TOB-LZM2102RADIO-Z MODULE

Radio Z DataSheet Author : Samuel Asare & Khalid Mehmood Logitech Inc-Canada L-ZM2102 Preliminary Datasheet Datasheet L-ZM2102 Z-Wave Module Datasheet This document is the property of Logitech Inc-Canada. The data contained herein, in whole or in part, may not be duplicated, used or disclosed outside the recipient for any purpose other than to conduct technical evaluation. This restriction does not limit the recipient's right to use information contained in the data if it is obtained from another source without restriction. REVISION RECORD Doc. Rev Date By Pages affected Brief description of changes 01.00 20050412 TJO ALL First release 01.01 20050718 TJO Table 4: SAW filter insertion note inserted Table 5: Min temp extended from -15¡C to -30¡C Table 6: footnote 2 added Chapter 2.7 inserted: Reflow profile Table 7: module weight inserted Chapter 3.1: wording changed L-ZM2102 Preliminary Datasheet Integrated Z-Wave RF Module The L-ZM2102 Z-Wave Module is a fully integrated RF communication module that uses the unlicensed Short-Range-Device (SRD) frequency band of 868.42MHz in Europe and 908.42MHz in US. The L-ZM2102 is dedicated for wireless control and monitoring of residential products like lighting and appliance control, energy management, access control, security and building automation. Together with the patented Z-Wave Protocol the L-ZM2102 Z-Wave Module delivers a complete highly reliable RF communication solution. The Z-Wave Protocol uses Frame Acknowledgement, Retransmission, Collision Avoidance, Frame Checksum Check and sophisticated Routing to assure reliable full home coverage. The L-ZM2102 Z-Wave Module contains the integrated ZW0201 Z-Wave Single Chip, system crystal and RF front-end circuitry. The ZW0201 Single Chip is an integrated chip containing RF Transceiver, 8051 MCU core, SRAM, Flash Memory for Z-Wave Protocol and OEM Application software storage, Triac Controller and a wide range of HW interfaces. This complete RF solution makes it very easy for OEM customers to RF enable their products without having to do the time consuming work of designing, verifying and optimizing the RF design and thereby enables faster time to marked. Features APPENDIX A.1 Interfaces • 10 General Purpose I/O’s • Two Interrupt Inputs • Serial UART • SPI Interface • Triac Control Interface • PWM Output • Four multiplexed 12/8 bit ADC inputs APPENDIX A.2 APPENDIX A.3 ZW0201 Single Chip • Optimized 8051 CPU Core • 32kbyte Flash • 2kbyte SRAM • Power-On-Reset / Brown-Out Detection • Supply Voltage: 2.1V-3.6V • Power Consumption o TX@-5dBm = 23mA o TX@+3dBm = 39mA o RX = 21mA o Power down/sleep mode = 2.5μA APPENDIX A.4 RF • Freq: 908.42MHz (US) / 868.42MHz (EU) • High Sensitivity (-101dBm) • FSK Modulation • 9.6kbit/s Data Rate • -20dBm to +3dBm Output power (ZW0201) • Complies with EN 300 220 and FCC CFR47 part 15 APPENDIX A.5 Applications • Home Automation o Lighting/Drape Control o Automated Meter Reading o Access Control o HVAC o Universal Remote Controls MPQ Test Radio Z 2005-10-03 LOGITECH CONFIDENTIAL (Printed on 10/3/2005 ) page 6 of 19 Table of Contents Compliance Statement 1 PRODUCT DESCRIPTION...................................................................................................................5 1.1 Overview................................................................................................................................................5 1.2 Signal Description..................................................................................................................................6 1.3 RF Front-End.........................................................................................................................................7 1.3.1 RF input/output...........................................................................................................................7 1.3.2 Antenna Matching.......................................................................................................................7 1.4 Z-Wave Module Programming..............................................................................................................8 2 SPECIFICATIONS................................................................................................................................9 2.1 ZW0201 Specification...........................................................................................................................9 2.2 ZW0201 Single Chip Peripherals..........................................................................................................9 2.3 RF Specification....................................................................................................................................9 2.4 Electrical Specification........................................................................................................................10 2.4.1 Absolute Maximum Ratings......................................................................................................10 2.4.2 DC Characteristics....................................................................................................................10 2.5 Physical Specification..........................................................................................................................11 2.6 Process Specification..........................................................................................................................11 2.7 Recommended PCB Footprint Outline................................................................................................12 2.8 Recommended Reflow Profile.............................................................................................................13 2.9 Application PCB Layout Recommendation.........................................................................................13 2.9.1 Supply Voltage....................................................................................…

Text truncated - open the document above for the full version.

