TQ2-SC600PDT-BWGPortable Data Terminal

SC600 / SC620 User’s Manual WinCE. NET Rugged Portable Data Terminal January/30/2007 Ver: 1.4 Table of Contents Chapter 1. Introduction ........................................................................ 1-1 1.1 About this Manual............................................................................1-1 1.2 User and Product Safety...................................................................1-2 1.3 Battery Safety...................................................................................1-3 1.4 FCC Statement .................................................................................1-4 1.5 Recycling & disposal instructions. ..................................................1-5 1.6 Regulatory information. ...................................................................1-5 1.7 Product Labeling ..............................................................................1-6 1.8 System Specifications ....................................................................1-10 1.9 Environment Standard....................................................................1-12 1.10 Warranty and after service ...........................................................1-12 Chapter 2. Getting Started.................................................................... 2-1 2.1 Check the package ...........................................................................2-1 2.2 General View of the PDT.................................................................2-3 2.2.1 SC600 general view ................................................................2-3 2.2.2 SC620 general view ................................................................2-5 2.3 Charging the Battery Pack ...............................................................2-7 2.3.1 Installing the battery pack .......................................................2-7 2.3.2 Charging the battery pack with Power Adapter ......................2-9 2.4. Handling the PDT .........................................................................2-10 2.4.1 Starting the PDT....................................................................2-10 2.4.2 Power on / off........................................................................2-10 2.4.3 Calibration of the touch Screen.............................................2-11 2.4.4 Adjusting the brightness........................................................2-11 2.4.5 To mute the Sound ................................................................2-12 2.4.6 Using the Stylus ....................................................................2-12 2.4.7 Using the SC600 Keypad......................................................2-12 2.4.8 Using the SC620 Keypad......................................................2-21 2.4.9 Using the Ear/Microphone ....................................................2-31 2.5 Navigating the Display ..................................................................2-32 2.5.1 Setting Time and Date...........................................................2-32 2.5.2 Entering the Data ..................................................................2-32 2.5.3 The Command Bar ................................................................2-33 2.5.4 The Task Bar .........................................................................2-33 2.5.5 The Soft Keypad ...................................................................2-34 2.5.6 Setting Up Wireless LAN RF ...............................................2-34 2.5.7 Reading barcodes, 1D laser version......................................2-35 2.5.8 Help.......................................................................................2-36 2.6 Power management ........................................................................2-37 2.6.1 Suspend Mode.......................................................................2-37 2.6.2 Resuming ..............................................................................2-38 2.7 Resetting the PDT ..........................................................................2-38 2.7.1 Software (Warm) Reset .........................................................2-38 2.7.2 Cold Reset .............................................................................2-38 Chapter 3. Setting................................................................................. 3-1 3.1 Introduction......................................................................................3-1 3.2 Control Panel ...................................................................................3-1 3.2.1 BarCode Setting ......................................................................3-2 3.2.2 Symbologies List ....................................................................3-8 3.2.3 Bluetooth Device Properties .................................................3-24 3.2.4 Certificates ............................................................................3-26 3.2.5 Control Center.......................................................................3-28 3.2.6 Date/Time..............................................................................3-32 3.2.7 Dialing Properties .................................................................3-33 3.2.8 Display Properties .................................................................3-35 3.2.9 Input Panel ............................................................................3-36 3.2.10 Internet Options ..................................................................3-37 3.2.11 Keyboard .............................................................................3-39 3.2.12 Network and Dial-up Connections......................................3-40 3.2.13 Owner..................................................................................3-44 3.2.14 Password .............................................................................3-45 3.2.15 PC Connection ......................................…

Text truncated - open the document above for the full version.

