TSWAV-650T2DIN INDASH TYPE CAR A/V WITH BLUETOOTH

Contents Introduction . . . . . . . . . . . . . . . . . . . . . . . . .2 Safety .Precautions . . . . . . . . . . . . . . . . . . .3 Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 BOX .Contents . . . . . . . . . . . . . . . . . . . . . . .5 Name .and .Function .of .Each .Parts . . . . . . .6 Front Panel Description . . . . . . . . . . . . . . . . . . .6 . Left Side View . . . . . . . . . . . . . . . . . . . . . . . . . .7 Rear Side View . . . . . . . . . . . . . . . . . . . . . . . . .7 Front Side View . . . . . . . . . . . . . . . . . . . . . . . . .7 . Remote Control Description . . . . . . . . . . . . . . .8 Mode .Selection . . . . . . . . . . . . . . . . . . . . . .9 DVD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 DVD Main Screen . . . . . . . . . . . . . . . . . . . . . .10 . DVD Simple Operation . . . . . . . . . . . . . . . . . .11 . Move to DVD Setup . . . . . . . . . . . . . . . . . . . . .12 . DVD Setup . . . . . . . . . . . . . . . . . . . . . . . . . . .14 . DVD Front Side Menu . . . . . . . . . . . . . . . . . . .15 SD .CARD . . . . . . . . . . . . . . . . . . . . . . . . . .16 SD CARD Main Screen . . . . . . . . . . . . . . . . . .16 . SD CARD Simple Operation . . . . . . . . . . . . . .17 . SD CARD Side Menu . . . . . . . . . . . . . . . . . . .18 iPod . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19 iPod Main Screen . . . . . . . . . . . . . . . . . . . . . .19 . iPod Simple Operation . . . . . . . . . . . . . . . . . .20 . iPod Side Menu . . . . . . . . . . . . . . . . . . . . . . . .21 RADIO . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22 RADIO Main Screen . . . . . . . . . . . . . . . . . . . .22 . RADIO Simple Operation . . . . . . . . . . . . . . . .23 . RADIO Detailed Functions . . . . . . . . . . . . . . .24 . RADIO Side Menu . . . . . . . . . . . . . . . . . . . . . .25 AV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26 AV Main Screen . . . . . . . . . . . . . . . . . . . . . . .26 AV Simple Operation . . . . . . . . . . . . . . . . . . . .26 . AV Side Menu . . . . . . . . . . . . . . . . . . . . . . . . .27 REARVIEW . . . . . . . . . . . . . . . . . . . . . . . . .28 REARVIEW Main Screen . . . . . . . . . . . . . . . .28 REARVIEW Simple Operation . . . . . . . . . . . .28 B/T .(BLUETOOTH) . . . . . . . . . . . . . . . . . . .29 B/T Main Screen . . . . . . . . . . . . . . . . . . . . . . .29 . B/T Simple Operation . . . . . . . . . . . . . . . . . . .30 PAIRING . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30 . Operation Specification Sequence . . . . . . . . .31 . B/T Detailed Functions . . . . . . . . . . . . . . . . . .32 . Mobile Phone MP3 Player Function . . . . . . . .33 . B/T Side Menu . . . . . . . . . . . . . . . . . . . . . . . . .34 Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . .35 DISPLAY Setting Procedure . . . . . . . . . . . . . .35 . DISPLAY Settings . . . . . . . . . . . . . . . . . . . . . .36 . AUDIO Setting Procedure . . . . . . . . . . . . . . . .37 . AUDIO Settings . . . . . . . . . . . . . . . . . . . . . . . .38 . ETC . Setting Procedure . . . . . . . . . . . . . . . . .39 . ETC Settings . . . . . . . . . . . . . . . . . . . . . . . . . .40 Installation .& .Connection . . . . . . . . . . . . .42 WARNING . . . . . . . . . . . . . . . . . . . . . . . . . . . .42 . CAUTION . . . . . . . . . . . . . . . . . . . . . . . . . . . .42 . Installation Procedure . . . . . . . . . . . . . . . . . . .42 . How to install . . . . . . . . . . . . . . . . . . . . . . . . . .43 . How to install . . . . . . . . . . . . . . . . . . . . . . . . . .44 . How to disassemble . . . . . . . . . . . . . . . . . . . .45 System .Connection . . . . . . . . . . . . . . . . . .46 OUTPUT connection . . . . . . . . . . . . . . . . . . . .46 Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . .48 Troubleshooting .Guide . . . . . . . . . . . . . . .49 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49 Disc source . . . . . . . . . . . . . . . . . . . . . . . . . . .50 . MP3/WMA source . . . . . . . . . . . . . . . . . . . . . .50 Troubleshooting .Guide . . . . . . . . . . . . . . .51 Specifications . . . . . . . . . . . . . . . . . . . . . .52 FCC .