September 22, 2005 Federal Communications Commission Dear Application Examiner, Request For a Modular Approval – FCC ID: TOB-LZM2102 Logitech Inc, - Canada, is seeking for FCC authorization for the use of their RF Module “TOB- LZM2102” as a modular transmitter. The requirements of the FCC Public notice DA00-1407 is met. The following requirements are fulfilled: 1. The Modular Transmitter must have its own RF shielding The radio portion of the module is contained in its own RF shielding. See photos in exhibits. 2 The modular transmitter must have buffered modulation/data inputs The modulation/Data inputs are buffered. 3 The modular transmitter must have its own power supply regulation The modular transmitter has its own power supply regulation. 4. The Modular Transmitter must comply with the antenna requirements of Section 15.203 and 15.204c The transmitter shall only be used with tested antenna. 5. The Modular Transmitter must be tested in a stand-alone configuration The EUT was tested in the requested “stand-alone” configuration 6. The Modular Transmitter must be labeled with its own FCC ID number The EUT will be labeled with its own FCC ID number. The label is specified in related exhibit. If the Module is installed inside of an end-point; the label will not be visible. In this case the OEM customer will be instructed to how to apply the exterior label. 7. The Modular Transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. The EUT is compliant with all applicable FCC rules. Detail instructions are given in the users Guide. 8. The Modular Transmitter must comply with any applicable RF exposure requirements. The EUT is in compliant with RF exposure requirements, see users Guide for details. Please contact us if you have any additional questions. 2355 Skymark Avenue, Suite 200 Mississauga, Ontario L4W 4Y6 Canada Main: 905 273 4571 Fax: 905 273 9789 www.logitech..com Sincerely, ___________________________ ______________________ Doug Kay Samuel Asare Embedded Systems/QA Group – Manager Quality Assurance Specialist Logitech Inc., Logitech Inc., 2355 Skymark Ave., 2355 Skymark Ave., Suite 200 Suite 200 Remote Control Business Unit Remote Control Business Unit Mississauga, Ontario L4W 4Y6 Mississauga, Ontario L4W 4Y6

September 22, 2005 FEDERAL COMMUNICATIONS COMMISSION 7435 Oakland Mills road Columbia, MD 21046 U.S.A Subject: Request for withholding from public disclosure of proprietary information submitted pursuant to an Application for Equipment Authorization Applicant: Logitech Inc. - Canada Product: Radio-Z Module Model: L-ZM2102 FCC ID: TOB-LZM2102 Dear Sir/Madam, We, Logitech Inc. - Canada, would like to request that the schematic diagram, system block diagram, and parts list, submitted with the application for certification be withheld from public disclosure as per Section 0.459 of FCC Rules. This request is made under the provisions of Section 0.457(d) of the commission’s Rules, and Section 552(b)(4) of the Freedom of Information Act. These sections authorize as a withholding from public inspection materials, which would be privileged as a matter of law if retained by the person submitting them, and materials which would not customarily be released to the public by that person. If you have any queries, please do not hesitate to contact us. . Yours truly, ________________________ ________________________ Doug Kay Samuel Asare Embedded Systems/QA Group – Manager Quality Assurance Specialist Logitech Inc., Logitech Inc., 2355 Skymark Ave., 2355 Skymark Ave., Suite 200 Suite 200 Remote Control Business Unit Remote Control Business Unit Mississauga, Ontario L4W 4Y6 Mississauga, Ontario L4W 4Y6 2355 Skymark Avenue, Suite 200 Mississauga, Ontario L4W 4Y6 Canada Main: 905 273 4571 Fax: 905 273 9789 www.logitech..com

September 20, 2005 Timco Engineering, Inc. 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 USA Subject: Equipment Authorization Application under FCC Part 15, Subpart C, Section 15.249, Low Power Transmitters Operating in the Frequency Band 902-928 MHz. Applicant: Logitech Inc. - Canada Product: Radio-Z Module Model: L-ZM2102 FCC ID: TOB- LZM2102 Dear Sir/Madam, As appointed agent for Logitech Inc., we would like to submit this application for FCC Certification of the above product. Please review all necessary files uploaded to TIMCO Upload site. ƒ Modular Transmitter Approval Request: This application is subject to the FCC certification for a Mobile & Fixed Base Station modular transceiver, please kindly refer to Logitech Inc. - Canada letter requesting for Modular Approval and clarification of compliance for this modular transmitter with FCC Public Notice DA 00-1407. If you have any queries, please do not hesitate to contact us. Yours truly, Tri Minh Luu, P. Eng., V.P., Engineering TML/DH UltraTech Group of Labs 31040/SIT C-1376 46390-2049 200093-0 2 00-034 SL2-IN-E-1119R 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com Email: [email protected]

