TLRRC-E-14Remote Control Toy Transmitter

NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER AUTHORITY TO OPERATE THE EQUIPMENT .）

DC 9V POWER SUPPLY IC2 OSCIL LATING & MIX AMP MODULATION

FCC ID Location FCC ID Label Sample FCC ID No.: TLRRC-E-14 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Operational description of Remote Control Car as follow: RC-E-14 is a toy which includes several functions,such as Forward,Backward,Left, Right ,Door Control Key,Switch,Horn Voice,Shift speed Key ,three kinds of gear about the Motor sound, music. and so on. Go with the front light,back light,turn left /right light,skid light,disco music light,shift speed light,lock light. And could be external sound light as MP3 or radiogram.when play the mp3 or radiogram,the other sound will be vanish. Open the car bottom power swicth,,the Horn Voice will appear sound.the car has three kinds of speed ,the first speed light will be flicker,according to the speed ,the car will appear different sound and turn on the different indicator light.while Forwarding or Backwarding,the car can turn right-and-left with the indicator light.and the roaring sound is allowed too.the car have 3 different speed when go forward,but only 1 speed when backward.when the car go forward,and press the music keystoke,the music sound instead of the Motor sound,meanwhile,the four music light flicker.the music will be play for 60 second and turn to the shift speed sound if don’t operate, the other function operate could be intermit the music play.the four music only light when press the music keystoke. The door can be opened when the car stop.if press the lock function when the door open,the car will be close the door first than lock the car.Without receiving the control signal ,the Honrn Voice will make a sound,at the end of the thirtieth second the car will be locked automatically,after being locked ,all the funtions counldn’t control the car except switch.all the funtions will be coded in different scale by the sending port, after receiving the control Signal,the sink decode and input the signal to the drive circuit. Complete and repeat all the funtions.

1 2 3 4 56 ABCD 6 5 4 3 2 1 D CBA Title Number Revision Size B Date: 14-Aug-2005 Sheet of File: E:\p cb\ \G K-98 0B.DD B Drawn By: L2 L1 Q3 C19 R3 C1 C15 R19 C18 C15 C21 R13 R4 R9 R10 R6 R1 R7 R12 R8 C9 Q1 C2 D2 R2 1 2 3 4 5 6 7 8 IC2 C5 R14 R5 1 2 3 45678 C8 C3 VDD RMT C10 C12 1.0 866-399RD SCHEMATIC DRAWING JINWEI INDUSTRIAL, CO.,LTD L2 L2 Q2 C14 R18 C16 C15 R15 C12 C6 C11 R12 R8 k1

Report No.: SZEMO050800864RFF Page: 1 of 10 FCC ID: TLRRC-E-14 Authorized Signature: Robinson Lo Laboratory Manager This report refers to the General Conditions for Inspection and Testing Services, printed overleaf This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International Electrical Approvals in writing. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the federal government. All test results in this report can be traceable to National or International Standards. Member of the SGS Group (SGS SA) SGS-CSTC Standards Technical Services Ltd. 1/F., Building No. 1 Building, Agriculture Machinery Materials Co. Wushan Road, Shipai, Tianhe District,Guangzhou, China Telephone: +86 (0) 20 3848 1001 Fax: +86 (0) 20 3848 1006 Email: [email protected] FEDERAL COMMUNICATIONS COMMISSION Registration number: 282399 TEST REPORT Application No. : SZEMO050800864RF(SGS SZ No. SZTYR050801048/EL) Applicant: Guangdong Shantou City Chenghai District Jinwei Co., Ltd FCC ID: TLRRC-E-14 Fundamental Frequency : 27.145MHz and 49.860MHz Equipment Under Test (EUT): Name: 1:4 ESCALADE Model No.: RC-E-14 Standards: FCC PART 15, SUBPART C : 2004 Section 15.227 and Section 15.235 Date of Receipt: 15 August 2005 Date of Test: 17 to 20 August 2005 Date of Issue: 25 August 2005 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. FCC ID: TLRRC-E-14 Report No.: SZEMO050800864RFF Page: 2 of 10 SGS-CSTC Standards Technical Services Ltd. 2 Test Summary Test Test Requirement Stanadard Paragraph Result Radiated Emission (30MHz to 1000MHz) FCC PART 15 :2004 Section 15.227 and Section 15.235 PASS Occupied Bandwidth FCC PART 15 :2004 Section 15.215 and Section 15.235 PASS Tx: In this whole report Tx (or tx) means Transmitter. Rx: In this whole report Rx (or rx) means Receiver. RF: In this whole report RF means Radiated Frequency. Remark: The EUT included 27.145MHz and 49.860MHz. The electrical circuit design, layout, components used and internal wiring were identical for the 27.145MHz and 49.860MHz, with only difference being the crystals. The EUT passed Radiated Emission test after the modification as shown as the below: . 1, Replaced orinial inductor by following inductance. Inductance L: GL0306, 5.6μH, SUNSHINE ELECTRONICS CO., LTD. 2, Add one capacitance (56pF) specified above. FCC ID: TLRRC-E-14 Report No.: SZEMO050800864RFF Page: 3 of 10 SGS-CSTC Standards Technical Services Ltd. 3 Contents Page 1 COVER PAGE ...........................................................................................................................................1 2 TEST SUMMARY....................................................................................................................................................2 3 CONTENTS..............................................................................................................................................................3 4 GENERAL INFORMATION...................................................................................................................................4 4.1 C LIENT INFORMATION.......................................................................................................................................4 4.2 D ETAILS OF E.U.T............................................................................................................................................4 4.3 DESCRIPTION OF SUPPORT UNITS...................................................................................................................4 4.4 TEST LOCATION................................................................................................................................................4 4.5 O THER INFORMATION REQUESTED BY THE CUSTOMER..................................................................................4 4.6 TEST FACILITY...................................................................................................................................................5 5 TEST RESULTS......................................................................................................................................................6 5.1 TEST INSTRUMENTS..........................................................................................................................................6 5.2 E.U.T. OPERATION...........................................................................................................................................6 5.3 T EST PROCEDURE & MEASUREMENT DATA.....................................................................................................6 5.3.1 Radiated Emissions...................................................................................................................................6 5.3.2 Occupied Bandwidth.................................................................................................................................9 FCC ID: TLRRC-E-14 Report No.: SZEMO050800864RFF Page: 4 of 10 SGS-CSTC Standards Technical Services Ltd. 4 General Information 4.1 Client Information Applicant Name: Guangdong Shantou City Chenghai District Jinwei Co., L…