(Federal .Communications .Commission) . .53 C O N T E N T S  .VAVN 6500VAVN 6500  Introduction Thank you for choosing and purchasing this unit . This instruction manual aims to provide you with installation and operating instructions for the unit . Features “Multi-tasking” refers to the simultaneous use of numerous programs or applications on one system . HIGH RESOULUTION & BRIGHT ACTIVE WIDE TFT LCD with Touch Screen 5 Step Automatic Motorized Viewing Angle Last Angle Memory Blue Back Light Control Buttons Full-Funtion Infrared Remote Control Max Output Power 50W x 4ch A/V INPUT , REARVIEW INPUT, A/V OUPUT Auto Dimmer Control Multi Screen Aspect ( Normal , Full , Wide ) Picture Adjustable ( Brightness, Contrast, Color, Hue, Sharpness) NTSC/PAL Auto Selection DVD/DVD-RW/DVD-R/VCD/CD-R/CD-RW/MP3/JPEG DVD Last Position Memory Electronic Anti-Shock Built-in FM/AM Tuner Auto Scan Memory(ASM) Store/Preset Scan FM Frequency : 87.5 - 108Mhz, 12 Memory Preset(FM1/FM2) AM Frequency : 530Khz - 1720Khz , 6 Memory Preset(AM) Bulit-in Bluetooth for Bluetooth Enabled Device (Celluar Phone) IPOD Port Tell Mute Funtion This instruction manual is only for reference . Modifying rights are reserved . Modifications are subject to change without notice . NOTE Safety Precautions To prevent injury or fire, take the following precautions: To prevent a short circuit, never put or lnsert any metallic objects (such as coins or metal tools) inside the unit . Do not touch the liquid crystal fluid if the LCD is damaged or broken due to shock. The liquid crystal fluid may be dangerous to your health or even fatal. If the liquid crystal fluid from the LCD contacts your body or clothing, wash it off with soap immediately. Do not…

Text truncated - open the document above for the full version.

 .VAVN 6500VAVN 6500  REARVIEW REARVIEW Main Screen Operates only when the REARVIEW Cable of the Power & Speaker Cable (16P) is connected to the car . Converts to REARVIEW MODE when Backgear is detected . REARVIEW Playback Screen Dual ON Status (refer to page 40) REARVIEW does not operate when ACC is off . NOTE REARVIEW Simple Operation  REARVIEW MODE is selected when backgear is detected . Connect to the backgear in REARVIEW, and connect the rear camera to REARVIEW IN . (refer to pages 46~47) 1 To move to another mode, press the < > button .  B/T (BLUETOOTH) The B/T Function is available only with B/T-enabled mobile phones . Refer to the Mobile Phone Manual for instructions regarding mobile phone B/T connection. (Default password: 0000) B/T Main Screen B/T Function Icons PHONE Select to make calls or enter a telephone number . PHONE .BOOK Use to make call using the PHONE BOOK, or to erase content from the PHONE BOOK. PAIRING Use to try pairing . List Up/Down button in PHONE BOOK MODE CALL - Select CALL ICON to connect incoming or outgoing calls . - Use CALL button to switch to an incoming call while a call is in progress . (Can vary according to mobile phone specifications.) END Use to end a call . DEL - Use to delete one number at a time when telephone number input errors are made . - Use to delete selected content from the PHONE BOOK. SAVE - Use to save a directly-entered telephone number . - Total of six SAVE functions (SAVE in sequence). - Use to save the number of an incoming call to the PHONE BOOK. CALL .TRANS Converts answering modes between mobile phone and Bluetooth - Default Mode: Bluetooth answering ● When answering via mobile phone: Current audio mode maintained on all speakers ● When answering via Bluetooth: Call audio is outputted only via the left front, driver-side speaker 0 .VAVN 6500VAVN 6500 1 B/T (BLUETOOTH) The B/T Function is available only with B/T-enabled mobile phones . Refer to the Mobile Phone Manual for instructions regarding mobile phone B/T connection. (Default password: 0000) B/T Simple Operation Select <B/T> .  