TRUD1-FMRemote Controller

Ruoey Lung Enterprise Corp.

Click to zoom

Application Details

Equipment Class: DSC - Part 15 Security/Remote Control Transmitter
Date of Grant: Nov 03, 2015
Application Purpose: Original Equipment
Date of Application: Nov 03, 2015
Equipment Note: Remote Controller
Frequency Range: 433.32000000 - 434.52000000
Company: Ruoey Lung Enterprise Corp.
Country: Taiwan

Documents & Files

Select a file to view

Test Report

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

D1-FM

External Photos

HongAn TECHNOLOGY CO., LTD. Report No.: HA150721-RA FCC Test Report Page 35 of 37 8 Photographs of the EUT Front View of the EUT Rear View of the EUT

ID Label/Location Info

LABEL’S LOCATION FCC ID：TRUD1-FM MODEL NO: D1-FM 26mm 18mm 標籤作成 “淺藍色底黑字”! FCC ID：TRUD1-FM “This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.”

Internal Photos

HongAn TECHNOLOGY CO., LTD. Report No.: HA150721-RA FCC Test Report Page 36 of 37 Inside View of the EUT Front View of the PCB HongAn TECHNOLOGY CO., LTD. Report No.: HA150721-RA FCC Test Report Page 37 of 37 Rear View of the PCB Closer view of the PCB antenna Spring antenna

Parts List/Tune Up Info

Comment PatternQuantityComponents PCB143mm*53mm 板厚1.0mm Switch PT5501G-3Ree1 160g 19 SW1~ SW19 MLCC0603- NPO-100P-50V+/-0.25PF 1 C16 Chip Resistor 0603 100R +-5% 18 R1~ R18 MLCC0603-Y5V-1N( 102)-25V+80/-20% 1C4 MLCC0603-Y5V-10N( 103)-25V+80/-20% 1 C15 MLCC0603-Y5V-100N( 104)-25V+80/-20% 1C5 MLCC0603-Y5V-1u( 105)-25V+80/-20% 2 C19 C20 Chip Resistor 0603 10K +-5% 1 R28 MLCC 0805 10U 1C6 Cryatal XTAL3.2X2.5 12.8MHz 1X1 MLCC0603- NPO-56P-50V+/-0.25PF 1 C12 Chip InductorsSMD 0603 47N+-5% 1L1 MLCC0603- NPO-6P8-50V+/-0.25PF 1 C13 MLCC0603-2.2uF-25V+80/-20% 3 C1 C2 C3 Chip Resistor 0603 220R +-5% 1 R20 Chip InductorsSMD 0603 120N+-5% 2 L2 L3 MLCC0603- NPO-27P-50V+/-0.25PF 1 C14 MLCC0603-10P-25V+80/-20% 1 C21 Chip InductorsSMD 0603 330N+-5% 1L4 MLCC0603-15P-25V+80/-20% 1 C17 Chip InductorsSMD 0603 82N+-5% 1L5 MLCC0603- NPO-470P-50V+/-0.25PF 1 C18 Chip Resistor 0603 47K +-5% 1 R26 MLCC SMD 1812-47U-10V-BTYE 1C7 MLCC0603- NPO-12P-50V+/-0.25PF 2 C8 C11 Chip Resistor 0603 820R +-5% 1 R19 MLCC0603- NPO-8P2-50V+/-0.25PF 2 C9 C10 ANTANT 1 ANT1 LED0805 白光 (write) 18 LED1~ LED18 LED0805 紅光 (red) 1 LED19 RF IC A7108 1U2 IC SN8F27E65LF 1U1 Transistor 2N3904 2 Q1 Q2 battery spring70942-0001 BAT(-) battery spring70941-0801 BAT(+) 銳龍_(D1-FM)無線按摩床發射器 KRF-R008_V03.PCB 2015/8/14

Test Setup Photos

HongAn TECHNOLOGY CO., LTD. Report No.: HA150721-RA FCC Test Report Page 34 of 37 7 Photographs of the Tests 7.1 Radiated Disturbances Emission Test (Below 1GHz) and (Above 1 GHz) Front View (X axes) Front View (X axes)