ANNEX 2 – EXTERNAL PHOTOGRAPHS Logitech Inc. Radio-Z Module, Model L-ZM2102 FCC ID: TOB-LZM2102 IC: 1807E-LZM2102 A2 - 1 ANNEX 2 – EXTERNAL PHOTOGRAPHS Logitech Inc. Radio-Z Module, Model L-ZM2102 FCC ID: TOB-LZM2102 IC: 1807E-LZM2102 A2 - 2

Logitech lnc. Model: L-ZM2102 FCC ID: TOB-LZM2102 IC: 1807E-LZM2102 MPQ Test Radio Z 2005-10-03 LOGITECH CONFIDENTIAL (Printed on 10/3/2005 ) page 7 of 19 Compliance Statement FCC Class B Part 15 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. If the FCC ID for the module is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must display a label referring to the enclosed module. This exterior label can use wording such as the following: Contains FCC ID: TOB-LZM2102

ANNEX 3 – INTERNAL PHOTOGRAPHS Logitech Inc. Radio-Z Module, Model L-ZM2102 FCC ID: TOB-LZM2102 IC: 1807E-LZM2102 A3 - 1 ANNEX 3 – INTERNAL PHOTOGRAPHS Logitech Inc. Radio-Z Module, Model L-ZM2102 FCC ID: TOB-LZM2102 IC: 1807E-LZM2102 A3 - 2