Connect the mobile phone to the product . 1 Select < > . AUTO PAIRING attempts PAIRING for one minute .  Use the function buttons to operate .  Automatic connection whenever ACC is on (connects to most recent paired phone) Auto connection run whenever power is turned on Pairing attempted in background even when another mode is run Mode is maintained if pairing is successful, and pairing is tried continuously for one minute if failed Failure mode maintained if pairing is tried for more than one minute without success NOTE Convert to B/T MODE . 01 B/T (BLUETOOTH) Operation Specification Sequence AUTO PAIRING attempts PAIRING for one minute . 02 PAIR SUCCESS 1 . Image 1 is displayed for one second . 2. The icon changes : (changes to blue) 3 . Image 2 (changes to PHONE MODE) 1 2 PAIR FAILURE 1 . Image 3 is displayed for one second 2. BLUETOOTH OFF ICON maintained : (red) 3 PHONE, PHONE BOOK, PAIRING are all available for use. Even if PAIRING has failed, the user can press the PAIRING button to retry . 03 PAIRING 01 .Press the button in B/T MODE . 02 .The user’s mobile phone searches for devices and finds the SJ-AVN. (Refer to the corresponding manual .) 03 .The SJ-AVN is registered. (Default password at registration: 0000) 04 .When PAIRING is successfully completed, the icon turns from red blue . ( ) To move to another mode, press the < > button .   .VAVN 6500VAVN 6500  B/T (BLUETOOTH) B/T Detailed Functions PHONE .[ . .] Select to make calls or enter a telephone number . - Select the PHONE ICON to bring up the display as shown . - How to make a call: ● Pressing CALL in the display makes a call to the recently dialed telephone number . ● Enter a telephone number and press CALL . (Use DEL to delete one number at a time when incorrect phone number is inputted .) - When receiving calls 01 NON-BLUETOOTH ● Display as shown ● Call ID Display ● Press the END Icon to end the call when finished. Current .ModeOperation BLUETOOTH ● Convert to BLUETOOTH MODE to bring up the Display as shown . ● Call ID Display ● Press the END Icon to end the call when finished. ● When the call is ended, the previous mode is selected . PHONE .BOOK .[ . .] - Use to make a call using the PHONE BOOK, or to erase content from the PHONE BOOK. - SAVING to the PHONE BOOK ● Can directly press the number buttons and SAVE ● Can save up to a total of six (Move via / buttons .) ● Press the SAVE button during a call to save the currently-connected telephone number . - ERASING from the PHONE BOOK ● Select the content to be deleted from the LIST and press the DEL ICON . ● The next number in the sequence fills the space of the entry that was deleted. 02 B/T (BLUETOOTH) Mobile Phone MP3 Player Function The MP3 Player Function is available only when Pairing has been successful . Mobile Phone MP3 CONTROL when using the Mobile Phone MP3 PLAYER : Use to change the icon to . Plays MP3 files in the mobile phone in sequence. : When MP3 files are playing, stops play : When MP3 files are playing, plays the previous file : When MP3 files are playing, plays the next file Only changes icon below when audio is played If the MP3 Player stops: Stops when the MP3 STOP function of the mobile phone is activated . * Due to the differences in MP3 Player functions per different mobile phone manufacturers * When the MP3 Player stops, the icon changes to . 01 When an incoming call is received in another mode, enters B/T MODE, reverts back to the previous mode after the call is ended . PRESTOP activated when an incoming call is received during DVD PLAY and converts to B/T MODE, returns to DVD MODE after the call is ended . In B/T MODE, Audio output is through the Front (driver’s side, passenger’s side seats) Music outputted through all channels after connecting a stereo headset and playing . Call receiving function not permitted . Reject calls function: When an incoming call is received, the call continue…

Text truncated - open the document above for the full version.
