TQEEPM-300Digital Audio Player

EPM-300 USER MANUALEPM-300 USER MANUAL Table of contents Product formatting 24 How to use the product 25 Preparation before operation 25 Different modes appeared on LCD window 26 Functions of keys 28 Music mode 35 Voice mode 35 FM mode36 Setting mode38 Brief description of menu function39 Erase files44 Firmware update 4 6 Product specifications 48 Trouble shooting 49 Safety precautions 3 Product features 5 Packing contents 6 Packing contents6 7Names of parts Connection to PC 8 Minimum requirements on PC deployment 8 Remarks8 Application of USB 9 How to intall windows98/SE device driver Disconnection from PC 14 10 Download LDB 15 Download LDB (auto search) 18 Download LDB (manual search) 20 0102 EPM-300 USER MANUALEPM-300 USER MANUAL 1112 2. click "Next step"on the Add New Hardware Wizard window as described in the picture. When the message,What would you like Windows to do, appears,click Search for the best driver for your device and click Next. 3. Select ''CD-ROM Drive'' for the location of the driver and click ''Next''. 4. 5.When installation is complete, click "finish". 6. Select Digital Audio Player in the Device Manager and right click on the device for ''Properties''. 7. When the driver installation is complete, a''Removable Drive'' icon appears. EPM-300 USER MANUAL NOTE : This equipment has been tested and found to comply with the limits for a Class B digital device,pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates,uses and can radiate radio frequency energy and,if not installed and used in accordance with the instructions,may cause harmful interference to radio communications. However,there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception which can be determined by turning the equipment off and on,the user is encouraged to try to correct the interference by one or more of the following measures. - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio,TV technical for help. - Only shielded interface cable should be used. Finally,any changes or modifications to the equipment by the user not expressly approved by the grantee or manufacturer could void the users authority to operate such equipment. THIS DEVICE COMPLIESWITH PART 15 OFTHE FCC RULES.OPERATION IS SUBJECTTOTHE FOLLOWINGTWO CONDITIONS:(1)THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE,AND (2)THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED,INCLUDING INTERFERENCETHAT MAY CAUSE UNDESIRED OPERATION. FCC RF INTERFERENCE STATEMENT

■ BLOCK DIAGRAM(EPM-300) Sigmatel 3502 PLL(39.6MHZ - 120MHZ) USB 480MHZ PLL Li-Ion Battery 3.3V step down 1.8V step down USB 2.0 24MHZ X-TAL FM MODULE NAND FLASH Key Ear Jack C-Mic LCD(128*64) 2color OLED

June 22, 2005 Compliance Certification Service 561F Monterey Road, Morgan Hill, CA 95037 USA To whom it may concern: We, the undersigned, hereby authorize IST Co.,Ltd. to act an our behalf in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by IST Co.,Ltd., on our behalf shall have the same effect as acts of our own. This letter is an authorization to accept IST Co., Ltd. As the agent for ENOX Co., Ltd. to sign applications before the Commission on our behalf, to make representations to you on our behalf, and to receive and exchange data between our company and the Commission in connection with certification of the following ENOX Co., Ltd. product : Product FCC ID Digital Audio Player EPM-300 Sincerely, Young Guan Yang/ Director ENOX Co., Ltd

1 Helen Zhao Subject:FW: ENOX Co., Ltd, FCC ID: TQEEPM-300, Assessment NO.: AN06T5404, Notice#1 -----Original Message----- From: Compliance Certification Services [mailto:[email protected]] Sent: Friday, January 20, 2006 2:31 AM Subject: You Have New Uploading File(s): Assessment NO: AN06T5404 for ENOX Co., Ltd Product description to be marketed : Digital Audio Player Equipment code: JBP - Part 15, Class B Computing Device Peripheral Agent firm name: IST Co.,Ltd. -----Original Message----- From: Compliance Certification Services [mailto:[email protected]] Sent: Thursday, January 05, 2006 4:24 PM Subject: ENOX Co., Ltd, FCC ID: TQEEPM-300, Assessment NO.: AN06T5404, Notice#1 Question #1: The block diagram indicates the device uses 120MHz PLL, but the test report indicates radiated emission test was investigated upto 1GHz only. Based upon FCC15.33(b)(1), however you need to test upto 2GHz. Please explain. Question #2: This is a hand-held device. The test report does not show radiated emission test was done in three orthogonal planes to find maximum emission. Please explain. Best Regards, Helen Zhao The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender.

ID Label/Location Information DIGITAL AUDIO PLAYER FCC ID : TQEEPM-300 MADE IN KOREA