2005-07-22 Z-Wave™ Modules – L-ZM2102 Microcontroller LOGITECH CONFIDENTIAL (Printed on 10/3/2005 ) page 1 of 7 Z-Wave Module – Radio Z Author : Samuel Asare / Khalid Mehmood Logitech: Canada 2005-07-22 Z-Wave™ Modules – L-ZM2102 Microcontroller LOGITECH CONFIDENTIAL (Printed on 10/3/2005 ) page 2 of 7 User’s Manual & Developer’s Guide Design US/EU Radio Z 2005-07-22 Z-Wave™ Modules – L-ZM2102 Microcontroller LOGITECH CONFIDENTIAL (Printed on 10/3/2005 ) page 3 of 7 Table of Contents 1 ABBREVIATIONS..............................................................................................................................................3 1.1.1 Z-Wave Modules for Embedded Intelligence and Wireless Communication......................................4 1.1.2 Modular Design for Easy Design and Integration ...............................................................................4 1.2 Z-Wave™ Module Designs for Your Need......................................................4 1.2.1.1 Z-Wave Module Features: ..............................................................................................................6 1 Abbreviations Abbreviation Explanation DUT Device Under Test PCB Printed Circuit Board NOP No operation ACK Acknowledgement RF Radio Frequency RX Receive TBD To Be Determined LCD Liquid Crystal Display QA Quality Assurance ZM1220 20cm 2 Z-Wave Module with integrated PCB antenna ZW0102 Z-Wave Single Chip 2005-07-22 Z-Wave™ Modules – L-ZM2102 Microcontroller LOGITECH CONFIDENTIAL (Printed on 10/3/2005 ) page 4 of 7 1.1.1 Z-Wave Modules for Embedded Intelligence and Wireless Communication Logitech’s (Canada) L-ZM2102 Z-Wave Module is a manufacturing Blueprint for fully RF qualified communication PCBs that enable embedded intelligence and wireless communication capabilities in virtually any controllable device. The L-ZM2102 Z-Wave Module is a fully integrated RF communication module that uses unlicensed Short-Range-Device (SRD) frequency of 868.42MHz in Europe and 908.42MHz in the US. The L- ZM2102 is dedicated for wireless control and monitoring of residential products like lighting and appliance control, energy management, access control, security and building automation. Together with the patented Z-Wave Protocol the L-ZM2102 Z-Wave Module delivers a complete highly reliable RF communication solution. The Z-Wave Protocol uses Frame Acknowledgement, Retransmission, Collision Avoidance, Frame Checksum Check and sophisticated Routing Algorithms to assure full home coverage. 1.1.2 Modular Design for Easy Design and Integration The L-ZM2102 Z-Wave Module contains the integrated L-ZW0201 Z-Wave Single Chip, system crystal and RF front-end circuitry. The L-ZW0201 Single Chip is an integrated chip containing RF Transceiver, 8051 MCU core, SRAM, Flash Memory for Z-Wave Protocol and OEM Application SW storage, Triac Controller and a wide range of HW interfaces. This complete RF solution makes it very easy for OEM customers to RF enable their products without having to do the time consuming work of designing, verifying and optimizing the RF design and thereby enables faster time to market. 1.2 Z-Wave™ Module Designs for Your Need Zensys has developed manufacturing Blueprints for the L-ZM2102 Z-Wave Module, which includes an on-board antenna, making it easy for OEMs to incorporate Z-Wave into almost any controllable device. At less than a third the size, the “Small Form Factor” family enables OEMs to incorporate Z-Wave into the smallest of devices, including sensors and power outlets. In addition Zensys also assist OEMs with custom designs if their particular application does not allow for using one of the existing Z-Wave Modules. 2005-07-22 Z-Wave™ Modules – L-ZM2102 Microcontroller LOGITECH CONFIDENTIAL (Printed on 10/3/2005 ) page 5 of 7 Z-Wave Module Specifications L-ZM2102 LZM0201 Single Chip Optimized 8051 CPU core 32Kbyte Flash 2Kbyte SRAM 16MHz internal system clock freq Power-on-Reset/Brown-Out Detection Supply Voltage: 2.2V-3.6V X-tal frequency RF frequency RF data rate 32 mhZ 868.42mhZ (EU) 908.42MHz 9.6kbps High Sensitivity Typ: -101dBm @ 9.6kbit/s Modulation FSK Programmable transmit power Power Consumption: Transmit Receive Power down (Timer Wake up and POR enabled) -20 to +5dBm - Typ: 23mA @ -5dBm Typ: 21mA Typ: 3μA @ 25ºC Operating temperature 15 to 85ºC Applications Home Automation - - Lighting/Drape Control - - Automated Meter Reading - - Access Control - - Universal Remotes Controls - - Thermostats - - Sensors Interfaces available through application connector - - - Regulatory Compliance 10 GPIOs - - UART - - SPI - - Triac Control - - PWM 4 multiplexed 12/8 bit inputs FCC CFR47 part 15 EN 300 220 Note: data is applicable for Z-Wave Developer’s kit v4.0 2005-07-22 Z-Wave™ Modules – L-ZM2102 Microcontroller LOGITECH CONFIDENTIAL (Printed on 10/3/2005 ) page 6 of 7 1.2.1.1 Z-Wave Module Features: • Completely RF qualified design • Compliant with FCC Part 15 and R&TTE 1999/5/EC • Available to OEMs as fully production matured Blueprint Documentation Packages • Handling and storage of both Z-Wave Protocol and OEM Application SW • Application Connector for interfacing to and controlling Application hardware • Serial (UART) and SPI interfaces for easy communication with any other MCUs in final OEM product 1.2.1.1.1.1 Z-Wave L-ZM2102 Block Diagram 1.2.1.1.1.2 Fast Manufacturing Ramp-up with Z-Wave Module Blueprints The Z-Wave Module manufacturing Blueprints have already been production matured and tested to be in compliance with FCC and R&TTE requirements. The OEM can therefore quickly set up volume production of Z-Wave Modules. The Blueprint Documentation package contains: • Datasheet • Bill of material • Schematic • PCB documentation • Manufacturing guidelines • Programming instructions • RF/EMC report 2005-07-22 Z-Wave™ Modules – L-ZM2102 Microcontroller LOGITECH CONFIDENTIAL (Printed on 10/3/2005 ) page 7 of 7