3-39 Figure 3-57 Internet Settings Figure 3-58 Internet Settings 3.2.11 Keyboard Table 3-32 Keyboard ICON ITEM & FUNCTION
“Repeat” Tab :( Figure 3-59)  To change the amount of time between depressions before repetition starts, adjust the Repeat delay slider  To change the repeat rate, adjust the Repeat rate slider.  Test your new setting.  Tap “ OK” to exit the “Keyboard” Tab. 3-40 Figure 3-59 Keyboard Properties 3.2.12 Network and Dial-up Connections Table 3-33 Network and Dial-up Connections ICON ITEM & FUNCTION
“Connection” Tab :  To create a “Dial-up Connection”:  Double-tap the “Make New connection”.  In the “Make New Connection” dialog box, enter a name for the connection.  Select “Dial-Up Connection”.  Select the “Next” button.  Select the modem you want use.  Select “Configure”  Under “Connection Reference”, use the default settings provided. If you can’t connect using these settings, see your ISP or network administrator for specific information. If you want to always enter a phone number before connecting, Select “Manual Dial”. Select “OK”. 3-41  Select “TCP/IP Settings”. In the “General” tab, ensure “Use Server-assigned IP address” is selected. In the “Name Servers” tab, ensure “Use Server-assigned addresses” is selected, and select “OK”. If you are unable to connect with these default settings, see your ISP or network administrator for specific TCP/IP information.  Select the “Next” button and type the telephone number.  Select the “Finish” button. The connection you just created appears as an icon in the “Network and Dial-up Connections” folder.  Set up a point-to-Point Protocol(PPP) account with an ISP and obtain the following information:  Access telephone number  User name  Password Once you have established an account, create a new connection on your device. When creating this connection, you should be able to use all of the default TCP/IP settings provided in the Make New Connection Wizard. If you can’t connect using the default settings, contact your ISP or access your ISP’s Web site for specific TCP/IP information as well as primary and secondary DNS address.  Modify connection setting  Select Start > Settings > Network and Dialup Connections  Select the icon for connection settings you want to modify.  Select File > Properties, or double- tap the appropriate icon.  Select desired options. There may be additional settings that depend on the connection. To modify, select the icon and select the icon and select Advanced Settings... from the menu. 3-42 Figure 3-60 Network and Dial-up Connections Figure 3-61 Network and Dial-up Connections Figure 3-62 Network and Dial-up Connections Figure 3-63 Network and Dial-up Connections 3-43 Figure 3-64 Network and Dial-up Connections Figure 3-65 Network and Dial-up Connections Figure 3-66 Network and Dial-up Connections Figure 3-67 Network and Dial-up Connections 3-44 Figure 3-68 Network and Dial-up Connections Figure 3-69 Network and Dial-up Connections Figure 3-70 Network and Dial-up Connections Figure 3-71 Network and Dial-up Connections 3.2.13 Owner Table 3-35 Owner ICON ITEM & FUNCTION
“Identification” Tab : (Figure 3-72) 3-45  Fill in or edit the data as desired.  To have this information displayed when you start your device, select “Display Owner Identification” at Power On.  To set up identification for remote networks, see Setting up identification for remote networks.
“Network ID” Tab: (Figure 3-73)  Enter the user name, password, and domain name you use to log on to remote network. Figure 3-72 Owner Properties Figure 3-73 Owner Properties 3.2.14 Password Table 3-36 Password ICON ITEM & FUNCTION
“Password Setting” Tab : (Figure 3-74)  Enter the password  In the “Confirm password “box, enter the password again.  To require the password on startup, select “Enable password protection at power- on“. and/or select “Enable password protection for screen saver”  To exit the Password control panel, press “OK” from the control bar, or press the <Enter> key on the keypad. 3-46 Figure 3-74 Password Properties 3.2.15 PC Connection Table 3-37 PC Connection ICON ITEM & FUNCTION
“PC Connection” Tab : (Figure 3-75)  Select the first checkbox to enable direct connections to the desktop computer. (Figure 3-75)  Tap the “Change Connection...” button to modify the connection method from USB or Serial. (Figure 3-76)  To exit the “Change Connection” dialog, press “OK” from the control bar, or press the <Enter> key on the keypad.  To exit the “PC Connection” properties control panel, press “OK” from the control bar, or press the <Enter> key on the keypad. 3-47 Figure 3-75 PC Connection Figure 3-76 PC Connection 3.2.16 Power Table 3-38 Power ICON ITEM & FUNCTION
“Battery” Tab : (Figure 3-77)  Provide change level indicators for Main battery and Backup battery.  Provide remaining power capacity of main battery.  If a “Main Batteries very Low” warning message shows, the remaining battery life is around 30 minutes to SC600 shuts down. ( Figure 3-81)  The PDT will shutdown during the main batteries capacity is around 0%  To exit Battery control panel, press “OK” from the command bar, or press <Enter> key on keypad.
“ Schemes” Tab: (Figure 3-78) 3-48  The Scheme Tab allows you to determine the time to switch state to Suspend mode when using either Battery Power or AC Power.  Select Battery Power or AC Power as the power scheme from the pull-down list.( Figure 3-78)  Select the time to suspend mode from the pull-down list. ( Figure 3-79)
“Device Status” Tab: ( Figure 3-80) Provide power level of device – The power level ranges from “ High(D0)” which means the device is at the highest power level to “Off(D4)” which means the device is at the lowest power level. Note: This ICON inside the Task Bar shows that AC adapter provides power to the PDT The ICON inside the Task Bar shows that Main Batteries provides the power to the PDT. The ICON inside the Task Bar shows that AC adapter provides the …

