TOTBLUEAUDIO2BlueAudio2

LensLogica S.r.l. Via S.Salvatore, 35 35100 Padova – Italy Tel: +39-049-870.5048 Fax: +39-049-870.6426 www.lenslogica.com P.IVA 03559840289 Authors: A. Colognese ________________ ________________ Date:________________ LensLogica s.r.l. BLUEAUDIO2 USER MANUAL LensLogica S.r.l. Via S.Salvatore, 35 35100 Padova – Italy Tel: +39-049-870.5048 Fax: +39-049-870.6426 www.lenslogica.com P.IVA 03559840289 Revision List RELEASE LIST AND CHANGE LOG EDIZ.DATAPAG.NOTE 1.430/06/2003- SW Release V1.2b. DRAFT 1.509/09/2003-Photo of board Included 1.601/12/2003-Mechanical table 1.720/01/2004-Pre-release of BlueAudio2 2.0 03/06/2005- BlueAudio2 initial DRAFT LensLogica s.r.l. LensLogica S.r.l. Via S.Salvatore, 35 35100 Padova – Italy Tel: +39-049-870.5048 Fax: +39-049-870.6426 www.lenslogica.com P.IVA 03559840289 Table of Contents 1INTRODUCTION.........................................................................................................5 2BLUEAUDIO2 SYSTEM..............................................................................................6 2.1System Description.......................................................................................................6 2.2Hardware Description....................................................................................................7 2.3Electrical specifications.................................................................................................8 2.3.1Maximum ratings...................................................................................................................8 2.3.2Mechanical specifications......................................................................................................8 2.3.3Bluetooth Specifications........................................................................................................9 3FEATURES................................................................................................................10 3.1Power Supply..............................................................................................................10 3.2User Interface..............................................................................................................10 3.2.1Button functions...................................................................................................................10 3.2.2Led Messages.....................................................................................................................12 3.2.3Audio messages - Tones.....................................................................................................12 4PAIRING....................................................................................................................14 4.1HS pairing mode.........................................................................................................14 4.1.1Pairing with a mobile supporting Headset profile................................................................15 4.1.2Pairing with a HU device.....................................................................................................15 4.2HF pairing mode..........................................................................................................15 4.2.1Pairing with a mobile supporting Headset profile................................................................15 5AUDIO LINK SET-UP.................................................................................................17 5.1HU ↔ HU....................................................................................................................17 5.2CU ↔ HU....................................................................................................................17 6EXTERNAL CONNECTIONS.....................................................................................19 LensLogica s.r.l. LensLogica S.r.l. Via S.Salvatore, 35 35100 Padova – Italy Tel: +39-049-870.5048 Fax: +39-049-870.6426 www.lenslogica.com P.IVA 03559840289 6.1Power Supply Connector – JP3..................................................................................19 6.2Speaker Connector – JP1...........................................................................................19 6.3Microphone Connector – BFIN....................................................................................20 6.4User Interface Connector – JP2 .................................................................................20 7BLUEAUDIO BOARD VIEW......................................................................................21 LensLogica s.r.l. LensLogica S.r.l. Via S.Salvatore, 35 35100 Padova – Italy Tel: +39-049-870.5048 Fax: +39-049-870.6426 www.lenslogica.com P.IVA 03559840289 1Introduction This document describes main characteristics and features of BlueAudio2 devices for intercom or mobile applications. Conventions In the document following conventions are assumed: •HU: BlueAudio2 or BlueAudio device. •CU: Mobile cellular phone with Bluetooth support. LensLogica s.r.l. LensLogica S.r.l. Via S.Salvatore, 35 35100 Padova – Italy Tel: +39-049-870.5048 Fax: +39-049-870.6426 www.lenslogica.com P.IVA 03559840289 2BlueAudio2 system 2.1System Description BlueAudio2 is a wireless device that allows hands-free use of any mobile phone supporting Bluetooth Headset or Hands-free profiles, but also provides capability for easy wireless audio communication with another BlueAudio2 device, or a BlueAudio one. Its main application could be a Bluetooth Helmet. All functions are implemented with a user-friendly interface based on a multifunctional button located on the helmet, an external led and audio messages sent to hi-fidelity acoustic speakers. User will be able to talk with a passenger and in case of a incoming call from a paired cellular phone, he will be able to answer. The connection with the paired device is automatically set-up and it can be dropped by each user. In the previous figure, a blue …

Text truncated - open the document above for the full version.