ENGINEERING TEST REPORT Radio-Z Module MODEL NO.: L-ZM2102 FCC ID: TOB-LZM2102 Applicant: Logitech Inc. - Canada 2355 Skymark Avenue, Suite 200 Mississauga, ON Canada L4W 4Y6 Tested in Accordance With FCC Part 15, Subpart C, Section 15.249 Low Power Transmitters Operating in the Frequency Band 902 - 928 MHz UltraTech's File No.: LOG-003F15C249 This Test report is Issued under the Authority of Tri M. Luu, Professional Engineer, Vice President of Engineering UltraTech Group of Labs Date: September 20, 2005 Report Prepared by: Dan Huynh Issued Date: September 20, 2005 Tested by: Mr. Hung Trinh, EMC/RFI Technician Test Dates: September 1, 2005 ƒ The results in this Test Report apply only to the sample(s) tested, and the sample tested is randomly selected. ƒ This report must not be used by the client to claim product endorsement by NVLAP or any agency of the US Government. UltraTech 3000 Bristol Circle, Oakville, Ontario, Canada, L6H 6G4 Tel.: (905) 829-1570 Fax.: (905) 829-8050 Website: www.ultratech-labs.com , Email: [email protected], Email: [email protected] 2 31040/SIT C-1376 46390-2049 200093-0 SL2-IN-E-1119R 00-034 FCC Part 15, Subpart C, Section 15.249 – Intentional Radiators Content i Radio-Z Module, Model: L-ZM2102 FCC ID: TOB-LZM2102 ULTRATECH GROUP OF LABS File #: LOG-003F15C249 3000 Bristol Circle, Oakville, Ontario, Canada L6H 6G4 September 20, 2005 Tel.: 905-829-1570, Fax. : 905-829-8050 All test results contained in this engineering test report are traceable to National Institute of Standards and Technology (NIST) TABLE OF CONTENTS EXHIBIT 1. INTRODUCTION............................................................................................................................................................1 1.1. SCOPE..............................................................................................................................................................................................1 1.2. RELATED SUBMITTAL(S)/GRANT(S) ........................................................................................................................................1 1.3. NORMATIVE REFERENCES ........................................................................................................................................................1 EXHIBIT 2. PERFORMANCE ASSESSMENT .................................................................................................................................2 2.1. CLIENT INFORMATION ...............................................................................................................................................................2 2.2. EQUIPMENT UNDER TEST (EUT) INFORMATION ..................................................................................................................2 2.3. EUT’S TECHNICAL SPECIFICATIONS .......................................................................................................................................3 2.4. LIST OF EUT’S PORTS ..................................................................................................................................................................3 2.5. ANCILLARY EQUIPMENT ...........................................................................................................................................................3 2.6. GENERAL TEST SETUP ................................................................................................................................................................3 EXHIBIT 3. EUT OPERATING CONDITIONS AND CONFIGURATIONS DURING TESTS...................................................4 3.1. CLIMATE TEST CONDITIONS.....................................................................................................................................................4 3.2. OPERATIONAL TEST CONDITIONS & ARRANGEMENT FOR TESTS ..................................................................................4 EXHIBIT 4. SUMMARY OF TEST RESULTS..................................................................................................................................5 4.1. LOCATION OF TESTS ...................................................................................................................................................................5 4.2. APPLICABILITY & SUMMARY OF EMC EMISSION TEST RESULTS ...................................................................................5 4.3. MODIFICATIONS INCORPORATED IN THE EUT FOR COMPLIANCE PURPOSES .............................................................5 EXHIBIT 5. MEASUREMENTS, EXAMINATIONS & TEST DATA FOR EMC EMISSIONS ..................................................6 5.1. TEST PROCEDURES......................................................................................................................................................................6 5.2. MEASUREMENT UNCERTAINTIES............................................................................................................................................6 5.3. MEASUREMENT EQUIPMENT USED.........................................................................................................................................6 5.4. ESSENTIAL/PRIMARY FUNCTIONS AS DECLARED BY THE MANUACTURER ................................................................6 5.5. AC/DC POWER LINE CONDUCTED EMISSIONS [47 CFR 15.107(a) & 15.207]......................................................................7 5.6. 20 dB BANDWIDTH ..................................................................................................................................................................... 13 5.7. FUNDAMETAL FIELD STRENGTH AND HARMONIC EMISSIONS (RADIATED @ 3 METERS) [47 CFR 15.249(a), 15.209 & 15.205]............................................................................................................................................................…

Text truncated - open the document above for the full version.

ANNEX 1 – TEST SETUP PHOTOS Logitech Inc. - Canada Radio-Z Module, Model L-ZM2102 FCC ID: TOB-LZM2102 A1 - 1 Transmitter Radiated Emissions at 3 Meters ANNEX 1 – TEST SETUP PHOTOS Logitech Inc. - Canada Radio-Z Module, Model L-ZM2102 FCC ID: TOB-LZM2102 A1 - 2 Transmitter Radiated Emissions at 3 Meters ANNEX 1 – TEST SETUP PHOTOS Logitech Inc. - Canada Radio-Z Module, Model L-ZM2102 FCC ID: TOB-LZM2102 A1 - 3 Transmitter Radiated Emissions at 3 Meters ANNEX 1 – TEST SETUP PHOTOS Logitech Inc. - Canada Radio-Z Module, Model L-ZM2102 FCC ID: TOB-LZM2102 A1 - 4 Transmitter Radiated Emissions at 3 Meters