Text truncated - open the document above for the full version.

SC600 / SC620 User’s Manual WinCE. NET Rugged Portable Data Terminal April/10/2007 Ver: 1.5 Table of Contents Chapter 1. Introduction ........................................................................ 1-1 1.1 About this Manual............................................................................1-1 1.2 User and Product Safety...................................................................1-2 1.3 Battery Safety...................................................................................1-3 1.4 FCC Statement .................................................................................1-4 1.5 Recycling & disposal instructions. ..................................................1-5 1.6 Regulatory information. ...................................................................1-5 1.7 Product Labeling ..............................................................................1-6 1.8 System Specifications ....................................................................1-10 1.9 Environment Standard....................................................................1-12 1.10 Warranty and after service ...........................................................1-12 Chapter 2. Getting Started.................................................................... 2-1 2.1 Check the package ...........................................................................2-1 2.2 General View of the PDT.................................................................2-3 2.2.1 SC600 general view ................................................................2-3 2.2.2 SC620 general view ................................................................2-5 2.3 Charging the Battery Pack ...............................................................2-7 2.3.1 Installing the battery pack .......................................................2-7 2.3.2 Charging the battery pack with Power Adapter ......................2-9 2.4. Handling the PDT .........................................................................2-10 2.4.1 Starting the PDT....................................................................2-10 2.4.2 Power on / off........................................................................2-10 2.4.3 Calibration of the touch Screen.............................................2-11 2.4.4 Adjusting the brightness........................................................2-11 2.4.5 To mute the Sound ................................................................2-12 2.4.6 Using the Stylus ....................................................................2-12 2.4.7 Using the SC600 Keypad......................................................2-12 2.4.8 Using the SC620 Keypad......................................................2-21 2.4.9 Using the Ear/Microphone ....................................................2-31 2.5 Navigating the Display ..................................................................2-32 2.5.1 Setting Time and Date...........................................................2-32 2.5.2 Entering the Data ..................................................................2-32 2.5.3 The Command Bar ................................................................2-33 2.5.4 The Task Bar .........................................................................2-33 2.5.5 The Soft Keypad ...................................................................2-34 2.5.6 Setting Up Wireless LAN RF ...............................................2-34 2.5.7 Reading barcodes, 1D laser version......................................2-35 2.5.8 Help.......................................................................................2-36 2.6 Power management ........................................................................2-37 2.6.1 Suspend Mode.......................................................................2-37 2.6.2 Resuming ..............................................................................2-38 2.7 Resetting the PDT ..........................................................................2-38 2.7.1 Software (Warm) Reset .........................................................2-38 2.7.2 Cold Reset .............................................................................2-38 Chapter 3. Setting................................................................................. 3-1 3.1 Introduction......................................................................................3-1 3.2 Control Panel ...................................................................................3-1 3.2.1 BarCode Setting ......................................................................3-2 3.2.2 Symbologies List ....................................................................3-8 3.2.3 Bluetooth Device Properties .................................................3-24 3.2.4 Certificates ............................................................................3-26 3.2.5 Control Center.......................................................................3-28 3.2.6 Date/Time..............................................................................3-32 3.2.7 Dialing Properties .................................................................3-33 3.2.8 Display Properties .................................................................3-35 3.2.9 Input Panel ............................................................................3-36 3.2.10 Internet Options ..................................................................3-37 3.2.11 Keyboard .............................................................................3-39 3.2.12 Network and Dial-up Connections......................................3-40 3.2.13 Owner..................................................................................3-44 3.2.14 Password .............................................................................3-45 3.2.15 PC Connection ........................................…

Text truncated - open the document above for the full version.

