable cord Finding a good spot for your wine cooler: • Place your wine bar on a flat surface that is strong enough to support it when fully loaded. • Allow 5 cm of space on the back side of the wine cooler to allow proper ventilation. • This wine cooler is designed to be free standing only, and should not be recessed or built-in (fully recessed). • Do not place any objects on top of the unit. • Do not locate the unit in a moist place. • The unit’s cooling system operates efficiently with an ambient temperature of less than 21°C. • Do not locate the wine bar in direct sunlight. • ALWAYS REMOVE ALL BOTTLES BEFORE MOVING THE WINE COOLER A B C D E A - Probe A (Left Zone) B - Probe B (Right Zone) C - Left Zone Wine Type Button D - Right Zone Wine Type Button E - Power Button WC202-7 Manual.indd 28/22/2006 11:15:05 PM SETUP CHECKLIST □ Unit must be placed on a flat surface. □ Unit should not be placed in direct sunlight. □ Room should be 21°C or cooler for unit to function properly. □ Do not place unit next to a major appliance that emits large amounts of heat, such as a dishwasher, microwave, oven, barbecue, etc. □ Do not plug unit into the same outlet as a refrigerator. □ Plug the unit into a standard wall outlet that is of the same type as the power cord that is included with the unit. □ There should be 5 cm of clear space around the unit’s vents. □ Unit should not be built-in into a wall recess, cabinet or niche □ Unit should not be placed in any type of enclosed area. WC202-7 Manual.indd 38/22/2006 11:15:05 PM Installing / Replacing Batteries in your Wine Bar’s wireless temperature probes The Wine Bar’s Wireless Temperature Sensors already come with batteries installed at the factory. Should the Sensor Unit batteries ever need to be replaced: 1. Open the Sensor Unit by removing the battery lid with a small flat head screwdriver. 2. Remove the exhausted battery and replace it with a lithium button cell “CR2032” 3. When inserting the new battery make sure that the positive “+” terminal of the battery is upwards. 4. Replace the battery lid. BE CAREFUL WHEN INSTALLING BATTERIES WIRELESS TEMPERATURE SENSOR OF WINE BAR. INSTALLING THE INCORRECT BATTERIES OR REVERSING THE POLARITIES COULD CAUSE PERMANENT DAMAGES TO THE PRODUCT. Operating instructions Easy to Use Preset Mode 1. Turn on the Wine Bar by pressing the “POWER” button on the Main Unit 2. For each zone (left & right) set the wine setting according to the type wine bottle you wish to chill by pressing the “SELECT” button. Keep pressing the select button until the correct setting appears on the LCD & screen. 3. Once you have selected the appropriate temperature preset turn on the correct temperature probe to activate that particular zone (Left or Right) 4. Your Wine Bar will now chill your wine to the appropriate temperature preset selected and once that temperature is acheived it will maintain the set temperature. How the Display Works The grapes below are displayed on the Wine Bar’s display each having its own Preset setting automatically programmed into it to chill your wine to its appropriate serving temperature. The preset temperatures can be modified see the section “Manual Mode” for instructions on how to do so. Red 17°C (63°F) Rosé 13°C (55°F) White 10°C (50°F) Champagne 9°C (48°F) ������������������ �������…

Text truncated - open the document above for the full version.

External Photo FCC ID : TLN-CSLAA External Photo - front External Photo - rear

F C C I D : T L N - C S L A A outline 100% outline 200% Position Sketch 17mm → → 5mm → →

Internal Photo FCC ID : TLN-CSLAA Internal Photo - 1 Internal Photo - 2 Internal Photo FCC ID : TLN-CSLAA Internal Photo - 3

WC202 Transmission Principle Description: The transmitter is a low-power communication device operating at frequency 27.145 MHz by crystal resonator (L1). The signal is a digital coding modulated transmission, which transmitted data to a receiver. This digital coding provides different patterns by proprietary integrated circuit U1. Function: The digital modulator (N2) is employed in the proprietary integrated circuit (U1), which sends encoded digital data. The capacitor (C1 and C3) and ceramic resonator (TX1) established the clock rate of 4 MHz. The output data from the proprietary integrated circuit (U1) drives a Colpitts power oscillator. The frequency of oscillation is controlled by a crystal oscillator (L1)