STLC2510 Quartz 13 MHz Antenna

Date 13 October 2005 Telecommunication Certification Body RFI Global Services Ltd. Pavilion A Ashwood Park Basingstoke Hampshire RG23 8BG United Kingdom Subject: Certification Application FCC ID: TOTBLUEAUDIO2 It is requested that the following information is to be held confidential on behalf of Engineering and Security srl. FCC Rules Part 0.459 refers disclosure of the information below could result in substantial competitive harm. Exhibit File name Number of pages Schematics ITEM_5_Schematics 8 Component Layout ITEM_7_ComponentsLayout 1 Parts List ITEM_9_PartList 1 Yours sincerely Giancarlo Olive

Requesting modular approval The company Engineering and Security SRL request the limited modular approval of the BlueAudio2 device that has the follow characteristics: 1. The modular transmitter haven't its own RF shielding. 2. The modular transmitter has standard bluetooth V1.1 modulation/data rates. 3. The modular transmitter has its own power supply regulation. 4. The modular transmitter is comply with the antenna requirements of Section 15.203 and 15.204(c). The antenna is permanently attached. 5. The modular transmitter is tested in a stand-alone configuration, i.e., the module is not inside another device during testing. 6. The modular transmitter is labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. 7. The modular transmitter is comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. 8. The modular transmitter is comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 2.1091, 2.1093 and specific Sections of Part 15, including 15.319(i), 15.407(f), 15.253(f) and 15.255(g), require that Unlicensed PCS, UNII and millimeter wave devices perform routine environmental evaluation for RF Exposure to demonstrate compliance. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF Exposure compliance in accordance with Section 15.247(b)(4). Modular transmitters approved under other Sections of Part 15, when necessary, may also need to address certain RF Exposure concerns, typically by providing specific installation and operating instructions for users, installers and other interested parties to ensure compliance. Yours Sincerely, Giancarlo Olive

FCC ID : TOTBLUEAUDIO2 IC : 6104A-BLUEAUD2

BlueAudio is a headset and intercommunication audio application. It works with Bluetooth compliant cellular phone with both HS and HF profiles: it drops the link audio between two BlueAudio device when there is an incoming call from the cellular phone; is possible to do outgoing call by the voice capabilities of the cellular phone. The volume control and all the others functions are done via one push button. The BlueAudio device can be paired with a cellular phone and another BlueAudio device. The BlueAudio device has an antenna designed in the PCB directly, and is a quarter wavelength trace. The ground area see completed the antenna and the radio chipset is grounded as recommended by the chip designer.