3-25 Figure 3-27 Bluetooth Error Windows Figure 3-28 Bluetooth Manager Windows Figure 3-29 Bluetooth Enter PIN Windows Figure 3-30 Bluetooth Manager Windows Note: If the device to which the mobile computer is bonding does not appear in the list, ensure it is turned on, in discoverable mode, and within range (30 feet / 10 meters) of the mobile computer. Table 3-21 Bluetooth Icon Icon Description Unknown device icon Device is not defined Locked icon Device is locked and cannot be bonded to. Not locked icon Device is not locked and can be bonded to. Bluetooth device icon Bluetooth device Bonded device icon Bonded Bluetooth device 3-26 Icon Description Mobile device icon Device is a mobile device Phone icon Device is a phone. Printer icon Device is a printer Network icon Device is a network. Linked icon Device is linked. 3.2.4 Certificates Certificates are used by some applications for establishing trust and for secure communications. Certificates are signed and issued by certificate authorities and are valid for a prescribed period of time. Windows CE manages multiple certificate stores. Table 3-22 Certificates ICON ITEM & FUNCTION
“Store” Tab ( Figure 3-31) :  In the Stores tab, select the certificate store you wish to view or modify from the drop-down list (Figure 3-32).  The “Trusted Authorities “store lists the top-level certificates for authorities you trust.( Figure 3-33 , Figure 3-34)  The “My Certificates “store contains your personal certificates, which you use to identify yourself.  Intermediate certificate authorities that help establish a chain of trust are stored in the “Other Authorities” store.
“Store” Tab :  To add a certificate or associated private key to the selected store, select “Import” (Figure 3-35).  To view more details of the selected certificate, such as the expanded name or expiration date, choose “View”.  To delete the selected certificate from the store, choose “Remove”. 3-27 Figure 3-31 Certificates Figure 3-32 Certificates Figure 3-33 Certificates Figure 3-34 Certificates Figure 3-35 Certificates 3-28 3.2.5 Control Center The Control Center includes four AP, listed the following ...... Figure 3-36 Control Center 3.2.5.1 Information Table 3-23 Information ICON ITEM & FUNCTION
“Information” Tab :  Provide Software version, MAC address, Bluetooth ID, Serial No. and Configuration No. 3-29 3.2.5.2 Brightness Table 3-24 Brightness ICON ITEM & FUNCTION LCD Brightness Tune the LCD brightness by tapping right-arrow & left-arrow. Can also tune the LCD brightness by pressing right-direction key or left-direction key of keypad. Amounts 7 steps: Every step have corresponding picture of self. 1.2.3.4. 5. 6.7. Enable Keypad Brightness Open keypad brightness or not. Backlight Timeout Save battery life by automatically turning off the backlight when not used. The table must disable when its item is not marked. Battery Power, turn off backlight after The table has 15 seconds, 30 seconds, 1 minute, 2 minutes and 5 minutes. The table must disable when its item is not marked. AC Power, turn off backlight after The table has 15 seconds, 30 seconds, 1 minute, 2 minutes and 5 minutes. Dim backlight after 20 seconds of idleness. Save battery life functionally of idleness mode, open it or not. 3-30 Figure 3-37 Brightness 3.2.5.3 Backup Restore Table 3-25 Backup Restore ICON ITEM & FUNCTION 1. You can backup/restore system to/from flash disk or inserted memory card. (A. Disk on Chip, B. CF Card, C. SD Card) ( Figure 3-38) 2. When you launch this AP, it must check backup file in DOC first. And if you select other storage, it will check again. 3. Then if it has the file, appeared its date behind “Last backup date:”; if not, disable “Restore Now” Button. 4. When you press the Backup/Restore Button will be a warning dialog pop up. ( Figure 3-39) 5. When system backup/restoring finished will be a message dialog will pop up. (A. Backup: Figure 3-40, B. Restore: Figure 3-41) 3-31 Figure 3-38 Backup Restore Figure 3-39 Backup & Restore Start Figure 3-40 Backup OK Figure 3-41 Restore OK 3.2.5.4 Fn-key Settings Table 3-26 Fn-Key ICON ITEM & FUNCTION
Fn-Key Setting (Figure 3-42) Fn Key The Application Program of default setting F1 Internet Explorer F2 Microsoft WordPad F3 Inbox F4 My Computer F5 Barcode Settings F6 Media Player F7 Calculator Only for SC620 3-32 F8 Information  To assign your favorite application program to Hot Keys.  Choose one of Hot Keys from pull-down list.(Figure 3-43)  To tap “Browse...” inside “Assign program” applet.  Select one application program you want from program list, then, choose “OK”. (Figure 3-43)  To tap “Default” to return back to default setting. (Figure 3-42) Figure 3-42 Fn-Key Settings Figure 3-43 Fn-Key Settings 3.2.6 Date/Time Table 3-27 Date/Time ICON ITEM & FUNCTION
“Date/Time” Tab :( Figure 2-14)  Please see the detail information of 2.5.1 Setting Time and Date on P.2-21 3-33 3.2.7 Dialing Properties Table 3-28 Dialing properties ICON ITEM & FUNCTION
“Dialing Properties” Tab :( Figure 3-44)  In the When dialing from list, select the “Location” where you want to change settings.(Figure 3-45)  To create a new location, select “New”. Enter the name of the location, and then select “OK”.(Figure 3-46)  Enter or edit the area code and local country code as needed.  In Dial using, select “Tone dialing” or “Pulse dialing”. Most phone lines are tone.  To automatically disable call waiting, select “□ □□ □ Disable call waiting by dialing”, select the appropriate number sequence in the list, or enter a new sequence.
Editing dialing patterns (Figure 3-47)  Using the codes listed in the topic; revise the dialing patterns as needed. Notes:  If you need to use character other than the ones listed here, use manual dialing.  Hyphens and spaces in dialing strings are ignored.  Some modems may not respond to the following characters, even though your device lets you add them to the dial string. 3-34 Figure 3-44 Dialing Properties Figur…