• The test results reported in this test report shall refer only to the sample actually tested and shall not refer or be deemed to refer to bulk from which such a sample may be said to have been obtained. • This report shall not be reproduced except in full without prior authorization from Intertek Testing Services Hong Kong Limited. • For Terms And Conditions of the services, it can be provided upon request. • The evaluation data of the report will be kept for 3 years from the date of issuance. Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2371 0521 Website: www.hk.intertek-etlsemko.com Concept Solutions Ltd. Application For Certification (FCC ID: TLN-CSLAA) Transmitter 0620975 BC/ Sandy Lee October 17, 2006 INTERTEK TESTING SERVICES FCC ID: TLN-CSLAA i LIST OF EXHIBITS INTRODUCTION EXHIBIT 1: General Description EXHIBIT 2: System Test Configuration EXHIBIT 3: Emission Results EXHIBIT 4: Equipment Photographs EXHIBIT 5: Product Labelling EXHIBIT 6: Technical Specifications EXHIBIT 7: Instruction Manual EXHIBIT 8: Miscellaneous Information INTERTEK TESTING SERVICES FCC ID: TLN-CSLAA ii MEASUREMENT/TECHNICAL REPORT Concept Solutions Ltd. - MODEL: CHAMBRER WC202 FCC ID: TLN-CSLAA October 17, 2006 This report concerns (check one:) Original Grant X Class II Change Equipment Type: Low Power Transmitter (example: computer, printer, modem, etc.) Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? Yes No X If yes, defer until: date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37? Yes No X If no, assumed Part 15, Subpart C for intentional radiator - the new 47 CFR [04-05-05 Edition] provision. Report prepared by: Chow Chi Ming, Billy Intertek Testing Services Hong Kong Ltd. 2/F., Garment Center, 576, Castle Peak Road, Kowloon, Hong Kong. Phone: 852-2173-8528 Fax: 852-2371-0521 INTERTEK TESTING SERVICES FCC ID: TLN-CSLAA iii Table of Contents 1.0 General Description............................................................................................ 2 1.1 Product Description ............................................................................................ 2 1.2 Related Submittal(s) Grants ............................................................................... 2 1.3 Test Methodology............................................................................................... 3 1.4 Test Facility........................................................................................................ 3 2.0 System Test Configuration ................................................................................. 5 2.1 Justification ........................................................................................................ 5 2.2 EUT Exercising Software.................................................................................... 5 2.3 Special Accessories ........................................................................................... 5 2.4 Equipment Modification ...................................................................................... 6 2.5 Measurement Uncertainty .................................................................................. 6 2.6 Support Equipment List and Description ............................................................. 6 3.0 Emission Results ................................................................................................ 8 3.1 Field Strength Calculation................................................................................... 9 3.2 Radiated Emission Configuration Photograph................................................... 10 3.3 Radiated Emission Data ................................................................................... 11 4.0 Equipment Photographs ................................................................................... 14 5.0 Product Labelling.............................................................................................. 16 6.0 Technical Specifications................................................................................... 18 7.0 Instruction Manual ............................................................................................ 20 8.0 Miscellaneous Information ............................................................................... 22 8.1 Bandwidth Plot ................................................................................................. 23 8.2 Discussion of Pulse Desensitization.................................................................. 24 8.3 Emissions Test Procedures .............................................................................. 25 INTERTEK TESTING SERVICES FCC ID: TLN-CSLAA iv List of attached file Exhibit type File Description filename Test Report Test Report report.pdf Operation Description Technical Description descri.pdf Test Setup Photo Radiated Emission radiated photos.doc Test Report Bandwidth Plot bw.pdf External Photo External Photo external photos.doc Internal Photo Internal Photo internal photos.doc Block Diagram Block Diagram block.pdf Schematics Circuit Diagram circuit.pdf ID Label/Location Label Artwork and Location label.pdf User Manual User Manual manual.pdf INTERTEK TESTING SERVICES FCC ID: TLN-CSLAA 1 EXHIBIT 1 GENERAL DESCRIPTION INTERTEK TESTING SERVICES FCC ID: TLN-CSLAA 2 1.0 General Description 1.1 Product Description The Equipment Under Test (EUT) is a Transmitter operating at 27.145MHz. The EUT is powered by 3.0V d.c. (1 x 3.0V “CR2032” battery). During normal use, it transmit temperature signal to the corresponding receiver and the temperature will shown on the display of receiver. Antenna Type : Internal, Integral For electronic filing, the brief circuit description is saved with filename: descri.pdf. 1.2 Related Su…

Text truncated - open the document above for the full version.

Test Setup FCC ID : TLN-CSLAA Radiated - front Radiated - rear