IST Co., Ltd EMC LABORATORY TEST REPORT NO. : 05-IST-0392 1 of 32 Certification of Compliance CFR 47 Part 15 Subpart B Test Report File No. : 05-IST-0392 Date of Issue : January 20, 2006 Model(s) : EPM-300 Kind of Product : Digital Audio Player FCC ID : TQEEPM-300 Applicant : ENOX INC. Address : Anyang Venturetel Suite #1111, 1107-1, Bisan-dong Dongan-gu, Anyang-si, Gyeonggi-do, Korea Manufacturer : ENOX INC. Address : Anyang Venturetel Suite #1111, 1107-1, Bisan-dong Dongan-gu, Anyang-si, Gyeonggi-do, Korea Test Result ■ Positive □ Negative Reviewed By Approved By S.J.CHO / EMC Group Manager J.H.LEE / Chief Comment(s) - Investigations requested : Measurement to the relevant clauses of FCC rules and regulations Part 15 Subpart B – Unintentional Radiators, Class B. - The test report with appendix consists of 32 pages. - The test result only responds to the tested sample. - It is not allowed to copy this report even partly without the allowance of IST EMC Laboratory. - This equipment as for has been shown to be capable of continued compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.4 2003. IST Co., Ltd EMC LABORATORY TEST REPORT NO. : 05-IST-0392 2 of 32 TABLE OF CONTENTS Table of contents 2 Information of test laboratory, Environmental conditions, Power used, Product information 3 Descriptions of test Conducted Emission 4 Radiated Emission 5 Measurement Uncertainty Calculations 6 Equipment Under Test 7 Test Set-Up (Figure) 8 Summary 9 ■ Test Conditions and Data - Emissions ◆ Conducted Emissions 0.15MHz - 30MHz Applicable Test Conditions / Data and Plots 10-12 ◆ Radiated Emissions 30MHz - 2GHz Applicable Test Conditions / Data and Plots 13-25 Appendix A. The Photos of Test Setup 26-30 B. The Photos of Equipment Under Test 31-32 Note: IST Co., Ltd EMC LABORATORY TEST REPORT NO. : 05-IST-0392 3 of 32 INFORMATIONS OF TEST LABORATORY EMC LABORATORY of IST Co., Ltd. (FCC Filing Lab.) San 21-8, Goan-Ri, Baekam-Myun, Yongin-City Kyonggi-Do, 449-860, Korea TEL : +82 31 333 4093 FAX : +82 31 333 4094 ENVIRONMENTAL CONDITIONS Temperature 18 °C Humidity 39 % Atmospheric pressure 1013 mbar POWER SUPPLY SYSTEM USED Power supply system AC 120Vac, 60Hz(PC Power) (Refer to the product information) PRODUCT INFORMATION The Equipment Under Test(EUT) is Digital Audio Player of ENOX INC. (FCC ID : TQEEPM-300) memory: 128MB Support: MPEG 1/2/2.5 Layer3(8 320kbps,VBR) WMA(5~320kbps)ASK,OGG(OGG320kbps).WAV Battery: Built-in Li-ion battery (3V) Interface: USB 2.0 LCD: OLED double color dimension 59(W) x 29(H) x 15.5(D)mm Weight: 25g Support OS: Windows 98SE / ME / 2000 / XP / MAC - EMC suppression device is not used during the test . - Please refer to user’s manual. IST Co., Ltd EMC LABORATORY TEST REPORT NO. : 05-IST-0392 4 of 32 < Concept Drawing > 215 >150 >40 80 Receiver EUT LISN 80 ≥ 80 80 40 ≥ 80 Measuring apparatus Mains Filter Mains Rear side Equipment under test Coaxial cable Artificial mains networ k Screened room Non-metallic support 80 DESCRIPTIONS OF TEST Conducted Emissions: The measurement were performed over the frequency range of 0.15MHz to 30MHz using a 50 Ω /50uH LISN as the input transducer to a Spectrum Analyzer or a Field Intensity Meter. The measurements were made with the detector set for "Peak" amplitude within a bandwidth of 10KHz or for "quasi-peak" & “Average” within a bandwidth of 9KHz. - Procedure of Test The line-conducted facility is located inside a shielded room No.1. A 1m X 1.5m wooden table 80cm height is placed 40cm away from the vertical wall and 1.5m away from the other wall of the shielded room. The R/S ESH3 and Hyup-Rip KNW-407 LISN are bonded to bottom of the shielded room. The EUT is located on the wooden table with distance more than 80cm from the LISN and powered from the EMCO LISN .The peripheral equipment is powered from the other LISN. Power to the LISNs are filtered by a noise cut power line filters. All electrical cables are shielded by braided tinned steel tubing with inner φ 1.2cm. If the EUT is a DC-powered device, power will be derived from the source power supply it normally will be powered from and this supply lines will be connected to the EMCO LISN. All interconnecting cables more than 1m were shortened by non-inductive bundling to a 1m length. Sufficient time for the EUT, support equipment, and test equipment was allowed in order for them to warm up to their normal operating conditions. The RF output of the LISN was connected to the R/S receiver to determine the frequency producing the maximum emission from the EUT. The frequency producing the maximum level was reexamined using Quasi-Peak mode by manual measurement, after scanned by automatic Peak mode for frequency range from 0.15 to 30MHz. The bandwidth of the receiver was set to 10kHz. The EUT, peripheral equipment, and interconnecting cables were arranged and manipulated to maximize each EME emission. < Side View > IST Co., Ltd EMC LABORATORY TEST REPORT NO. : 05-IST-0392 5 of 32 DESCRIPTION OF TEST Radiated Emissions: The measurement was performed over the frequency range of 30MHz to 1GHz using antenna as the input transducer to a Spectrum analyzer or a Field Intensity Meter. The measurement was made with the detector set for "quasi-peak" within a bandwidth of 120KHz. - Procedure of Test Preliminary measurements were made at 3 meter using bi-log antennas, and spectrum analyzer to determine the frequency producing the max. emission in anechoic chamber. Appropriate precaution was taken to ensure that all emission from the EUT were maximized and investigated. The system configuration, mode of operation, turn-table azimuth and height with respect to the antenna were noted for each frequency found. The spectrum was scanned from 30MHz to 1000MHz using bi-log antenna. Above 1GHz, linearly polarized double ridge horn antennas were used. Final measurements were made at open site with 3-mete…