Text truncated - open the document above for the full version.

Dear Diane, Re: Applicant: Shin Chuan Computer Co., Ltd. FCC ID: TQ2-SC600PDT-BWG Correspondence Reference Number: 32840 / 32843 731 Confirmation Number: EA559309 / EA917708 Date of Original E-Mail: 4/9/2007 Subject: FCC Equipment Authorization System 1) For parts 22, 24, 22/24 devices, FCC requests additional Form 731 line-entries with emission designator G7W for devices containing GPRS / EGPRS / EDGE modes - please state requested listing for these additional 800 & 1900 MHz line-entries, and update any test report, op desc, etc exhibits if appropriate <Response> product includes GPRS for 850 and 1900M band and related test data has been included in the original test report. Please include following line items for GPRS model. Thanks. GPRS850 : 824.2-848.8M 0.855W (erp) 318KG7W GPRS1900 :1850.2-1909.8M 0.603W (eirp) 321KG7W 2) User manual RF exposure body-worn instructions are not consistent with OET 65 Suppl. C, i.e., more details are needed about whatever separation distance is applicable for accessories not designated for or furnished with the product <Response> Page 10 of user manual has been revised to include following warning massage: “This phone has been tested and meets the FCC RF exposure requirements when used with those supplied accessories designed for this product. Third-party belt-clips, holsters, and similar accessories, if used, should not contain any metallic components and must keep at least 14mm from your body as the original supplied accessory. Body-worn accessories that ...” 3) User manual mentions Bluetooth (WPAN) is optional - please note this FCC ID TQ2- SC600PDT-BWG is applicable only for products containing all three transmitters (WPAN, WLAN, WWAN). Please explain Certification status for "depopulated" products, e.g., versions containing only WLAN + WWAN, etc., and/or submit separate FCC ID applications for such other versions if appropriate. <Response> this is typo. Both Bluetooth and WLAN are default to the product and will be shipped with product. Wording “optional” has been removed from manual. Please refer to Page 7 and 16 or revised user manual. 4) Perhaps due to display scaling issues, filing seems unclear whether both "long" and "short" models have same display-screen size or not - please explain <Response> both long and short models have same LCD size. The difference is due to the different scaling factor during the photo taking. Please refer to uploaded photo “LCD size comparison between two models.pdf” which has both units sit side by side to show the actual relevant size. 5) Please describe whether device has built-in speaker and microphone functions to support held-to-ear voice-mode operations (eg "1.5W speaker") <Response> No, this product doesn’t have built-in speaker and microphone. The only way to use phone function is use supplied external earphone/Microphone. Please refer to user manual page 49 for related info. Best regards, ADT