TEST REPORT FROM RFI GLOBAL SERVICES LTD Test of: Engineering and Security srl. Blue Audio. To: FCC Part 15.247: 2004 (Subpart C) Test Report Serial No: RFI\MPTE2\RP47410JD01A Supersedes Test Report Serial No: RFI/MPTE1/RP47410JD01A This Test Report Is Issued Under The Authority Of Andrew Brown, Operations Manager: pp Tested By: Fara Razally Checked By: Michael Derby pp Report Copy No: PDF01 Issue Date: 26 October 2005 Test Dates: 13 July 2005 to 21 July 2005 This report is issued in Adobe Acrobat portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI\MPTE2\RP47410JD01A Page 2 of 50 Issue Date: 26 October 2005 Test of: Engineering and Security srl. Blue Audio. To: FCC Part 15.247: 2004 (Subpart C) This page has been left intentionally blank. Test Report Serial No: RFI\MPTE2\RP47410JD01A Supersedes Test Report Serial No: RFI/MPTE1/RP47410JD01A RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI\MPTE2\RP47410JD01A Page 3 of 50 Issue Date: 26 October 2005 Test of: Engineering and Security srl. Blue Audio. To: FCC Part 15.247: 2004 (Subpart C) Table of Contents 1. Client Information .............................................................................................................4 2. Equipment Under Test (EUT) ...........................................................................................5 3. Test Results.......................................................................................................................9 4. Deviations from the Test Specification.........................................................................10 5. Operation of the EUT during Testing ............................................................................11 6. Summary of Test Results ...............................................................................................12 7. Measurements, Examinations and Derived Results ....................................................13 8. Measurement Uncertainty ..............................................................................................38 9. Measurement Methods ...................................................................................................39 Appendix 1. Test Equipment Used ....................................................................................46 Appendix 2. Test Configuration Drawings........................................................................47 RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI\MPTE2\RP47410JD01A Page 4 of 50 Issue Date: 26 October 2005 Test of: Engineering and Security srl. Blue Audio. To: FCC Part 15.247: 2004 (Subpart C) 1. Client Information Company Name: Engineering and Security srl. Address: Via Isorelle, 19 16010 Savignone (Genova) Italy Contact Name: Mr G. Olive RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI\MPTE2\RP47410JD01A Page 5 of 50 Issue Date: 26 October 2005 Test of: Engineering and Security srl. Blue Audio. To: FCC Part 15.247: 2004 (Subpart C) 2. Equipment Under Test (EUT) The following information (with the exception of the Date of Receipt) has been supplied by the client: 2.1. Identification of Equipment Under Test (EUT) Brand Name: Blue Audio 2 Model Name or Number: Blue Audio 2 Unique Type Identification: Not Applicable Serial Number: None stated Hardware Version: 2.0A Software Version: 2.0A FCC ID Number: TOTBLUEAUDIO2 Country of Manufacture: Italy Date of Receipt: 14 July 2005 RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI\MPTE2\RP47410JD01A Page 6 of 50 Issue Date: 26 October 2005 Test of: Engineering and Security srl. Blue Audio. To: FCC Part 15.247: 2004 (Subpart C) 2.2. Accessories The following accessories were supplied with the EUT: Description: Li-on Battery Brand Name: STILO Li-on Battery Model Name or Number: Not Applicable Serial Number: Not Applicable Cable Length and Type: Not Applicable Connected to Port: Not Applicable Description: Microphone Brand Name: STILO Microphone Model Name or Number: Not Applicable Serial Number: Not Applicable Cable Length and Type: Not Applicable Connected to Port: Not Applicable Description: Speaker Brand Name: STILO Speaker Model Name or Number: Not Applicable Serial Number: Not Applicable Cable Length and Type: Not Applicable Connected to Port: Not Applicable RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI\MPTE2\RP47410JD01A Page 7 of 50 Issue Date: 26 October 2005 Test of: Engineering and Security srl. Blue Audio. To: FCC Part 15.247: 2004 (Subpart C) 2.3. Description of EUT The equipment under test is a helmet intercom with Bluetooth technology. It supports headset and hands-free profile, when paired with an enabled cellular phone. 2.4. Modifications Incorporated in EUT During the course of testing the EUT was not modified. RFI GLOBAL SERVICES LTD TEST REPORT S.No. RFI\MPTE2\RP47410JD01A Page 8 of 50 Issue Date: 26 October 2005 Test of: Engineering and Security srl. Blue Audio. To: FCC Part 15.247: 2004 (Subpart C) 2.5. Additional Information Related to Testing Power Supply Requirement: Internal battery supply of 3.6 V Intended Operating Environment: Residential, commercial and Light Industry Equipment Category: Short Range (Low Power), Bluetooth Type of Unit: Portable (Standalone battery powered device) Transmit Frequency Range: 2402 MHz to 2480 MHz Channel ID Channel Number Channel Frequency (MHz) Bottom 1 2402 Middle 40 2441 Transmit Channels Tested: Top 79 2480 Receive Frequency Range: 2402 MHz to 2480 MHz Channel ID Channel Number Channel Frequency (MHz) Bottom 1 2402 Middle 40 2441 Receive Channels Tested: Top 79 2480 Maximum Peak Power Output (EIRP): 1.4 dBm (measured) Occupied Bandwidth: 889.780 kHz (measured) 2.6. Port Identification Port Description Type/Length Applicable 1 Enclosure - Y 2.7. Support Equipment No support equipment was used to e…