Page 1 CONSTRUCTION PHOTOS OF EUT For Model: SC600 Page 2 Page 3 Page 4 For Model: SC620 Page 5

Model No.:SC600 Made in Taiwan Approved RLAN card may be installed FCC ID :TQ2- SC600PDT-BWG This device complies With part 15 of the FCC rule Operation issubject to the following two conditions. (1)This device may notcause harmful interference. (2)This device must accept anyinterference received. Including interference that may causeundesired operation. Complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50, July 26, 2001 Tested To Comply with FCC Standards FOR HOME OR OFFICE USE 5VDC 2.6A R32334 CMII ID: 2006DJ0826 R C U S I S E D 34GH E302749 0560 ! RoHS CCC  Model No.:SC600 Made in Taiwan Approved RLAN card may be installed FCC ID :TQ2- SC600PDT-BWG This device complies With part 15 of the FCC rule Operation issubject to the following two conditions. (1)This device may notcause harmful interference. (2)This device must accept anyinterference received. Including interference that may causeundesired operation. Complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50, July 26, 2001 Tested To Comply with FCC Standards FOR HOME OR OFFICE USE 5VDC 2.6A R32334 CMII ID: 2006DJ0826 R C U S I S E D 34GH E302749 0560 ! RoHS SC600 AB 7 6 4 5 3 2 A 1 B DCE 7 6 4 5 3 DC 2 E 1 MODEL: TITLE: P/N: FILE NAME:FILE NAME: REV UNIT: SCALE: MATERIAL: FINISH: DESIGN: CHK: APP'D: A4 SHEET OF REV DATE DESCRIPTION DESIGN APP'D Model No.:SC600 Made in Taiwan Approved RLAN card may be installed FCC ID :TQ2- SC600PDT-BWG This device complies With part 15 of the FCC rule Operation issubject to the following two conditions. (1)This device may notcause harmful interference. (2)This device must accept anyinterference received. Including interference that may causeundesired operation. Complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50, July 26, 2001 Tested To Comply with FCC Standards FOR HOME OR OFFICE USE 5VDC 2.6A R32334 CMII ID: 2006DJ0826 R C U S I S E D 34GH E302749 0560 ! RoHS

Page 6 For Model: SC600 Page 7 Page 8 Page 9 For Model: SC620 Page 10 Page 11 Page 12 Page 13 Page 14 Page 15 Page 16 Page 17 Page 18 Page 19 Page 20 Page 21 Page 22 Page 23 Page 24 Page 25 Page 26 Page 27 Page 28 Page 29 Page 30 Page 31

Chapter 30 Multiband Evaluation 30.1 Introduction Wireless devices exist that can transmit at multiple frequencies at the same time. An example of this is a cellular telephone and PDA combination that can simultaneously transmit a cellular telephone signal (e.g., at 900 MHz) and a wireless LAN signal (e.g., at 2450 MHz). It is possible that such a device may be compliant with the regulatory SAR limit at each frequency while the composite SAR from simultaneous transmission is above the limit. Therefore, the accurate determination of the SAR in this situation is important. Given that the tissue simulating liquid and the probe calibration are frequency dependent, and given that existing SAR measurement systems are unable to…
